DEVKIT-MPC5748G
QUICK START GUIDE (QSG)

EXTERNAL USE
1
Contents
•Quick Start Package Overview
•Step-by-Step Installation Instructions
•Hardware: DEVKIT-MPC5748G Board
−Features
−Overview
−Pinout, Jumper and Peripherals Settings
•Software:
−Software Development Tools
−Pre-compiled Code Examples
•Documentation
•MPC574xG/C/B/D Family : Phantom Feature Differences
•OpenSDA
•Recommendations

EXTERNAL USE
2
Quick Start Package Overview
Name Description
Quick Start Guide(QSG) Detailed description on availability of Hardware, Software and Documents to quick start with
MPC5748G project (this document)
Software Integration Guide(SWIG) Detailed walk through on how to install and use S32 Design Studio IDE for Power Architecture
Application Notes Detailed documents covering topics from ‘how to design hardware’ to ‘how to write software’
Fact Sheets, Reference Manuals and Data Sheets Detailed manuals for MPC5748G family of MCU and DEVKIT-MPC5748G board
Name Description
Integrated Development Environment (IDE) Eclipse based S32DS IDE with free GCC compiler and Debugger support
DEVKIT-MPC5748G Quick Start Package All in one package: Software examples and supporting documents for getting started
DEVKIT-MPC5748G Schematics PDF schematic files for the DEVKIT-MPC5748G board
DEVKIT-MPC5748G PCB Design Package Gerber files and Bill of Material
Downloads:
Documents:
Board:
DEVKIT-MPC5748G Low cost EVB with MPC5748G(176 LQFP-EP) Auto quality MCU on board

EXTERNAL USE
3
DEVKIT-MPC5748G Board : Features
•MPC5748G has 2 x 160 MHz Power Architecture® e200Z4 Dual issue
cores and 1 x 80 MHz Power Architecture® e200Z2 Single issue core
•MPC5748G qualified to AEC-Q100 Grade 1, ambient temperature of -40 to
+125 °C and suitable for ASIL-B/SIL2 applications
•Arduino™ UNO R3 footprint-compatible with expansion “shield” support
•Integrated Open-standard Serial and Debug Adapter (OpenSDA) with
support for several industry-standard debug interfaces as well as JTAG
connector
•Easy access to the MCU I/O header pins for prototyping
•On-chip connectivity for Ethernet, FlexRay, USB, SDHC, CAN, LIN,
UART/SCI and SPI
•MicroSD card slot for access to SDHC interface.
•Potentiometer for precise voltage and analog measurement
•8 user LED
•2 user push-button switches
•Flexible power supply options
•micro-B USB
•12V External power supply
•Similar hardware across ARM®, S12 and Power Architecture®architecture
based MCUs
•DEVKIT-COMM shield boards for extended 4 CAN and 6 LIN ports
•Box includes:
−DEVKIT-MPC5748G Board
−USB Cable
•Downloads includes:
−Quick Start Package
−S32 Design Studio IDE
−Application notes

EXTERNAL USE
4
DEVKIT-MPC5748G Board : Revision D Update
Improvements
•Latest MPC5748G silicon used (mask set 0N78S).
•Added MicroSD connector for SDHC access.
•MicroUSB connector replaced with full-size connector for easier use with USB devices.
•Alternative placement of JTAG header and power supply jumper for easier access when using shields.
•User LEDs: DS4 changed to red, and DS5 changed to orange.
•Added pre-soldered pull resistor on CAN0 interface which can be can be added or removed with J16.
•Shorter array of female pin headers, allowing for smaller form factor.
Fixes
•Fixed issue with USB
The release of DEVKIT-MPC5748G Revision D brought several changes and improvements to the development board:

EXTERNAL USE
5
Step-by-Step Installation Instructions
1
Install Software and Tools
Install S32 Design Studio IDE for Power Architecture.
S32 Design Studio for Power
See Software Installation Guide (SWIG) for detailed procedure
2
Connect the USB Cable
Connect one end of the USB cable to the PC and the other end to
the micro-B connector on the DEVKIT-MPC5748G board. Allow the
PC to automatically configure the USB drivers.
3
Observe the Default Program reaction
The pre-loaded example project utilizes the DEVKIT-MPC5748G
user push button (SW2) and the user LEDs. Once the board is
plugged in, LEDs will blink in default pattern. Press push button to
switch between the two different patterns. Use Potentiometer to
change blinking speed. (Clock is configured to PLL running at 160
MHz)
4
Learn More About the DEVKIT-MPC5748G
Read release notes and documentation on the
nxp.com/DEVKIT-MPC5748G
nxp.com/MPC5748G
In this quick start guide, you will learn how to set up the
DEVKIT-MPC5748G board and run the default program.
J11
3 1 Jumper Setting:
2-3: USB powered
5V Supply, through
OpenSDA interface

