Objecto T1 User manual
USER MANUAL
F
F
1
180200aT1CHMS-011USAll.indb1180200aT1CHMS-011USAll.indb1 2018/09/1411:09:362018/09/1411:09:36
2
English
Safety Information
This section presents important safety information. Always follow
these instructions when using the product.
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic precautions should always be
followed to reduce the risk of fire, electric shock, and injury to
persons, including the following:
1. Read all instructions before using this product.
2. This product is hot when in use. To avoid burns, do not let bare skin touch hot
surfaces. Use the handle when moving this product. Keep combustible materials,
such as furniture, pillows, bedding, papers, clothes, and curtains at least 1.6 feet
from the foot warmer and keep them away from the sides and rear.
3. Extreme caution is necessary when the foot warmer is used by or near children or
invalids and whenever the product is left operating and unattended.
4. Always unplug the product when not in use.
5. Do not operate the foot warmer with a damaged cord or plug or after the product
malfunctions, has been dropped or damaged in any manner. Return the product
to authorized service facility for examination, electrical or mechanical adjustment,
or repair.
6. Do not use outdoors.
7. This product is NOT intended for use on tabletops or desktops, use ONLY ON
FLOORS. It is not to be used in wet or moist locations, such as bathrooms and
laundry areas. Never position the product where it may fall into a bathtub or other
water container.
8. Do not run cord under carpeting. Do not cover cord with throw rugs, runners,
or similar coverings. Do not run cord under furniture or appliances. Arrange cord
away from traffic area to avoid tripping over it.
9. To disconnect the product, first turn controls to the OFF position, then grip the
plug and pull it from the wall outlet. Never pull by the cord.
10. Do not insert or allow foreign objects to enter any ventilation or exhaust opening
as this may cause an electric shock or fire, or damage the foot warmer.
11. The foot warmer has hot and/or sparking parts inside. Do not use it in the areas
where gasoline, paint, or flammable liquids are used or stored.
12. Use this product only as described in this manual. Any other use not
recommended by the manufacturer may cause fire, electric shock, or injury to
persons.
13. Always plug the product directly into a wall outlet/receptacle. Never use with an
extension cord or power strip.
14. To prevent a possible fire, do not block air intakes or exhaust in any manner.
Do not use on soft surfaces, like a bed, where openings may become blocked.
15. This appliance has a polarized plug (one blade is wider than the other). To reduce
the risk of electric shock, this plug is intended to fit in a polarized outlet only one
way. lf the plug does not fit fully in the outlet, reverse the plug. lf it still does not
fit, contact a qualified electrician.
Do not modify the plug in any way.
180200aT1CHMS-011USAll.indb2180200aT1CHMS-011USAll.indb2 2018/09/1411:09:362018/09/1411:09:36
3
English
16. a) A short power-supply cord (or short detachable power-supply cord) is provided
to reduce the risks resulting from becoming entangled in or tripping over a
longer cord.
b) Extension cords (or longer detachable power-supply cords) are available and
may be used if care is exercised in their use.
c) If an extension cord (or a long detachable power-supply cord) is used:
1) The marked electrical rating of the detachable power-supply cord or extension
cord should be at least as great as the electrical rating of the appliance;
2) If the appliance is of the grounded type, the extension cord should be a
grounding type 3- wire cord; and
3) The longer cord should be arranged so that it will not drape over the
countertop or tabletop where it can be tripped over, snagged, or pulled on
unintentionally (especially by children).
17.
SAVE THESE INSTRUCTIONS
WARNING
In order to avoid any electrical shock, short-circuit, burns, injury, or
fire:
Use only with the designated power supply 120 V.•
Do not scratch, damage, modify, forcibly bend, pull, twist, bind/clamp, or place heavy objects on•
the power cord.
Do not use if the power cord or plug is damaged, or if the plug is not fully inserted into the•
outlet.
Do not allow children to use this product by themselves, and keep product and power cords out•
of the reach of small children.
Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may•
cause an electric shock or fire, or damage the foot warmer.
Do not leave items like spray cans near the foot warmer.•
Do not use while clothing or a blanket is hanging on the foot warmer.•
Do not use while in bed.•
If you notice anything unusual during operation (burning smell, smoke, etc.), immediately stop•
use, and unplug the power cord.
Use a wall outlet rated at 15A or greater, with no other devices plugged in.•
Wipe off any dust adhering to the power plug blades and plug surface.•
After use, be sure to turn off the power, and unplug the power cord from the outlet.•
When cleaning the product, for safety's sake be sure to unplug it from the outlet.•
Do not disassemble. This product may only be disassembled by qualified repair technicians. To•
180200aT1CHMS-011USAll.indb3180200aT1CHMS-011USAll.indb3 2018/09/1411:09:362018/09/1411:09:36
4
English
request repair, see Warranty Page at the back of this manual.
Do not plug in or unplug the product while your hands are wet.•
Do not get the product wet.•
CAUTION
Always allow the unit to cool down before picking it up for service or storage.•
Do not use close to walls or furniture.•
Do not use in unstable locations or on flooring that may be easily damaged by heat.•
Never use in a location that produces flammable or corrosive gases, or where they accumulate.•
Do not use for other purposes, such as drying things.•
Do not leave the room while the foot warmer is on.•
Do not use it as a heater for dogs, cats, or other pets.•
When cleaning the product, do not use household detergent, thinner, benzene, alcohol or a•
polishing powder or spray.
Always keep the filter in place while operating the foot warmer.•
Do not touch places that get extremely hot, such as the hot air outlet during use or for some•
time afterwards.
180200aT1CHMS-011USAll.indb4180200aT1CHMS-011USAll.indb4 2018/09/1411:09:362018/09/1411:09:36
5
English
Names of Parts and Their Functions
Handle
Power switch (Power lamp)
Heater Lamp
Front
Back
Power cord
Power plug
[Filter cover + activated carbon filter] × 2
Bottom
Air intake
Hot air outlet
Activated carbon filter
Filter cover
180200aT1CHMS-011USAll.indb5180200aT1CHMS-011USAll.indb5 2018/09/1411:09:362018/09/1411:09:36
6
English
Correct Use of the Foot Warmer
Preparation Before Use
CAUTION
Always keep the filter case and the activated carbon filter in place while
running it.
Running without the filter case or activated carbon filter could result in fire or
damage to the product.
Attach the [filter cover + activated carbon filter] included in the main unit1.
on the two recesses on the back side of the unit.
1
1
2
2
Catch
Filter cover + activated carbon filter
Body recess
Remove the [filter cover + activated carbon filter] packaging.• As shown in the above figure, 1. Attach the front, 2. Push in the rear catch until• you hear a click.
Attach to the two left and right recesses in the same way.•
Place the foot warmer on a level surface.2.
Make sure nothing flammable is nearby; if there is something flammable, move it*
before using the foot warmer.
Keep the foot warmer an appropriate distance from walls and
surrounding objects (Otherwise, it could result in a fire.)
Do not use it in the following kinds of locations:
Unstable places, such as on a thick carpet or on top of a cushion (which may*
cause the unit to tilt, be unsteady or tip over), on easily flammable items (which
could result in a fire), tightly sealed spaces, etc.
About Safety Features
If the foot warmer falls over during use, it activates the tipover switch, turning the• power off.
If the foot warmer gets too hot, it activates the thermostat and automatically• shuts it off. (Once it cools down, it turns back on.) If the temperature gets even
hotter, it activates the thermal fuse, cutting off the operation circuit. (Even after
it cools down, it will not turn back on.) Please contact your dealer or the Service
Center (see the back cover).
180200aT1CHMS-011USAll.indb6180200aT1CHMS-011USAll.indb6 2018/09/1411:09:362018/09/1411:09:36
7
English
Auto switch-off function
When operation continues for about 8 hours, the front heater lamp and the power
turn off.
