OfficeSource OSBHAT4860SI User manual

1
ENGLISH
2 Leg / 1 Motor
OSBHAT4860SI
SINGLE MOTOR 2 STAGE HEIGHT ADJUSTABLE BASE
®
OFFICE FURNITURE
MODEL NO. OSBHAT4860
OFFICESOURCE.COM
Last Updated: 01/2022
ASSEMBLY INSTRUCTIONS
Page 1 of 8
MODEL NO. OSBHAT4860
OFFICESOURCE.COM
ASSEMBLY INSTRUCTIONS
Last Updated: 3/2023

2
ASSEMBLY GUIDE
Table of contents
1. General
• 1.1 Local value of the user manual
• 1.2 Intended use
2. Safety Information
• 2.1 Informal safety measures
• 2.2 Use of the adjustable frame
• 2.3 Specific Dangers
• 2.4 In an emergency
• 2.5 Maintenance
• 2.6 Cleaning
3. Packaging
• 3.1 Packing
• 3.2 Part Check List
• 3.3 Screw List
4. Assembly
• 4.1 Torque Guide
• 4.2 Assembly Step by Step
5. Operating Instructions
• 5.1 General Operation
omni
®
OFFICE FURNITURE
MODEL NO. OSBHAT4860
OFFICESOURCE.COM
Last Updated: 01/2022
ASSEMBLY INSTRUCTIONS
Page 2 of 8
MODEL NO. OSBHAT4860
OFFICESOURCE.COM
ASSEMBLY INSTRUCTIONS
Last Updated: 3/2023

3
ASSEMBLY GUIDE
1.1 Local value of the user manual
The guiding principle for safe use and trouble-free operation of this adjustable frame is the knowledge of basic safety information
and regulations. This user manual includes the most important information needed for assembling and operating the adjustable
frame safely. More importantly, the safety information about the adjustable frame must be observed at all times.
1.2 Intended use
The adjustable frame must be used only as a workstation for sitting / standing within the oce environment or other indoor areas.
Please observe the provision of section 2, Safety Information. Children may be unaware of the dangers caused by the adjustable
frame if unsupervised. Any other use except the above should be considered improper. The manufacturer can in no way be held
liable for damage arising from improper use.
1. General
2. Safety Information
When installing and using electrical equipment, basic safety precaution should always be followed to avoid a risk of fire, elec-
tric shock, or injury to persons.
2.1 Informal safety measures
• Keep the user manual in the place where the adjustable frame is used at all times.
• Keep children away from the appliance when operation.
2.2 Use of the adjustable frame
• When adjusting upwards and downwards, make sure that no persons or items will collide with the frame.
• Don’t use the adjustable frame on an uneven surface, or it will not be steady.
• Never exceed the maximum load capacity on the adjustable frame. Please check the load capacity in Section 7, Specification.
• The control unit is only used for specified linear actuator, don’t use appliances not recommended by the manufacturer.
2.3 Specific Dangers
• When assembling and operating the adjustable frame, make sure there is enough space to avoid collisions in all available
directions.
• Don’t pull, push or lift the frame if operating. Make sure to avoid twisting the legs.
• Insert the plug only into a proper socket. If it does not fit, contact a qualified electrician to install the proper outlet. Don’t change
the plug in any way.
• Be aware that the control box can only be connected to the voltage printed on the label.
2.4 In an emergency
• Stop using the adjustable frame immediately if you notice anything unusual (strange sounds etc.).
• The frame should be repaired by professional sta. Stop using the adjustable frame until it has been successfully repaired.
• Any other emergencies please contact customer services.
2.5 Maintenance
• The adjustable frame and its components are low-maintenance items and need no special regular maintenance.
• Any broken components removed must be replaced with new, original components made by the manufacturer.
• Don’t alter the construction of the adjustable frame.
2.6 Cleaning
• Clean the frame once a week with a dry cloth.
• Clean the frame with a damp cloth and a weak solution of cleaner once every two weeks.
Any changes or modification not expressly approved by the manufacturer could void the user’s authority to
operate the equipment.
omni
®
OFFICE FURNITURE
MODEL NO. OSBHAT4860
OFFICESOURCE.COM
Last Updated: 01/2022
ASSEMBLY INSTRUCTIONS
Page 3 of 8
MODEL NO. OSBHAT4860
OFFICESOURCE.COM
ASSEMBLY INSTRUCTIONS
Last Updated: 3/2023

