OBO Bettermann GR-Magic User guide

06/2017 EN
Magic
® mesh cable tray system
Brief system instructions for GR-Magic®
Building Connections

Table of contents
1 General safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
2 Straight connection of mesh cable trays . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
2.1 Connection of of stock length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.1 Connection of cut mesh cable trays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3 Use of fittings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3.1 Integration of factory-created mesh cable tray bends . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.2 Mounting of factory-made mesh cable tray bends . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.3 Mesh cable tray bends created on-site with large radius . . . . . . . . . . . . . . . . . . . . . . . . . . 9
© 2013 OBO BETTERMANN GmbH & Co. KG
Reprinting, even of extracts, as well as photographic or electronic reproduction are prohibited.
1. General safety Information
kg
r
If cable support systems are touched with bare hands, then cutting could result on account of the
sharp edges. Always wear suitable protective gloves when handling system parts.
When working with the cable support system, in particular during shortening, e.g. with an angle
grinder, splinters and chips may result, which can cause injury. For this reason, wear personal
protective equipment (PPE) during mounting.
If the maximum load capacity is exceeded, the cable support system may collapse. Comply with
the load limits!
Cables can be damaged on bending. When inserting the cables, ensure that the minimum
bending radius, prescribed by the cable manufacturer, is observed.
.
.
.

Brief system instructions, Magic® mesh cable tray systems DE | 3
2. Straight connection of mesh cable trays
The GR-Magic® mesh cable tray system with shaped connector for screwless quick mounting
guarantees the shortest possible installation times, even for complex mounting operations.
1.1 Connection of lengths stock lengths
Fig. 2.1.1
Connect the mesh cable trays, as
shown.
Fig. 2.1.2
The three transverse wires
run in parallel when mounted.

OBO Bettermann
4 | DE
1.2 Connection of cut mesh cable trays
Fig. 2.2.2
Positioning and quantity of
mesh cable tray connectors.
Width 50‒150 mm = 2
Width 200‒300 mm = 3
Width 400 mm = 4
Width 450‒600 mm = 5
Fig. 2.2.3
Use of the quick connector
type GRS 3.9 or GRS 4.8 ana-
logue to the mesh cable tray wire
thickness. For use with mesh cable
trays up to a width of 150 mm.
Fig. 2.2.1
Use of the joint connector type
GSV 34.

Brief system instructions, Magic® mesh cable tray systems DE | 5
Fig. 2.2.4
Use of the quick connector
type GRV 245.
2.2 Connection of cut mesh cable trays

OBO Bettermann
6 | DE
3.2 Mesh cable tray bends created on-site with small radius
Below, you will find the cutting templates/samples of the mesh cable bends to be created
with a small radius.
155
100
370
105
150
370
Fig. 3.1.1
Mesh cable trays of type GRB
are integrated into the route using
joint connectors (GSV 34) and
corner connectors (GEV 36).
3.1 Mounting of factory-made mesh cable tray bends
3. Use of fittings
Besides the available mesh cable tray bends, flexible fittings can be created during construction.
Quantity according to
width
1x GEV 36
1x GSV 34
1x GSV 34

Brief system instructions, Magic® mesh cable tray systems DE | 7
115
200
530
115
300
530
3.2 Mesh cable tray bends created on-site with small radius
115
400
630
1x GSV 34
1x GSV 34
2x GSV 34

OBO Bettermann
8 | DE
115
500
730
115
600
830
3.2 Mesh cable tray bends created on-site with small radius
2x GSV 34
2x GSV 34

Brief system instructions, Magic® mesh cable tray systems DE | 9
3.3 Mesh cable tray bends created on-site with large radius
Below, you will find the cutting templates/samples of the mesh cable bends to be created
with a large radius.
100
320
108
150
556
363
200
684
441
300
939
598
1x GEV 36
3x GEV 36
4x GEV 36
5x GEV 36
1x GSV 34

OBO Bettermann
10 | DE
400
1,195
753
500
1,577
1,035
600
1,832
1,190
3.3 Mesh cable tray bends created on-site with large radius
7x GEV 36
9x GEV 36
11x GEV 36

Brief system instructions, Magic® mesh cable tray systems DE | 11
3.4 Reduction created on-site, asymmetrical
A reduction of the mesh cable tray width by 100 mm can be created.
100
GSV 34 joint connector
Please refer to Fig. 2.2.2 for the required
number minus one connector being replaced
by the GEV 36.
Fig. 3.4.1
Fig. 3.4.2
GEV 36 corner connector
GSV 34 joint connector
GSV 34 joint connector

OBO Bettermann
12 | DE
5050
3.4 Reduction created on-site, symmetrical
A reduction of the mesh cable tray width by 50 mm (Fig. 1, 2) or 100 mm (Fig. 3) can be created.
For the required number of GSV 34 joint connectors, please refer to Fig. 2.2.2, page 4.
When using the GEV 36 corner connector, the same number of GSV 34 joint connectors can be left out.
100100
GEV 36 corner con-
nector
GSV 34 joint connector
Fig. 3.4.3
Fig. 3.4.4
Fig. 3.4.5

Brief system instructions, Magic® mesh cable tray systems DE | 13
3.5 Earthing connection
Integration of the mesh cable trays into the equipotential bonding. Please refer to the installation
regulations valid for you for the number of connections.
Fig. 3.5.1 Integration of a cut mesh cable tray
Fig. 3.5.2. Integration in a Magic mesh cable tray connection
Joint connector, GSV 34
Earthing screw, EKL
Connection and
earthing terminal, VEK-GRM
Earthing screw, EKL

OBO Bettermann
14 | DE
3.6 Negative height offset created on-site
3.7 Positive height offset created on-site

Brief system instructions, Magic® mesh cable tray systems DE | 15
120
250
380
500
3.8 Falling mesh cable tray bends created on-site
120
250
380
500
3.9 Rising mesh cable tray bends created on-site

OBO Bettermann
16 | DE
4. Tee created on-site
Fig. 4.2
Notching out of the side grids on
both mesh cable trays to be con-
nected (see Fig. 1).
Fig. 4.1
Tee after
completion
Fig. 4.3
Bend the mesh cable trays as
shown.
Fig. 4.4
Mounting of the corner connector
type GEV 36 (2x) and the mesh
cable tray connector type GSV 34
in the base. Refer to Fig.
2.2.2 ,
page 4 for the number of type GSV
34 mesh cable tray connectors
in the base. If the GEV 36 corner
connector is used, the same num-
ber of GSV 36 joint connectors can
be left out.
2x GEV 36
GSV 34

Brief system instructions, Magic® mesh cable tray systems DE | 17
4.1 Vertical branch created on-site
Fig. 4.1.2
Notching out of the wires in the
base of the horizontally routed
mesh cable tray.
Fig. 4.1.3
Notching out of the side grids of
the vertically routed mesh cable
tray.
Fig. 4.1.4
Mounting of the mesh cable tray
connector type GSV 34 in the
base. Refer to Fig.
2.2.2 , page 4
for the number of type GSV 34
mesh cable tray connectors in the
base.
Fig. 4.1.1
Side view of the vertical branch
after completion.
GSV 34

OBO Bettermann GmbH & Co. KG
P.O. Box 1120
58694 Menden
GERMANY
Customer Service Germany
Tel. [phone]
Fax [phone]
expor[email protected]
OPTO 130038 Date 05/2017 EN
