1 OVERVIEW
This user manual is aimed to give users a fast introduction to the use of NuMaker-M263KI board.
The NuMaker-M263KI consists of two parts, a M263 platform and an on-board Nu-Link2-Me debugger
and programmer. The NuMaker-M263KI allows users to quickly develop and easily program and
debug application.
The NuMaker-M263KI offers M263KIAAE full pins extension connectors, Arduino UNO compatible
extension connectors and diversified power supply option. It is an easy-to-develop platform for user to
expand the functionality and build the applications. The NuMaker-M263KI also provides an ammeter
connector, allows user to monitor the microcontroller’s power consumption during development.
The Nu-Link2-Me is a debugger and programmer that supports on-line programming and debugging
through SWD interface. The on-board 16 Mbit SPI Flash allows it to off-line program the target
microcontroller. The Nu-Link2-Me provides virtual COM port (VCOM) function to print out messages
on PC. The Nu-Link2-Me can be separated from NuMaker-M263KI, allowing user to use it as a mass
production programming tool.
Figure 1-1 NuMaker-M263KI Board
NuMaker-M263KI Features1.1
NuMicro®M263KIAAE used as main microcontroller with functions downward compatible
with:
M261ZIAAE
M261SIAAE
M261KIAAE
M262ZIAAE
M262SIAAE
M262KIAAE
M263ZIAAE
M263SIAAE
M263KIAAE

NuMaker-M263KI
Apr 16, 2019 Page 7of 39 Rev 1.00
NUMAKER-M263KI USER MANUAL
Maker Nu-mbed NUC472 User Manual
M263KIAAE full pins extension connectors
Arduino UNO compatible extension connectors
Ammeter connector for measuring the microcontroller’s power consumption
Fixable board power supply:
External VDD power connector
Arduino UNO compatible extension connector VIN
USB OTG connector on M263 platform
ICE USB connector on Nu-Link2-Me
On-board Nu-Link2-Me debugger and programmer:
Debug through SWD interface
On-line/off-line programming
Virtual COM port function

NuMaker-M263KI
Apr 16, 2019 Page 8of 39 Rev 1.00
NUMAKER-M263KI USER MANUAL
Maker Nu-mbed NUC472 User Manual
2 NUMAKER-M263KI OVERVIEW
Front View2.1
ICE USB Connector
VCOM Switch
Reset Button
ICE Status LED
Off-line Program Button
USB OTG Connector
Power LED
PB10 LED
VDD Switch
Target Chip: M263KIAAE Target Chip Extension Connector
Arduino UNO Compatible Extension Connector
External VDD Connector
Nu-Link2-Me
Ammeter
ICE Chip: M48SSIDAE
External VSS Connector
M263 Platform
External VREF Connector
Figure 2-1 Front View of NuMaker-M263KI
Figure 2-1 shows the main components and connectors from the front side of NuMaker-M263KI. The
following lists components and connectors from the front view:
Target Chip: M263KIAAE (U4)
USB OTG Connector (J2)
Arduino UNO Compatible Extension Connectors (NU1, NU2, NU3, NU4)
M263KIAAE Extension Connectors (JP3, JP4, JP5 and JP6)
External VDD Power Connector (JP1)
External VSS Power Connector (JP2)
External VREF Connector (VREF1)
VDD Switch (SW2)
Ammeter Connector (AMMETER)
Reset Button (SW1)
Power LED and PB10 LED (LEDG1 and LEDR1)
Nu-Link2-Me
VCOM Switch
ICE Chip: M48SSIDAE (ICEU2)
ICE USB Connector (ICEJ3)
ICE Status LED (ICES0,ICES1, ICES2, ICES3)
Off-line Program Button (ICESW1)

NuMaker-M263KI
Apr 16, 2019 Page 9of 39 Rev 1.00
NUMAKER-M263KI USER MANUAL
Maker Nu-mbed NUC472 User Manual
Rear View2.2
Figure 2-2 shows the main components and connectors from the rear side of NuMaker-M263KI.
The following lists components and connectors from the rear view:
Nu-Link2-Me
MCUVCC Power Switch (ICEJPR1)
ICEVCC Power Switch (ICEJPR2)
ICEVCC Power Switch
MCUVCC Power Switch
Figure 2-2 Rear View of NuMaker-M263KI

NuMaker-M263KI
Apr 16, 2019 Page 10 of 39 Rev 1.00
NUMAKER-M263KI USER MANUAL
Maker Nu-mbed NUC472 User Manual
Arduino UNO Compatible Extension Connectors2.3
Figure 2-3 shows the Arduino UNO compatible extension connectors.
