Officine Gullo GGS8P User manual

INSTRUCTIONS
FOR INSTALLATION AND USE
GGS8P - GGS12P - GGPS8P - GGPS12P
GES8P - GES12P - GEPS8P - GEPS12P
RANGE WITH OVEN FOR RESIDENTIAL AND PROFESSIONAL USE

3
Ofcine Gullo
INDEX
INSTALLATION MANUAL
DECLARATION OF COMPLIANCE ..........................................................................................17
GAS TECHNICAL DATA TABLE ...............................................................................................17
ELECTRIC TECHNICAL DATA TABLE .........................................................................................18
INSTALLATION.....................................................................................................................18
CHECKING FOR ADEQUATE VENTILATION.............................................................................19
PIPE FOR GAS CONNECTION..............................................................................................19
ELECTRIC CONNECTION.....................................................................................................20
EQUIPOTENTIAL ..................................................................................................................20
CHECKING HEAT OUTPUT ...................................................................................................20
CHECKING PRIMARY AIR TO THE MAIN BURNERS AND PILOT NOZZLES ...................................21
BURNER TECHNICAL DATA TABLE ..........................................................................................21
RULES FOR CONVERTING AND INSTALLING OTHER TYPES OF GAS ..........................................23
CHANGING THE OPEN RING NOZZLES ...............................................................................23
SUBSTITUTING THE NOZZLE IN THE OVEN BURNER ...............................................................23
SUBSTITUTING THE NOZZLE IN THE COUP DE FEU BURNER.....................................................23
CHECKING FUNCTIONING.................................................................................................24
MAINTENANCE..................................................................................................................24
SPARE PARTS .......................................................................................................................24
USER MANUAL
INSTRUCTIONS FOR USE .....................................................................................................25
LIGHTING AND ADJUSTING THE BURNERS.............................................................................25
LIGHTING AND ADJUSTING THE COUP DE FEU ......................................................................25
LIGHTING AND REGULATING GAS OVEN BURNER .................................................................26
LIGHTING AND REGULATING THE ELECTRIC OVEN.................................................................26
CLEANING AND MAINTENANCE.........................................................................................27
WHAT TO DO IN THE EVENT OF A BREAKDOWN..................................................................28
PROCEDURE TO FOLLOW IF THE APPLIANCE IS NOT GOING TO BE USED FOR SOME TIME........28
MAINTENANCE (only for qualied personnel)...........................................................................28
INSTRUCTIONS FOR DISCHARGING GAS EMISSIONS ............................................................28
FES8
ELECTRIC OVEN FOR RESIDENTIAL AND PROFESSIONAL USE

3
Ofcine Gullo
INDEX
INSTALLATION MANUAL
DECLARATION OF COMPLIANCE ..........................................................................................17
GAS TECHNICAL DATA TABLE ...............................................................................................17
ELECTRIC TECHNICAL DATA TABLE .........................................................................................18
INSTALLATION.....................................................................................................................18
CHECKING FOR ADEQUATE VENTILATION.............................................................................19
PIPE FOR GAS CONNECTION..............................................................................................19
ELECTRIC CONNECTION.....................................................................................................20
EQUIPOTENTIAL ..................................................................................................................20
CHECKING HEAT OUTPUT ...................................................................................................20
CHECKING PRIMARY AIR TO THE MAIN BURNERS AND PILOT NOZZLES ...................................21
BURNER TECHNICAL DATA TABLE ..........................................................................................21
RULES FOR CONVERTING AND INSTALLING OTHER TYPES OF GAS ..........................................23
CHANGING THE OPEN RING NOZZLES ...............................................................................23
SUBSTITUTING THE NOZZLE IN THE OVEN BURNER ...............................................................23
SUBSTITUTING THE NOZZLE IN THE COUP DE FEU BURNER.....................................................23
CHECKING FUNCTIONING.................................................................................................24
MAINTENANCE..................................................................................................................24
SPARE PARTS .......................................................................................................................24
USER MANUAL
INSTRUCTIONS FOR USE .....................................................................................................25
LIGHTING AND ADJUSTING THE BURNERS.............................................................................25
LIGHTING AND ADJUSTING THE COUP DE FEU ......................................................................25
LIGHTING AND REGULATING GAS OVEN BURNER .................................................................26
LIGHTING AND REGULATING THE ELECTRIC OVEN.................................................................26
CLEANING AND MAINTENANCE.........................................................................................27
WHAT TO DO IN THE EVENT OF A BREAKDOWN..................................................................28
PROCEDURE TO FOLLOW IF THE APPLIANCE IS NOT GOING TO BE USED FOR SOME TIME........28
MAINTENANCE (only for qualied personnel)...........................................................................28
INSTRUCTIONS FOR DISCHARGING GAS EMISSIONS ............................................................28
FES8
ELECTRIC OVEN FOR RESIDENTIAL AND PROFESSIONAL USE