EXTERNAL USE
6
DEVKIT-MPC5748G Board Rev B : Overview
The DEVKIT-MPC5748G
is an ultra-low-cost
development platform for
MPC5748G
Microcontrollers.
Features include easy
access to all MCU I/Os, a
standard-based form
factor compatible with the
Arduino™ pin layout,
providing a broad range of
expansion board options,
and a USB serial port
interface for connection to
the IDE. The board has
option to be powered via
USB or an external power
supply.
NXP Microcontroller
MPC5748G (176 LQFP-EP)
JTAG
MPC5748G
JTAG
OpenSDA MCU
User LEDs
LIN Bus
CAN Bus
Ethernet
FlexRay
USB
Potentiometer
User Switch 2
User Switch 4
12V External
Power Supply
OpenSDA
micro-USB
J13 J14 J12
J3 J2 J4
OpenSDA
MCU
Reset Button
OpenSDA MCU
Boot Entry Button

EXTERNAL USE
7
DEVKIT-MPC5748G Board Rev D : Overview
The DEVKIT-MPC5748G
is an ultra-low-cost
development platform for
MPC5748G
Microcontrollers.
Features include easy
access to all MCU I/Os, a
standard-based form
factor compatible with the
Arduino™ pin layout,
providing a broad range of
expansion board options,
and a USB serial port
interface for connection to
the IDE. The board has
option to be powered via
USB or an external power
supply.
NXP Microcontroller
MPC5748G (176 LQFP-EP)
JTAG
MPC5748G
JTAG
OpenSDA MCU
User LEDs
LIN Bus
CAN Bus
Ethernet
FlexRay
USB
Potentiometer
User Switch 2
User Switch 4
12V External
Power Supply
OpenSDA
micro-USB
J13 J14 J12
J3 J2 J4
OpenSDA
MCU
Reset Button
OpenSDA MCU
Boot Entry Button
MicroSD card
slot

EXTERNAL USE
8
DEVKIT-MPC5748G Board : Pinout 1 of 3
Arduino Compatibility
The internal rows of the I/O headers on
the DEVKIT-MPC5748G are arranged to
fulfill Arduino™ shields compatibility .
J3
J2 FUNCTION PORT PIN PIN PORT FUNCTION
PB15 J2-15 J2-16 PE13
Timer
PB14 J2-13 J2-14 PF15
Timer
PB13 J2-11 J2-12 PE11
PB12 J2-09 J2-10 PE10
Timer
PB11 J2-07 J2-08 PE9
PB10 J2-05 J2-06 PE8
LIN4TX(UART)
PA5 J2-03 J2-04 PE7
LIN4RX
(UART) PA6 J2-01 J2-02 PE6
FUNCTION PORT PIN PIN PORT FUNCTION
SCL1
PI1 J3-19 J3-20 PG9
SDA1
PI0 J3-17 J3-18 PG8
NC J3-15 J3-16 PG7
GND J3-13 J3-14 PG6
SCLK_4
PF2 J3-11 J3-12 PI7
SIN_4
PF1 J3-09 J3-10 PI6
SOUT_4
PF0 J3-07 J3-08 PA15
SS_4
PF3 J3-05 J3-06 PA14
Timer
PA2 J3-03 J3-04 PA13
PA1 J3-01 J3-02 PA12
J3
J2

EXTERNAL USE
9
DEVKIT-MPC5748G Board : Pinout 1 of 3
Arduino Compatibility
The internal rows of the I/O headers on
the DEVKIT-MPC5748G are arranged to
fulfill Arduino™ shields compatibility .
J13
J14
FUNCTION PORT PIN PIN PORT FUNCTION
PF11 J13-02
J13
-
01
VIN
12V
PF10 J13-04
J13
-
03
PER_HVA
PF6 J13-06
J13
-
05
RESET
MPC5748G Reset
PF4 J13-08
J13
-
07
3V3_SR
3.3V
PF5 J13-10 J13-9 5V0_SR
5V
PF7 J13-12
J13
-
11
GND
PF8 J13-14
J13
-
13
GND
PF9 J13-16
J13
-
15
VIN
12V
FUNCTION PORT PIN PIN PORT FUNCTION
PB4 J14-02
J14
-
01
PG13
ADC1_S[1]
PB5 J14-04
J14
-
03
PG12
ADC1_S[2]
PB6 J14-06
J14
-
05
PI8
ADC0_S[16]
PB7 J14-08
J14
-
07
PI11
ADC0_S[19]
PD0 J14-10 J14-9 PI12
ADC0_S[20]
PD1 J14-12
J14
-
11
PI13
ADC0_S[21]
PD2 J14-14
J14
-
13
PI14
ADC0_S[22]
PD3 J14-16
J14
-
15
PI15
ADC0_S[23]
J13
J14