MISO CLK RESET SS
PA.9 PA.11 nRESET PA.8
USCI0_DAT1 USCI0_CLK USCI0_CTL1
5V MOSI GND -
VDD PA.10 VSS PB.11
USCI0_DAT0
UART5_TXD EPWM0_CH0 PA.5 D8
UART5_RXD EPWM0_CH1 PA.4 D9
SPI0_SS EPWM0_CH2 PA.3 D10
SPI0_MOSI EPWM0_CH5 PA.0 D11
SPI0_MISO EPWM0_CH4 PA.1 D12
SPI0_CLK EPWM0_CH3 PA.2 D13
VSS VSS
VREF VREF
UART2_RXD I2C0_SDA PC.0 SDA
UART2_TXD I2C0_SCL PC.1 SCL
UART1_RXD EPWM0_CH3 PB.2 D0
UART1_TXD EPWM0_CH2 PB.3 D1
I2C1_SDA EPWM1_CH1 PC.4 D2
I2C1_SCL EPWM1_CH0 PC.5 D3
UART3_TXD EPWM1_CH2 PC.3 D4
UART3_RXD EPWM1_CH3 PC.2 D5
EPWM1_CH4 PA.7 D6
EPWM1_CH5 PA.6 D7
VIN
VSS
VSS
5V
3V
RST
IOREF VDD
NC
A5 PB.1 ADC0_CH1 I2C1_SCL UART2_TXD
A4 PB.0 ADC0_CH0 I2C1_SDA UART2_RXD
A3 PB.4 ADC0_CH4
A2 PB.5 ADC0_CH5
A1 PB.6 ADC0_CH6
A0 PB.7 ADC0_CH7
Figure 2-3 Arduino UNO Compatible Extension Connectors

NuMaker-M263KI
Apr 16, 2019 Page 11 of 39 Rev 1.00
NUMAKER-M263KI USER MANUAL
Maker Nu-mbed NUC472 User Manual
Header
–NuMaker-M263KI
–Header
–NuMaker-M263KI
Compatible to
Arduino UNO
GPIO Pin of
M263KIAAE
Compatible to
Arduino UNO
–GPIO Pin
of
M263KIAA
E
N
U
3
NU3.1
D0
PB.2
N
U
2
NU2.6
A5
PB.1
NU3.2
D1
PB.3
NU2.5
A4
PB.0
NU3.3
D2
PC.4
NU2.4
A3
PB.4
NU3.4
D3
PC.5
NU2.3
A2
PB.5
NU3.5
D4
PC.3
NU2.2
A1
PB.6
NU3.6
D5
PC.2
NU2.1
A0
PB.7
NU3.7
D6
PA.7
N
U
1
NU1.8
VIN
-
NU3.8
D7
PA.6
NU1.7
VSS
N
U
4
NU4.1
D8
PA.5
NU1.6
VSS
NU4.2
D9
PA.4
NU1.5
5V
NU4.3
D10
PA.3
NU1.4
3V
NU4.4
D11
PA.0
NU1.3
RST
nRESET
NU4.5
D12
PA.1
NU1.2
IOREF
VDD
NU4.6
D13
PA.2
NU1.1
NC
-
NU4.7
VSS
VSS
NU4.8
VREF
VREF
NU4.9
SDA
PC.0
NU4.10
SCL
PC.1
Table 2-1 Arduino UNO Extension Connectors and M263KIAAE Mapping GPIO List

NuMaker-M263KI
Apr 16, 2019 Page 12 of 39 Rev 1.00
NUMAKER-M263KI USER MANUAL
Maker Nu-mbed NUC472 User Manual
Pin Assignment for Extension Connectors2.4
The NuMaker-M263KI provides the M263KIAAE target chip onboard and full pins extension
connectors (JP3, JP4, JP5 and JP6). Figure 2-4 shows the M263KIAAE extension connectors.
JP3
Pin1 ~ Pin32
JP6
Pin97 ~ Pin128
JP5 Pin33 ~ Pin64
JP4 Pin65 ~ Pin96
Figure 2-4 M263KIAAE Extension Connectors

NuMaker-M263KI
Apr 16, 2019 Page 13 of 39 Rev 1.00
NUMAKER-M263KI USER MANUAL
Maker Nu-mbed NUC472 User Manual
Header
M263KIAAE
Pin No.
