ODE +SMART User manual

FOGLIO ISTRUZIONI PER UNITA’ DI CONTROLLO
INSTRUCTIONS FOR ELECTRONIC CONTROL UNIT
+SMART
1. PRINCIPIO DI FUNZIONAMENTO
Il dispositivo +SMART è un’unità di controllo avanzato che
combina le funzionalità PLC IEC 61131-3 e la connessione
Wi-Fi 802.11b/g/n.
Può essere utilizzato per tutte le elettrovalvole ODE,
dotate di solenoide con connessione EN 175301-803
(Ex DIN43650/A) e aventi una tensione nominale di 24V DC.
Grazie ai molteplici canali I/O è possibile connettere svari-
ate tipologie di sensori e attuatori.
Per ulteriori informazioni tecniche fare riferimento al
“Manuale Utente” e “Scheda Tecnica”.
2. CONNESSIONE USB
Il dispositivo +SMART è dotato di una porta di connessio-
ne USB con la quale è possibile connettere un PC per la
programmazione attraverso CODESYS, fare riferimento al
“Manuale Utente” per ulteriori informazioni.
Sequenza per poter accedere al connettore USB:
• svitare la vite centrale nel coperchio e rimuoverla;
• svitare le quattro viti ai lati del coperchio;
• rimuovere il coperchio;
• connettere un comune cavo dati USB dotato di con-
nessione Micro-B;
• per la programmazione il dispositivo deve essere ali-
mentato ed attendere il termine della fase di BOOT;
• togliere l’alimentazione prima di rimuovere la connes-
sione USB.
2. INDICAZIONI LED
LED verde | indica la presenza di alimentazione alla CPU.
LED rosso |indica lo stato operativo della CPU, du-
rante la fase di BOOT il LED avrà luce lampeggiante
due volte al secondo, una volta completato, il LED
lampeggierà una volta al secondo.
LED RGB | impostabile attraverso CODESYS, secondo
le esigenze del cliente.
3 . CONNESSIONI
Eseguire tutte le connessioni elettriche con il dispositivo
NON alimentato.
• Connettere il dispositivo +SMART al solenoide come un
comune connettore per elettrovalvole EN 175301-803
comma 5.3.1 (Ex DIN43650/A);
• assicurarsi di aver interposto la guarnizione tra bobina
e dispositivo;
• avvitare la vite centrale sul retro del connettore sino
al bloccaggio;
• connettere il cavo mutlipolare come da schema elet-
trico sotto riportato (fig.1)
Una volta terminate tutte le connessioni è possibile alimentare
il dispositivo.
Se una o più connessioni non vengono utilizzate, isolare i
cavi liberi con appropriati dispositivi.
5. RIAVVIO FORZATO
Per riavviare il dispositivo +SMART togliere l’alimentazione
per almeno 5 secondi. Durante il riavvio il dispositivo ese-
guirà nuovamente la fase di BOOT.
6. SUPPORTO TECNICO
Per informazioni dettagliate relative al dispositivo +SMART
ed alla programmazione fare riferimento al “Manuale
Utente”.
La documentazione relativa al prodotto è scaricabile dal
sito www.plusmart.it oppure www.ode.it.
Per richiedere supporto tecnico inviare una mail all’indiriz-
zo plusmart@ode.it oppure contattare il nostro Ufficio
Commerciale [email protected]
7. CONDIZIONI GENERALI
La ODE non è responsabile per danni causati da inosser-
vanza di questa informativa così come nel caso di inter-
venti impropri sulle elettrovalvole o sul dispositivo ad esse
connesso.
Inoltre la garanzia per dispositivi ed accessori sarà conside-
rata non valida.
ITALIANO
fig. 1
VCC/RED
VCC/RED
0V/BLACK
0V/BLACK
PINK/GRAY
YELLOW
V1 V2
0-10V 0-10V
PURPLE
BLUE
4-20mA 4-20mA
12
GNDA BLACK/WHITE
GRAY
OUT1 OPEN-COLLECTOR
VCC1
RED/BLUE
OUT2 OPEN-COLLECTOR
VCC2
PINK
OUT3 OPEN-COLLECTOR
VCC3
POWER SUPPLY
24 Vdc
BROWN
IN1
WHITE
GREEN
IN3
0V/BLACK
EARTH YELLOW/GREEN
+ SMART
SOLENOID VALVE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
11
IN2

Questi dati sono chiaramente indicati nella documentazione
tecnica (Scheda tecnica, Manuale Utente, ecc.)