Ofcine Gullo4
E.Electrical Connection
G. Gas Connection
INSTALLATION MANUAL
Fig. A/1
GES8P
5
Ofcine Gullo
E.Electrical Connection
G. Gas Connection
Fig. A/2
GES12P

5
Ofcine Gullo
E.Electrical Connection
G. Gas Connection
Fig. A/2
GES12P

Ofcine Gullo6
E.Electrical Connection
G. Gas Connection
Fig. A/3
GEPS8P
7
Ofcine Gullo
E.Electrical Connection
G. Gas Connection
Fig. A/4
GEPS12P

7
Ofcine Gullo
E.Electrical Connection
G. Gas Connection
Fig. A/4
GEPS12P

Ofcine Gullo8
E.Electrical Connection
G. Gas Connection
Fig. A/5
GGS8P
9
Ofcine Gullo
E.Electrical Connection
G. Gas Connection
Fig. A/6
GGS12P

9
Ofcine Gullo
E.Electrical Connection
G. Gas Connection
Fig. A/6
GGS12P

Ofcine Gullo10
E.Electrical Connection
G. Gas Connection
Fig. A/7
GGPS8P
11
Ofcine Gullo
E.Electrical Connection
G. Gas Connection
Fig. A/8
GGPS12P

11
Ofcine Gullo
E.Electrical Connection
G. Gas Connection
Fig. A/8
GGPS12P

Ofcine Gullo12
4
FIG. H (FORNO, FOUR, BACKOFEN, OVEN, HORNO)
1
Iniettore forno Einspritzventil backofen Injecteur four Oven Injector Inyector horno
2
Regolazione aria forno Luftregelung Backofen Réglage d'air four Oven air regulation Regulación aire horno
FIG.I
(FORNO, FOUR, BACKOFEN, OVEN, HORNO)
1 Iniettore pilota Einspritzv. ZündBrenner Injecteur veilleuse Pilot Injector Inyector piloto
2 Candela accensione Zündkerze Bougie d'allumage Lighting spark plug Candela encendido
3 Termocoppia Thermoelement Thermocouple Thermocouple Termopar
4 Staffa pilota Bügel Leitflamme Bride veilleuse Pilot bracket Brida del piloto
FIG. J
(FORNO, FOUR, BACKOFEN, OVEN, HORNO)
1
2
1
2
3
4
H
Fig. B
1. Cooking rings by-pass 2. Oven by-pass
Fig. C
1. Injector cooking rings
2. Air regulation
3. Lighting spark plug
4. Thermocouple
3
FIG. D
1 By-pass fuochi aperti Bypass flamme By-pass feux Cooking rings by-pass By-pass fuegos
2 By-pass forno Backofen Bypass By-pass four Oven by-pass By-pass horno
FIG. F PC…-GP , CF…-GP
(FUOCHI, FLAMME, FEUX, COOKING RINGS, FUEGOS)
562047300M00P00
1
2
3
4
1 Iniettore fuochi Einspritzventil flamme Injecteur feux Injector cooking rings Inyector fuegos
2 Regolazione aria Luftregelung Réglage d'air Air regulation Regulación aire
3 Candela accensione Zündkerze Bougie d'allumage Lighting spark plug Candela encendido
4 Termocoppia Thermoelement Thermocouple Thermocouple Termopar
13
Ofcine Gullo
4
FIG. H (FORNO, FOUR, BACKOFEN, OVEN, HORNO)
1
Iniettore forno Einspritzventil backofen Injecteur four Oven Injector Inyector horno
2
Regolazione aria forno Luftregelung Backofen Réglage d'air four Oven air regulation Regulación aire horno
FIG.I
(FORNO, FOUR, BACKOFEN, OVEN, HORNO)
1 Iniettore pilota Einspritzv. ZündBrenner Injecteur veilleuse Pilot Injector Inyector piloto
2 Candela accensione Zündkerze Bougie d'allumage Lighting spark plug Candela encendido
3 Termocoppia Thermoelement Thermocouple Thermocouple Termopar
4 Staffa pilota Bügel Leitflamme Bride veilleuse Pilot bracket Brida del piloto
FIG. J
(FORNO, FOUR, BACKOFEN, OVEN, HORNO)
1
2
1
2
3
4
H
1. Oven injector 2. Oven air regulation
1. Pilot injector
2. Lighting spark plug
3. Thermocouple
4. Pilot bracket
Fig. E (oven)
Fig. D (oven)
Fig. F (oven)

