1. General description
The TFA9812 is a high-efficiency Bridge Tied Load (BTL) stereo Class-D audio amplifier
with a digital I2S audio input. It is available in a HVQFN48 package with exposed die
paddle. The exposed die paddle technology enhances the thermal and electrical
performances of the device.
The TFA9812 features digital sound processing and audio power amplification. It supports
I2C control mode and Legacy mode. In Legacy mode I2C involvement is not needed
because the key features are controlled by hardware pin connections.
A continuous time output power of 2 ×12W(R
L=8Ω,V DDP = 15 V) is supported without
an external heat sink. Due to the implementation of a programmable thermal foldback
even for high supply voltages, higher ambient temperatures, and/or lower load
impedances, the device operates without sound interrupting behavior.
TFA9812 is designed in such a way that it starts up easily (no special power-up sequence
required). It features various soft and hard impact protection mechanisms to ensure an
application that is both user friendly and robust.
A modulation technique is applied for the TFA9812, which supports common mode choke
approach (1 common mode choke only per BTL amplifier stage). This minimizes the
number of external components.
2. Features
2.1 General features
n3.3 V and 8 V to 20 V external power supply
nHigh efficiency and low power dissipation
nSpeaker outputs fully short circuit proof across load, to supply lines and ground
nPop noise free at power-up/power-down and sample rate switching
nLow power Sleep mode
nOvervoltage and undervoltage protection on the 8 V to 20 V power supply
nUndervoltage protection on the 3.3 V power supply
nOvercurrent protection (no audible interruptions)
nOverdissipation protection
nThermally protected and programmable thermal foldback
nClock error protection
nI2C mode control or Legacy mode (i.e. no I2C) control
nFour different I2C addresses supported
nInternal Phase-Locked Loop (PLL) without using external components
TFA9812
BTL stereo Class-D audio amplifier with I2S input
Rev. 02 — 22 January 2009 Preliminary data sheet

TFA9812_2 © NXP B.V. 2009. All rights reserved.
Preliminary data sheet Rev. 02 — 22 January 2009 2 of 66
NXP Semiconductors TFA9812
BTL stereo Class-D audio amplifier with I2S input
nNo high system clock required (PLL is able to lock on BCK)
nNo external heat sink required
n5 V tolerant digital inputs
nSupports dual coil inductor application
nEasy application and limited external components required
2.2 DSP features
nDigital parametric 10-band equalizer
nDigital volume control per channel
nSelectable +24 dB gain boost
nAnalog interface to digital volume control in Legacy mode
nDigital clip level control
nSoft and hard mute
nThermal foldback threshold temperature control
nDe-emphasis
nOutput power limiting control
nPolarity switch
nFour Pulse Width Modulation (PWM) switching frequency settings
2.3 Audio data input interface format support
nMaster or slave Master Clock (MCLK), Bit Clock (BCK) and Word Select (WS) signals
nPhilips I2S, standard I2S
nJapanese I2S, Most Significant Bit (MSB) justified
nSony I2S, Least Significant Bit (LSB) justified
nSample rates from 8 kHz to 192 kHz
3. Applications
nDigital-in Class-D audio amplifier applications
nCRT and flat-panel television sets
nFlat-panel monitors
nMultimedia systems
nWireless speakers
nDocking stations for MP3 players

TFA9812_2 © NXP B.V. 2009. All rights reserved.
Preliminary data sheet Rev. 02 — 22 January 2009 3 of 66
NXP Semiconductors TFA9812
BTL stereo Class-D audio amplifier with I2S input
4. Quick reference data
[1] IPis the current through the analog supply voltage (VDDA) pin added to the current through the power supply
voltage (VDDP) pin.
Table 1. Quick reference table
Unless specified otherwise, V
DDA
=V
DDP
=12V,V
SSP1
=V
SSP2
=0V,V
DDA(3V3)
=V
DDD(3V3)
= 3.3 V,
V
SS1
=V
SS2
= REFD = REFA = 0 V, T
amb
=25 ° C, R
L
=8 Ω ,f
i
= 1 kHz, f
s
= 44.1 kHz, f
sw
= 400 kHz,
24-bit I
2
S input data, MCLK clock mode, typical application diagram (Figure 13).
Symbol Parameter Conditions Min Typ Max Unit
General
VDDA analog supply
voltage 81220V
VDDP power supply
voltage 81220V
VDDA(3V3) analog supply
voltage (3.3 V) 3.0 3.3 3.6 V
VDDD(3V3) digital supply
voltage (3.3 V) 3.0 3.3 3.6 V
IPsupply current soft mute mode, with load,
filter and snubbers
connected
[1] -3845mA
sleep mode [1] - 160 270 µA
IDDA(3V3) analog supply
current (3.3 V) operating mode
I2S slave mode - 2 4 mA
I2S master mode - 4 6 mA
sleep mode
VDDA =V
DDP = 12 V - 120 - µA
VDDA =V
DDP = 1 V - 40 70 µA
IDDD(3V3) digital supply
current (3.3 V) operating mode
I2S slave mode - 15 25 mA
I2S master mode - 25 40 mA
sleep mode;
DATA = WS = BCK =
MCLK = 0 V
-430µA
Po(RMS) RMS output power Continuous time output power per channel; THD = 10 %;
RL=8Ω
VDDA = VDDP = 12 V - 8.3 - W
VDDA = VDDP = 13.5 V - 10 - W
VDDA = VDDP = 15 V - 12 - W
Short time (≤10 s) output power per channel; THD = 10 %;
RL=8Ω
VDDA = VDDP = 17 V - 15 - W
ηpo output power
efficiency RL=8Ω; Po(RMS) = 8.3 W - 88 - %