Function
JP3
JP3.1
1
PB.5/EADC0_CH5/ACMP1_N/EBI_ADR0/SD0_DAT3/SPI1_MISO/I2C0_SCL/UART5_TXD/USCI1
_CTL0/SC0_CLK/I2S0_BCLK/EPWM0_CH0/TM0/INT0
JP3.2
2
PB.4/EADC0_CH4/ACMP1_P1/EBI_ADR1/SD0_DAT2/SPI1_MOSI/I2C0_SDA/UART5_RXD/USCI
1_CTL1/SC0_DAT/I2S0_MCLK/EPWM0_CH1/TM1/INT1
JP3.3
3
PB.3/EADC0_CH3/ACMP0_N/EBI_ADR2/SD0_DAT1/SPI1_CLK/UART1_TXD/UART5_nRTS/USC
I1_DAT1/SC0_RST/I2S0_DI/EPWM0_CH2/TM2/INT2
JP3.4
4
PB.2/EADC0_CH2/ACMP0_P1/EBI_ADR3/SD0_DAT0/SPI1_SS/UART1_RXD/UART5_nCTS/USC
I1_DAT0/SC0_PWR/I2S0_DO/EPWM0_CH3/TM3/INT3
JP3.5
5
PC.12/EBI_ADR4/UART0_TXD/I2C0_SCL/SPI3_MISO/SC0_nCD/ECAP1_IC2/EPWM1_CH0/ACM
P0_O
JP3.6
6
PC.11/EBI_ADR5/UART0_RXD/I2C0_SDA/SPI3_MOSI/ECAP1_IC1/EPWM1_CH1/ACMP1_O
JP3.7
7
PC.10/EBI_ADR6/SPI3_CLK/UART3_TXD/ECAP1_IC0/EPWM1_CH2
JP3.8
8
PC.9/EBI_ADR7/SPI3_SS/UART3_RXD/EPWM1_CH3
JP3.9
9
PB.1/EADC0_CH1/EBI_ADR8/SD0_CLK/SPI1_I2SMCLK/SPI3_I2SMCLK/UART2_TXD/USCI1_CL
K/I2C1_SCL/I2S0_LRCK/EPWM0_CH4/EPWM1_CH4/EPWM0_BRAKE0
JP3.10
10
PB.0/EADC0_CH0/EBI_ADR9/SD0_CMD/UART2_RXD/SPI0_I2SMCLK/I2C1_SDA/EPWM0_CH5/
EPWM1_CH5/EPWM0_BRAKE1
JP3.11
11
VSS
JP3.12
12
VDD
JP3.13
13
PA.11/ACMP0_P0/EBI_nRD/SC2_PWR/SPI2_SS/USCI0_CLK/I2C2_SCL/BPWM0_CH0/EPWM0_
SYNC_OUT/TM0_EXT/DAC1_ST
JP3.14
14
PA.10/ACMP1_P0/EBI_nWR/SC2_RST/SPI2_CLK/USCI0_DAT0/I2C2_SDA/BPWM0_CH1/QEI1_I
NDEX/ECAP0_IC0/TM1_EXT/DAC0_ST
JP3.15
15
PA.9/EBI_MCLK/SC2_DAT/SPI2_MISO/USCI0_DAT1/UART1_TXD/BPWM0_CH2/QEI1_A/ECAP
0_IC1/TM2_EXT
JP3.16
16
PA.8/EBI_ALE/SC2_CLK/SPI2_MOSI/USCI0_CTL1/UART1_RXD/BPWM0_CH3/QEI1_B/ECAP0_I
C2/TM3_EXT/INT4
JP3.17
17
PC.13/EBI_ADR10/SC2_nCD/SPI2_I2SMCLK/USCI0_CTL0/UART2_TXD/BPWM0_CH4/CLKO/EA
DC0_ST
JP3.18
18
PD.12/EBI_nCS0/UART2_RXD/BPWM0_CH5/QEI0_INDEX/CLKO/EADC0_ST/INT5
JP3.19
19
PD.11/EBI_nCS1/UART1_TXD/CAN0_TXD/QEI0_A/INT6
JP3.20
20
PD.10/EBI_nCS2/UART1_RXD/CAN0_RXD/QEI0_B/INT7
JP3.21
21
PG.2/EBI_ADR11/SPI2_SS/I2C0_SMBAL/I2C1_SCL/TM0
JP3.22
22
PG.3/EBI_ADR12/SPI2_CLK/I2C0_SMBSUS/I2C1_SDA/TM1
JP3.23
23
PG.4/EBI_ADR13/SPI2_MISO/TM2
JP3.24
24
PF.11/EBI_ADR14/SPI2_MOSI/TAMPER5/TM3
JP3.25
25
PF.10/EBI_ADR15/SC0_nCD/I2S0_BCLK/SPI0_I2SMCLK/TAMPER4
JP3.26
26
PF.9/EBI_ADR16/SC0_PWR/I2S0_MCLK/SPI0_SS/TAMPER3
JP3.27
27
PF.8/EBI_ADR17/SC0_RST/I2S0_DI/SPI0_CLK/TAMPER2
JP3.28
28
PF.7/EBI_ADR18/SC0_DAT/I2S0_DO/SPI0_MISO/UART4_TXD/TAMPER1
JP3.29
29
PF.6/EBI_ADR19/SC0_CLK/I2S0_LRCK/SPI0_MOSI/UART4_RXD/EBI_nCS0/TAMPER0
JP3.30
30