Turn OFF the power switch momentarily and turn it ON again when the Auto*
switch-off function operates.
Plug the power cord into the outlet.3.
Make sure that the operation switch is OFF, and then plug the power plug
into the power outlet.
WARNING
Use a wall outlet rated at 15A or greater, with no other devices plugged•
in.
If used with other devices plugged in, the outlet may heat abnormally and ignite.
Do not use while clothing is hanging on the foot warmer.•
Do not use the foot warmer with the power cord bundled up.•
If you are going out or will be away from the foot warmer for a long time,•
unplug the power cord from the outlet.
The foot warmer may have stopped due to the Safety Features. Since operation
will start automatically when the temperature goes down, you could forget to
turn it off or a fire could result.
The product is not a seat or a step, so do not sit or step on it.•
180200aT1CHMS-011USAll.indb7180200aT1CHMS-011USAll.indb7 2018/09/1411:09:362018/09/1411:09:36
8
English
Usage
Turn the power switch ON.1.
[ON]: ON
[OFF]: OFF
Operation starts and the foot warmer starts to warm up.
During operation, the front heater lamp (green) and the power lamp (power switch)
light up.
CAUTION
Do not leave the foot warmer unattended during use.•
Only move the foot warmer after it has cooled down, and use the handle.•
Do not touch the hot air outlet during use or for some time afterwards.•
Turn the power switch OFF after use2.
Unplug the power plug3.
180200aT1CHMS-011USAll.indb8180200aT1CHMS-011USAll.indb8 2018/09/1411:09:362018/09/1411:09:36
9
English
Cleaning and Storage
WARNING
When cleaning the product, be sure to unplug the power plug from the
outlet and check that the unit has cooled down.
Failing to do so can result in an electrical shock or burns.
CAUTION
Never use household detergent, thinner, benzene, alcohol, or polishing•
powder on this product.
When using a cloth containing chemical substances, follow its safety•
information.
When cleaning the product, do not use neutral detergent for tableware•
containing citrus ingredients such as orange or lime. Doing so could cause
discoloration or degradation of the plastic.
Cleaning the Foot Warmer
When the unit gets dirty, wipe it clean with a soft cloth dipped in warm
water and/or dish detergent (not citrus type) and well wrung out. Then
polish it gently with a dry cloth. (Do not rub hard on the plastic parts.
Doing so may scratch them.)
Cleaning the hot air outlet/air intake
For normal cleaning, suck up any dust with a vacuum cleaner.
180200aT1CHMS-011USAll.indb9180200aT1CHMS-011USAll.indb9 2018/09/1411:09:362018/09/1411:09:36
10
English
Replacing Activated Carbon Filters
Knob
Activated carbon filter
Filter cover
Catch
Activated carbon filter
Knob
Please attach so that there is nothing
protruding from the filter cover catch.
Filter cover
If the filters are torn, extremely dirty or lost, purchase new ones.
When purchasing activated carbon filters, contact the sales outlet where
you purchased the foot warmer or the Service Center.
Activated carbon filters are not free even during the warranty period.*
Replacement ACFT-CHMR011 filters are sold separately.
Please contact your dealer or the Service Center.
CAUTION
Always attach the activated carbon filter and filter cover except when
cleaning.
Failure to do so may cause foreign matter to enter the heater, causing accidents,
fire, or malfunction.
180200aT1CHMS-011USAll.indb10180200aT1CHMS-011USAll.indb10 2018/09/1411:09:362018/09/1411:09:36
11
English
Storage
After cleaning, let the foot warmer dry off completely.*
Put in a plastic bag or the like, then pack it back in the original product box with*
the User's Manual and store in a place with low humidity.