TFA9812_2 © NXP B.V. 2009. All rights reserved.
Preliminary data sheet Rev. 02 — 22 January 2009 4 of 66
NXP Semiconductors TFA9812
BTL stereo Class-D audio amplifier with I2S input
5. Ordering information
Table 2. Ordering information
Type number Package
Name Description Version
TFA9812HN HVQFN48 plastic thermal enhanced very thin quad flat package; no leads;
48 terminals; body 7 ×7×0.85 mm SOT619-8

xxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxx x x x xxxxxxxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxx xx xx
xxxxx xxxxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxx xxxxxx xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxx x x
xxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxxxxxxxxxxxx xxxxx xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxx
xxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxx xxx
TFA9812_2 © NXP B.V. 2009. All rights reserved. Preliminary data sheet Rev. 02 — 22 January 2009 5 of 66 NXP Semiconductors TFA9812
BTL stereo Class-D audio amplifier with I2S input
6. Block diagram
Fig 1. TFA9812 block diagram
15
16, 17
18, 19
10, 11
25
23, 24
26, 27
VDDP
VSSP1
22
BOOT1P
VDDP
OUT1P
VSSP2
BOOT1N
OUT1N
STAB1
BOOT2P
STAB1
CONTROL
LOGIC 20, 21
DRIVER
HIGH
12
13, 14
VDDP
VSSP2
VDDP
OUT2P
VSSP2
BOOT2N
OUT2N
STAB2
STAB2
XTALIN
XTALOUT
MCLK
REFERENCES
PROTECTION
OVP
UVP
OCP
OTP
ODP
WP
CDELAYDIAG
1
2
47
31
39
41 42 45
TFA9812
010aaa217
CONTROL
LOGIC
DRIVER
HIGH
DRIVER
LOW
DRIVER
LOW
CONTROL
LOGIC
CONTROL
LOGIC
DRIVER
HIGH
DRIVER
LOW
DRIVER
HIGH
DRIVER
LOW
PWM
CONTROLLER
PWM
CONTROLLER
CONTROL
INTERFACE
REGISTER
ADDRESS
HEX 01
PHASED
LOCKED
LOOP
THERMAL
FOLDBACK
OSCILLATOR
ADC
10
34
35
36
37
38
POWERUP
SDA/MS
GAIN
33ENABLE
CSEL
ADSEL2/PLIM2
ADSEL1/PLIM1
SCL/SFOR
STABD REFD STABA REFA
30
29 488
EXPOSED DIE PADDLE VSS1 VSS2
46
45
44
BCK
WS
DATA
CSEL
TEST1 TEST2 AVOL VDDD(3V3) VDDA(3V3) VDDA
743 32 40 36
9
28
CLOCK
PROTECTION
LP
UFP
OFP
IBP
SERIAL
AUDIO
INTERFACE
10-BAND
PARAMETRIC
EQUALIZER
VOLUME
CONTROL
AND SOFT
MUTE
INTER-
POLATION
FILTER AND
DE-EMPHASIS
POWER
LIMITER
GAIN

