ObboMed MM-3600 User manual

1
Your healthy living center
www.obbomed.com
Infrared Ear Thermometer
Model No.: MM-3600
Please carefully read through this manual before first use, and store it in safe place.
If you pass the product to another person, hand over this manual along with it!
EXPLANATION SYMBOLS
INTENDED USE OF PRODUCT
SAFETY & INSTALLATION INSTRUCTION
SCOPE OF DELIVERY (ACCESSORIES)
DANGER: Warning of risk of serious injury or health hazards
WARNING: Warning of risk of injury or health hazards
CAUTION: Safety informaon about possible damage to appliance/ accessories
NOTE: Important informaon
- For family use only, this product is not designed for hospital/ medical use.
- Use product only for its intended use as described in the manual.
- Recommended for: measuring human body temperature.
All below informaon serves to protect health of user and the health of other person. Also protects the product from
any damage while using.
- The product is only designed for the measuring area on the human body stated in this manual.
- Do not disassemble or aempt to repair. There are no user serviceable parts inside.
- Do not place or store this product where it might fall into water or any kind of liquids.
- Always consult the doctor. Self-diagnosis of measurement results and self-treatment are dangerous.
- Do not take any therapeuc measures on the basis of a self measurement. Never alter the dose of a medicine
prescribed by a doctor.
- Please keep the product and its baery away from heat, moisture, and direct sunlight.
- Do not use the product in places where strong stac electricity or electromagnec fields are present.
- Do not let children use this product without supervision.
- This product is not shock resistant, please do not drop it.
- This product is not waterproof; please do not soak the enre product in water or cleaning detergent.
- Remove the baeries from the product if not used for long me.
- Infrared Ear Thermometer
- User’s manual
- Baery included: 3V CR2032 lithium baery

2
PRODUCT FEATURES
APPLIANCE DESCRIPTION & OPERATION
- For ear use only
- Probe cover is not required
- °C / °F switchable funcon
- 2-second response me
- Easy-to-read LCD display
- Stores 10 memories
- Peak temperature tone
- Auto off
°C/ °F SWITCHABLE
Temperature readings are switchable in both Fahrenheit and Celsius scale. To switch between Fahrenheit and Celsius,
please turn off the thermometer, press and hold the ‘On/Off & Memory’ buon unl the C or F appears on the LCD.
The screen displays Lo if the temperature is below 32°C/ 90°F; the LCD displays Hi if the temperature is higher
than 42.9°C/ 109.9°F.
Normal beep is slow beep (bi- bi- bi-), if tested temperature is higher than 37.8°C/ 100°F, the fever alarm will go
off with faster beeps.
DIRECTION
1. Disinfect the probe with alcohol coon ball. This model does not need the probe cover.
2. Press the ‘On/Off & Memory’ buon, the LCD will light up with a beep. The thermometer will be ready for
measurement when LCD displays Fig. 2.
3. Place the probe inside the ear canal, make sure the probe faces the eardrum for accurate reading, see Fig. 3
4. Press the Test buon and the result will be shown on the LCD screen in 2 seconds with a short beep.
5. The temperature may differ between two eardrums, make sure to take the measurement at the same ear when
comparing the results.
6. To turn off, press and hold the ‘On/Off & Memory’ buon for 5 seconds, or idling 1 minute.
Fig. 3Fig. 2
MEMORY FUNCTION
This thermometer can store 10 last memories.
1. Memory mode can be accessed in two ways:
a. When the thermometer is on, press the ‘On/ Off & Memory’ Buon.
b. Aer test, press the ‘On/Off & Memory’ buon.
2. The display will show the most recent reading, with , Fig. 4
3. Press the ‘On/Off & Memory Buon’ to read through the saved readings. They are numbered 0-9, the number 1 is the
most recent reading.
4. Press the ‘Test buon’ again to test.
5. To turn off, press and hold the ‘On/Off & Memory Buon’ for 5 seconds, or idling 1 minute.
Fig. 4
Fig. 1
LCD
On/ Off & Memory Buon
Probe
Test Buon
BATTERY REPLACEMENT
Baery Type: one 3V CR2032 lithium baery.
1. Replace the baery when the low baery sign appears on the LCD screen.
2. Slide the baery cover and gently pull the metal clip and the baery will flip up automacally.
3. Please use 3V, CR2032 type, or equivalent. Be sure to install the baery with “+” side up.
4. Slide the baery cover back into place.
The dispose of the baery should comply with local regulaon.