EXTERNAL USE
10
DEVKIT-MPC5748G Board : Pinout 3 of 3
Arduino Compatibility
The internal rows of the I/O headers on
the DEVKIT-MPC5748G are arranged to
fulfill Arduino™ shields compatibility .
J12 J4
FUNCTION PORT PIN PIN PORT FUNCTION
PF12 J4-19 J4-20 PE5
PF13 J4-17 J4-18 PE4
PC6 J4-15 J4-16 PE0
PC7 J4-13 J4-14 PE1
PI2 J4-11 J4-12 GND
PI3 J4-09 J4-10
PER_HVA
PH3 J4-07 J4-08 PC11
PH4 J4-05 J4-06 PC10
PG3 J4-03 J4-04 PG5
PG2 J4-01 J4-02 PG4
FUNCTION PORT PIN PIN PORT FUNCTION
PD12 J12-2 J12-1 PD15
PD10 J12-4 J12-3 PD14
PD9 J12-6 J12-5 PD13
PD8 J12-8 J12-7 PH8
PER_HVA
J12-10 J12-9 PH7
GND J12-12
J12
-
11
PH6
PD7 J12-14
J12
-
13
PJ3
PD6 J12-16
J12
-
15
PJ2
PD5 J12-18
J12
-
17
PJ1
PD4 J12-20
J12
-
19
PJ0
J4
J12

EXTERNAL USE
11
DEVKIT-MPC5748G Board : Jumper Settings
J11
There is only one jumper: J11
It is to select Power source:
1-2: Default External 12 V Supply
2-3: USB powered 5V Supply, through
OpenSDA interface
3 1
Note: For high power/current consuming applications (like
using external shield boards) use “External 12 V Supply” only
Rev D
Rev B

EXTERNAL USE
12
DEVKIT-MPC5748G Board : Communication Interfaces 1 of 2
LIN
CAN
FlexRay
LIN_0
DESCRIPTION
NAME
PIN
GND
P3
-
01
GND
P3
-
02
Connect to
12V
VBAT
P3
-
03
Port PB2
& PB3
LIN
P3
-
04
CAN_0
DESCRIPTION NAME PIN
Port PB0 & PB1
CANH
P5
-
01
CANL
P5
-
02
NC
P5
-
03
GND
P5
-
04
FlexRay_A
DESCRIPTION
NAME PIN
FRA
-DATA-A P2_1
FRA
-DATA-B P2_2
FlexRay_A
DESCRIPTION
PORT
FR_A_TX
PC5
FR_A_TX_EN
PE2
FR_A_RX
PE3
Note: LIN Physical Interface require 12V supply on pin P3-03
CAN termination resistor jumper:
Open = No resistor
Closed = 120Ohm
(Rev D only)

EXTERNAL USE
13
DEVKIT-MPC5748G Board : Communication Interfaces 2 of 2
Ethernet USB
ETHERNET_0
DESCRIPTION PORT
RMII_0_TXD[0]
PH1
RMII_0_TXD[1]
PH0
RMII_0_TX_EN
PH2
RMII_0_RXD[0]
PA9
RMII_0_RXD[1]
PA8
RMII_0_RX_ER
PA11
RMII_0_RX_DV
PF15
RMII_0_MDC
PG0
RMII_0_MDIO
PF14
RMII_0_TX_CLK (Reference clock)
PG1
USB_1
DESCRIPTION PORT
ULPI1_D7
PH12
ULPI1_D6
PH11
ULPI1_D5
PG11
ULPI1_D4
PG10
ULPI1_D3
PE15
ULPI1_D2
PE14
ULPI1_D1
PG15
ULPI1_D0
PG14
ULPI1_STP
PI4
ULPI1_NXT
PI5
ULPI1_DIR
PC3
ULPI1_CLK
PC2
UART
UART_2 –LinFlex_2
OpenSDA micro-USB
DESCRIPTION
PORT
TX PC8
RX PC9
SDHC SDHC
DESCRIPTION PORT
SDHC_DATA0
PI3
SDHC_DATA1
PI2
SDHC_DATA2
PI1
SDHC_DATA3
PI0
SDHC_CMD
PE6
SDHC_CLK
PE7
SDHC_CD
PA1
SDHC_WP
N/A for MicroSD