13
Ofcine Gullo
4
FIG. H (FORNO, FOUR, BACKOFEN, OVEN, HORNO)
1
Iniettore forno Einspritzventil backofen Injecteur four Oven Injector Inyector horno
2
Regolazione aria forno Luftregelung Backofen Réglage d'air four Oven air regulation Regulación aire horno
FIG.I
(FORNO, FOUR, BACKOFEN, OVEN, HORNO)
1 Iniettore pilota Einspritzv. ZündBrenner Injecteur veilleuse Pilot Injector Inyector piloto
2 Candela accensione Zündkerze Bougie d'allumage Lighting spark plug Candela encendido
3 Termocoppia Thermoelement Thermocouple Thermocouple Termopar
4 Staffa pilota Bügel Leitflamme Bride veilleuse Pilot bracket Brida del piloto
FIG. J
(FORNO, FOUR, BACKOFEN, OVEN, HORNO)
1
2
1
2
3
4
H
1. Oven injector 2. Oven air regulation
1. Pilot injector
2. Lighting spark plug
3. Thermocouple
4. Pilot bracket
Fig. E (oven)
Fig. D (oven)
Fig. F (oven)

Ofcine Gullo14
Fig. G
Coup de feu
1. Injector
2. Pilot
15
Ofcine Gullo
ELECTRICAL SCHEME TOP