VBAT
JP3.31
31
PF.5/UART2_RXD/UART2_nCTS/BPWM0_CH4/EPWM0_SYNC_OUT/X32_IN/EADC0_ST
JP3.32
32
PF.4/UART2_TXD/UART2_nRTS/BPWM0_CH5/X32_OUT

NuMaker-M263KI
Apr 16, 2019 Page 14 of 39 Rev 1.00
NUMAKER-M263KI USER MANUAL
Maker Nu-mbed NUC472 User Manual
JP5
JP5.1
33
PH.4/EBI_ADR3/SPI1_MISO
JP5.2
34
PH.5/EBI_ADR2/SPI1_MOSI
JP5.3
35
PH.6/EBI_ADR1/SPI1_CLK
JP5.4
36
PH.7/EBI_ADR0/SPI1_SS
JP5.5
37
PF.3/EBI_nCS0/UART0_TXD/I2C0_SCL/XT1_IN/BPWM1_CH0
JP5.6
38
PF.2/EBI_nCS1/UART0_RXD/I2C0_SDA/QSPI0_CLK/XT1_OUT/BPWM1_CH1
JP5.7
39
VSS
JP5.8
40
VDD
JP5.9
41
PE.8/EBI_ADR10/I2S0_BCLK/SPI2_CLK/USCI1_CTL1/UART2_TXD/EPWM0_CH0/EPWM0_BRA
KE0/ECAP0_IC0/TRACE_DATA3
JP5.10
42
PE.9/EBI_ADR11/I2S0_MCLK/SPI2_MISO/USCI1_CTL0/UART2_RXD/EPWM0_CH1/EPWM0_BR
AKE1/ECAP0_IC1/TRACE_DATA2
JP5.11
43
PE.10/EBI_ADR12/I2S0_DI/SPI2_MOSI/USCI1_DAT0/UART3_TXD/EPWM0_CH2/EPWM1_BRA
KE0/ECAP0_IC2/TRACE_DATA1
JP5.12
44
PE.11/EBI_ADR13/I2S0_DO/SPI2_SS/USCI1_DAT1/UART3_RXD/UART1_nCTS/EPWM0_CH3/E
PWM1_BRAKE1/ECAP1_IC2/TRACE_DATA0
JP5.13
45
PE.12/EBI_ADR14/I2S0_LRCK/SPI2_I2SMCLK/USCI1_CLK/UART1_nRTS/EPWM0_CH4/ECAP1
_IC1/TRACE_CLK
JP5.14
46
PE.13/EBI_ADR15/I2C0_SCL/UART4_nRTS/UART1_TXD/EPWM0_CH5/EPWM1_CH0/BPWM1_
CH5/ECAP1_IC0
JP5.15
47
PC.8/EBI_ADR16/I2C0_SDA/UART4_nCTS/UART1_RXD/EPWM1_CH1/BPWM1_CH4
JP5.16
48
PC.7/EBI_AD9/SPI1_MISO/UART4_TXD/SC2_PWR/UART0_nCTS/I2C1_SMBAL/EPWM1_CH2/B
PWM1_CH0/TM0/INT3
JP5.17
49
PC.6/EBI_AD8/SPI1_MOSI/UART4_RXD/SC2_RST/UART0_nRTS/I2C1_SMBSUS/EPWM1_CH3/
BPWM1_CH1/TM1/INT2
JP5.18
50
PA.7/EBI_AD7/SPI1_CLK/SC2_DAT/UART0_TXD/I2C1_SCL/EPWM1_CH4/BPWM1_CH2/ACMP
0_WLAT/TM2/INT1
JP5.19
51
PA.6/EBI_AD6/SPI1_SS/SC2_CLK/UART0_RXD/I2C1_SDA/EPWM1_CH5/BPWM1_CH3/ACMP1
_WLAT/TM3/INT0
JP5.20
52
VSS
JP5.21
53
VDD
JP5.22
54
LDO_CAP
JP5.23
55
PA.5/QSPI0_MISO1/SPI1_I2SMCLK/SC2_nCD/UART0_nCTS/UART5_TXD/I2C0_SCL/CAN0_TX
D/BPWM0_CH5/EPWM0_CH0/QEI0_INDEX
JP5.24
56
PA.4/QSPI0_MOSI1/SPI0_I2SMCLK/SC0_nCD/UART0_nRTS/UART5_RXD/I2C0_SDA/CAN0_RX
D/BPWM0_CH4/EPWM0_CH1/QEI0_A
JP5.25
57
PA.3/QSPI0_SS/SPI0_SS/SC0_PWR/UART4_TXD/UART1_TXD/I2C1_SCL/BPWM0_CH3/EPWM
0_CH2/QEI0_B
JP5.26
58
PA.2/QSPI0_CLK/SPI0_CLK/SC0_RST/UART4_RXD/UART1_RXD/I2C1_SDA/BPWM0_CH2/EP
WM0_CH3
JP5.27
59
PA.1/QSPI0_MISO0/SPI0_MISO/SC0_DAT/UART0_TXD/UART1_nCTS/I2C2_SCL/BPWM0_CH1/
EPWM0_CH4/DAC1_ST
JP5.28
60
PA.0/QSPI0_MOSI0/SPI0_MOSI/SC0_CLK/UART0_RXD/UART1_nRTS/I2C2_SDA/BPWM0_CH0