EXTERNAL USE
14
DEVKIT-MPC5748G Board : User Peripherals
User
Switch 2 DESCRIPTION PIN PORT
Potentiometer (ADC0 CH9)
RV1/POT
PB4
User Switch 2
SW2
PE12
User Switch
4
SW4
PA3
User LEDs
DS4
PA10
DS5
PA7
DS6
PH13
DS7
PC4
DS8
PH5
DS9
PJ4
DS10
PA0
DS11
PA4
Reset Button
SW1
User
Switch 4
Potentiometer
User
LEDs
Reset
Button

EXTERNAL USE
15
DEVKIT-MPC5748G Board : Programing Interface
OpenSDA Interface
DESCRIPTION PIN
OpenSDA MCU Boot Entry
SW3
OpenSDA micro USB:
On
-
board JTAG connection via
open source
OSBDM circuit using the
MC9S08JM60
Microcontroller
J1
OpenSDA JTAG
:
JTAG to update firmware in
OpenSDA MCU
J6
OpenSDA JTAG
JTAG
OpenSDA micro USB
OpenSDA MCU
Boot Entry Button
JTAG
DESCRIPTION PIN
Support for USB Multilink
Interface
P4

EXTERNAL USE
16
Software Development Tools
•IDE & Compilers
−Free S32 Design Studio IDE for Power Architecture with GCC compiler
−GHS MULTI Integrated Development Environment
−Cosmic IDE
−iSystems winIDEA IDE
−SourceryTM CodeBench Development Tools
•Debuggers
−Free OpenSDA debugger on board and supported by S32DS IDE
−P&E USB Multilink
−iSystems iC6000
−Lauterbach TRACE32 JTAG Debugger

EXTERNAL USE
17
Pre-Compiled Code Examples
•Pre-compiled example projects are
available in S32DS as well as on
nxp.com/DEVKIT-MPC5748G for quick
start
•Example projects also includes the
projects from Application Note, AN4830:
Qorivva Recipes for MPC574xG
List of code examples:
1. Hello
2. Hello+pll
3. Hello+pll+interrupts
4. eDMA+ PBridge
5. Semaphores
6. Register Protection
7. Low Power: STOP mode
8. Analog-to-digital
Converter
9. Timed I/O (eMIOS)
10. CAN
11. CAN+DMA
12. LIN
13. UART
14. SPI
15. SPI+DMA
16. I2C
17. Ethernet
18. Body Cross Trigger
Unit (BCTU)
19. System Memory
Protection Unit
(SMPU)
20. Flash

EXTERNAL USE
18
Documentation
General Documents
•MPC5748G Microcontroller Data Sheet
•MPC5748G Microcontroller Reference Manual
•MPC5748G Microcontroller Fact Sheet
•DEVKIT-MPC5748G Board Fact Sheet
•Software Integration Guide (SWIG)
Application Notes
•AN4830: Qorivva Recipes for MPC574xG
•AN5220: MPC5748G Hardware Design Guidelines
•AN5114: Migrating between MPC5748G and MPC5746C
•AN4868: EEPROM Emulation with NXP MPC55xx, MPC56xx, and MPC57xx Microcontrollers
•AN4805: A Practical Approach to Hardware Semaphores

EXTERNAL USE
19
MPC574xG/C/B/D Family : Phantom Feature Differences
Flash/RAM Package
100MAPBGA
(11x11mm, 1mm) 176LQFP-EP
(24x24mm, 0.5mm)
256MAPBGA
(17x17mm, 1mm)
324MAPBGA
(19x19mm, 1mm)
6M/768k
6M/768k SPC5748G
SPC5748C SPC5748G SPC5748C SPC5748G SPC5748C
4M/768k
4M/512k SPC5747G
SPC5747C SPC5747G SPC5747C SPC5747G SPC5747C
3M/768k SPC5746G SPC5746G SPC5746G
3M/384k (512k optional)
3M/384k (512k optional) SPC5746C
SPC5746B SPC5746C SPC5746B SPC5746C SPC5746B PPC5746C
2M/256k
2M/256k SPC5745C
SPC5745B SPC5745C SPC5745B SPC5745C SPC5745B
1.5M/192k
1.5M/192k SPC5744C
SPC5744B SPC5744C SPC5744B SPC5744C SPC5744B
Color Coding:
Triple Core, Ethernet, FlexRay, USB, SDHC,
(optional HSM, 2nd Ethernet + switch)
Dual Core, Ethernet, FlexRay
(all: optional HSM, 5747C/5748C: 2nd
Ethernet + switch)
Single Core, FlexRay, Ethernet (optional
HSM)
Debug device for SPC5745B/C and
SPC5746B/C
- not for production