1. Electrical connection
2. Push-button starting burner
3/4. Power-station starting burner
Fig. H

15
Ofcine Gullo
ELECTRICAL SCHEME TOP

1. Electrical connection
2. Push-button starting burner
3/4. Power-station starting burner
Fig. H

Ofcine Gullo16
WIRING DIAGRAM STATIC OVEN GN2/1
1. Commutator
2. Junction-box
3. Element
4. White light
5. Green light
6. Thermostat
7. Safety thermostat
Fig. I
17
Ofcine Gullo
DECLARATION OF COMPLIANCE
This appliance is manufactured by OFFICINE GULLO S.r.l
Headquarters and factory
Via Della Torricella 29, Antella, Bagno a Ripoli
50012 Florence - Italy
Tel. [phone]
[phone]
ofcinegullo.com | info@ofcinegullo.com
The manufacturer declares that the appliances are compliant with the prescriptions of the EEC norm 2009/142
for the gas part and with norm 2006/95/CE, 2004/108/CE for the electric part. The installation must be done
observing the norms in force particularly concerning room ventilation and discharging gas emissions.
N.B.: The manufacturer declines any responsibility for direct or indirect damage caused by improper or incorrect
installation, alterations, maintenance or use of the appliance, as in all the other cases considered in the items of our
sales conditions.
GAS TECHNICAL DATA TABLE
MODEL Dimensions
cm
NOMINAL BURNER CAPACITY kW
TOT. NOM.
CAPACITY
kW Gas coupling
ISO 7-1
Burner
3,5 kW
Burner
5,5 kW
Burner
7,5 kW
Coup de
feu
7 kW
Gas
oven
7,3 kW
Gas
GGS8P 80x70x90h 1 2 1 - 1 29,3 R3/4GM
GES8P 80x70x90h 1 2 1 - - 22 R3/4GM
GGS12P 120x70x90h 1 3 2 - 1 42,3 R3/4GM
GES12P 120x70x90h 1 3 2 - - 35 R3/4GM
GGPS8P 80x70x90h - 1 1 1 1 27,3 R3/4GM
GEPS8P 80x70x90h - 1 1 1 - 20 R1/2GM
3/4GM(1007)
GGPS12P 120x70x90h 1 2 1 1 1 36,3 R3/4GM
GEPS12P 120x70x90h 1 2 1 1 - 29 R3/4GM

17
Ofcine Gullo
DECLARATION OF COMPLIANCE
This appliance is manufactured by OFFICINE GULLO S.r.l
Headquarters and factory
Via Della Torricella 29, Antella, Bagno a Ripoli
50012 Florence - Italy
Tel. [phone]
[phone]
ofcinegullo.com | info@ofcinegullo.com
The manufacturer declares that the appliances are compliant with the prescriptions of the EEC norm 2009/142
for the gas part and with norm 2006/95/CE, 2004/108/CE for the electric part. The installation must be done
observing the norms in force particularly concerning room ventilation and discharging gas emissions.
N.B.: The manufacturer declines any responsibility for direct or indirect damage caused by improper or incorrect
installation, alterations, maintenance or use of the appliance, as in all the other cases considered in the items of our
sales conditions.
GAS TECHNICAL DATA TABLE
MODEL Dimensions
cm
NOMINAL BURNER CAPACITY kW
TOT. NOM.
CAPACITY
kW Gas coupling
ISO 7-1
Burner
3,5 kW
Burner
5,5 kW
Burner
7,5 kW
Coup de
feu
7 kW
Gas
oven
7,3 kW
Gas
GGS8P 80x70x90h 1 2 1 - 1 29,3 R3/4GM
GES8P 80x70x90h 1 2 1 - - 22 R3/4GM
GGS12P 120x70x90h 1 3 2 - 1 42,3 R3/4GM
GES12P 120x70x90h 1 3 2 - - 35 R3/4GM
GGPS8P 80x70x90h - 1 1 1 1 27,3 R3/4GM
GEPS8P 80x70x90h - 1 1 1 - 20 R1/2GM
3/4GM(1007)
GGPS12P 120x70x90h 1 2 1 1 1 36,3 R3/4GM
GEPS12P 120x70x90h 1 2 1 1 - 29 R3/4GM

