OBDPROG MT401 User manual

OBDPROG MT401 User Manual
autosensus.com
1
OBDPROG MT401 User Manual
Statement
This handbook is the manual of OBDPROG MT401. Without the written
permission from the manufacturer, any company or individual shall not copy
or backup it in any form (electronic, mechanical, photocopying, recording or
otherwise).This manual is only operating instructions for OBDPROG MT401. If
any result caused by using it on other equipment, the company does not
assume any responsibility for it.
If not quality problems of OBDPROG MT401，such as equipment failure
caused by user abuse or misuse, unauthorized disassembly, repair equipment
yourself, not operate or maintain by the instructions, lose it, the repair will
not be free. Other product names mentioned in this manual are in order to
describe how to use OBDPROG MT401, and their copyrights are still observed
by the original company.
OBDPROG MT401 and files are used for normal vehicles maintenance. If used
for illegal purposes, the company does not assume legal responsibility.

OBDPROG MT401 User Manual
autosensus.com
2
Content
Chapter 1 : Summary…………………………………………….…………………………………………3
1.1 Features…………………………………………………………….…………..……………………3
1.1.1 Advantages…………………………………………………………………………………….3
1.1.2 Durability………………………………………………………………………………………..3
1.2 Introduction of the device……………………………………………………………………....4
1.2.1 The main unit and accessories………………………………………………………….4
1.3 Hardware technical specification………………………………………………………………4
1.4 Functions Setting……………………………………………………………………………………..5
1.4.1 Functions Selection…………………………………………………………………………5
1.4.2 System Setting……………………………………………………………………………….6
1.4.2.1 Language Selection……………………………………………………………. 6
1.4.2.2 Metric/Inch………………………………..……………………………...………7
1.4.2.3 Data logging…………………………………………………………...…………7
1.4.2.4 Font setting………………………………………………………….…..……….8
1.4.3 System Information………………………………………………………….……..……8
1.4.4 Device Self-test………………………………………………………………….………….9
Chapter 2:
How to update software for OBDPROG MT401……………………………….…….……9
2.1 Update Tool software Installation……………………………………………….…………9
2.2 Software Updating………………………………………………………………………………11

OBDPROG MT401 User Manual
autosensus.com
3
Chapter 1: Summary
1.1.Features
1.1.1. Advantages
●Multi-language environment can be applied in different countries and regions.
●The main unit system adopts ARM high speed chip to keep it running fast,
stable and anti-jamming.
●Updating via TF card at any moment.
●Modern design and high-definition true color screen realize the integration of
automotive industry and electronic information technologies and make auto
diagnosis and key programming easier, practical and economical.
1.1.2 Durability
●Integrity structure design makes it crack resistance, shock resistance and
durable.
●Industrial design ensures the tool work stably under tough environment, such
as high and low temperatures.

OBDPROG MT401 User Manual
autosensus.com
4
1.2 Introduction of the device
1.2.1 The main unit and accessories(Picture as below)
Name
Instruction
Testing cable port
Connect to the main test cable for auto
key programming
Display Screen
Show information
F1
Keyboard input option key
F2
Keyboard input option key
Enter
OK
ESC
Exit or give up
Up
Up
Right
To right
Down
Down
Left
To left
TF card slot
To keep diagnostic program or data
Right

OBDPROG MT401 User Manual
autosensus.com
5
1.3 Hardware technical specification
Dimension: 22cm(L)*11cm(W)*6.0cm(H)
CPU :ARM7
Power Supply:DC12V
Operation Power:DC12V
Operation Temperature: -20~60℃
Display Screen:160*160
1.4 Functions Setting
Power on，and then press ENTER on the screen，then go to the function setting,
setting information as shown below:
1.4.1 Function Selection
Select different functions according to different requirements.

OBDPROG MT401 User Manual
autosensus.com
6
Note: Software numbers and functions are different according to different product
configuration. Further detailed information, please contact your distributor.
1.4.2 System Setting
Select System Setting, language and font can be adjusted, as shown below:
1.4.2.1 Language Selection

OBDPROG MT401 User Manual
autosensus.com
7
This device supports English. In the language directory, select required language
and press ENTER to confirm it.
1.4.2.2 Metric/Inch
According to different requirements, select the Metric/Inch by the up and down keys,
and press ENTER to confirm as show below,

OBDPROG MT401 User Manual
autosensus.com
8
1.4.2.3 Data Logging
Any problems during testing, please use the Data Logging function to record the test
process and send the data to us. Select ON by the up and down keys and press
ENTER to confirm, shown as below,
Note: Every time you need to select ON if you want to record the data before testing
car.
1.4.2.4 Font setting
According to requirement, select different font

OBDPROG MT401 User Manual
autosensus.com
9
1.4.3 System Information
System information includes product serial number, hardware version, software
version, release date, register password, etc.

OBDPROG MT401 User Manual
autosensus.com
10
1.4.4 Device Self-test
Device self-test includes screen display, keyboard testing. hardware self-testing, etc.
If it cannot show enough pictures on the screen, keyboard not work, and hardware
self-test not get through, please return this OBDPROG MT401 to the manufacturer.
Chapter 2: How to update software for OBDPROG MT401
2.1 Update Tool software installation
Download the update tool and diagnostic software on www.obdprog.com, double
click , then go to the next step:
Step 1：Click “Next”

OBDPROG MT401 User Manual
autosensus.com
11
Step 2: Click “Next
Step 3: Click “Next”
Step 4: Click “Finish”

OBDPROG MT401 User Manual
autosensus.com
12
2.2 Software Updating
After Update Tool installation completed, click the Update Tool software icon on
desktop to start the update tools. Operation steps as following:
Step 1：Open update tool
Step 2: Click the source menu, choose the program you want to update, click it and
confirm

OBDPROG MT401 User Manual
autosensus.com
13
Step 3: Click and select all the software then click “update”
Step 4: Wait for several minutes then the updating finished
Note：For new update software and questions during updating, please
contact your distributor.
