FRDM-HB2001-EVM evaluation board
Figure 1. FRDM-HB2001-EVM

FRDM-HB2001-EVM evaluation board, Rev. 1.0
2NXP Semiconductors
Contents
1 Important notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3 Getting to know the hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4 FRDM-KL25Z Freedom SPI dongle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5 Installing the software and setting up the hardware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
6 Schematic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
7 Board layout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
8 Board Bill of Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
9 Accessory item Bill of Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
10 References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
11 Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Important notice
FRDM-HB2001-EVM evaluation board, Rev. 1.0
NXP Semiconductors 3
1 Important notice
NXP provides the enclosed product(s) under the following conditions:
This evaluation kit is intended for use of ENGINEERING DEVELOPMENT OR EVALUATION PURPOSES ONLY.
It is provided as a sample IC pre-soldered to a printed circuit board to make it easier to access inputs, outputs, and
supply terminals. This evaluation board may be used with any development system or other source of I/O signals
by simply connecting it to the host MCU or computer board via off-the-shelf cables. This evaluation board is not a
Reference Design and is not intended to represent a final design recommendation for any particular application.
Final device in an application will be heavily dependent on proper printed circuit board layout and heat sinking
design as well as attention to supply filtering, transient suppression, and I/O signal quality.
The goods provided may not be complete in terms of required design, marketing and or manufacturing related
protective considerations, including product safety measures typically found in the end product incorporating the
goods. Due to the open construction of the product, it is the user's responsibility to take any and all appropriate
precautions with regard to electrostatic discharge. In order to minimize risks associated with the customers
applications, adequate design and operating safeguards must be provided by the customer to minimize inherent or
procedural hazards. For any safety concerns, contact NXP sales and technical support services.
Should this evaluation kit not meet the specifications indicated in the kit, it may be returned within 30 days from the
date of delivery and will be replaced by a new kit.
NXP reserves the right to make changes without further notice to any products herein. NXP makes no warranty,
representation or guarantee regarding the suitability of its products for any particular purpose, nor does NXP
assume any liability arising out of the application or use of any product or circuit, and specifically disclaims any and
all liability, including without limitation consequential or incidental damages. “Typical” parameters can and do vary
in different applications and actual performance may vary over time. All operating parameters, including “Typical”,
must be validated for each customer application by customer’s technical experts.
NXP does not convey any license under its patent rights nor the rights of others. NXP products are not designed,
intended, or authorized for use as components in systems intended for surgical implant into the body, or other
applications intended to support or sustain life, or for any other application in which the failure of the NXP product
could create a situation where personal injury or death may occur.
Should the Buyer purchase or use NXP products for any such unintended or unauthorized application, the Buyer
shall indemnify and hold NXP and its officers, employees, subsidiaries, affiliates, and distributors harmless against
all claims, costs, damages and expenses, and reasonable attorney fees arising out of, directly or indirectly, any
claim of personal injury or death associated with such unintended or unauthorized use, even if such claim alleges
NXP was negligent regarding the design or manufacture of the part. NXP™ and the NXP logo are trademarks of
NXP Semiconductor, Inc. All other product or service names are the property of their respective owners.
© 2016 NXP B.V.