La mancata osservanza di queste istruzioni può provocare
danni a cose e/o persone.
IMPORTANTE
QUESTE ISTRUZIONI SONO INDICATIVE PER UN
CORRETTO USO DEL DISPOSITIVO +SMART, MA NON
SOSTITUISCONO IN ALCUN MODO IL CATALOGO,
OVE SONO INDICATE TUTTE LE SPECIFICHE PROPRIE
DI OGNI DISPOSITIVO. PER VENTUALI CHIARIMENTI
CONTATTARE IL NOSTRO UFFICIO COMMERCIALE.
1. PRINCIPLE OF OPERATION
The +SMART device is an advanced control unit that com-
bines PLC IEC 61131-3 and Wi-Fi 802.11b/g/n connection.
The +SMART device can be used for all ODE’s solenoid valve,
equipped coil with EN 175301-803
(Ex DIN43650/A) electrical connection and power supply
24V DC .
Thanks of multi-channel I/O it is possible to connect to
various type of sensor and actuator.
For further technical information please refer to “User’s
Guide” and “Datasheet”.
2. USB CONNECTION
The +SMART device is equipped with USB connection port
with which is possible to connect a PC for programming
through CODESYS, please refer to “User’s Guide” for addi-
tional information.
Mounting sequence for the access to USB connection
• unscrew the central screw and remove it;
• unscrew the four screw at the side of cover;
• remove the cover;
• connect a common data USB cable with Micro-B
connector;
• For programming the device must to be powered
end wait until BOOT step is finished;
• switch OFF the power before removing USB connection.
2. LED INDICATORS
Green LED | indicates the presence of CPU power
supply.
Red LED | indicates operative state of CPU, during
BOOT step LED blink tow time at second, when it’s
completed LED will blink one time at second.
RGB LED | LED is customizable with CODESYS accor-
ding to customer’s needs.
3. CONNECTIONS
Make all electrical connection with device not powered.
• Connect the +SMART device to the coil like a
common solenoid valve connector EN 175301-803
(Ex DIN43650/A);
• be sure that gasket is between coil and device;
• then fasten the central screw on rear side of connec-
tor until the screw is blocked.
• multipolar connect the cable as per wiring diagram (fig.1).
When whole connections are finished it is possible to power
ON the supply.
If one or more connections are not used, the free cables
must to be isolated with specific device.
5. FORZCED RESTART
To restar the +SMART device power OFF the supply for at
least 5 seconds. During restart the device will redo BOOT step.
6. TECHNICAL SUPPORT
For detailed information related to +SMART device and its
programming please refer to “User’s Guide”.
The documentation related to the product can be down-
loaded from internet site www.plusmart.it or www.ode.it
To request technical support please send an e-mail to
7 . GENERAL CONDITIONS
ODE is not responsible for damages caused by any failure
to comply with this statement as well as in the case of
improper action on the device or on the solenoid valve
connected to it.
This information is clearly stated in the technical documen-
tation (datasheet, user’s guide, etc.).
Failure to observe the safety instruction may lead to default
of claims.
IMPORTANT
THESE INSTRUCTIONS ARE INTENDED AS A GUIDE FOR
CORRECT USE OF DEVICE +SMART, BUT IN ANY EVENT
DO NOT SUBSTITUITE THE CATALOG, WHICH PROVIDES
FULL DETAILS OF ALL TECHNICAL FEATURES OF EACH
+SMART DEVICES. CONTACT OUR SALES OFFICE FOR
ANY FURTHER CLARIFICATIONS.
ENGLISH
ed. 10/2020 - 300081 - 003
ODE reserves the right to make any changes without prior notice - ©ODE - All rights reserved