Ofcine Gullo18
ELECTRIC TECHNICAL DATA TABLE
MODEL Dimensions
cm Power Supply
Tot.
power
(KW)
Max.
absorb
A
Power
supply
cable mm²
GGS8P 80x70x90h 230V~ 50/60 Hz 0,01 0,04 5x1
GES8P 80x70x90h 400V~3N 50/60 Hz 5 10,4 5x1,5
GGS12P 120x70x90h 230V~ 50/60 Hz 0,01 0,04 5x1
GES12P 120x70x90h 400V~3N 50/60 Hz 5 10,4 5x1,5
GGPS8P 80x70x90h 230V~ 50/60 Hz 0,01 0,04 5x1
GEPS8P 80x70x90h 400V~3N 50/60 Hz 5 10,4 5x1,5
GGPS12P 120x70x90h 230V~ 50/60 Hz 0,01 0,04 5x1
GEPS12P 120x70x90h 400V~3N 50/60 Hz 5 10,4 5x1,5
INSTALLATION
• The operations for installing, conversions for use with other types of gas and starting up must be done only
by qualied personnel whose qualications comply with the norms in force.
• Gas installations, the electrical connections and the rooms in which the appliances are installed must comply
with the norms in force in the Country in which the installation is carried out; above all, the appliance must
be installed in a well ventilated room, preferably under an extractor hood, so as to ensure the complete
extraction of gas emissions which are formed during combustion. The air necessary for combustion is
2m3/h per kW of power installed.
Attention: In accordance with international rules, when connecting the appliance, an automatic device enabling the
disconnection of all contacts from the mains, must be installed above it; this device must have a contacts opening
of at least 3 mm.
19
Ofcine Gullo
CHECKING FOR ADEQUATE VENTILATION
Make sure that the air intake into the room where the appliance is installed is sufcient for an adequate change of air, as
specied by regulations in effect.
The appliances installed in buildings open to the public must satisfy the following requirements.
Installation rules
The installation and maintenance of the appliance must be done according to the correct procedures and regulation
texts in use, particularly:
• safety standards for the prevention of re and panic.
Connection and installation of appliance, ventilation and exhaust removal systems, shall be done according to the
Manufacturer’s instructions and by qualied technicians and according to the regulations in effect. The electric wiring shall
conform to the regulations in effect.
All re prevention codes shall be observed.
a) General indications (Rules valid for GB only)
- For all appliances:
Gas safety Regulations, 1984; Health and safety at Work Act, 1974 Codes of Practice, BS 8173, 1982, The Building
Regulations 1985; The Building Standards Regulations, 1981, the IEE Regulations and the by-laws of the local Water
Undertaking.
The local gas Region or LPG supplier and the local authority and the relevant recommendation of the British Standards
(latest editions) concerned.
The installation, transformation and repair of appliances for professional kitchens as well as removal due to malfunction,
and the supply of gas, may be made only by means of a maintenance contract stipulated with an authorized sales ofce
and in observance of technical regulations.
The appliance can be installed by itself or in a series side by side with appliances produced by us.
There must be a minimum distance of at least 10 cm between the appliance and the sides of the nearby cabinets made
of inammable material.
Take suitable measures to guarantee thermal insulation of the inammable sides, such as, for example, the installation of
protection against radiation.
The appliances must be installed in a suitable manner, observing the safety standards.
The small feet are adjustable to level the appliance.
PIPE FOR GAS CONNECTION
The gas connection must be done with steel or copper pipes, or otherwise with exible steel pipes in compliance
with the national norms, if any exist. Each appliance must be provided with a cut-off cock for rapid interruption of the
gas supply. Once the appliance has been installed, it is necessary to check for gas leaks for the pipe ttings; do not
use a ame for this purpose but a non-corrosive substance such as soapy water or foamy substances as contained
in leaknder sprays. All our appliances undergo careful testing: the type of gas, the operating pressure and the
category are indicated on the data plate.
NB: The year of the appliance manufacture is shown in item “N” on the data plate. The rst two numbers (e.g. 08..)
represent the year of manufacture.

