OEM PD7000 User manual

User’s Manual
Multimedia Customer Pole Display

Contents
1. General Information.......................................1
1.1 Features.................................................................................................. 2
1.2 Size............................................................................................................2
1.3 Introduction and Specifications.....................................................3
2. Standard Package................. 错误！未定义书签。
3. Hareware Installation......................................3
4. Driver Installation............................................4
5. Test.................................................................... 5
6. Promo Graphics Replacement......................... 7

1
1. General Information
PD7000 customer pole display with TFT-LCD monitor and 2x20 characters is designed to
replace traditional VFD customer pole display. It can be used for delivering latest promotion
information to customer. With a 300cd/ ㎡brightness and 800 x 480 optimal resolution, the
screen projects vivid graphics (full-screen picture and half-screen picture) to grab customer
attention at the POS, enhancing your overall business experience.
PD7000 media display can emulate many popular VFD serial port customer display
command sets, retailers/software engineers do not need to go through difficult setup process
and modify their existing program and system. RS232 port or USB port powered, no external
power adapter. Both connections require power DC5V.
1.1 Features
1.2 Size

2
1.3 Introduction and Specifications
TFT 7" LCD monitor
Supports graphics display (in JPG/BMP format)
Supports different language character sets (English/French/Spanish/Russian/Portuguese
etc.)
20 characters X2 lines
Emulates popular customer pole display command sets
RS-232 port or USB port powered (optional), no external power adapter
Software programming: ESC/POS, CD5220, UTC, OPOS
Viewing angle: -5°~60°
Maximum adjustable angle:270°
Simple installation
Optional pole height (3 kinds of height)
Optional shell color: white, black or custom color
NO
Item
Description
1
Display Method
TFT 7" LCD monitor
2
Number of character
20 characters X2 lines
3
Character font
800X480 Dot matrix
4
Display back-light
LED back light
5
Brightness
350 cd/㎡
6
Language
English/French/Spanish/Russian/Portuguese/Italy
7
Font size
24X48/48X48 dot
8
Power supply
DC5V/1000MA
9
Power consumption
3.5W
10
MTBF
30000 Hours (power on time)
11
Communication Interface
RS232/ USB2.0 (optional)
12
Baud Rate
2400/9600BPS
13
Package size
260X205X120mm
14
Operating temperature
-30—50℃
15
Operating Humidity
30%—80%
16
Storage temperature
-40--60℃
17
Storage Humidity
10%-90%
18
Pole display command
ESC/POS ADM787/788 DSP800 AEDEX NCR
POS PD6000 UTC-S UTC-E CD5220
19
OPOS system
Epson OPOS
20
Height
170 mm with stand-alone base
290 mm with base and 1 support
410 mm with base and 2 supports
21
Panel dimension
185(W)X115(H)X55(D)mm
22
Support dimension (1pcs)
120mm
23
Base dimension
182(W)X85(H)X115(D)mm
24
Weight
1.5KG

3
2. Standard Package
1pcs Module with cable
2pcs Support
1pcs Base
1pcs RS232 cable or USB cable (optional)
1pcs CD
3. Hareware Installation
Assembling steps:
Step 1: Attach the two supports to the base.
Step 2: Pass the display cable through the supports and base (insert the cable into the
hole); Connect the cable to the port on the base.

4
Step 3:
For PD7000 customer pole display with RS232 interface, connect the RS232 cable to
the computer. Connection requires power DC5V, 750mA.
For PD7000 customer pole display with USB interface, connect the USB cable to the
the computer. Connection requires power DC5V, 750mA.
Step 4: Turn on the computer, the display will be on and show a self-diagnostic status.
There will be slides (full-screen pictures and half-screen pictures) displayed on the monitor.
The resolution of full-screen picture is 800X480ppi, half-screen picture’s is 400X480ppi.
Picture format: JPG BMP
4. Driver Installation
For PD7000 customer pole display with RS232 interface, there is no need to install
driver, it can work directly after turning on the computer (jump to the test).
For PD7000 customer pole display with USB interface, it requires installing USB to
PL2303 driver.
Installing steps:
Step 1: Run and install “PL2303_Prolific_DriverInstaller_v1.8.0” program.
Follow the installation guide, click “Finish”.

5
Step 2: When finished, disconnect the customer display connector from the computer and then
connect it to the computer again. Back to the computer desktop, right-click “Computer”, select
“Properties” from the context menu. Find and click “Device Manager”, a window pops up:
Double-click “Ports (COM and LPT)”, there will be a port named “Prolific USB-to-Serial Comm
Port (COM3)”, remember this “COM3” port to prepare for test and device working.
5. Test
PD7000 customer pole display can emulate many popular VFD serial port customer
display command sets.
Test steps:
Step 1: Open testing program “D7000 COMMAND SET”.

6
Step 2: Select “COM3” next to the “Ports” which shows up right after driver installation.
Baud Rate: 9600，Data Bits:8, Stop Bits:1. (Default protocol: 9600bps, non-parity, 8 data bits,
1 stop bit.)
Step 3: When finished, input any text in appropriate langu or numbers into the boxes，
click “Send Content”. Check the text or numbers are displayed on the display or not. Or
click“Auto Demo”, the device will be on self-inspection. If there is no problem, test is done.

7
6. Promo Graphics Replacement
PD7000 customer pole display can display digital image and promotional graphics.
Replacement steps:
Step 1: Connect PD7000 customer pole display to the computer, open testing program
“PD7000 COMMAND SET”. Select “COM3” next to “Ports”, then select “1-USB OPEN”
next to “Command” to invoke the U disk function.
Step 2: Back to the computer desktop. Open “Computer”, you will see an U disk named
“DISPLAY”. Open the U disk, some folders are in it. Full-screen pictures is in folder
“pic_full”, half-screen pictures is in folder “pic_half”.

8
Step 3: Put the new pictures (in JPG or BMP format) into appropriate folder. The
resolution of full-screen picture should be 800X480ppi, the half-screen picture’s resolution
should be 400X480ppi. The name of new picture must be the same as the initial picture’s in
the folder. For example, if you want to replace initial picture “f001”, the new one must be
also named “f001”, thus delete the old one. See the figure shows as below:
Before Replacement

9
After Replacement
Step 4: Back to the testing program, select “2-USB END” next to “Command” . Click
“Send”to shut down the U disk function.
Step 5: Close the testing program, restart computer，reconnect the display to the
computer. Graphics replacement done.