3
NORMAL TEMPERATURE REFERENCE
Oral: 35.1 - 37.3 ˚C/ 96.3 - 99.1 ˚F
Rectal: 36.2 - 37.7 ˚C/ 97.2 - 99.9 ˚F
Armpit: 35.2 - 36.7 ˚C/ 95.4 - 98.1 ˚F
Ear: 35.7 - 37.9˚C/ 96.3 - 100.2 ˚F
TECHNICAL DATA & MATERIAL
TROUBLESHOOTING
CARE AND STORAGE INSTRUCTION
Technical specificaons are subject to change without noce.
Product Name: Infrared Ear Thermometer with Backlight
Model: MM-3600
Dimensions: 11.8 x 3.8 x 3.5 cm/ 4.65” x 1.5” x 1.38”
Weight: 40 g
Display: Liquid Crystal Display (LCD), no mercury
Memory: Stores 10 readings
Temperature Range: 32.0 – 43.0°C (90.0 – 109.4°F)
Accuracy: ± 0.2°C (± 0.4°F)
Operang Environment: Temperature: 10 – 40°C (50 – 104°F)
Humidity: ≤ 95%
Storage Environment: Temperature: -25 – 55°C (-13 – 131°F)
Humidity: ≤95%
Input Power : One 3V lithium CR2032 baery
Approvals: CE0197, RoHS
Applied part:
= Type B
Problem Cause Soluon
Temperature results are not within
normal human temperature range:
32.0 to 43°C (89.6 to 109.4°F).
Lo = low; H= high.
The ambient temperature is not
within the suitable operang
temperature range:
10 – 40°C (50 – 104°F).
Place the thermometer within the suitable
temperature range: 10 – 40°C (50 – 104°F)
and try again.
Other error. Contact local dealer.
1. Make sure the probe surface is clean.
2. Make sure the probe are correctly inserted
into ear canal.
Please contact the local dealer if the problem
connues to occur with proper operaon.
- This product is not waterproof; please do not soak the enre product in water and cleaning detergent.
In the unlikely event of product malfuncon, stop using immediately.
Please contact the local dealer for repair. Any tampering voids warranty.
- Clean the probe with soap and warm water or rubbing alcohol.
- Do not immerse the product into any liquid.
- Do not use any thinner or chemical solvent to clean the product.
- Keep the product out of reach and sight of children.
- Keep this product and its baery away from heat, moisture, and direct sunlight.
- Remove the baeries from the
product if not used for long me.

4
Distribuon by ObboMed Group:
Webshop: www.obbomed.com
Europe:
Morseweg 11, 8503 Ah Joure
The Netherlands
Mail: [email protected]
United States:
1210 E Lexington Ave,
Pomona, CA 91766, U.S.A.
Mail: [email protected]
Australia:
39/3 Kelso Crescent Moorebank,
NSW 2170, Australia
Mail: [email protected]
ObboMed® is registered Trademark of ObboMed Group.
DISPOSAL
Disposal of packing and product aer end of lifeme.
Deliver all packing materials at a collecon point or in the appropriate bins for recycling. For further queson
please contact local recycling office.
WARRANTY
DISTRIBUTION & SERVICE
The statutory warranty period applies. If the product is defecve, please contact the manufacturer's service centre (see
service e-mail at the end of this manual) or your retailer. For repair and warranty processing, please include the following
documents when you send in the product:
• A copy of the receipt with purchasing date.
• A reason for the claim or descripon of the fault.
No guarantee is provided when the product is not installed/ operated according to this manual, used for other purposes
or careless use of the product.
Manufacturer: Picard Healthcare Technology (Dongguan) Co. Ltd.
Address: No. 149, Chunfung Rd, Longbelin, Tangxia, Dongguan,
Guangdong Prov., China
European Representative: ObboMed Group B.V.
Address: Morseweg 11, 8503 Ah Joure, The Netherlands
Tel: [phone] 0197