180200aT1CHMS-011USAll.indb11180200aT1CHMS-011USAll.indb11 2018/09/1411:09:362018/09/1411:09:36
12
English
Before Requesting Repairs or Service
WARNING
This product can be disassembled and repaired by qualified repair
technicians only.
If you find any problems, follow the troubleshooting procedures below.
Problem Primary Cause Solution
The power switch is
turned ON, but the
power lamp does not
light up and the unit
does not operate
The power cord is not
plugged into the outlet. Plug the power cord into the
outlet.
The power switch is
turned ON, and the
power lamp lights up,
but the unit does not
operate (the heater
lamp does not light
up)
Not located in a flat
stable location (tip over
function activated).
Check the location and locate the
unit in a flat, stable location.
The unit is hot and the
thermostat is working
(see page 7)
The unit will work when the
temperature cools.
If there is an object in the hot air
outlet or opening, please remove it
The hot air outlet/air intake may
be dirty and not be able to suck,
causing the temperature to rise.
Please clean the filter (see page 9)
The unit has been used
continuously for about
8 hours (the power was
automatically turned off
by the Auto switch-off
function (see page 7))
Turn OFF the power switch
momentarily and turn it ON again.
Safety equipment
(thermal-fuse) is
activated (See page 7).
Contact the sales outlet or the
service center.
180200aT1CHMS-011USAll.indb12180200aT1CHMS-011USAll.indb12 2018/09/1411:09:362018/09/1411:09:36
13
English
Specifications
Product name T1 Foot Heater
Power supply 110 / 120 V AC, 60Hz
Power consumption 130W
Heat source Heater
Safety features Tipover switch (internal type), thermal fuse, thermostat
Power cord length approx. 71 inches
External dimensions approx. Width 13 in × Depth 8 in × Height 11 in
Weight approx. 4 lbs
Accessories User's Manual and Warranty × 1, activated carbon
filter × 2 (already attached to the filter cover (must be
opened at the beginning of use))
Due to a continuous process of product improvement, the specifications and other information*
are subject to change without notice.
180200aT1CHMS-011USAll.indb13180200aT1CHMS-011USAll.indb13 2018/09/1411:09:362018/09/1411:09:36
English
LIMITED WARRANTY POLICY
Thank you for selecting our Products.
Please carefully read the User’s Manual furnished with this product.We believe that you will be very
satisfied with your purchase. We will provide the following LIMITED WARRANTY to you as the original
purchaser.
Should service be necessary for any reason due to manufacturing defect or malfunction during a
period of 90 days, OBJECTO will provide carry-in repair service at our FACTORY SERVICE CENTER at no
charge, and for the duration of the extended 9 months parts warranty period will replace the defective
part only, not including labor, provided the defect or malfunction is verified along with the date of
purchase. In the event service is necessary, you may return the unit to our FACTORY SERVICE CENTER
listed below.
Pack the unit in a well padded heavy corrugated box. Be certain that the unit is well protected.a) Enclose your check or money order payable to H.S.I in the amount of $40.00.b) Enclose copy of proof of purchase.c) Ship the unit prepaid via UPS or parcel post insured.d)
NOTE: This warranty does not cover:
OBJECTO products which have been damaged by negligence, misuse or accident or which havea) been modified or repaired by anyone other than our FACTORY SERVICE CENTER.
Damage to OBJECTO equipment that has been improperly connected to the equipment of otherb) manufacturers
Costs incurred in the shipping of OBJECTO products to our FACTORY SERVICE CENTER.c)
This warranty is valid only to the original purchaser and does not extend to owners of the product
subsequent to the original purchaser. Any applicable implied warranties, including the warranty of
merchantability, are limited in duration to a period of 90 days from the date of original purchase at
retail and no warranties, whether expressed or implied, shall apply to this product thereafter. Under no
circumstances shall OBJECTO be liable for any loss or damage, direct or consequential, arising out of
the use of, or inability to use this product. (Some states do not allow limitation or implied warranties
or exclusion of consequential damage, therefore these restrictions may not apply to you.)