TFA9812_2 © NXP B.V. 2009. All rights reserved.
Preliminary data sheet Rev. 02 — 22 January 2009 6 of 66
NXP Semiconductors TFA9812
BTL stereo Class-D audio amplifier with I2S input
Figure 1 shows the block diagram of the TFA9812. For a detailed description of the audio
signal path see Section 8.1.
7. Pinning information
7.1 Pinning
Fig 2. Pin configuration, transparent top view
Table 3. Pinning description TFA9812
Pin Symbol Type Description
1 XTALIN I Crystal oscillator input
2 XTALOUT O Crystal oscillator output
3V
DDA(3V3) P Analog supply voltage (3.3 V)
4 STABA O 1.8 V analog stabilizer output
5 REFA P Analog reference voltage
6V
DDA P Analog supply voltage (8 V to 20 V)
7 TEST1 I Test signal input 1. For test purposes only (connect to VSS)
8V
SS1 P PCB ground reference
9 STAB2 O Decoupling of internal 11 V regulator for channel 2 drivers
10 VSSP2 P Negative power supply voltage for channel 1 and channel 2
11 VSSP2 P Negative power supply voltage for channel 1 and channel 2
12 BOOT2N O Bootstrap high-side driver negative PWM output channel 2
13 OUT2N O Negative PWM output channel 2
010aaa218
TFA9812HN
BOOT1N
VSSP2
BOOT2N
VSSP1
VSSP2 VSSP1
STAB2 STAB1
VSS1 DIAG
TEST1 CDELAY
VDDA POWERUP
REFA AVOL
STABA ENABLE
VDDA(3V3) GAIN
XTALOUT CSEL
XTALIN ADSEL2/PLIM2
OUT2N OUT2N
BOOT1P
OUT2P OUT1P
VDDP
VDDP
OUT1P OUT1P
BOOT1P
OUT1N OUT1N
VSS2
MCLK BCK WS DATA TEST2 REFD STABD VDDD(3V3) SDA/MS SCL/SFOR ADSEL1/PLIM1
12 25
11 26
10 27
9 28
8 29
7 30
6 31
5 32
4 33
3 34
2 35
1 36
13 14 15 16 17 18 19 20 21 22 23 24
48 47 46 45 44 43 42 41 40 39 38 37
terminal 1
index area
Transparent top view

TFA9812_2 © NXP B.V. 2009. All rights reserved.
Preliminary data sheet Rev. 02 — 22 January 2009 7 of 66
NXP Semiconductors TFA9812
BTL stereo Class-D audio amplifier with I2S input
14 OUT2N O Negative PWM output channel 2
15 BOOT1P O Bootstrap high-side driver positive PWM output channel 1
16 OUT1P O Positive PWM output channel 1
17 OUT1P O Positive PWM output channel 1
18 VDDP P Positive power supply voltage (8 V to 20 V)
19 VDDP P Positive power supply voltage (8 V to 20 V)
20 OUT2P O Positive PWM output channel 2
21 OUT2P O Positive PWM output channel 2
22 BOOT2P O Bootstrap high-side driver positive PWM output channel 2
23 OUT1N O Negative PWM output channel 1
24 OUT1N O Negative PWM output channel 1
25 BOOT1N O Bootstrap high-side driver negative PWM output channel 1
26 VSSP1 P Negative power supply voltage for channel 1 and channel 2
27 VSSP1 P Negative power supply voltage for channel 1 and channel 2
28 STAB1 O Decoupling of internal 11 V regulator for channel 1 drivers
29 DIAG O Fault mode indication output (open-drain pin)
30 CDELAY I Timing reference
31 POWERUP I Power-up pin to switch between Sleep and other operational
modes
32 AVOL I Analog volume control (Legacy mode)
33 ENABLE I Enable input to switch between 3-state and other
operational modes
34 GAIN I Gain selection input to select between 0 dB and +24 dB
gain (Legacy mode)
35 CSEL I Control selection input to select between Legacy mode
(no I2C bus control) and I2C bus control
36 ADSEL2/PLIM2 I Address selection in I2C mode input 2, power limiter
selection input 2 in Legacy mode
37 ADSEL1/PLIM1 I Address selection in I2C mode input 1, power limiter
selection input 1 in Legacy mode
38 SCL/SFOR I I2C bus clock input in I2C mode, I2S serial data format
selection input in Legacy mode
39 SDA/MS I/O I2C bus data input and output in I2C mode, master/slave
selection input in Legacy mode
40 VDDD(3V3) P Digital supply voltage (3.3 V)
41 STABD O 1.8 V digital stabilizer output
42 REFD P Digital reference voltage
43 TEST2 I Test signal input 2; for test purposes only (connect to VSS)
44 DATA I I2S bus data input
45 WS I/O I2S bus word select input (I2S slave mode) or output (I2S
master mode)
46 BCK I/O I2S bus bit clock input (I2S slave mode) or output (I2S
master mode)
Table 3. Pinning description TFA9812
…continued
Pin Symbol Type Description

