odass OD-0703-AL User manual

www.odass.ca | [e-mail]
- 1 -
Model No :
OD-0703-AL INSTALLATION INSTRUCTIONS
TOWEL WARMER
This towel warmer is intended for the use in bathrooms or laundry areas. Read the instructions carefully before operating.
SPECIFICATION
Power consumption : 300W
Operating voltage : 120V
Operating temperature : Up to 55°
Maximum load : Each shelf 5kg and total 15kg
Power cord length : 1.5m cable
Measurement :
Open 147.5 (H) x 72 x 67cm
Folded 147.5 (H) x 72 x 9 cm
PANTONE 072 C
PANTONE 123 C Paper weight 60gsm
Open out the supports to 90o
Timer
Button
On/Off
Button
Control Panel
SAFETY INSTRUCTIONS
When using this EasyDry Foldaway Heated Airer,
please follow these basic safety precautions.
WARNING : This appliance can be used by children
aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
Children should be supervised not to play with the appliance.
Cleaning and user maintenance shall not be made by children.
Please read all instruction before using.
1. Please do not use the appliance if it has been dropped or da-
maged in any way.
2. Check the power cord regularly for signs of damage. Never at-
tempt to repair the appliance to replace the cord yourself as this
may lead to severe injury or electric shock. Call customer service
for replacement.
3. Never pull and carry the Airer by its power cord. Do not allow the
power cord to touch hot surfaces or sharp edges. Do not let it trail
over the edges where it may be pulled by children or tripped over.
4. Ensureallpackagingmaterialsareremovedbeforetherstuse.
5. Make sure your electricity supply matches the voltage shown on
the ratings label.
6. Do not connect this appliance to an external timer or re-
mote-control system.
7. We recommend to always plug directly into a wall socket. Howe-
ver, an extension lead may be used. The electrical rating of the
lead should be at least as great as the appliance
8. The Airer is for household and indoor use only. It is not sui-
table for commercial use or outdoor use. It must only be used
for its intended purpose.
9. To protect against electric shock, do not immerse the ap-
pliance, power cord or plug in water or other liquid.
10. The appliance must be placed on a level, dry and heat resis-
tant surface.
11. Always switch off and unplug the Airer after use, leaving it to
cool down completely before storing it away.
12. Do not wind the power cord around the appliance.
13. This Airer only operates in an upright position.
14. Do not leave plugged in overnight.
15. Do not use any accessories or attachments with this appliance
other than those recommended by seller.
16. Ensure the Airer is folded out securely before loading it with
laundry and switching it on.
17. When opening and closing the Airer, never use force. The
mechanisms should move freely and easily. Keep ngers
away from the folding parts
18. Do not overload the Airer, the maximum load of the Airer is
15kg. Load evenly across the surface to avoid the Airer tipping
over.

www.odass.ca | inf[email protected]
- 2 -
CAUTION : The plastic bubble bags used to wrap this appliance, or the packaging may be dangerous. To avoid risk of suffocation,
keep these bags out of reach of babies and children. These bags are not toys.
BEFORE FIRST TIME USE : Carefully unpack the Heated Tower Airer and remove any packaging, place the unit on a level, dry sur-
face ready for use.
NOTE : The appliance must be placed on a level, dry surface at least 1.5 meters away from any heat or water source
HOW TO SET UP THE AIRER:
1. Place the Airer on a dry level surface near a socket, with plenty
of space around it.
2. Open out the supports to a 90° angle
3. Slide all the shelf support clips (found on the two thinner sup-
ports), until they are facing straight out.
4. Stand at the side of the Airer that has the on/off switch and
openouttheshelves,startingwiththebottomshelfrst,then
the middle and then the top.
TO OPEN
 Shelvesopeninsequence-bottomshelfrst,thenmiddle,and
top shelf last.
TO CLOSE
 Shelves close in sequence - top shelf rst, then middle, and
bottom shelf last.
NOTE : There is a stopper on the top rail to ensure that the top
shelf cannot be over rotated.
IMPORTANT : If you force the shelf to rotate more than 90° (see
image below) you will break the shelf mechanism and invali-
date the warranty.