This warranty gives you specific legal rights and you may also have other rights which may vary from
state to state.
The Limited Warranty Registry Card must be completely filled out and mailed immediately in ordera) to validate the Limited Warranty.
You must include a copy of your purchase slip when you are returning the unit.b)
Register your new product online at www.OBJECTO.com
SERVICE INFORMATION:
OBJECTO
935 BROADWAY, 6TH FL.
NEW YORK, NY 10010
TELEPHONE: (844) OBJECTO (844-625-3286)
FAX: 800-433-9099
WWW.OBJECTO.COM
9B18A
180200aT1CHMS-011USAll.indb14180200aT1CHMS-011USAll.indb14 2018/09/1411:09:362018/09/1411:09:36
MANUAL DE USUARIO
F
F
1
180200aT1CHMS-011USAll.indb1180200aT1CHMS-011USAll.indb1 2018/09/1411:09:362018/09/1411:09:36
2
Español
Información de seguridad
Esta sección presenta información de seguridad importante. Siga estas
instrucciones siempre que utilice el producto.
INSTRUCCIONES DE SEGURIDAD
IMPORTANTES
Al utilizar aparatos eléctricos, es necesario tomar algunas
precauciones básicas con el fin de reducir el riesgo de incendios,
descargas eléctricas y lesiones en las personas. Entre estas se incluyen:
1. Lea todas las instrucciones antes de utilizar este producto.
2. Este producto se calienta cuando está siendo usado. Para evitar quemaduras,
no deje que la piel descubierta toque superficies calientes. Utilizar el la asa para
mover este producto. Mantenga los materiales combustibles, como muebles,
almohadas, ropa de cama, prendas y cortinas a una distancia mínima de 1,6 pies
del calentador de pies y manténgalos alejados de los lados y la parte posterior.
3. Es necesario tomar la máxima precaución cuando el calentador de pies es utilizado
cerca de niños o de personas discapacitadas y siempre que el producto se vaya a
dejar en operación sin supervisión.
4. Desenchufe siempre el producto cuando no esté siendo utilizado.
5.
No opere ningún calentador de pies que tenga un cable o un enchufe dañado, o si
observa que el producto no funciona correctamente, si se ha caído o ha sido dañado
de alguna forma. Devuelva el producto a un centro de servicio autorizado si necesita
revisarlo, realizar algún tipo de ajuste mecánico o eléctrico en este o repararlo.
6. No lo utilice en el exterior.
7. Este producto NO ha sido diseñado para ser usado sobre mesas o escritorios;
utilícelo ÚNICAMENTE EN EL SUELO. No debe ser usado en lugares mojados o
húmedos, como baños o lavaderos. No coloque nunca el producto en lugares en
los que pudiera caer dentro de una bañera u otro recipiente de agua.
8. No coloque el cable debajo de ninguna alfombra. No cubra el cable con tapetes,
alfombras de pasillo ni accesorios para cubrir el suelo similares. No coloque el
cable por debajo de muebles u otros aparatos. Coloque el cable lejos de la zona
de tránsito para evitar tropezar con él.
9. Para desconectar el producto, gire los controles primero hacia la posición OFF
(apagado) y, a continuación, agarre el enchufe y tire de él para extraerlo del
tomacorriente. No tire nunca del cable.
10. No ingrese objetos extraños ni permita que estos se ingresen en las aberturas
de ventilación o de escape, ya que podría producirse un choque eléctrico o un
incendio, o el calentador de pies podría resultar dañado.
11. El calentador de pies tiene en su interior partes calientes o chispas. No lo use en
áreas en las que gasolina, pintura o líquidos inflamables estén siendo utilizados o
almacenados.
12.
Utilice este producto solo según se describe en este manual. Otro uso no recomendado
por el fabricante podría causar fuego, choque eléctrico o lesiones a las personas.