/EPWM0_CH5/DAC0_ST
JP5.29
61
VDDIO
JP5.30
62
PE.14/EBI_AD8/UART2_TXD/CAN0_TXD
JP5.31
63
PE.15/EBI_AD9/UART2_RXD/CAN0_RXD
JP5.32
64
nRESET
JP4
JP4.1
65
PF.0/UART1_TXD/I2C1_SCL/BPWM1_CH0/ICE_DAT

NuMaker-M263KI
Apr 16, 2019 Page 15 of 39 Rev 1.00
NUMAKER-M263KI USER MANUAL
Maker Nu-mbed NUC472 User Manual
JP4.2
66
PF.1/UART1_RXD/I2C1_SDA/BPWM1_CH1/ICE_CLK
JP4.3
67
PD.9/EBI_AD7/I2C2_SCL/UART2_nCTS
JP4.4
68
PD.8/EBI_AD6/I2C2_SDA/UART2_nRTS
JP4.5
69
PC.5/EBI_AD5/QSPI0_MISO1/UART2_TXD/I2C1_SCL/CAN0_TXD/UART4_TXD/EPWM1_CH0
JP4.6
70
PC.4/EBI_AD4/QSPI0_MOSI1/SC1_nCD/I2S0_BCLK/SPI1_I2SMCLK/UART2_RXD/I2C1_SDA/CA
N0_RXD/UART4_RXD/EPWM1_CH1
JP4.7
71
PC.3/EBI_AD3/QSPI0_SS/SC1_PWR/I2S0_MCLK/SPI1_MISO/UART2_nRTS/I2C0_SMBAL/UAR
T3_TXD/EPWM1_CH2
JP4.8
72
PC.2/EBI_AD2/QSPI0_CLK/SC1_RST/I2S0_DI/SPI1_MOSI/UART2_nCTS/I2C0_SMBSUS/UART3
_RXD/EPWM1_CH3
JP4.9
73
PC.1/EBI_AD1/QSPI0_MISO0/SC1_DAT/I2S0_DO/SPI1_CLK/UART2_TXD/I2C0_SCL/EPWM1_C
H4/ACMP0_O
JP4.10
74
PC.0/EBI_AD0/QSPI0_MOSI0/SC1_CLK/I2S0_LRCK/SPI1_SS/UART2_RXD/I2C0_SDA/EPWM1_
CH5/ACMP1_O
JP4.11
75
VSS
JP4.12
76
VDD
JP4.13
77
PG.9/EBI_AD0/BPWM0_CH5
JP4.14
78
PG.10/EBI_AD1/BPWM0_CH4
JP4.15
79
PG.11/EBI_AD2/BPWM0_CH3
JP4.16
80
PG.12/EBI_AD3/BPWM0_CH2
JP4.17
81
PG.13/EBI_AD4/BPWM0_CH1
JP4.18
82
PG.14/EBI_AD5/BPWM0_CH0
JP4.19
83
PG.15/CLKO/EADC0_ST
JP4.20
84
PD.7/UART1_TXD/I2C0_SCL/SPI1_MISO/USCI1_CLK/SC1_PWR
JP4.21
85
PD.6/UART1_RXD/I2C0_SDA/SPI1_MOSI/USCI1_DAT1/SC1_RST
JP4.22
86
PD.5/I2C1_SCL/SPI1_CLK/USCI1_DAT0/SC1_DAT
JP4.23
87
PD.4/USCI0_CTL0/I2C1_SDA/SPI1_SS/USCI1_CTL1/SC1_CLK/USB_VBUS_ST
JP4.24
88
PD.3/EBI_AD10/USCI0_CTL1/SPI0_SS/UART3_nRTS/USCI1_CTL0/SC2_PWR/SC1_nCD/UART
0_TXD
JP4.25
89
PD.2/EBI_AD11/USCI0_DAT1/SPI0_CLK/UART3_nCTS/SC2_RST/UART0_RXD
JP4.26
90
PD.1/EBI_AD12/USCI0_DAT0/SPI0_MISO/UART3_TXD/I2C2_SCL/SC2_DAT
JP4.27
91
PD.0/EBI_AD13/USCI0_CLK/SPI0_MOSI/UART3_RXD/I2C2_SDA/SC2_CLK/TM2
JP4.28
92
PD.13/EBI_AD10/SD0_nCD/SPI0_I2SMCLK/SPI1_I2SMCLK/SC2_nCD
JP4.29
93
PA.12/I2S0_BCLK/UART4_TXD/I2C1_SCL/SPI2_SS/CAN0_TXD/SC2_PWR/BPWM1_CH2/QEI1_
INDEX/USB_VBUS
JP4.30
94
PA.13/I2S0_MCLK/UART4_RXD/I2C1_SDA/SPI2_CLK/CAN0_RXD/SC2_RST/BPWM1_CH3/QEI
1_A/USB_D-
JP4.31
95
PA.14/I2S0_DI/UART0_TXD/SPI2_MISO/I2C2_SCL/SC2_DAT/BPWM1_CH4/QEI1_B/USB_D+
JP4.32
96
PA.15/I2S0_DO/UART0_RXD/SPI2_MOSI/I2C2_SDA/SC2_CLK/BPWM1_CH5/EPWM0_SYNC_IN
/USB_OTG_ID
JP6
JP6.1
97