Getting started
FRDM-HB2001-EVM evaluation board, Rev. 1.0
4NXP Semiconductors
2 Getting started
2.1 Kit contents/packing list
The FRDM-HB2001-EVM contents includes:
• Assembled and tested evaluation board/module in anti-static bag
• FRDM-KL25Z
• Warranty card
2.2 Jump start
NXP’s analog product development boards help to easily evaluate NXP products. These tools support analog mixed signal and power
solutions including monolithic ICs using proven high-volume SMARTMOS mixed signal technology, and system-in-package devices
utilizing power, SMARTMOS and MCU dies. NXP products enable longer battery life, smaller form factor, component count reduction, ease
of design, lower system cost and improved performance in powering state of the art systems.
•Gotowww.nxp.com/FRDM-HB2001-EVM
•Review the Tool Summary Page
• Look for
• Download documents, software and other information
Once the files are downloaded, review the user guide in the bundle. The user guide includes setup instructions, BOM and schematics.
Jump start bundles are available on each tool summary page with the most relevant and current information. The information includes
everything needed for design.
2.3 Required equipment and software
To use this kit, you need:
• 3/16” blade screwdriver for connecting the cables
• DC Power supply: 5.0 V to 40 V with up to 20 A current handling capability, depending on motor requirements
• USB Standard A (male) to mini-B (male) cable
• Typical loads (brushed DC motor, power resistors or inductive load with up to 5.0 A and 28 V operation)
• Function generator (optional)
• FRDM-KL25Z Freedom Development Platform for SPI communication (included in KIT)
• SPIGen software from www.nxp.com (For using FRDM-KL25Z based SPI Dongle)
2.4 System requirements
The kit requires the following to function properly with the software:
• USB enabled computer with Windows XP or newer
Jump Start Your Design

Getting to know the hardware
FRDM-HB2001-EVM evaluation board, Rev. 1.0
NXP Semiconductors 5
3 Getting to know the hardware
3.1 Board overview
The FRDM-HB2001-EVM evaluation kit exercises all the functions of the MC33HB2001 H-Bridge device. The parallel input can be easily
controlled by lab equipment or any MCU with GPIOs. The board can be used in conjunction with a FRDM-KL25Z board connected to a
PC’s USB port. Configure, control, and monitor the status of MC33HB2001 by using the board’s SPI communication capabilities.
3.2 Board features
The FRDM-HB2001-EVM board evaluates the NXP part MC33HB2001, including all functions. The board features the following:
• Built-in reverse battery protection
• Test points allows probing its signals
• Built-in voltage regulator to supply logic level circuitry
• LEDs to indicate the supply status and the direction of the motor
• Low Equivalent Series Resistance (ESR) capacitor to reduce ripple in the power supply
• Transient voltage suppressor to handle system level transients
3.3 Block diagram
The hardware block diagram is shown in Figure 2.
Figure 2. Block diagram
MC33HB2001
Power Supply
Reverse
Battery and
Transient
Protection
5V Voltage
Regulator
VPWR
LED
VDD LED
Charge Pump Capacitor
VPWR
CCP
IN1
IN2
ENBL
MOSI
CFB
OUT2
OUT1
FS_B
A
ll Grounds
FS_B LED
FWD LED
REV LED
Load
From
MCU
GPIO
To MCU
A
DC inpu
t
To MCU
GPIO
Optional 5.0 V Supply to FRDM
Optional 3.3 V Supply from FRDM
DIS
MISO
SCLK
CSB
MCU
SPI
Shunt
Resistor
VDDQ

Getting to know the hardware
FRDM-HB2001-EVM evaluation board, Rev. 1.0
6NXP Semiconductors
3.3.1 Device features
This evaluation board features the following NXP product:
3.3.2 Modes of operation
Figure 3. Modes of operation
Table 1. Features
Device Description Features
MC33HB2001
The 33HB2001 is a monolithic
H-Bridge Power IC, enhanced with
SPI configurability and diagnostic
capabilities.
• Advanced diagnostic reporting via a serial peripheral interface (SPI): charge pump under-
voltage on VPWR, short to ground and short to VPWR for each output, open load, temper-
ature warning and overtemperature shutdown
• Thermal management: Excellent thermal resistance of <1.0 °C/W between junction and
case (exposed pad)
• Eight selectable slew rates via the SPI: 0.25 V/s to more than 16 V/s for EMI and thermal
performance optimization
• Four selectable current limits via the SPI: 5.4/7.0/8.8/10.7 A, covering a wide range of ap-
plications
• Can be operated without the SPI with a default slew rate of 2.0 V/s and a 7.0 A current
limit threshold
• Highly accurate real-time current feedback through a current mirror output signal with less
than 5.0% error
• Drives inductive loads in a full H-Bridge or Half-bridge configuration
• Overvoltage protection places the load in high-side recirculation (braking) mode with noti-
fication in H-Bridge mode
• Wide operating range: 5.0 V to 28 V operation
• Low RDS(on) integrated MOSFETs: Maximum of 125 m(TJ = 150 °C) for each MOSFET
• Internal protection for overtemperature, undervoltage and short-circuit by signaling the er-
ror condition and disabling the outputs
• I/0 Pins can withstand up to 36 V

