NXP Semiconductors Freescale MCIMX6Q-SL User manual

MCIMX6Q-SL: Development Platform for i.MX 6Quad
Board built to Free cale
®
SABRE Lite de ign

MCIMX6Q-SL: Development platform for i.MX 6Quad
Built to Free cale® SABRE Lite de ign
Doc ID: MCIMX6QSLUM
Rev. 0.9, 11/12/2012
Embe t and element14 are trademark of Premier Farnell plc 2
© 2012 Premier Farnell plc. All Right Re erved
Free cale and the Free cale logo are trademark of Free cale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off.
Table of Contents
1 BOARD OVERVIEW ................................................................................................................................................................5
1.1 P RODUCT I NTRODUCTION .....................................................................................................................................................5
1.2 F EATURES ..........................................................................................................................................................................6
2 QUICK START GUIDE ..............................................................................................................................................................8
2.1 U NPACKING THE K IT ............................................................................................................................................................8
2.2 W EB -B ASED C ONTENTS .......................................................................................................................................................8
2.3 S ETTING U P THE S YSTEM ......................................................................................................................................................8
2.3.1 Insert MicroSD Card...............................................................................................................................................8
2.3.2 Connect RS-232 cable ............................................................................................................................................9
2.3.3 Connect USB OTG (optional ..................................................................................................................................9
2.3.4 Connect the Power Supply.....................................................................................................................................9
3 HARDWARE DESCRI TION...................................................................................................................................................10
3.1 P ROCESSOR .....................................................................................................................................................................10
3.1.1 Core Features.......................................................................................................................................................10
3.1.2 External memory interfaces:................................................................................................................................ 11
3.1.3 Interface to external devices................................................................................................................................ 11
3.1.4 Advanced Power Management unit ....................................................................................................................12
3.1.5 Hardware Accelerators ........................................................................................................................................13
3.2 E XPANDED C HIP I NTRODUCTION ..........................................................................................................................................13
3.2.1 H5TQ2G63BFR-H9C .............................................................................................................................................13
3.2.2 SST25VF016B.......................................................................................................................................................13
3.2.3 KSZ9021RN ..........................................................................................................................................................13
3.2.4 USB2514B-AEZG for USB 2.0 High Speed 4-Port Hub ..........................................................................................14
3.2.5 SGTL5000.............................................................................................................................................................14
3.2.6 ICL3232CVZ..........................................................................................................................................................14
3.2.7 TJA1040T .............................................................................................................................................................14
3.3 H ARDWARE I NTERFACE ......................................................................................................................................................15
3.3.1 Power Input Jack..................................................................................................................................................15
3.3.2 SATA Power Interface...........................................................................................................................................15
3.3.3 SATA Data Interface .............................................................................................................................................16
3.3.4 CAN Interface ......................................................................................................................................................17
3.3.5 Parallel RGB Interface..........................................................................................................................................17
3.3.6 Audio Output Jack ...............................................................................................................................................19
3.3.7 Microphone Input Jack ........................................................................................................................................20

MCIMX6Q-SL: Development platform for i.MX 6Quad
Built to Free cale® SABRE Lite de ign
Doc ID: MCIMX6QSLUM
Rev. 0.9, 11/12/2012
Embe t and element14 are trademark of Premier Farnell plc 3
© 2012 Premier Farnell plc. All Right Re erved
Free cale and the Free cale logo are trademark of Free cale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off.
3.3.8 Camera Interface.................................................................................................................................................20
3.3.9 RS232 Serial Port .................................................................................................................................................22
3.3.10 RGMII LAN Interface............................................................................................................................................22
3.3.11 USB Host Interface...............................................................................................................................................23
3.3.12 Micro USB Interface.............................................................................................................................................24
3.3.13 SD Card Interface.................................................................................................................................................25
3.3.14 JTAG Interface......................................................................................................................................................25
3.3.15 Expansion Interface .............................................................................................................................................26
3.3.16 Boot Configuration Select....................................................................................................................................26
3.3.17 ANDROID KEYBOARD INTERFACE ........................................................................................................................27
3.3.18 LED.......................................................................................................................................................................28
3.3.19 Switch ..................................................................................................................................................................28
3.3.20 TF/MMC Card Interface .......................................................................................................................................29
3.3.21 HDMI Interface ....................................................................................................................................................29
3.3.22 LVDS Interface......................................................................................................................................................30
3.3.23 MIPI Interface ......................................................................................................................................................31
3.3.24 PCIe Interface ......................................................................................................................................................32
4 SOFTWARE DESCRI TION ....................................................................................................................................................33
4.1 S OFTWARE O VERVIEW - L INUX .............................................................................................................................................33
4.1.1 Overview..............................................................................................................................................................33
4.1.2 Software Features................................................................................................................................................33
4.1.3 System Development ...........................................................................................................................................34
4.1.3.1 Preparing the Board ..........................................................................................................................................................34
4.1.3.2 Booting your Board............................................................................................................................................................34
4.1.3.3 U ing the Demo.................................................................................................................................................................34
4.1.4 For More Information..........................................................................................................................................36
5 ESD RECAUTIONS AND RO ER HANDLING ROCEDURES ..............................................................................................37
6 A ENDIX A: SCHEMATICS ..................................................................................................................................................37
LIST OF FIGURES
FIGURE 1-1 FUNCTIONAL BLOCK DIAGRAM OF SABRE LITE BOARD......................................................................................5
FIGURE 3-1 BLOCK DIAGRAM OF I.MX 6DUAL/6QUAD .......................................................................................................11
FIGURE 3-2 POWER INPUT JACK ..........................................................................................................................................15
FIGURE 3-3 SATA POWER INTERFACE..................................................................................................................................15
FIGURE 3-4 SATA CONNECTOR ............................................................................................................................................16
FIGURE 3-5 CAN INTERFACE ................................................................................................................................................17
FIGURE 3-6 PARALLEL RGB INTERFACE................................................................................................................................17
FIGURE 3-7 AUDIO OUTPUT JACK........................................................................................................................................19
FIGURE 3-8 MIC IN JACK ......................................................................................................................................................20