PE.7/SD0_CMD/UART5_TXD/QEI1_INDEX/EPWM0_CH0/BPWM0_CH5
JP6.2
98
PE.6/SD0_CLK/SPI3_I2SMCLK/SC0_nCD/USCI0_CTL0/UART5_RXD/QEI1_A/EPWM0_CH1/BP
WM0_CH4
JP6.3
99
PE.5/EBI_nRD/SD0_DAT3/SPI3_SS/SC0_PWR/USCI0_CTL1/QEI1_B/EPWM0_CH2/BPWM0_CH
3

NuMaker-M263KI
Apr 16, 2019 Page 16 of 39 Rev 1.00
NUMAKER-M263KI USER MANUAL
Maker Nu-mbed NUC472 User Manual
JP6.4
100
PE.4/EBI_nWR/SD0_DAT2/SPI3_CLK/SC0_RST/USCI0_DAT1/QEI0_INDEX/EPWM0_CH3/BPW
M0_CH2
JP6.5
101
PE.3/EBI_MCLK/SD0_DAT1/SPI3_MISO/SC0_DAT/USCI0_DAT0/QEI0_A/EPWM0_CH4/BPWM0
_CH1
JP6.6
102
PE.2/EBI_ALE/SD0_DAT0/SPI3_MOSI/SC0_CLK/USCI0_CLK/QEI0_B/EPWM0_CH5/BPWM0_C
H0
JP6.7
103
VSS
JP6.8
104
VDD
JP6.9
105
PE.1/EBI_AD10/QSPI0_MISO0/SC2_DAT/I2S0_BCLK/SPI1_MISO/UART3_TXD/I2C1_SCL/UART
4_nCTS
JP6.10
106
PE.0/EBI_AD11/QSPI0_MOSI0/SC2_CLK/I2S0_MCLK/SPI1_MOSI/UART3_RXD/I2C1_SDA/UAR
T4_nRTS
JP6.11
107
PH.8/EBI_AD12/QSPI0_CLK/SC2_PWR/I2S0_DI/SPI1_CLK/UART3_nRTS/I2C1_SMBAL/I2C2_S
CL/UART1_TXD
JP6.12
108
PH.9/EBI_AD13/QSPI0_SS/SC2_RST/I2S0_DO/SPI1_SS/UART3_nCTS/I2C1_SMBSUS/I2C2_SD
A/UART1_RXD
JP6.13
109
PH.10/EBI_AD14/QSPI0_MISO1/SC2_nCD/I2S0_LRCK/SPI1_I2SMCLK/UART4_TXD/UART0_TX
D
JP6.14
110
PH.11/EBI_AD15/QSPI0_MOSI1/UART4_RXD/UART0_RXD/EPWM0_CH5
JP6.15
111
PD.14/EBI_nCS0/SPI3_I2SMCLK/SC1_nCD/USCI0_CTL0/SPI0_I2SMCLK/EPWM0_CH4
JP6.16
112
VSS
JP6.17
113
VSW
JP6.18
114
VDD
JP6.19
115
LDO_CAP
JP6.20
116
PB.15/EADC0_CH15/EBI_AD12/SC1_PWR/SPI0_SS/USCI0_CTL1/UART0_nCTS/UART3_TXD/I2
C2_SMBAL/EPWM1_CH0/TM0_EXT/USB_VBUS_EN
JP6.21
117
PB.14/EADC0_CH14/EBI_AD13/SC1_RST/SPI0_CLK/USCI0_DAT1/UART0_nRTS/UART3_RXD/I
2C2_SMBSUS/EPWM1_CH1/TM1_EXT/CLKO/USB_VBUS_ST
JP6.22
118
PB.13/EADC0_CH13/DAC1_OUT/ACMP0_P3/ACMP1_P3/EBI_AD14/SC1_DAT/SPI0_MISO/USC
I0_DAT0/UART0_TXD/UART3_nRTS/I2C2_SCL/EPWM1_CH2/TM2_EXT
JP6.23
119
PB.12/EADC0_CH12/DAC0_OUT/ACMP0_P2/ACMP1_P2/EBI_AD15/SC1_CLK/SPI0_MOSI/USCI
0_CLK/UART0_RXD/UART3_nCTS/I2C2_SDA/SD0_nCD/EPWM1_CH3/TM3_EXT
JP6.24
120
AVDD
JP6.25
121
VREF
JP6.26
122
AVSS
JP6.27
123
PB.11/EADC0_CH11/EBI_ADR16/UART0_nCTS/UART4_TXD/I2C1_SCL/CAN0_TXD/SPI0_I2SM
CLK/BPWM1_CH0/SPI3_CLK
JP6.28
124
PB.10/EADC0_CH10/EBI_ADR17/USCI1_CTL0/UART0_nRTS/UART4_RXD/I2C1_SDA/CAN0_R
XD/BPWM1_CH1/SPI3_SS
JP6.29
125
PB.9/EADC0_CH9/EBI_ADR18/USCI1_CTL1/UART0_TXD/UART1_nCTS/I2C1_SMBAL/BPWM1_
CH2/SPI3_MISO/INT7
JP6.30
126
PB.8/EADC0_CH8/EBI_ADR19/USCI1_CLK/UART0_RXD/UART1_nRTS/I2C1_SMBSUS/BPWM1