180200aT1CHMS-011USAll.indb2180200aT1CHMS-011USAll.indb2 2018/09/1411:09:362018/09/1411:09:36
3
Español
13. Enchufe siempre el producto directamente en el tomacorriente o en el receptáculo
de la pared. No lo utilice nunca con un cable de extensión o conector múltiple.
14. Para evitar un posible incendio, no bloquee las entradas o salidas de aire de
ningún modo.
No lo use sobre superficies blandas, como una cama, en la que las aberturas
pudieran verse bloqueadas.
15. Este aparato tiene un enchufe polarizado (un borne es más ancho que el otro).
Para reducir el riesgo de descarga eléctrica, este enchufe está diseñado para
que quepa en un tomacorriente polarizado en un único sentido. Si el enchufe
no encaja por completo en el tomacorriente, dé la vuelta al enchufe. Si sigue sin
encajar, contáctese con un electricista cualificado.
No modifique el enchufe de ningún modo.
16. a) Se provee un cable de suministro de alimentación corto (o cable de suministro
de alimentación desmontable corto) para reducir los riesgos resultantes de
quedarse enrollado o caerse por un cable de alimentación más largo.
b) Hay cables de extensión (o cables de alimentación desmontables más largos)
disponibles, y pueden ser usados si se tiene cuidado con su uso.
c) Si se usa un cable de extensión (o un cable de suministro de alimentación
desmontable más largo:
1) La potencia eléctrica marcada del cable de suministro de alimentación
desmontable o el cable de extensión debe ser como mínimo tan grande como la
potencia eléctrica del aparato;
2) Si el aparato es de tipo conexión a tierra, el cable de extensión debe ser un
cable de 3 hilos de tipo conexión a tierra; y
3) El cable más largo debe colocarse de manera que no se sitúe sobre una mesa
o encimera donde pueda provocar caídas, jalones o ser tirado de manera no
intencionada (especialmente por niños).
17.
GUARDE ESTAS INSTRUCCIONES
ADVERTENCIA
A fin de evitar choques eléctricos, cortocircuitos, quemaduras, lesiones
o un incendio:
Utilizar solo con la alimentación eléctrica designada: 120 V.•
No raspar, dañar, modificar, doblar por la fuerza, jalar, retorcer, unir/sujetar con abrazadera ni•
colocar objetos pesados sobre el cable de alimentación.
No utilizar si el cable de alimentación o el enchufe está dañado, o si el enchufe no está•
introducido por completo en el tomacorriente.
No permita que los niños utilicen este producto por su cuenta, y mantenga el producto y los•
cables de alimentación fuera del alcance de niños pequeños.
No ingrese objetos extraños ni permita que estos se ingresen en las aberturas de ventilación o•
de escape, ya que podría producirse un choque eléctrico o un incendio, o el calentador de pies
podría resultar dañado.
180200aT1CHMS-011USAll.indb3180200aT1CHMS-011USAll.indb3 2018/09/1411:09:362018/09/1411:09:36
4
Español
No deje objetos como latas de spray cerca del calentador de pies.•
No lo utilice cuando haya ropas o sábanas colgando del calentador de pies.•
No lo utilice mientras está en la cama.•
Si observa algo extraño durante la operación (olor a quemado, humo, etc.), deténgalo•
inmediatamente y desenchufe el cable de alimentación.
Utilice una toma de corriente de pared de 15 A o superior en la que no haya ningún otro•
dispositivo conectado.
Limpie el polvo de las clavijas y la superficie del enchufe.•
Después de utilizar el producto, asegúrese de apagarlo y desenchufe el cable de alimentación del•
tomacorriente.
Por su seguridad, asegúrese de desenchufar el producto del tomacorriente si va a limpiarlo.•
No desarme el producto. Este producto solo puede ser desarmado por técnicos en reparaciones•
calificados. Para solicitar una reparación, consulte la página de la Garantía al dorso de este
manual.