Getting to know the hardware
FRDM-HB2001-EVM evaluation board, Rev. 1.0
NXP Semiconductors 7
3.3.3 Architecture
Figure 4. Architecture
3.3.4 Thermal management
Figure 5. Architecture

Getting to know the hardware
FRDM-HB2001-EVM evaluation board, Rev. 1.0
8NXP Semiconductors
3.4 Board description
Figure 6 describes the main elements on the FRDM-HB2001-EVM.
Figure 6. Board description
Table 2. Board Description
Name Description
MC33HB2001 Monolithic H-Bridge Power IC in a robust thermally enhanced 32 lead SOIC-EP package
5.0 V Regulator 5.0 V regulator for VDD and supply
Jumpers Jumpers for configuring the board for different modes of operation
Reverse Battery Protection MOSFET for protecting MC33HB2001 in reverse battery condition
Power and Ground inputs Power supply terminal to connect the battery/power supply with the board
Test Points Test points to probe different signals
Output terminal Output connector to connect a load to the MC33HB2001 output
MC33HB2001
5.0 V Regulator
Output
Terminal
Test
Points Reverse
Battery
Protection
Power and
Ground
Inputs
Jumpers

Getting to know the hardware
FRDM-HB2001-EVM evaluation board, Rev. 1.0
NXP Semiconductors 9
3.5 LED display
The following LEDs serve as visual output devices for the evaluation board:
Figure 7. LED Locations
Table 3. LED Display
LED ID Description
VBAT GREEN LED, indicates when main/battery supply is connected
VDD GREEN LED, indicates when +5.0 V supply is connected
FS_B RED LED, illuminates when the H-Bridge detects a fault
FWD GREEN LED, indicates current flowing in forward direction
REV RED LED, indicates current flowing in reverse direction
FWD
VDD
REV
FS_B
VBAT

Getting to know the hardware
FRDM-HB2001-EVM evaluation board, Rev. 1.0
10 NXP Semiconductors
3.6 Jumper definitions
The Figure 8 illustrates the evaluation board jumper locations. Table 4 explains the function of each position. Blue fonts in the Jumper
Position column indicate the default settings for use with the FRDM-KL25Z.
Figure 8. Jumper locations
Table 4. Jumper definitions
Name Signal Jumper Position Connection
J1 IN1 1–2 IN1 control through MCU parallel output on J10 Pin 1 (DATA0)
2–3 IN1 control through external input on J15 Pin 1
J2 DIS 1–2 DIS control through MCU parallel output on J10 Pin 13 (CTRL1)
2–3 DIS connected to GND to keep the outputs enabled
J3 IN2 1–2 IN2 control through MCU parallel output on J10 Pin 3 (DATA1)
2–3 IN2 control through external input on J15 Pin 2
J4 CS_B 1–2 CS_B control through MCU SPI output J10 Pin 6 (SPI_CS_B)
2–3 CS_B pulled up to VDD for operation without SPI
J5 ENBL 1–2 ENBL control through MCU parallel output J10 Pin 11 (CTRL0)
2–3 ENBL pulled up to VDD to keep the outputs enabled
J6 SCLK 1–2 SPI clock SCLK from MCU J10 Pin 12 (SPI_SCLK
2–3 SCLK connected to GND for operation without SPI
J7 MOSI 1–2 MOSI control through MCU SPI output J10 Pin 8 (SPI_MOSI)
2–3 MOSI connected to GND for operation without SPI
J8 MISO 1–2 MISO control through MCU SPI output J10 Pin 10 (SPI_MISO)
2–3 MISO not connected for operation without SPI
J11 CFB 1-2 CFB connected to 200 resistor
J14 VDDQ 1–2 VDD connected to VDDQ
2–3 VDDQ not connected
DIS
VDD
CFB
ENBL
IN2 IN1 EX_IN
CFB_R
VDD_REG
MOSI
SCLK
MISO
CS_B
VDDQFS_B

Getting to know the hardware
FRDM-HB2001-EVM evaluation board, Rev. 1.0
NXP Semiconductors 11
The FRDM-HB2001-EVM, in conjunction with a FRDM-KL25Z board (shipped with the kit), can evaluate the design by means of a GUI,
any MCU with GPIO or with simple lab equipment. A FRDM-KL25Z-compatible GUI and MCU program are available online at the following
link: www.nxp.com/FRDM-HB2001-EVM.
The FRDM-HB2001-EVM is compatible with any Arduino™ platform board. However, if a board other than the FRDM-KL25Z is used, MCU
code must be written to work with the board.
3.7 Input signal definitions
The following input signals control the outputs or functions inside the circuit.
3.8 Output signal definitions
The FRDM-HB2001-EVM uses the following output signals to drive a load such as a brushed DC motor. The board provides an analog
output for real time load current monitoring. This signal allows closed loop control of the load.
3.9 Test point definitions
The following test points provide access to various signals to and from the board.
J17 VDD 1–2 VDD supply from regulator U2
2–3 VDD supply from FRDM board
J18 CFB_R 1–2 CFB connected to MCU ADC input J10 Pin 17 (CFB_READ)
J19 FS_B 1–2 FS_B connected to the pull-up resistor
J26 VDD_REG 1–2 VDD to FRDM board
J15 EX_IN Open IN1 and IN2 External Inputs
Table 5. Input signal definitions
Input Name Description
DIS Disable signal to tri-state the outputs
ENBL Disable signal to tri-state the output and put the part in Sleep mode
IN1 Logic input to control OUT1
IN2 Logic input to control OUT2
MOSI Master out slave input for the SPI
CS_B Chip select bar input for the SPI
SCLK Clock for the SPI
Table 6. Output signal definitions
Output Name Description
OUT1 Output 1 of H-Bridge
OUT2 Output 2 of H-Bridge
FS_B Open drain Active Low status flag output to indicate fault
CFB Current mirror output for real time load current monitoring
MISO Master input slave output for SPI
Table 4. Jumper definitions (continued)
Name Signal Jumper Position Connection

Getting to know the hardware
FRDM-HB2001-EVM evaluation board, Rev. 1.0
12 NXP Semiconductors
Figure 9. Test point locations
Table 7. Test point definitions
Test Point Name Signal Name Description
CFB_V CFB_READ CFB pin voltage going to ADC
CCP CCP Charge pump voltage
ENBL1 ENBL Enable/Disable signal to activate/tri-state the outputs and put the device to Sleep mode
DIS1 DIS Enable/Disable signal to activate/tri-state the outputs
IN_1 IN1 Direction control in H-Bridge mode and OUT1 control in Half-Bridge mode
IN_2 IN2 PWM control in H-Bridge mode and OUT2 control in Half-Bridge mode
VPWR VPWR System voltage
VDDQ1 VDDQ VDDQ Digital output supply voltage
FSB1 FSB Fault status monitoring pin
VDD1 VDD VDD supply for the part
CS_B1 CS_B Chip select bar
SCLK1 SCLK Clock for SPI
MOSI1 MOSI Master output slave input signal
MISO1 MISO Master input slave output signal
GND GND Ground signal
GND1 GND Ground signal
GND2 GND Ground signal
GND3 GND Ground signal
GND1
ENBL1
CCP
MISO1
CFB_V
VDD1
GND
IN_2 DIS1 IN_1
FS_B1
MOSI1
VPWR
SCLK1
GND2
CS_B1
GND3
VDDQ1

Getting to know the hardware
FRDM-HB2001-EVM evaluation board, Rev. 1.0
NXP Semiconductors 13
3.10 Screw terminal connections
The board has the following screw terminal connections to connect the power supply and the load.
Figure 10. Screw terminal locations
Table 8. Screw Terminal Connections
Screw Terminal Name Description
J20 Power supply connector for the MC33HB2001
J21 Output connector to connect load
J21 J20

FRDM-KL25Z Freedom SPI dongle
FRDM-HB2001-EVM evaluation board, Rev. 1.0
14 NXP Semiconductors
4 FRDM-KL25Z Freedom SPI dongle
The NXP Freedom development platform is a set of software and hardware tools supporting evaluation and development. It is ideal for
rapid prototyping of microcontroller-based applications. The NXP Freedom KL25Z hardware, FRDM-KL25Z, is a simple, yet sophisticated
design featuring a Kinetis L Series microcontroller, the industry's first microcontroller built on the ARM® Cortex™-M0+ core.
Figure 11. FRDM-KL25Z
4.1 Connecting the FRDM-KL25Z to the board
The FRDM-KL25Z evaluation board was chosen specifically to work with the FRDM-HB2001-EVM kit because of its low cost and features.
The FRDM-KL25Z board makes use of the USB, built in LEDs and I/O ports available with NXP’s Kinetis KL2x family of microcontrollers.
The FRDM-KL25Z connects to a PC through a USB port, which permits the user to control a DC brushed motor and to drive the evaluation
board inputs in order to operate the motor via the GPIOs and SPI pins. The FRDM-KL25Z also monitors the SPI registers, thereby
facilitating the use of safety and advanced diagnostic functions.
The FRDM-HB2001-EVM connects to the FRDM-KL25Z using the four dual row Arduino™ R3 connectors on the bottom of the board (see
Table 9, Figure 12 and Figure 13).
J10 I/O
Header
J9 I/O
Header
J1 I/O
Header
J2 I/O
Header
KL25Z
USB
Reset OpenSDA
USB
RGB
LED

FRDM-KL25Z Freedom SPI dongle
FRDM-HB2001-EVM evaluation board, Rev. 1.0
NXP Semiconductors 15
Figure 12. Connecting the FRDM-HB2001-EVM to the FRDM-KL25Z
Figure 13. FRDM-KL25Z to FRDM-HB2001-EVM connections

FRDM-KL25Z Freedom SPI dongle
FRDM-HB2001-EVM evaluation board, Rev. 1.0
16 NXP Semiconductors
Table 9. FRDM-HB2001-EVM to FRDM-KL25Z Connections
FRDM-HB2001-EVM FRDM-KL25Z Pin Hardware Name
Description
Header Pin Header Pin FRDM-HB2001-EVM FRDM-KL25Z
J24 1 J1 1 N/C PTC7 No Connection
J24 2 J1 2 N/C PTA1 No Connection
J24 3 J1 3 N/C PTC0 No Connection
J24 4 J1 4 N/C PTA2 No Connection
J24 5 J1 5 N/C PTC3 No Connection
J24 6 J1 6 N/C PTD4 No Connection
J24 7 J1 7 N/C PTC4 No Connection
J24 8 J1 8 N/C PTA12 No Connection
J24 9 J1 9 N/C PTC5 No Connection
J24 10 J1 10 N/C PTA4 No Connection
J24 11 J1 11 N/C PTC6 No Connection
J24 12 J1 12 N/C PTA5 No Connection
J24 13 J1 13 N/C PTC10 Not Connected
J24 14 J1 14 N/C PTC8 No Connection
J24 15 J1 15 N/C PTC11 Not Connected
J24 16 J1 16 N/C PTC9 No Connection
J10 1 J2 1 DATA0/IN1 PTC12 IN1 signal for the H-Bridge
J10 2 J2 2 N/C PTA13 No Connection
J10 3 J2 3 DATA1/IN2 PTC13 IN2 signal for the H-Bridge
J10 4 J2 4 N/C PTD5 No Connection
J10 5 J2 5 FS_B PTC16 Fault status pin to report fault
J10 6 J2 6 CS_B PTD0 Chip select bar pin
J10 7 J2 7 N/C PTC17 No Connection
J10 8 J2 8 MOSI PTD2 Master output serial input
J10 9 J2 9 N/C PTA16 No Connection
J10 10 J2 10 MISO PTD3 Master input serial output
J10 11 J2 11 N/C PTA17 No Connection
J10 12 J2 12 SCLK PTD1 Clock for SPI
J10 13 J2 13 N/C PTE31 No Connection
J10 14 J2 14 GND GND No Connection
J10 15 J2 15 N/C N/C No Connection
J10 16 J2 16 N/C VREFH No Connection
J10 17 J2 17 CFB_READ PTD6 ADC input for monitoring the CFB pin
J10 18 J2 18 N/C PTE0 Disable signal to tri-state the output and put
the part in Sleep mode (Active Low)

FRDM-KL25Z Freedom SPI dongle
FRDM-HB2001-EVM evaluation board, Rev. 1.0
NXP Semiconductors 17
J10 19 J2 19 N/C PTD7 No Connection
J10 20 J2 20 FRDM_VDD PTE1 No Connection
J23 1 J10 1 N/C PTE20 No Connection
J23 2 J10 2 N/C PTB0 No Connection
J23 3 J10 3 N/C PTE21 No Connection
J23 4 J10 4 N/C PTB1 No Connection
J23 5 J10 5 N/C PTE22 No Connection
J23 6 J10 6 N/C PTB2 No Connection
J23 7 J10 7 N/C PTE23 No Connection
J23 8 J10 8 N/C PTB3 No Connection
J23 9 J10 9 N/C PTE29 No Connection
J23 10 J10 10 N/C PTC2 No Connection
J23 11 J10 11 N/C PTE30 No Connection
J23 12 J10 12 N/C PTC1 No Connection
J25 1 J9 1 N/C PTB8 No Connection
J25 2 J9 2 N/C SDA_PTD5 No Connection
J25 3 J9 3 N/C PTB9 No Connection
J25 4 J9 4 N/C P3V3 No Connection
J25 5 J9 5 N/C PTB10 No Connection
J25 6 J9 6 N/C RESET/PTA20 No Connection
J25 7 J9 7 N/C PTB11 No Connection
J25 8 J9 8 N/C P3V3 No Connection
J25 9 J9 9 N/C PTE2 No Connection
J25 10 J9 10 N/C P5V_USB No Connection
J25 11 J9 11 N/C PTE3 No Connection
J25 12 J9 12 GND GND Ground
J25 13 J9 13 N/C PTE4 No Connection
J25 14 J9 14 GND GND No Connection
J25 15 J9 15 N/C PTE5 No Connection
J25 16 J9 16 VDD_REG P5-9V_VIN 5.0 V logic input to FRDM-KL25Z board from
FRDM-HB2001-EVM
Table 9. FRDM-HB2001-EVM to FRDM-KL25Z Connections (continued)
FRDM-HB2001-EVM FRDM-KL25Z Pin Hardware Name
Description
Header Pin Header Pin FRDM-HB2001-EVM FRDM-KL25Z

Installing the software and setting up the hardware
FRDM-HB2001-EVM evaluation board, Rev. 1.0
18 NXP Semiconductors
5 Installing the software and setting up the hardware
5.1 Configuring the hardware
The FRDM-HB2001-EVM consists of an H-Bridge, a parallel and SPI interface, power conditioning circuitry and an FRDM-KL25Z board.
The board can be configured for use in conjunction with a FRDM-KL25Z board or a function generator.
Caution:
When using the FRDM-HB2001-EVM, make sure that the maximum motor supply voltage (VPWR)
stays within the 5.0 V to 40 V range. Operating outside this range may cause damage to the board.
5.1.1 Step-by-step instructions for setting up the hardware for use with a
FRDM-KL25Z
To configure the FRDM-HB2001-EVM for use with the FRDM-KL25Z do the following:
1. Connect the FRDM-HB2001-EVM to the FRDM-KL25Z using the Arduino™ connectors on each board.
2. Connect the USB cable (not supplied with the kit) between the PC and the KL25Z USB port on the FRDM-KL25Z board.
3. With the power switched off, attach the DC power supply to the VBAT and GND screw connector terminal (J20) on the
evaluation board.
4. Connect the load to the screw terminal (J21).
Figure 14 illustrates the hardware configuration using a FRDM-KL25Z.
Figure 14. FRDM-HB2001-EVM Configured for Use with an FRDM-KL25Z Board
FRDM-KL25Z Board
FRDM-HB2001-EVM
Brushed DC Motor
5 - 40 V Power Supply, 20 A
Workstation
Standard A to Mini-B
USB Cable
USB

Installing the software and setting up the hardware
FRDM-HB2001-EVM evaluation board, Rev. 1.0
NXP Semiconductors 19
5.1.2 Step-by-step instructions for setting up the hardware for use with a function
generator
This section describes how to configure the FRDM-HB2001-EVM for use with a function generator. The same connections apply if the
board is connected to a microcontroller instead of a function generator. See the board description (Section 3.4, Board description, page
8), the schematic (Section 6, Schematic, page 25) and the MC33HB2001 datasheet, to configure the board for use in a specific
environment.
1. Connect the function generator to the EX_IN jumper, with one channel attached to each pin.
2. Change the board jumper connections, as shown in Figure 15.
3. With the power switched off, attach the DC power supply to the VBAT and GND screw connector terminal (J20) on the
evaluation board.
4. Connect the load to the screw terminal (J21).
Figure 15 illustrates the hardware configuration.
Figure 15. FRDM-HB2001-EVM configured for use with a function generator
Brushed DC Motor
Function Generator (or MCU)
5 - 40 V Power Supply, 20 A
VDD jumper
remains in
1 - 2 (default)
position
Jumpers moved from
1 - 2 (default) to
2 - 3 position
Jumpers moved from
1 - 2 (default) to
2 - 3 position

Installing the software and setting up the hardware
FRDM-HB2001-EVM evaluation board, Rev. 1.0
20 NXP Semiconductors
5.2 Installing and using SPIGen on the computer
The latest version of SPIGen supports the MC33HB2001 and is designed to run on any Windows 8, Windows 7, Vista, or XP-based
operating system. To install the software, do the following:
1. Go to the following website and click on the Download button: www.nxp.com/SPIGen.
2. When the SPIGEN: SPI Generator (SPIGen) Software page appears, go to the Device Drivers section and click on the
Download button associated with the description of the select environment. A wizard guides the user through the process.
3. If instructed for the SPIGen wizard to create a short-cut, a SPIGen icon appears on the desktop. If elected not to create a
short-cut, the SPIGen executable is installed by default at C:Program Files\SPIGen.
Note:
Installing the device drivers overwrites any previous SPIGen installation and replaces it with a current
version containing the MC33HB2001 drivers. However, configuration files (.spi) from the previous
version remain intact.
4. Launch SPIGen. The HB2000/HB2001 device should appear in the Device View panel at the left (see Figure 14).
Figure 16. SPIGen home page
5. To access the HB2000/HB2001 tab in the SPIGen window, expand the HB2000/HB2001 folder in the Device View. Then click on
the Registers icon (see Figure 17).
If the pre-programmed code on FRDM-KL25Z is accidentally erased, download "UsbSpiDongleKL25Z_SPIDrive_v512.srec" from the
following link: www.nxp.com/Usb-Spi-Dongle-firmware-KL25Z-HB2000-1.