_CH3/SPI3_MOSI/INT6
JP6.31
127
PB.7/EADC0_CH7/EBI_nWRL/USCI1_DAT0/UART1_TXD/EBI_nCS0/BPWM1_CH4/EPWM1_BR
AKE0/EPWM1_CH4/INT5/USB_VBUS_ST/ACMP0_O
JP6.32
128
PB.6/EADC0_CH6/EBI_nWRH/USCI1_DAT1/UART1_RXD/EBI_nCS1/BPWM1_CH5/EPWM1_BR
AKE1/EPWM1_CH5/INT4/USB_VBUS_EN/ACMP1_O
Table 2-2 M263KIAAE Full-pin Extension Connectors and GPIO Function List

NuMaker-M263KI
Apr 16, 2019 Page 17 of 39 Rev 1.00
NUMAKER-M263KI USER MANUAL
Maker Nu-mbed NUC472 User Manual
System Configuration2.5
2.5.1 VIN Power Source
Table 2-3 presents the VIN power source.
Connector
Net Name in
Schematic
Comment
NU1 pin8
NU1_VIN
Board external power source, with voltage range from 7
V to 12 V. The voltage regulator UP2 converts the NU1
pin8 input voltage to 5 V and supplies it to NuMaker-
M263KI.
Table 2-3 VIN Power Source
2.5.2 5 V Power Sources
Table 2-4 presents the 5 V power sources.
Connector
Net Name in
Schematic
Comment
ICEJ3
USB_HS_VBUS
ICE USB connector supplies 5 V power from PC to
M263 platform and Nu-Link2-Me.
J2
USB_VBUS
If target chip M263 acts as USB Device, USB connector
on NuMaker-M263KI supplies 5 V power from PC to
M263 platform and Nu-Link2-Me.
If target chip M263 acts as USB Host, USB connector
on NuMaker-M263KI supplies 5 V power from M263
platform to PC.
NU1 pin5
NU1_5VCC
ICEJ3, J2 or NU1 pin8 supplies 5 V power to NU1 pin5.
NU1 pin5 supplies 5 V power to target chip or Arduino
adapter board.
Note: M263 operating voltage range is from 1.8 V to 3.6
V. Do not switch SW2.1 (NU1 5VCC) to ON.
Table 2-4 5V Power Sources
2.5.3 3.3 V Power Sources
Table 2-5 presents the 3.3 V power sources.
Voltage Regulator
5V Source
Comment
ICEUP1
USB_HS_VBUS
ICEUP1 converts USB_HS_VBUS to 3.3 V and supplies
3.3V to M263 platform or ICE chip.
UP1
USB_VBUS
UP1 converts USB_VBUS to 3.3 V and supplies 3.3 V
to M263 platform.
Note: SW2.2 (NU1 3VCC) should be switched to ON.
UP1
NU1_5VCC
UP1 converts NU1_5VCC to 3.3 V and supplies 3.3 V to
M263 platform.

NuMaker-M263KI
Apr 16, 2019 Page 18 of 39 Rev 1.00
NUMAKER-M263KI USER MANUAL
Maker Nu-mbed NUC472 User Manual
Note: SW2.2 (NU1 3VCC) should be switched to ON.
Table 2-5 3.3 V Power Sources
2.5.4 1.8V Power Sources
Table 2-6 presents the 1.8 V power source.
Voltage Regular
5V Source
Comment
ICEUP2
USB_HS_VBUS
ICEUP2 converts USB_HS_VBUS to 1.8V and supplies
1.8V to M263 platform or ICE chip.