www.odass.ca | inf[email protected]
- 3 -
5. Now use the shelf support clip to secure the shelf, as shown in
the picture.
VERY IMPORTANT: The shelves should not be forced.
They naturally nd their position.
HOW TO OPERATE THE AIRER :
Ensure the Airer is folded out securely before loading it with laundry
and switching it on.
1. Make sure your electricity supply matches the voltage shown on
the ratings label then plug in the Airer.
2. Press On/Off button on the control panel. When it is on, the red
indicator light will turn on.
3. The Airer will heat up in 3 minutes.
4. Load evenly across the surface to avoid the Airer tipping over.
Clothes should be damp, not soaking wet. Wring out all
excess water rst. Do not overload the Airer, the maximum
load of the Airer is 15kg.
5. WhenyouhavenishedusingyourAirerswitchoffbypressing
the On/Off button again and unplug. Leave to cool down com-
pletely.
6. Tofoldclosed.StartwiththeTOPshelfrst,thenthemiddleand
then the bottom. Now fold the supports together so the Airer is
foldedat.
HOW TO USE TIMER :
1. Press On/Off button on the control panel. When it is on, the red
indicator light will turn on.
2. Press timer button to set Airer to 2 hours and press the same
button again to change setting to 4 hours. When desired time
has been selected, the corresponding light will turn blue and the
red light will turn off.
3. The Airer will stop heating and switch off automatically after set
hours have ended.
WHEEL ASSEMBLY :
To attach the wheels you will need a 12mm spanner.
BeginbylayingthefoldedAirieronasmooth,atsurfacebefore
you start assembling.
1. There are 4 wheels (Fig. 1), one for each of the 4 main supports
(Fig. 2).
2. Screw each wheel into the holes at the base of each support
(Fig. 3) and tighten using a 12mm spanner (Fig. 4).
3. Lock and unlock the wheels using the brake on the wheels (Fig.
5)
HOW TO HANG LONG ITEMS :
1. Unfold the Airer and open out the
bottom shelf
2. Leave the top two shelves in an
upright position and hang your
clothes from the top rail.
3. The shelves should not be
forced. They naturally nd their
position.
Red light = On 2 Hour Timer = Active 4 Hour Timer = Active
12345
6
6
6
6
6

www.odass.ca | inf[email protected]
- 4 -
LIMITED WARRANTIES
Odass warrants the product to be free from defects in workmanship
from the date of purchase.
These warranties extend only to the original owner/end-user for
personal household use and start from the date of purchase/billing.
This warranty cannot be transferred to a third party and additional
limitations apply for commercial uses.
In the eventuality that a manufacturing defect appears, the owner/
enduser must have in his possession, a proof of purchase as
well as a proof of installation by a professional recognized by the
construction industry.
Odass reserves the right to inspect on site, the defect by a repre-
sentative of is choice. Any return of goods will not be accepted
without the written authorization from Odass.
Odass cannot be held responsible about the defects or breaking
resulting from any act of god, accident, catastrophe, abuse, ne-
gligence, improper installation/use/maintenance, intensive varia-
tion of temperature, exposures to chemicals or stains caused by
differents types of water such as ferrous or alkaline water, etc. The
use of abrasives of any kind, gritting scraper, brushes or any other
scouring object which can damage the surface of the product is to
be proscribe and will cancel the present warranty.
Odass will be repaired or replaced (with a product of equal value)
to her discression of any product reported to the authorized dealer
or to Odass as being defective within the warranty period. Neither
the distributor, authorized Odass dealer nor any other person has
been authorized to make any afrmation, representation or war-
rantyotherthanthosecontainedinthewarranty;anyafrmation,
representation or warranty other than those contained in this war-
ranty shall not be enforceable against Odass or any other person.
This warranty excludes any expenses related to shipping, handling
and/or installation fees.
Odass cannot be held responsible for the fees of labor, wastes of
time, expenses of sundries or replacement of installation material,
including, but not limited to, tiles, marble, etc.
Odass reserves the right to modify this warranty at any time, it being
understoodthatsuchmodicationwillnotalterthewarrantycondi-
tions applicable at the time of the sale of the products in question
LIMITED WARRANTIES
Odass warrants for a period of 10 years, acrylic unit to be free
from defects in workmanship and materials under normal use and
service from the initial date of purchase by the owner/end-user,
contractor or builder.
Odasslifetimewarranty,chromeandnickelfaucetnish,roughand
cartridge.Also,5yearswarrantyfortheblackmatnish,hosefau-
cet of shower and bathtub to be free from defects in workmanship
and materials under normal use and service from the initial date of
purchase by the owner/end-user, contractor or builder.
Odass warrants for a period of 10 years, shower doors to be free
from defects in workmanship and materials under normal use and
service from the initial date of purchase by the owner/end-user,
contractor or builder.
Odass warrants for a period of 5 years, sanitary products (toilet,
lavatories basin) to be free from defects in workmanship and mate-
rials under normal use and service from the initial date of purchase
by the owner/end-user, contractor or builder.
Odass warrants for a period of 2 years, storage modules and va-
nities to be free from defects in workmanship and materials under
normal use and service from the initial date of purchase by the
owner/end-user, contractor or builder.
Odass warrants for a period of 2 years, glass mirrors to be free
from defects in workmanship and materials under normal use and
service from the initial date of purchase by the owner/end-user,
contractor or builder.
Odass warrants for a period of 2 years, electrical components to be
free from defects in workmanship and materials under normal use
and service from the initial date of purchase by the owner/end-user,
contractor or builder.
