OA Composites F3Klaus NRJ Instruction Manual

F3Klaus NRJ Building instructions Version 2020 04 11
1
All manuals and user guides at all-guides.com

F3Klaus NRJ Building instructions Version 2020 04 11
2
dirctory
1. Servo Setup...................................................................................................................................... 3
2. Installation of C- peg........................................................................................................................ 6
3. Horns for wing............................................................................................................................... 11
4. Servo rack ...................................................................................................................................... 20
5. Aileron push rods .......................................................................................................................... 23
6. Fin and stab ................................................................................................................................... 35
7. Finalize push rods .......................................................................................................................... 40
8. Finalize aerodynamic..................................................................................................................... 41
NOTE!
This manual is an example how to build this glider.
You do not need to build it according this decription.
You have to build and fly at your own risk.
All manuals and user guides at all-guides.com

F3Klaus NRJ Building instructions Version 2020 04 11
3
1. Servo Setup
All manuals and user guides at all-guides.com

F3Klaus NRJ Building instructions Version 2020 04 11
4
4 x KST -> Standard Servo Frame approx 38gramm
2 x KST + 2 x MKS DS75K (37,8 gramm incl Rack) -> MKS Servo Frame
All manuals and user guides at all-guides.com

F3Klaus NRJ Building instructions Version 2020 04 11
5
2 x Robbe FS31 + 2 x MKS DS75K (30 gramm incl Rack) -> Robbe MKS Servo Frame
All manuals and user guides at all-guides.com

F3Klaus NRJ Building instructions Version 2020 04 11
6
2. Installation of C- peg
Download file from lininger webside.
The peg hast o fit perfect to hole of the wing. Only than you can use CA.
All manuals and user guides at all-guides.com

F3Klaus NRJ Building instructions Version 2020 04 11
7
All manuals and user guides at all-guides.com

F3Klaus NRJ Building instructions Version 2020 04 11
8
All manuals and user guides at all-guides.com

F3Klaus NRJ Building instructions Version 2020 04 11
9
All manuals and user guides at all-guides.com

F3Klaus NRJ Building instructions Version 2020 04 11
10
After that sand the glue surface.
All manuals and user guides at all-guides.com

F3Klaus NRJ Building instructions Version 2020 04 11
11
3. Horns for wing
Check that the 1.0mm pushroad fits perfct tot he hole in the horn.
Sand the gluing surface
All manuals and user guides at all-guides.com

F3Klaus NRJ Building instructions Version 2020 04 11
12
Make a sharp shape to reduce aerodynamic drag
Check the distance between fuse and rudder
All manuals and user guides at all-guides.com

F3Klaus NRJ Building instructions Version 2020 04 11
13
Check the 90 degrees of the slice
All manuals and user guides at all-guides.com

F3Klaus NRJ Building instructions Version 2020 04 11
14
Check the alignment without CA
All manuals and user guides at all-guides.com

F3Klaus NRJ Building instructions Version 2020 04 11
15
Check the sitance between horns and fuse
All manuals and user guides at all-guides.com

F3Klaus NRJ Building instructions Version 2020 04 11
16
Horn has to adjust to forward position
Use 2mm distance holder to adjust the position
All manuals and user guides at all-guides.com

F3Klaus NRJ Building instructions Version 2020 04 11
17
Glue the ajusteed horns with CA.
All manuals and user guides at all-guides.com

F3Klaus NRJ Building instructions Version 2020 04 11
18
Send the horn and slice to have a soft movement oft he rudder.
All manuals and user guides at all-guides.com

F3Klaus NRJ Building instructions Version 2020 04 11
19
All manuals and user guides at all-guides.com

F3Klaus NRJ Building instructions Version 2020 04 11
20
4. Servo rack
You need the reight servo rack for you configuration.
Here is an example for Robbe and MKS.
First drill the holes