4
ASSEMBLY GUIDE
3. Packaging
3.1 Packing
• Open the packaging box carefully. Don’t use any long knife blades which will damage the components inside.
• Check the parts supplied against the list in Section 3.2.
• Don’t attempt to assemble the adjustable frame if there is any damage or if there are any incorrect components.
3.2 Part Check List
Carton Box Size (L:1080mm x H:275mm x W:185mm)
Parts displayed above may vary, based upon Frame Configuration
End Pipe (2 Pcs)
Gear Connection (1Pcs) Connection Cable (1 Pcs)
Left Leg (1 Pcs) Right Leg (1 Pcs)
Power Cable (1 Pcs)
Feet (2 Pcs)Frame (2 Pcs)
Control Unit (1 Pcs)Remote Control (1 Pcs)
M6x12 (4 Pcs) M6x8 (4 Pcs) ST 4.8x16 (8 Pcs)
3.3 Screw Check List
omni
Allen Key 4mm (1 Pcs) Allen Key 5mm（1Pcs）
®
OFFICE FURNITURE
MODEL NO. OSBHAT4860
OFFICESOURCE.COM
Last Updated: 01/2022
ASSEMBLY INSTRUCTIONS
Page 4 of 8
MODEL NO. OSBHAT4860
OFFICESOURCE.COM
ASSEMBLY INSTRUCTIONS
Last Updated: 3/2023

5
ASSEMBLY GUIDE
3. Packaging
3.4 Screw Part List
Feet Matching Screw (8 Pcs)
1Plastic
Remote Control Matching Screw (2 Pcs)
1
2
3
4
ST 4.2x19
ST 2.9x16
M6x30
omni
Remote Control Matching Screw (2 Pcs)
ST 4.2x19
®
OFFICE FURNITURE
MODEL NO. OSBHAT4860
OFFICESOURCE.COM
Last Updated: 01/2022
ASSEMBLY INSTRUCTIONS
Page 5 of 8
MODEL NO. OSBHAT4860
OFFICESOURCE.COM
ASSEMBLY INSTRUCTIONS
Last Updated: 3/2023

6
ASSEMBLY GUIDE
4. Assembly
Before attempting assembly of the Height Adjustable Frame, please read safety information in Section 2.
4.1 Torque Guide
Max torque
• M6 Screw’s max torque = 6nm
• M8 Screw’s max torque = 6nm
• M10 Screw’s max torque = 6nm
• Tapping screws is hand tightening only
4.2 Assembly Step by Step
M6X8
Step 3
Assemble the Leg and Frame as illustrated above. Please refer to
Torque Guide.
M6X12
Step 2
Mount the End Pipe to leg as illustrated above.
Step 1
Mount the Feet as illustrated above. Please refer to Screw Part List
select the appropriate feet and the matching screw. Please refer to
Torque Guide.
Step 4
Adjust Top Frame to suitable length.
omni
®
OFFICE FURNITURE
MODEL NO. OSBHAT4860
OFFICESOURCE.COM
Last Updated: 01/2022
ASSEMBLY INSTRUCTIONS
Page 6 of 8
MODEL NO. OSBHAT4860
OFFICESOURCE.COM
ASSEMBLY INSTRUCTIONS
Last Updated: 3/2023

7
ASSEMBLY GUIDE
Do not put power to the system before it is fully assembled.
4. Assembly
4.2 Assembly Step by Step
Step 6
Mount the Gear Connection to Leg as illustrated above.
Step 5
Loosen the Gear Connection rotating nut as illustrated above.
ST 4.8x16
Step 9
Mount the Control Unit as illustrated above.
ST 4.8x16
Step 7
Mount the Frame and End Pipe to the Table top as illustrated above.
Please refer to Torque Guide.
Step 8
Connect the Cables to the Control Unit as illustrated above.
Step 10
Connect the Connection Cable to the Leg as illustrated above.
omni
®
OFFICE FURNITURE
MODEL NO. OSBHAT4860
OFFICESOURCE.COM
Last Updated: 01/2022
ASSEMBLY INSTRUCTIONS
Page 7 of 8
MODEL NO. OSBHAT4860
OFFICESOURCE.COM
ASSEMBLY INSTRUCTIONS
Last Updated: 3/2023

8
ASSEMBLY GUIDE
4. Assembly
4.2 Assembly Step by Step
Step 11
Mount the Remote Control to the Table top as illustrated above.
Please refer to Screw Part List select the appropriate RC and the
matching screw. Please refer to Torque Guide.
-
5. Operating Instructions
5.1 General Operation
Please read below instructions carefully before operating the system.
Up Down
Setting Button
SMemory Position 1
1
Memory Position 3
3
Memory Position 2
2
omni
Up Down
®