MCIMX6Q-SL: Development platform for i.MX 6Quad
Built to Free cale® SABRE Lite de ign
Doc ID: MCIMX6QSLUM
Rev. 0.9, 11/12/2012
Embe t and element14 are trademark of Premier Farnell plc 4
© 2012 Premier Farnell plc. All Right Re erved
Free cale and the Free cale logo are trademark of Free cale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off.
FIGURE 3-9 RS232 SERIAL PORT ..........................................................................................................................................22
FIGURE 3-10 RGMII LAN INTERFACE....................................................................................................................................22
FIGURE 3-11 MICRO USB INTERFACE...................................................................................................................................24
FIGURE 3-12 TF/MMC CARD INTERFACE .............................................................................................................................29
LIST OF TABLES
TABLE 2-1 SABRE LITE KIT CONTENTS....................................................................................................................................8
TABLE 3-1 POWER INTERFACE.............................................................................................................................................15
TABLE 3-2 SATA POWER INTERFACE....................................................................................................................................16
TABLE 3-3 SATA CONNECTOR ..............................................................................................................................................16
TABLE 3-4 CAN INTERFACE ..................................................................................................................................................17
TABLE 3-5 PARALLEL RGB INTERFACE..................................................................................................................................18
TABLE 3-6 AUDIO OUTPUT JACK..........................................................................................................................................19
TABLE 3-7 MIC IN JACK ........................................................................................................................................................20
TABLE 3-8 CAMERA INTERFACE ...........................................................................................................................................20
TABLE 3-9 RS-232 SERIAL PORT ...........................................................................................................................................22
TABLE 3-10 RGMII LAN INTERFACE......................................................................................................................................23
TABLE 3-11 USB HOST INTERFACE .......................................................................................................................................23
TABLE 3-12 USB HOST INTERFACE .......................................................................................................................................24
TABLE 3-13 MICRO USB INTERFACE ....................................................................................................................................24
TABLE 3-14 SD CARD INTERFACE .........................................................................................................................................25
TABLE 3-15 JTAG INTERFACE ...............................................................................................................................................25
TABLE 3-16 IIC EXPANSION INTERFACE ...............................................................................................................................26
TABLE 3-17 BOOT CONFIGURATION SELECT........................................................................................................................26
TABLE 3-18 ANDROID BUTTONS..........................................................................................................................................27
TABLE 3-19 LED....................................................................................................................................................................28
TABLE 3-20 RESET SWITCH ..................................................................................................................................................28
TABLE 3-21 BOOT SWITCH...................................................................................................................................................28
TABLE 3-22 TF/MMC CARD INTERFACE ...............................................................................................................................29
TABLE 3-23 HDMI INTERFACE..............................................................................................................................................29
TABLE 3-24 LVDS INTERFACE ...............................................................................................................................................30
TABLE 3-25 MIPI INTERFACE................................................................................................................................................31
TABLE 3-26 PCIE INTERFACE ................................................................................................................................................32

MCIMX6Q-SL: Development platform for i.MX 6Quad
Built to Free cale® SABRE Lite de ign
Doc ID: MCIMX6QSLUM
Rev. 0.9, 11/12/2012
Embe t and element14 are trademark of Premier Farnell plc 5
© 2012 Premier Farnell plc. All Right Re erved
Free cale and the Free cale logo are trademark of Free cale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off.
1Board Overview
1.1 Product Introduction
The development platform for i.MX 6Quad from element14 (built to the Free cale® SABRE Lite de ign) i an
evaluation platform featuring the powerful i.MX 6Q, a multimedia application proce or with Quad ARM
Cortex-A9 core at 1.2 GHz from Free cale Semiconductor. The platform help evaluate the rich et of
peripheral and include a 10/100/Gb Ethernet port, SATA-II, HDMI v1.4, LVDS, parallel RGB interface,
touch creen interface, analog headphone/microphone, micro TF and SD card interface, USB, erial port,
JTAG, camera interface, and input key for Android, a hown in Figure 1-1.
The SABRE Lite can be u ed in the following application :
•Netbook (web tablet )
•Nettop (Internet de ktop device )
•High-end mobile Internet device (MID)
•High-end PDA
•High-end portable media player (PMP) with HD video capability
•Portable navigation device (PND )
•Indu trial control and Te t and mea urement (T&M)
•Single board computer (SBC )
Figure 1-1 Functional Block Diagram of SABRE Lite Board

MCIMX6Q-SL: Development platform for i.MX 6Quad
Built to Free cale® SABRE Lite de ign
Doc ID: MCIMX6QSLUM
Rev. 0.9, 11/12/2012
Embe t and element14 are trademark of Premier Farnell plc 6
© 2012 Premier Farnell plc. All Right Re erved
Free cale and the Free cale logo are trademark of Free cale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off.
1.2 Features
The SABRE Lite Board i ba ed on the i.MX 6Quad-core proce or from Free cale integrating all the
functionalitie of thi multimedia application proce or with the following feature :
•Mechanical Parameter
oWorking Temperature: 0°C - 70°C
oHumidity Range: 20% - 90%
oDimen ion : 82.55mm x 82.55mm
oInput Voltage: +5V
•Proce or
oARM Cortex A9 MPCore™ 4xCPU Proce or at 1GHz
oMulti- tream-capable HD video engine delivering H.264 1080p60 decode, 1080p30 encode,
and 3-D video playback in HD
oTriple Play Graphic Sy tem con i ting of a Quad- hader 3D unit capable of 200MT/ , and a
eparate 2-D and eparate OpenVG Vertex acceleration engine for uperior 3D, 2D, and u er
interface acceleration
•Memorie
o1GByte of 64-bit wide DDR3 @ 532MHz
o2MB SPI FLASH
•Media Interface
oAnalog headphone/microphone, 3.5mm audio jack
oLVDS interface
oHDMI interface
oParallel RGB interface
oCamera interface (Support CCD or CMOS camera)
oMIPI lane at 1 Gbp

MCIMX6Q-SL: Development platform for i.MX 6Quad
Built to Free cale® SABRE Lite de ign
Doc ID: MCIMX6QSLUM
Rev. 0.9, 11/12/2012
Embe t and element14 are trademark of Premier Farnell plc 7
© 2012 Premier Farnell plc. All Right Re erved
Free cale and the Free cale logo are trademark of Free cale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off.
•Data Tran fer Interface
oSerial Port
UART1, 3 line erial port, RS232 Logic
UART2, 3 line erial port, RS232 Logic
oUSB Port :
1 x USB2.0 OTG, micro USB, high- peed, 480Mbp
2 x USB2.0 HOST, Type A, high- peed, 480Mbp
1 x USB2.0 HOST, connector, high- peed, 480Mbp
oTF card interface
oSD card interface
oSATA II interface, 3.0 Gbp
o10M/100M/Gb Ethernet Interface (RJ45 jack)
o1 channel I2C interface
o1 channel PCIE X1 interface
oCAN bu
•Input Interface
oAndroid keyboard interface
o10-pin JTAG interface
o2 bit DIP witch for boot mode election
oBoot configuration interface
•Other
o1 Power LED
o1 DC Jack
o1 Re et button

MCIMX6Q-SL: Development platform for i.MX 6Quad
Built to Free cale® SABRE Lite de ign
Doc ID: MCIMX6QSLUM
Rev. 0.9, 11/12/2012
Embe t and element14 are trademark of Premier Farnell plc 8
© 2012 Premier Farnell plc. All Right Re erved
Free cale and the Free cale logo are trademark of Free cale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off.
2Quick Start Guide
Thi ection de cribe how to u e the SABRE Lite and a ociated component .
2.1 Unpacking the Kit
The SABRE Lite development kit i hipped with the item li ted in Table 2-1. Remove the circuit board
from the conductive bag and perform a vi ual in pection.
Table 2-1 SABRE Lite Kit Content
2.2 Web-Based Contents
Plea e refer to www.element14.com/iMX6 for the late t document and oftware, including:
Schematic
Board layout
Bill of Material (BOM)
Board Support Package (BSP )
2.3 Setting Up the System
2.3.1 Insert MicroSD Card
In ert the upplied MicroSD card into the board’ MicroSD card ocket J20.
Note: MicroSD Card i included if ready at the date your kit wa hipped.
For the late t ver ion of the BSP, plea e vi it www.element14.com/iMX6
Item Description
Circuit Board SABRE Lite boar d
USB cable Micro-B to tandard-A cable
RS-232 cable Cu tom erial cable
Serial Cable
Cro over cable
–
DB9 female to DB9 female
Ethernet cable Cro over cable to connect the board to ho t computer
Power Supply 5Vdc @ 4 A power upply
Documentation Quick-Start Guide
MicroSD Card The kit include a MicroSD Card pre-loaded with the Linux BSP from TimeSy

MCIMX6Q-SL: Development platform for i.MX 6Quad
Built to Free cale® SABRE Lite de ign
Doc ID: MCIMX6QSLUM
Rev. 0.9, 11/12/2012
Embe t and element14 are trademark of Premier Farnell plc 9
© 2012 Premier Farnell plc. All Right Re erved
Free cale and the Free cale logo are trademark of Free cale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off.
2.3.2 Connect RS-232 cable
Connect the cu tom erial cable provided to erial port J17, and then u e cro erial cable to connect to
the ho t computer.
Open a terminal window on the ho t (eg. Hyperterminal) with erial port configuration: 115.2 kbaud, 8
data bit , 1 top bit, with no parity.
2.3.3 Connect USB OTG (optional)
Connect the cable from the kit to micro USB connector J3 on the board.
2.3.4 Connect the ower Supply
Plug in the 5Vdc upply to power jack J10, the power LED (D1) hould illuminate.
To re-boot, pre the re et button SW4.

MCIMX6Q-SL: Development platform for i.MX 6Quad
Built to Free cale® SABRE Lite de ign
Doc ID: MCIMX6QSLUM
Rev. 0.9, 11/12/2012
Embe t and element14 are trademark of Premier Farnell plc 10
© 2012 Premier Farnell plc. All Right Re erved
Free cale and the Free cale logo are trademark of Free cale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off.
3Hardware Description
3.1 Processor
The i.MX 6Dual/6Quad proce or repre ent Free cale Semiconductor’ late t achievement in integrated
multimedia application proce or , which are part of a growing family of multimedia-focu ed product that
offer high performance proce ing and are optimized for lowe t power con umption.
The proce or feature Free cale’ advanced implementation of the quad ARM™ Cortex-A9 core, which
operate at peed up to 1GHz. They include 2D and 3D graphic proce or , 3D 1080p video proce ing, and
integrated power management. Each proce or provide a 64-bit DDR3/LVDDR3-1066 memory interface and a
number of other interface for connecting peripheral , uch a WLAN, Bluetooth™, GPS, hard drive, di play ,
and camera en or .
3.1.1 Core Features
The i.MX 6Dual/6Quad proce or are ba ed on the ARM Cortex A9 MPCore™ platform with the following
feature :
•ARM Cortex A9 MPCore™ 4xCPU Proce or (with Tru tZone)
•The core configuration i ymmetric, where each core include :
o32 KByte L1 In truction Cache
o32 KByte L1 Data Cache
oPrivate Timer and Watchdog
oCortex-A9 NEON MPE (Media Proce ing Engine) Co-proce or
•The ARM Cortex A9 MPCore™ complex include :
oGeneral Interrupt Controller (GIC) with 128 interrupt upport
oGlobal Timer
oSnoop Control Unit (SCU)
o1 MB unified I/D L2 cache, hared by two/four core
oTwo Ma ter AXI (64-bit) bu interface output of L2 cache
oTarget frequency of the core (including Neon and L1 cache) i :
o1 GHz overdrive over the pecified temperature rang
o900 MHz non-overdrive over the pecified temperature range
oNEON MPE coproce or
oSIMD Media Proce ing Architecture
oNEON regi ter file with 32x64bit general-purpo e regi ter
oNEON Integer execute pipeline (ALU, Shift, MAC)
oNEON dual, ingle-preci ion floating point execute pipeline (FADD, FMUL)
oNEON load/ tore and permute pipeline
•The memory y tem con i t of the following component :
oLevel 1 Cache--32 KB In truction, 32 KB Data cache per core
oLevel 2 Cache--Unified in truction and data (1 MByte)
oOn-Chip Memory:
oBoot ROM, including HAB (96 KB)
oInternal multimedia / hared,fa t acce RAM (OCRAM, 256 KB)
oSecure/non- ecure RAM (16 KB)

MCIMX6Q-SL: Development platform for i.MX 6Quad
Built to Free cale® SABRE Lite de ign
Doc ID: MCIMX6QSLUM
Rev. 0.9, 11/12/2012
Embe t and element14 are trademark of Premier Farnell plc 11
© 2012 Premier Farnell plc. All Right Re erved
Free cale and the Free cale logo are trademark of Free cale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off.
Figure 3-1 Block Diagram of i.MX 6Dual/6Quad
3.1.2 External memory interfaces:
o16-bit, 32-bit, and 64-bit DDR3-1066,LV-DDR3-1066, and 1/2 LPDDR2-1066 channel , upporting
DDR interleaving mode, for 2x32 LPDDR2-1066
o8-bit NAND-Fla h, including upport for Raw MLC/SLC, 2 KB, 4 KB, and 8 KB page ize, BA-NAND,
PBA-NAND, LBA-NAND, OneNAND™ and other . BCH ECC up to 32 bit.
o16-bit NOR Fla h. All WEIMv2 pin are muxed on other interface .
o16-bit PSRAM, Cellular RAM
3.1.3 Interface to external devices
Each i.MX 6Dual/6Quad proce or enable the following interface to external device ( ome of them are
muxed and not available imultaneou ly):
oHard Di k Drive --SATA II, 3.0 Gbp
oDi play --Total five interface available. Total raw pixel rate of all interface i up to 450
Mpixel / ec, 24 bpp. Up to four interface may be active in parallel.
oOne Parallel 24-bit di play port, up to 225 Mpixe / ec (for example, WUXGA at 60 Hz or
dual HD1080 and WXGA at 60 Hz)
oLVDS erial port !aOne port up to 165 Mpixel / eor two port up to 85 MP/ ec (for
example, WUXGA at 60 Hz) each
oHDMI 1.4 port
oMIPI/DSI, two lane at 1 Gbp
o
•Camera en or :
oParallel Camera port (up to 20 bit and up to 240 MHz peak)
oMIPI CSI-2 erial camera port, upporting up to 1000 Mbp /lane in 1/2/3-lane mode and up to

MCIMX6Q-SL: Development platform for i.MX 6Quad
Built to Free cale® SABRE Lite de ign
Doc ID: MCIMX6QSLUM
Rev. 0.9, 11/12/2012
Embe t and element14 are trademark of Premier Farnell plc 12
© 2012 Premier Farnell plc. All Right Re erved
Free cale and the Free cale logo are trademark of Free cale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off.
800 Mbp /lane in 4-lane mode. The CSI-2 Receiver core can manage one clock lane and up to four
data lane . Each i.MX 6Dual/6Quad proce or ha four lane .
•Expan ion card :
oFour MMC/SD/SDIO card port all upporting:
o1-bit or 4-bit tran fer mode pecification for SD and SDIO card up to UHS-I SDR-104 mode (104
MB/ max)
o1-bit, 4-bit, or 8-bit tran fer mode pecification for MMC card up to 52 MHz in both SDR and
DDR mode (104 MB/ max)
•USB
oHigh Speed (HS) USB 2.0 OTG (Up to 480 Mbp ), with integrated HS USB PHY
oThree USB 2.0 (480 Mbp ) ho t
oOne HS ho t with integrated High Speed PHY
oTwo HS ho t with integrated HS-IC USB (High Speed Inter-Chip USB) PHY
•Expan ion PCI Expre port (PCIe) v2.0 one lane
oPCI Expre (Gen 2.0) dual mode complex, upporting Root complex operation and Endpoint
operation . U e x1 PHY configuration.
•Mi cellaneou IP and interface :
oThree I2S/SSI/AC97,up to 1.4 Mbp each
oEnhanced Serial Audio Interface ESAI), up to 1.4 Mbp per channel
oFive UART , up to 4.0 Mbp each
oProviding RS232 interface
oSupporting 9-bit RS485 multidrop mode
oOne of the five UART (UART1) upport 8-wir while other four upport 4-wire. Thi i due to
the SoC IOMUX limitation, ince all UART IP are identical.
oFive eCSPI (Enhanced CSI), up to 52 Mbp each
oThree I2C, upporting 400 kbp
oGigabit Ethernet Controller(IEEE1588 compliant), 10/100/1000 Mbp
oFour Pul e Width Modulator (PWM)
oSy tem JTAG Controller (SJC)
oGPIO with interrupt capabilitie
o8x8 Key Pad Port (KPP)
oSony Philip Digital Interface (SPDIF), Rx and Tx
oTwo Controller Area Network (FlexCAN), 1 Mbp each
oTwo Watchdog timer (WDOG)
oAudio MUX (AUDMUX)
3.1.4 Advanced ower Management unit
The i.MX 6Dual/6Quad proce or integrate advanced power management unit and controller :
•Provide PMU, including DCDC and LDO upplie , for on-chip re ource
•U e Temperature Sen or for monitoring the die temperature
•Support DVFS technique for low power mode
•U e SW State Retention and Power Gating for ARM and MPE
•Support variou level of y tem power mode
•U e flexible clock gating control cheme

MCIMX6Q-SL: Development platform for i.MX 6Quad
Built to Free cale® SABRE Lite de ign
Doc ID: MCIMX6QSLUM
Rev. 0.9, 11/12/2012
Embe t and element14 are trademark of Premier Farnell plc 13
© 2012 Premier Farnell plc. All Right Re erved
Free cale and the Free cale logo are trademark of Free cale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off.
3.1.5 Hardware Accelerators
The i.MX 6Dual/6Quad proce or u e dedicated HW accelerator to meet the targeted multimedia
performance. The u e of HW accelerator i a key factor in obtaining high performance at low power
con umption number , while having the CPU core relatively free for performing other ta k .
The i.MX 6Dual/6Quad proce or incorporate the following hardware accelerator :
•VPU--Video Proce ing Unit
•IPUv3H--Image Proce ing Unit ver ion 3H (2 IPU )
•GPU3Dv4--3D Graphic Proce ing Unit (OpenGL ES 2.0) ver ion
•GPU2Dv2--2D Graphic Proce ing Unit (BitBlt)
•GPUVG—Open VG 1.1 Graphic Proce ing Unit
•ASRC--A ynchronou Sample Rate Converter
•Security function are enabled and accelerated by the following hardware:
•ARM Tru tZone including the TZ architecture ( eparation of interrupt , memory mapping, etc.)
•SJC--Sy tem JTAG Controller. Protecting JTAG from debug port attack by regulating or blocking the
acce to the y tem debug feature .
•CAAM--Cryptographic Acceleration and A urance Module, containing 16 KB ecure RAM and True and
P eudo Random Number Generator (NIST certified)
•SNVS--Secure Non-Volatile Storage, including Secure Real Time Clock
•CSU--Central Security Unit. Enhancement for the IC Identification Module (IIM). Will be configured
during boot and by eFUSE and will determine the ecurity level operation mode a well a the TZ
policy.
•A-HAB Advanced High A urance Boot--Hv4 with the new embedded enhancement :
•SHA-256, 2048-bit RSA key, ver ion control mechani m, warm boot, CSU, and TZ initialization.
3.2 Expanded Chip Introduction
3.2.1 H5TQ2G63BFR-H9C
The board ha 1GB of SDRAM (4x256MB). The H5TQ2G63BFR i a 256MB DDR3 Synchronou DRAM, ideally
uited for the main memory application which require large memory den ity and high bandwidth.
3.2.2 SST25VF016B
The erial EPROM SST25VF016B i a 16Mb SPI Serial Fla h u ed for boot code torage. Booting from erial
EPROM i recommended.
3.2.3 KSZ9021RN
The KSZ9021RN i a ingle-port 10/100/1000Ba e-T Gigabit tran ceiver in indu try’ malle t footprint,
upporting data tran fer over tandard CAT-5 un hielded twi ted pair cable. Thi device offer robu t
performance and low power con umption. On-chip integration of termination re i tor and LDO controller,
along with built-in diagno tic feature , ignificantly reduce the co t and the complexity of Gigabit Ethernet
application . Thi device i ideal for enabling Gigabit Ethernet performance in SOHO and SMB networking
application , uch a SOHO media center, wired/wirele Gigabit SOHO/SMB router, and VoIP gateway.
The SABRE Lite can be connected to a network hub directly through a cable. It al o can be directly connected
with a computer through a cro over cable which i provided with the kit.

MCIMX6Q-SL: Development platform for i.MX 6Quad
Built to Free cale® SABRE Lite de ign
Doc ID: MCIMX6QSLUM
Rev. 0.9, 11/12/2012
Embe t and element14 are trademark of Premier Farnell plc 14
© 2012 Premier Farnell plc. All Right Re erved
Free cale and the Free cale logo are trademark of Free cale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off.
3.2.4 USB2514B-AEZG for USB 2.0 High Speed 4- ort Hub
The USB2514 hub i a family of low-power, OEM configurable, MTT (multi tran action tran lator) hub
controller IC with 4 down tream port for embedded USB olution . The SMSC hub upport low- peed, full-
peed, and hi- peed (if operating a a hi- peed hub) down tream device on all of the enabled down tream
port .
3.2.5 SGTL5000
The SGTL5000 i a low power tereo Codec with Headphone Amp from Free cale, and i de igned to provide a
complete audio olution for portable product needing line-in, mic-in, line-out, headphone-out, and digital I/O.
Deriving it architecture from be t-in-cla Free cale-integrated product currently on the market, the
SGTL5000 i able to achieve ultra low-power with very high performance and functionality, all in one of the
malle t footprint available.
De igned with feature uch a caple headphone and an integrated PLL to allow clock reu e within the
y tem, it help cu tomer achieve a lower overall y tem co t.
3.2.6 ICL3232CVZ
The Inter il ICL32XX X interface IC operate from a ingle +3V to +5.5V upply, guarantee a 250kbp minimum
data rate, require only four mall external 0.1µF capacitor , feature low power con umption, and meet all ElA
RS-232C and V.28 pecification . Targeted application are PDA , Palmtop , and notebook and laptop
computer where the low operational and even lower tandby, power con umption i critical.
3.2.7 TJA1040T
The TJA1040, a High Speed CAN tran ceiver i the interface between the Controller Area Network (CAN)
protocol controller and the phy ical bu . It i primarily intended for high peed application , up to 1MBaud, in
pa enger car . The device provide differential tran mit capability to the bu and differential receive
capability to the CAN controller.

MCIMX6Q-SL: Development platform for i.MX 6Quad
Built to Free cale® SABRE Lite de ign
Doc ID: MCIMX6QSLUM
Rev. 0.9, 11/12/2012
Embe t and element14 are trademark of Premier Farnell plc 15
© 2012 Premier Farnell plc. All Right Re erved
Free cale and the Free cale logo are trademark of Free cale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off.
3.3 Hardware Interface
3.3.1 ower Input Jack
The 5V/4A AC-to-DC power upply that come with the board i plugged into the Power Jack (J10) on the
board. It is not recommended to use a higher voltage since possible damage to the board may result due to
failure of the protection circuitry.
Figure 3-2 Power input jack
Table 3-1 Power Interface
J10
Pin Signal Function
1 GND GND
2 NC NC
3 +5V Power upply (+5V) 2A (Type)
3.3.2 SATA ower Interface
A 3-pin SATA power connector for 2.5 inch SATA hard di k i hown in Figure 3-3 below.
Figure 3-3 SATA Power Interface

MCIMX6Q-SL: Development platform for i.MX 6Quad
Built to Free cale® SABRE Lite de ign
Doc ID: MCIMX6QSLUM
Rev. 0.9, 11/12/2012
Embe t and element14 are trademark of Premier Farnell plc 16
© 2012 Premier Farnell plc. All Right Re erved
Free cale and the Free cale logo are trademark of Free cale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off.
Table 3-2 SATA Power Interface
J19
Pin
Signal
Function
1
+3.3V
3.3
V output
2
GND
GND
3
+5V
5V output
3.3.3 SATA Data Interface
A SATA 7-pin data connector (J21) i provided on the Quick Start Board and i connected to the SATA
module of the i.MX6 proce or. The SABRE Lite board i capable of communicating with any tandard SATA
device, uch a a hard drive or optical DVD/CD reader. The SATA data cable i plugged into the SABRE Lite
board at the location hown in Figure 3-4.
Figure 3-4 SATA connector
Table 3-3 SATA Connector
J21
Pin Signal Function
1 GND GND
2 SATA_TXP SATA receive data(po itive)
3 SATA_TXN SATA receive data(negative)
4 GND GND
5 SATA_RXN SATA tran mit data(negative)
6 SATA_RXP SATA tran mit data(po itive)
7 GND GND

MCIMX6Q-SL: Development platform for i.MX 6Quad
Built to Free cale® SABRE Lite de ign
Doc ID: MCIMX6QSLUM
Rev. 0.9, 11/12/2012
Embe t and element14 are trademark of Premier Farnell plc 17
© 2012 Premier Farnell plc. All Right Re erved
Free cale and the Free cale logo are trademark of Free cale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off.
3.3.4 CAN Interface
Figure 3-5 CAN Interface
Table 3-4 CAN Interface
J22
Pin Signal Function
1 CANH CAN differential pair high level
2 GND GND
3 CANL CAN differential pair low level
3.3.5 arallel RGB Interface
Figure 3-6 Parallel RGB Interface

MCIMX6Q-SL: Development platform for i.MX 6Quad
Built to Free cale® SABRE Lite de ign
Doc ID: MCIMX6QSLUM
Rev. 0.9, 11/12/2012
Embe t and element14 are trademark of Premier Farnell plc 18
© 2012 Premier Farnell plc. All Right Re erved
Free cale and the Free cale logo are trademark of Free cale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off.
Table 3-5 Parallel RGB interface
J15
Pin
Signal
Function
1
GND
GND
2
GND
GND
3
GND
GND
4
DISP0_CNTRST
GPIO
5
R0
DISP0
data bit1
6
6
R1
DISP0
data bit1
7
7
R2
DISP0
data bit1
8
8
R3
DISP0
data bit1
9
9
R4
DISP0
data bit
20
10
R5
DISP0
data bit
21
11
R6
DISP0
data bit
22
12
R7
DISP0
data bit
23
13
G0
DISP0
data bit
8
14
G1
DISP0
data bit
9
15
G2
DISP0
data bit
10
16
G3
DISP0
data bit
11
17
G4
DISP0
data bit
12
18
G5
DISP0
data bit
13
19
G6
DISP0
data bit
14
20
G7
DISP0
data bit
15
21
B0
DISP0
data bit
0
22
B1
DISP0
data bit
1
23
B2
DISP0
data bit
2
24
B3
DISP0
data bit
3
25
B4
DISP0
data bit
4
26
B5
DISP0
data bit
5
27
B6
DISP0
data bit
6
28
B7
DISP0
data bit
7
29
GND
GND
30
DISP0_CLK
Pixel Clock
31
GND
GND
32
DISP0_HSYNC
DISP0
HSYNC
33
DISP0_VSYNC
DISP0
VSYNC
34
DISP0_DRDY
DISP0
enable chip elect
35 I2C3_SCL IIC ma ter erial clock,

MCIMX6Q-SL: Development platform for i.MX 6Quad
Built to Free cale® SABRE Lite de ign
Doc ID: MCIMX6QSLUM
Rev. 0.9, 11/12/2012
Embe t and element14 are trademark of Premier Farnell plc 19
© 2012 Premier Farnell plc. All Right Re erved
Free cale and the Free cale logo are trademark of Free cale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off.
36 I2C3_SDA IIC erial bidirectional data,
37 PWM1 Backlight brightne control
38 5VIN +5V
39 5VIN +5V
40 5VIN +5V
3.3.6 Audio Output Jack
A headphone with a tandard 3.5mm tereo jack can be connected to the Audio Output jack at the point
hown in Figure3-7.
Figure 3-7 Audio Output Jack
Table 3-6 Audio Output Jack
J8
Pin Signal Function
1 GND_ANALOG ANALOG GND
2 HP_L Left output
3 HP_R Right output
10 Default et Pull down 10k re i ter

MCIMX6Q-SL: Development platform for i.MX 6Quad
Built to Free cale® SABRE Lite de ign
Doc ID: MCIMX6QSLUM
Rev. 0.9, 11/12/2012
Embe t and element14 are trademark of Premier Farnell plc 20
© 2012 Premier Farnell plc. All Right Re erved
Free cale and the Free cale logo are trademark of Free cale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off.
3.3.7 Microphone Input Jack
The SABRE Lite board provide a 3.5mm tereo connector for a microphone input, a hown in Figure 3-8. A
mono microphone will input it ignal though the tip of the 3.5mm plug.
Figure 3-8 MIC In Jack
Table 3-7 MIC In Jack
J9
Pin Signal Function
1 GND_ANALOG ANALOG GND
2 MIC_IN_P MIC input
3 NC NC
10 MIC_DET MIC input Jack detect
3.3.8 Camera Interface
Table 3-8 Camera Interface
J5
Pin Signal Function
1 GND GND
2 CSI0_DAT19 CSI0 capture data bit 19
3 CSI0_DAT18 CSI0 capture data bit 18
4 CSI0_DAT17 CSI0 capture data bit 17
5 CSI0_DAT16 CSI0 capture data bit 16
6 CSI0_DAT15 CSI0 capture data bit 15
7 CSI0_DAT14 CSI0 capture data bit 14
8 CSI0_DAT13 CSI0 capture data bit 13