No enchufar ni desenchufar el producto si tiene las manos mojadas.•
No moje el producto.•
PRECAUCIÓN
Permita siempre que la unidad se enfríe antes de tomarla para servicio o almacenaje.•
No usar el producto cerca de paredes o muebles.•
No usar el producto en ubicaciones inestables ni en suelos que puedan resultar fácilmente•
dañados por el calor.
No usar el producto nunca en una ubicación que produzca gases inflamables o corrosivos, o en•
los que estos se acumulen.
No usar el producto para ningún otro propósito, por ejemplo para secar cosas.•
No salga de la sala mientras el calentador de pies esté encendido.•
No usar el producto como calentador para perros, gatos u otras mascotas.•
Al limpiar el producto, no utilice detergentes, solventes, benceno, alcohol ni polvos o spray•
abrillantadores para el hogar.
Mantenga siempre el filtro en su sitio al operar el calentador de pies.•
Durante el uso y un tiempo después, no toque partes que alcancen temperaturas•
extremadamente altas, como la salida de aire caliente.
180200aT1CHMS-011USAll.indb4180200aT1CHMS-011USAll.indb4 2018/09/1411:09:362018/09/1411:09:36
5
Español
Nombres de las piezas y sus funciones
Asa
Interruptor de alimentación (lámpara de
alimentación)
Lámpara del calentador
Parte frontal
Parte posterior
Cable de alimentación
Enchufe
[Cubierta del filtro + filtro de carbono activo] × 2
Parte inferior
Entrada de aire
Salida de aire caliente
Filtro de carbono activo
Cubierta del filtro
180200aT1CHMS-011USAll.indb5180200aT1CHMS-011USAll.indb5 2018/09/1411:09:362018/09/1411:09:36
6
Español
Uso correcto del calentador de pies
Preparativos previos al uso
PRECAUCIÓN
Siempre mantenga la caja del filtro y el filtro de carbono activo en su sitio al
operar el producto.
Operar el producto sin la caja del filtro o el filtro de carbono activo podría resultar
en un incendio o daños en el producto.
Acople el conjunto [cubierta del filtro + filtro de carbono activo] incluido en1.
la unidad principal en los dos huecos del lado posterior de la unidad.
1
1
2
2
Cierre
Cubierta del filtro + filtro de carbono
activo
Hueco en el cuerpo
Quite el empaquetado de [cubierta del filtro + filtro de carbono activo].• Como se muestra en la figura arriba, 1. Acople el frontal, 2. Empuje el cierre• posterior hasta que escuche un clic.
Acople los dos huecos izquierdo y derecho del mismo modo.•
Coloque el calentador de pies en una superficie nivelada.2.
Asegúrese de que no haya ningún objeto inflamable cerca; si lo hay, muévalo*
antes de utilizar el calentador de pies.
Mantenga el calentador de pies a una distancia apropiada de las
paredes y los objetos que lo rodean (de lo contrario, se podría
producir un incendio).
No lo utilice en los siguientes tipos de ubicaciones:
Lugares inestables, como una alfombra gruesa o sobre un cojín (que puede causar*
que la unidad se incline, esté inestable o se vuelque), sobre objetos fácilmente
inflamables (que puede resultar en un incendio), espacios muy sellados, etc.
Acerca de las características de seguridad
Si el calentador de pies se cae mientras es usado, activa el interruptor de vuelco• que apaga la alimentación.
Si el calentador de pies se calienta demasiado, activa el termostato y se apaga• automáticamente (cuando se enfría, se enciende nuevamente). Si la temperatura
aumenta más todavía, activa el fusible térmico y desconecta el circuito de
operación (incluso luego de enfriarse, no se enciende nuevamente). Contáctese
con su distribuidor o con el Centro de Mantenimiento (refiérase a la cubierta
posterior).
180200aT1CHMS-011USAll.indb6180200aT1CHMS-011USAll.indb6 2018/09/1411:09:362018/09/1411:09:36
Table of contents
Languages:
