PARTS INSTRUCTIONS
PART DESCRIPTION QTY
1
Pre-assembled Seat
Cushion, Arms,
Mechanism and
Wood Base
1
21
3
1
4
3” Big Screws 2
5Ottoman Base
2
6
1” Big Screws
2
7
Back Cushion
4
8
Nuts
¾” Small Screws
3
9
3
10
Spring Washer
Flat Washer 3
12
1
13
14
Hexagonal Wrench
INSTRUCTIONS
A. Remove all parts from the carton and separate them into part number groups as indicated in the parts list.
B. Lift and place the Back Cushion (2) on the Seat Cushion (1), then open the zipper located on the Back
Cushion (2) and align the holes on the Back Cushion (2) with the holes on the Arms (1) and attach by using
the 3” Big Screws (6). After tightening the screws, close the zipper.
C. After assembling the Back Cushion (2) to the Arms (1), loosen the tension adjustment knob located on the right
side of the recliner and slide the seat forward. While pulling slightly on the Back Cushion (2) from behind the
recliner, align the metal connection points at the bottom of the Back Cushion (2) to the rear of the Seat
Cushion (1). Insert 1” Big Screws (7) through the metal connection points, using Nuts (8) and then tighten
them with Wrenches (13 & 14).
.
E.
Attach the Ottoman Base (5) on top of the Ottoman Central Post (4) by using 1¾” Big Screws (10).
with Spring Washers (11) and Flat Washers (12). Tighten all screws. Turn the ottoman upright.
CUSTOMER SERVICE HOTLINE
800-626-6060
ATTENTION:
Make certain to fully tighten all screws
before using chair.
ASSEMBLY INSTRUCTIONS
Congratulations on the purchase of your new chair!
OMEGA LEATHER RECLINER WITH OTTOMAN
11
1
1¾” Big Screws
Wrench
Ottoman Cushion 1
Ottoman Central
Post 1
D. Place the Ottoman Cushion (3) upside down on the carpet and attach the Ottoman Central Post (4) (with front of
ottoman central post facing front of ottoman cushion). Tighten with the ¾” Small Screws(9).
Two people are recommended for back cushion assembly!
D E
B C
1
1
2
6
2
78
10
5
4
9
3
11
13
13
14
12
FRONT
F R O N T
F R O N T
F R O N T
4
13
13