TFA9812_2 © NXP B.V. 2009. All rights reserved.
Preliminary data sheet Rev. 02 — 22 January 2009 8 of 66
NXP Semiconductors TFA9812
BTL stereo Class-D audio amplifier with I2S input
8. Functional description
8.1 General
The TFA9812 is a high-efficiency stereo BTL Class-D amplifier with a digital I2S audio
input. It supports all commonly used I2S formats.
Figure 1 shows the functional block diagram, which includes the key function blocks of the
TFA9812. In the digital domain the audio signal is processed and converted to a pulse
width modulated signal using BD modulation. A BTL configured power comparator carries
out power amplification.
The audio signal processing path is as follows:
1. The Digital Audio Input (DAI) block translates the I2S (-like) input signal into a
standard internal stereo audio stream.
2. The 10-band parametric equalizer can optionally equalize the stereo audio stream.
Both channels have separate equalization streams. It can be used for speaker transfer
curve compensation to optimize the audio performance of applied speakers.
3. Volume control in the TFA9812 is done by attenuation. The attenuation depends on
the volume control settings and the thermal foldback value. Soft mute is also arranged
at this part. In Legacy mode the volume control is done by an on-board
Analog-to-Digital Converter (ADC) which measures the analog voltage on pin 32.
4. The interpolation filter interpolates from 1 fs to the PWM controller sample rate
(2048 fs at 44.1 kHz) by cascading FIR filters.
5. The gain block can boost the signal with 0 dB or +24 dB. Four specific gain settings
are also provided in this block. These specific gain settings are related to maximum
clip levels of < 0.5 %, 10 %, 20 % or 30 % THD at the TFA9812 output. These
maximum clip levels are only valid with the gain boost set to 0 dB and a 0 dBFS input
signal.
6. The power limiter limits the maximum output signal of the TFA9812. The power limiter
settings are 0 dB, −1.5 dB, −3 dB, and −4.5 dB. This function can be used to reduce
the maximum output power delivered to the speakers at a fixed supply voltage and
speaker impedance.
7. The PWM controller block transforms the audio signal into a BD-modulated PWM
signal. The BD-modulation provides a high signal-to-noise performance and
eliminates clock jitter noise.
8. Via four differential comparators the PWM signals are amplified by two BTL power
output stages. By default the left audio signal is connected to channel 1 and the right
audio signal to channel 2.
47 MCLK I/O Master clock input (I2S slave mode) or output (I2S master
mode)
48 VSS2 P PCB ground reference
Exposed
die-paddle - P PCB ground reference
Table 3. Pinning description TFA9812
…continued
Pin Symbol Type Description

TFA9812_2 © NXP B.V. 2009. All rights reserved.
Preliminary data sheet Rev. 02 — 22 January 2009 9 of 66
NXP Semiconductors TFA9812
BTL stereo Class-D audio amplifier with I2S input
The block control defines the operational control settings of the TFA9812 in line with the
actual I2C settings and the pin-controlled settings.
The PLL block creates the system clock and can take the I2S BCK, the MCLK or an
external crystal as reference source.
The following protections are built into the TFA9812:
•Thermal Foldback (TF)
•OverTemperature Protection (OTP)
•OverCurrent Protection (OCP)
•OverVoltage Protection (OVP)
•UnderVoltage Protection (UVP)
•Window Protection (WP)
•Lock Protection (LP)
•UnderFrequency Protection (UFP)
•OverFrequency Protection (OFP)
•Invalid BCK Protection (IBP)
•DC-blocking
•ElectroStatic Discharge (ESD)
8.2 Functional modes
8.2.1 Control modes
The two control modes of the TFA9812 are I2C and legacy.
•In I2C mode the I2C format control is enabled.
•In Legacy mode a pin-based subset of the control options is available. The control
settings for features which are not available in Legacy mode are set to the default I2C
register settings.
The control mode is selected via pin CSEL as shown in Table 4.
In the functional descriptions below the control for the various functions will be described
for each control mode. Section 9.6 summarizes the support given by each control mode
for the various TFA9812 functions.
8.2.2 Key operating modes
There are six key operating modes:
•In Sleep mode the voltage supplies are present, but power consumption for the whole
device is reduced to the minimum level. The output stages in Sleep mode are 3-state
and I2C communication is disabled.
Table 4. Control mode selection
CSEL Pin value Control mode
0 Legacy (no I2C)
1I
2C

TFA9812_2 © NXP B.V. 2009. All rights reserved.
Preliminary data sheet Rev. 02 — 22 January 2009 10 of 66
NXP Semiconductors TFA9812
BTL stereo Class-D audio amplifier with I2S input
•In Soft mute mode the I2S input signal is overruled with a soft mute.
–In Legacy control mode the analog input pin AVOL controls Soft mute mode.
–In I2C control mode I2C control can be used to enable an automatic soft mute
function. See also Section 8.5.3.
•In Hard mute mode the PWM controller is overruled with a 50 % duty cycle square
pulse. The Hard mute mode is only available in I2C control mode.
•In Operating mode the TFA9812 amplifies the I2S audio input signal in line with the
actual control setting.
•In 3-state mode the output stages are switched off.
•Fault mode is entered when a fault condition is detected by one or more of the
protection mechanisms implemented in the TFA9812. In Fault mode the actual device
configuration depends on the fault detected: see Section 8.7 for more information.
Fault mode is for a subset of the faults flagged on the DIAG output pin. When the
DIAG pin is flagged the output stages will be forced to enter 3-state mode. In Sleep
mode the DIAG pin will not flag fault modes.
[1] Clocking faults do not trigger DIAG output.
[2] Under these conditions soft mute still has to be enabled by the appropriate I2C setting.
8.2.3 I2S master/slave modes and MCLK/BCK clock modes
The I2S interface can be set in master or in slave.
•In I2S master mode the PLL locks to the output signal of the internal crystal oscillator
circuit which uses an external crystal. The BCK, WS and MCLK signals are generated
by the TFA9812. On the MCLK pin the TFA9812 delivers a master clock running at the
crystal frequency.
•In I2S slave mode the PLL can lock to:
–The external MCLK signal on the MCLK pin called MCLK clock mode.
–The I2S input BCK signal on the BCK pin called BCK clock mode.
The I2S master or slave mode can be selected:
•In I2C control mode by selecting the right I2C setting.
•In legacy control mode by selecting the right setting on the SDA/MS pin.
Table 5. Operational mode selection
Pin: DIAG Output Operational mode
selected:
POWERUP ENABLE CSEL AVOL
0 - - - floating Sleep mode
1 - - - 0 / floating Fault mode (enabled by
system)[1]
1 1 1 - floating Soft mute mode (in I2C
control mode)[2]
1 1 0 < 0.8 V floating Soft mute (in Legacy control
mode)
1 0 - - floating 3-state mode
1 1 - - floating Operational mode

TFA9812_2 © NXP B.V. 2009. All rights reserved.
Preliminary data sheet Rev. 02 — 22 January 2009 11 of 66
NXP Semiconductors TFA9812
BTL stereo Class-D audio amplifier with I2S input
[1] Under these conditions the mode is enabled by the appropriate I2C setting.
In I2S slave mode selection between BCK and MCLK clock modes is automatic.
MCLK clock mode is given higher priority than BCK. If the MCLK clock is judged valid by
the protection circuit then MCLK clock mode is enabled. BCK clock mode is enabled when
the MCLK clock is invalid (e.g. not available) and the BCK clock is judged valid by the
protection circuit (see Section 8.7.11).
Table 7 shows the supported crystal frequencies in I2S master mode.
Table 8 shows the supported MCLK frequencies in MCLK mode (I2S slave mode).
Table 9 shows the supported BCK frequencies in BCK mode (I2S slave mode).
Table 6. I2S master/slave mode selection
Pin value Clock mode I2S mode
CSEL SDA/MS
0 0 legacy slave
0 1 legacy master
1- I
2C slave or master[1]
Table 7. Valid crystal frequencies in I2S master mode
Control mode fs(kHz) Crystal frequency (MHz)
I2C 8, 16, 32, 64, 128 8.192
11.025, 22.05, 44.1, 88.2,
176.4 11.2896
12, 24, 48, 96, 192 12.288
Legacy 32 8.192
44.1 11.2896
48 12.288
Table 8. Valid MCLK frequencies in I2S slave mode
Control mode fs(kHz) MLCK frequency (MHz)
I2C 8, 16, 32, 64, 128 8.192
12.288
32 18.432 (576 fs)
11.025, 22.05, 44.1, 88.2,
176.4 11.2896
16.9344
44.1 25.4016 (576 fs)
12, 24, 48, 96, 192 12.288
18.432
48 27.648 (576 fs)

TFA9812_2 © NXP B.V. 2009. All rights reserved.
Preliminary data sheet Rev. 02 — 22 January 2009 12 of 66
NXP Semiconductors TFA9812
BTL stereo Class-D audio amplifier with I2S input
[1] The valid sample frequencies are shown in Section 9.5.7.
Legacy 32 8.192
12.288
18.432 (576 fs)
44.1 11.2896
16.9344
25.4016 (576 fs)
48 12.288
18.432
27.648 (576 fs)
Table 9. Valid BCK frequencies in I2S slave mode
Control mode fs(kHz) BCK (x fsinput)
I2C 8 to 192[1] 32 fs
8 to 192[1] 48 fs
8 to 192[1] 64 fs
Legacy 32, 44.1, 48 32 fs
32, 44.1, 48 48 fs
32, 44.1, 48 64 fs
Table 8. Valid MCLK frequencies in I2S slave mode
Control mode fs(kHz) MLCK frequency (MHz)

TFA9812_2 © NXP B.V. 2009. All rights reserved.
Preliminary data sheet Rev. 02 — 22 January 2009 13 of 66
NXP Semiconductors TFA9812
BTL stereo Class-D audio amplifier with I2S input
8.3 Power-up/power-down
8.3.1 Power-up
Figure 3 and Table 10 describe the power-up timing while Table 11 shows the pin control
for initiating a power-up reset.
[1] Mute in Legacy mode is controlled by AVOL pin.
Fig 3. Power-up/power-down timing
external
voltage
supplies
POWERUP
pin
I2C
available
ENABLE
pin
PWM
outputs
twake td(on) td(mute_off) td(soft_mute)
010aaa219
soft mute
setting in
I2C mode
AVOL pin
in Legacy
mode
Operating
mode active
Table 10. Power-up/power-down timing
Symbol Parameter Conditions Min Typ Max Unit
twake wake-up
time I2C control - 4 - ms
td(on) turn-on
delay time - 70 - 135 ms
td(mute_off) mute off
delay time - - - 128/fss
td(soft_mute) Soft mute
delay time I2C control - - 128/fss
legacy
control[1] -15-ms

TFA9812_2 © NXP B.V. 2009. All rights reserved.
Preliminary data sheet Rev. 02 — 22 January 2009 14 of 66
NXP Semiconductors TFA9812
BTL stereo Class-D audio amplifier with I2S input
In I2C control mode communication is enabled after 4 ms. The preferred I2C settings can
be made within 66 ms before the PLL starts running. Finally, the output stages are
enabled and the audio level is increased via a demute sequence if mute has previously
been disabled.
Remark: In I2C mode soft mute is enabled by default. It can be disabled at any time while
I2C communication is valid. In order to prevent audio clicks volume control (default setting
is 0 dB) should be set before soft mute is disabled.
Remark: For a proper start-up in I2S master mode and I2C mode the following sequence
should be followed:
1. The I2S master setting should be set and keep the default sample rate setting active.
2. Next, another sample rate setting than the default one should be selected.
3. Finally, when the default sample rate is used the default sample rate setting should be
selected again.
8.3.2 Power-down
Figure 3 includes the power-down timing while Table 11 shows the pin control for enabling
power-down.
Putting the TFA9812 into power-down is equivalent to enabling Sleep mode
(see Section 8.2.2). This mode is entered immediately and no additional clock cycles are
required.
In order to prevent audible clicks, soft mute should be enabled at least Td(soft_mute)
seconds before enabling Sleep mode.
The specified low current and power conditions in Table 1 are valid within 10 µs after
enabling Sleep mode.
8.4 Digital audio data input
8.4.1 Digital audio data format support
The TFA9812 supports a commonly used range of I2S and I2S-like digital audio data input
formats. These are listed in Table 12.
Table 11. Power-up/power-down selection
Power-up pin
value Description
0 Power-down (Sleep mode)
1 Power-up
Table 12. Supported digital audio data formats
BCK frequency Interface format (MSB first) Supported in I2C
control mode Supported in Legacy control mode
32 fsI2S up to 16-bit data yes yes
32 fsMSB-justified 16-bit data yes yes
32 fsLSB-justified 16-bit data yes yes
48 fsI2S up to 24-bit data yes yes
48 fsMSB-justified up to 24-bit data yes yes

TFA9812_2 © NXP B.V. 2009. All rights reserved.
Preliminary data sheet Rev. 02 — 22 January 2009 15 of 66
NXP Semiconductors TFA9812
BTL stereo Class-D audio amplifier with I2S input
Remark: Only MSB-first formats are supported.
48 fsLSB-justified 16-bit data yes no
48 fsLSB-justified 18-bit data yes no
48 fsLSB-justified 20-bit data yes no
48 fsLSB-justified 24-bit data yes yes
64 fsI2S up to 24-bit data yes yes
64 fsMSB-justified up to 24-bit data yes yes
64 fsLSB-justified 16-bit data yes no
64 fsLSB-justified 18-bit data yes no
64 fsLSB-justified 20-bit data yes no
64 fsLSB-justified 24-bit data yes no
Table 12. Supported digital audio data formats
BCK frequency Interface format (MSB first) Supported in I2C
control mode Supported in Legacy control mode
Fig 4. Serial interface input and output formats
16
MSB B2 B3 B4 B5 B6
LEFT
LSB-JUSTIFIED FORMAT 20 BITS
WS
BCK
DATA
RIGHT
1518 1720 19 2 1
B19 LSB
16
MSB B2 B3 B4 B5 B6
1518 1720 19 2 1
B19 LSB
MSB MSBB2
2112 3
LEFT
I2S-BUS FORMAT
WS
BCK
DATA
RIGHT
3
MSB B2
010aaa458
16
B5 B6 B7 B8 B9 B10
LEFT
LSB-JUSTIFIED FORMAT 24 BITS
WS
BCK
DATA
RIGHT
1518 1720 1922 212324 2 1
B3 B4
MSB B2 B23 LSB
16
B5 B6 B7 B8 B9 B10
1518 1720 1922 212324 2 1
B3 B4
MSB B2 B23 LSB
16
MSB B2
LEFT
LSB-JUSTIFIED FORMAT 16 BITS
WS
BCK
DATA
RIGHT
15 2 1
B15 LSB
16
MSB B2
15 2 1
B15 LSB
16
MSB B2 B3 B4
LEFT
LSB-JUSTIFIED FORMAT 18 BITS
WS
BCK
DATA
RIGHT
1518 17 2 1
MSB B2 B3 B4
B17 LSB
16 1518 17 2 1
B17 LSB
MSB-JUSTIFIED FORMAT
WS LEFT RIGHT
321321
MSB B2 MSBLSB LSB MSB B2B2
BCK
DATA

TFA9812_2 © NXP B.V. 2009. All rights reserved.
Preliminary data sheet Rev. 02 — 22 January 2009 16 of 66
NXP Semiconductors TFA9812
BTL stereo Class-D audio amplifier with I2S input
In I2C control mode the following sample frequency fscan be used: 8 kHz, 11.025 kHz,
12 kHz, 16 kHz, 22.05 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz, 64 kHz, 88.2 kHz, 96 kHz,
128 kHz, 176.4 kHz or 192 kHz. The I2C control for fsselection can be found in
Section 9.5.7.
In Legacy control mode the following sample frequencies (fs) can be used: 32 kHz,
44.1 kHz or 48 kHz.
8.4.2 Digital audio data format control
The BCK-to-WS and MCLK-to-WS frequency ratios are automatically detected, so no
control settings need to be configured for these.
In I2C control mode all the formats listed in Table 12 are supported. The appropriate I2C
controls for selecting the supported formats can be found in Section 9. In the Legacy
control mode only a subset of the supported formats can be used. These are shown in
Table 12 and the required pin control is given in Table 13.
See Section 8.2.1 for details of how to enable Legacy control mode.
8.5 Digital signal-processing features
8.5.1 Equalizer
8.5.1.1 Equalizer options
The equalizer function can be bypassed and the equalizer can be configured to either a
5-band or 10-band function. These settings are for both audio channels simultaneously.
There are 20 bands in the equalizer. These are distributed as follows:
•Bands A1 to A5 are bands 1 to 5 of output 1 (used in 5-band and 10-band
configuration).
•Bands B1 to B5 are bands 1 to 5 of output 2 (used in 5-band and 10-band
configuration).
•Bands C1 to C5 are bands 6 to 10 of output 1 (used in 10-band configuration only).
•Bands D1 to D5 are bands 6 to 10 of output 2 (used in 10-band configuration only).
In I2C control mode each band can be configured separately using I2C register settings.
In Legacy control mode the equalizer is bypassed.
8.5.1.2 Equalizer band function
The shape of each parametric equalizer band is determined by the three filter parameters:
•(Relative) center frequency .
•Quality factor Q.
•Gain factor G.
Table 13. Digital audio data format selection in Legacy control mode
SCL/SFOR pin value Interface formats (MSB-first)
0I
2S
1 MSB-justified
ω2πfcfs ⁄()=

TFA9812_2 © NXP B.V. 2009. All rights reserved.
Preliminary data sheet Rev. 02 — 22 January 2009 17 of 66
NXP Semiconductors TFA9812
BTL stereo Class-D audio amplifier with I2S input
In the above equation fcis the center frequency and fsis the sample frequency.
The definition of the quality factor is the center frequency divided by the 3 dB bandwidth,
see Equation 1. In parametric equalizers this is only valid when the gain is set very small
(−30 dB).
(1)
Each band filter can be programmed to perform a band-suppression (G < 1) or a
band-amplification (G > 1) function around the center frequency.
Each band of the TFA9812 equalizer has a second-order Regalia-Mitra all-pass filter
structure. The structure is shown in Figure 5.
The transfer function of this all-pass filter is shown in Equation 2:
(2)
A(z) is the second-order filter structure. The transfer function of A(z) is shown in
Equation 3:
(3)
The relationship between the programmable parameters K0, K1, and K2and the filter
parameters G, ω, Q is shown in Equation 4 and Equation 5.
Use Equation 4 to calculate band suppression (G < 1) functions.
(4)
Use Equation 5 to calculate band amplification (G ≥1) functions.
Fig 5. Regalia filter flow-diagram
Qfc
f2f1 –
----------------- ;=
f1:2010 Af1
Afc
--------



log 3dB fcf1 >=
f2:2010 Af2
Afc
--------



log 3dB f2fc >,=
½
X(z)
A(z)
s
Y(z)
+
+
+
−
010aaa406
K0/2
Hz() 12⁄1Az()+()K02⁄1Az()–()⋅+⋅=
Az() K1K21K
1
+()Z1–Z2– +⋅⋅+
1K
21K 1
+()Z1–K1Z2– ⋅+⋅⋅+
---------------------------------------------------------------------------------
=
K0G=
K1ωcos–=
K22Q G ωsin–⋅()2Q G ωsin+⋅()⁄=G1<

TFA9812_2 © NXP B.V. 2009. All rights reserved.
Preliminary data sheet Rev. 02 — 22 January 2009 18 of 66
NXP Semiconductors TFA9812
BTL stereo Class-D audio amplifier with I2S input
(5)
The ranges of the TFA9812 parametric equalizer settings for each band are:
•The Gain, G is from −30 dB to +12 dB.
•The center frequency, fcis from 0.0004 * fsto 0.49 * fs.
•The quality factor Q is from 0.001 to 8.
Using I2C control, filter coefficients need to be entered for each filter stage to configure it
as desired.
Figure 6,Figure 7 and Figure 8 show some of the possible transfer functions of the
equalizer bands. The relations are symmetrical for the suppression and amplification
functions. A skewing effect can be observed for the higher frequencies.
Different configurations are available for the same filter transfer function, thus allowing
optimum numerical noise performance. The binary filter configuration parameters t1and t2
control the actual configuration and should be chosen according to Equation 6.
(6)
A maximum of 12 dB amplification per equalizer stage can be achieved with respect to the
input signal. Each band of the equalizer is provided with a −6 dB amplification, so in order
to prevent numerical clipping for some filter settings with over 6 dB of amplification, band
filters can be scaled by 0 dB or −6 dB. For optimum numerical noise performance steps of
−6 dB amplification should be applied to the highest possible sections that are still within
scale signal processing safeguards. Band filters can be scaled with the binary parameters
listed in Table 14.
8.5.1.3 Equalizer band control
For compact representation with positive signed parameters, parameters k1’ and k2’ are
introduced in Equation 7.
The parameters k0, k1', k2', t1, t2and s must be combined in two 16-bit control words,
word1 and word2, and must fit within the representation given in Table 15. Parameters k1'
and k2' are unsigned floating-point representations in Equation 8.
Table 14. Equalizer scale factor coding
s scale factor (dB)
00
1−6
K0G=
K1ωcos–=
K22Q ωsin–()2Q ωsin+()⁄=G1≥
t10ω<=π2⁄
1ω>π2⁄


=
t2
0k
2>=0
1k
2<0



=

TFA9812_2 © NXP B.V. 2009. All rights reserved.
Preliminary data sheet Rev. 02 — 22 January 2009 19 of 66
NXP Semiconductors TFA9812
BTL stereo Class-D audio amplifier with I2S input
(7)
(8)
In Equation 8, M is the unsigned mantissa and E the negative signed exponent. For
example, in word2 bits [14:8] = [0111 010] represent k2' = (7/24)×2−2= 1.09375 10
−1.
Section 9.5.4 shows the I2C address locations of the controls for various bands of the
equalizer.
Table 15. Equalizer control word construction
Word Section Data
word1 15 t1
word1 [14:4] 11 mantissa bits of k1’
word1 [3:0] Four exponent bits of k1’
word2 15 t2
word2 [14:11] Four mantissa bits of k2’
word2 [10:8] Three exponents bits of k2’
word2 [7:1] k0
word2 0 s
Fig 6. Transfer functions for several quality factors Q
k1′1k
1
–t11=
1k
1
+t10=



=
k2′1k
2
–t20=
1k
2
+t21=



=
kxM2
E–
⋅M1< =
010aaa222
4
8
12
Gain
(dB)
0
Frequency (Hz)
101105
104 102103
Q1 = 0.27
Q2 = 0.61
Q3 = 1.65

TFA9812_2 © NXP B.V. 2009. All rights reserved.
Preliminary data sheet Rev. 02 — 22 January 2009 20 of 66
NXP Semiconductors TFA9812
BTL stereo Class-D audio amplifier with I2S input
8.5.2 Digital volume control
In I2C control mode both audio channels have separate digital volume control. In Legacy
control mode the volume control of both channels is common and the volume control
setting depends on the supply voltage on the pin AVOL (32).
8-bit volume control is available per channel. This is dB-linear down to −124 dB in steps of
0.5 dB. The last step of the volume control is mute.
Table 16 shows the various settings and their related channel suppression:
Fig 7. Transfer functions for several center frequencies fc
Fig 8. Transfer functions for several gain factors G
010aaa223
Frequency (Hz)
101105
104 102103
4
8
12
Gain
(dB)
0
010aaa224
Frequency (Hz)
101105
104 102103
0
-6
6
12
Gain
(dB)
-12