Table 2-6 1.8V Power Sources
2.5.5 Power Connectors
Table 2-7 presents the power connectors.
Connector
Comment
JP1
VDD (1.8 V ~ 3.6 V) connector on the NuMaker-M263KI.
JP2
VSS connector on the NuMaker-M263KI.
Table 2-7 Power Connectors
2.5.6 USB Connectors
Table 2-8 presents the USB connectors.
Connector
Comment
ICEJ3
ICE USB connector on Nu-Link2-Me for power supply, debugging and
programming from PC.
J2
USB OTG connector on NuMaker-M263KI for USB function.
Table 2-8 USB Connectors
2.5.7 Power Switches
Table 2-9 presents the power switches.
Switch
Comment
ICEJPR1
Configure the target chip operating voltage at 1.8 V / 3.3 V / 5 V.
ICEJPR2
Configure the ICE chip operating voltage at 1.8 V / 3.3 V.
SW2
Configure the target chip operating voltage at 3.3 V / 5 V.
Table 2-9 Power Switches

NuMaker-M263KI
Apr 16, 2019 Page 19 of 39 Rev 1.00
NUMAKER-M263KI USER MANUAL
Maker Nu-mbed NUC472 User Manual
2.5.8 Power Supply Models
External Power Supply through Nu-Link2-Me to Target Chip2.5.8.1
The external power supply source on Nu-Link2-Me is shown in Figure 2-5.
ICE USB Connector (ICEJ3)
Nu-Link2-Me
Figure 2-5 External Power Supply Sources on Nu-Link2-Me
To use ICEJ3 as external power supply source with Nu-Link2-Me, please follow the steps below:
1. Solder the resistor on ICEJPR1 (MCUVCC) depends on the target chip operating voltage.
2. Solder the resistor on ICEJPR2 (ICEVCC) depends on the ICE chip operating voltage.
3. Switch the SW2 to OFF.
Table 2-10 presents all power models when supplies external power through Nu-Link2-Me. The Nu-
Link2-Me external power sources are highlighted in yellow.
Model
Target
Chip
Voltage
ICEJ3
ICEJPR1
(MCUVCC)
Selection [1]
ICEJPR2
(ICEVCC)
Selection [2]
ICE
Chip
Voltage
SW2
Selection
J2
VIN
JP1
1
1.8 V
Connect
to PC
1.8 V
1.8 V
1.8 V
Off
Ignore
Ignore
1.8 V
output
2
3.3 V
Connect
to PC
3.3 V (default)
3.3 V (default)
3.3 V
Off
Ignore
Ignore
3.3 V
output
3
5 V
Connect
to PC
5V
3.3 V (default)
3.3 V
Off
Ignore
Ignore
5 V
output
X: Unused.
Note:
1. 0 Ω should be soldered between ICEJPR1’s MCUVCC and 1.8 V / 3.3 V / 5 V.
2. 0 Ω should be soldered between ICEJPR2’s ICEVCC and 1.8 V / 3.3 V.
Table 2-10 Supply External Power through Nu-Link2-Me

NuMaker-M263KI
Apr 16, 2019 Page 20 of 39 Rev 1.00
NUMAKER-M263KI USER MANUAL
Maker Nu-mbed NUC472 User Manual
External Power Supply through M263 Platform to Target Chip2.5.8.2
The external power supply sources on M263 Platform are shown in Figure 2-6.
USB Power Connector (J2)
NU1 pin8 (Vin)
External VDD Connector (JP1)
External VSS Connector (JP2)
Figure 2-6 External Power Supply Sources on M263 Platform
To use VIN or J2 as external power supply source, please follow the steps below:
1. Switch the SW2 depends on the target chip operating voltage.
2. Remove the resistor on ICEJPR1 (MCUVCC).
3. Solder the resistor on ICEJPR2 (ICEVCC) depends on the ICE chip operating voltage.
4. Connect the external power supply to VIN or J2.
To use JP1 as external power supply source, please follow the steps below:
1. Switch the SW2 to OFF.
2. Remove the resistor on ICEJPR1 (MCUVCC).
3. Solder the resistor on ICEJPR2 (ICEVCC) depends on the ICE chip operating voltage.
4. Connect ICEJ3 to PC.
5. Connect the external power supply to JP1.
To use VIN or J2 as external power supply source with Nu-Link2-Me separated from NuMaker-
M263KI, please follow the steps below:
1. Switch the SW2 depends on the target chip operating voltage.
2. Separate the Nu-Link2-Me from NuMaker-M263KI.
3. Connect the external power supply to VIN or J2.
To use JP1 as external power supply source with Nu-Link2-Me separated from NuMaker-M263KI,
please follow the steps below:
1. Switch the SW2 to OFF.
2. Separate the Nu-Link2-Me from NuMaker-M263KI.
3. Connect the external power supply to JP1.