19
Ofcine Gullo
CHECKING FOR ADEQUATE VENTILATION
Make sure that the air intake into the room where the appliance is installed is sufcient for an adequate change of air, as
specied by regulations in effect.
The appliances installed in buildings open to the public must satisfy the following requirements.
Installation rules
The installation and maintenance of the appliance must be done according to the correct procedures and regulation
texts in use, particularly:
• safety standards for the prevention of re and panic.
Connection and installation of appliance, ventilation and exhaust removal systems, shall be done according to the
Manufacturer’s instructions and by qualied technicians and according to the regulations in effect. The electric wiring shall
conform to the regulations in effect.
All re prevention codes shall be observed.
a) General indications (Rules valid for GB only)
- For all appliances:
Gas safety Regulations, 1984; Health and safety at Work Act, 1974 Codes of Practice, BS 8173, 1982, The Building
Regulations 1985; The Building Standards Regulations, 1981, the IEE Regulations and the by-laws of the local Water
Undertaking.
The local gas Region or LPG supplier and the local authority and the relevant recommendation of the British Standards
(latest editions) concerned.
The installation, transformation and repair of appliances for professional kitchens as well as removal due to malfunction,
and the supply of gas, may be made only by means of a maintenance contract stipulated with an authorized sales ofce
and in observance of technical regulations.
The appliance can be installed by itself or in a series side by side with appliances produced by us.
There must be a minimum distance of at least 10 cm between the appliance and the sides of the nearby cabinets made
of inammable material.
Take suitable measures to guarantee thermal insulation of the inammable sides, such as, for example, the installation of
protection against radiation.
The appliances must be installed in a suitable manner, observing the safety standards.
The small feet are adjustable to level the appliance.
PIPE FOR GAS CONNECTION
The gas connection must be done with steel or copper pipes, or otherwise with exible steel pipes in compliance
with the national norms, if any exist. Each appliance must be provided with a cut-off cock for rapid interruption of the
gas supply. Once the appliance has been installed, it is necessary to check for gas leaks for the pipe ttings; do not
use a ame for this purpose but a non-corrosive substance such as soapy water or foamy substances as contained
in leaknder sprays. All our appliances undergo careful testing: the type of gas, the operating pressure and the
category are indicated on the data plate.
NB: The year of the appliance manufacture is shown in item “N” on the data plate. The rst two numbers (e.g. 08..)
represent the year of manufacture.

Ofcine Gullo20
ELECTRIC CONNECTION
The appliance is supplied without the connection cable; to install it, proceed in the following way:
- Remove the back panel
- Push the connection cable through the cable channel, connect the conductor wires to the corresponding terminals
in the junction box and x them into place.
- Block the cable with the cable blocker, and reassemble the panel. The earth wire must be longer than the others so
that if the cable blocker should break, it will disconnect after the tension wires.
N.B. The connection cable must have the following characteristics: it must be type H05RN-F and must have an
adequate section for the power of the appliance (see technical data table).
EQUIPOTENTIAL
The appliance must be connected to an equipotential system.
The connection screw is positioned at the back of the appliance and is identied by the symbol .
Attention! The manufacturer will neither be held responsible for, nor will give any compensation during the guarantee
period for any damage caused, and which is due to inadequate installations not compliant with the instructions.
CHECKING HEAT OUTPUT
The appliances must be checked in such a way as to verify that the heat output is correct:
• The heat output (thermal power) is indicated on the data plate of the appliance;
• Firstly, check that the appliance can be used with the type of gas supplied; then check that the indication
on the plate corresponds to the gas to be used. For converting to another type of gas, check that the type
of gas complies with what is stated in this instruction manual.
The pressure is read with a gauge (minimum resolution of 0.1 mbar) inserted in the relative pressure outlet.
Remove the hermetically closed screw and insert the gauge pipe.
After reading, put back the screw tightening it hermetically and check for pressure leaks.
Connection for liquid gas G30/G31
The connection pressure for liquid gas is 30 mbar with butane and 37 mbar with propane.
Check the plate, read the pressure and verify that the description of the nozzle installed corresponds to the one
supplied by the manufacturer.
Connection with natural gas H G20
The connection pressure for natural gas is 20 mbar.
Check the plate, read the pressure and verify that the description of the nozzle installed corresponds to the one
supplied by the manufacturer.
21
Ofcine Gullo
CHECKING PRIMARY AIR TO THE MAIN BURNERS AND PILOT NOZZLES
All the burners are tted with an air regulator by means of which the primary air can be varied thanks to an adjustable
bush that can be locked with a screw. In the Burner Technical Data table you will nd the approximate values for the
“h” parameter (primary air). The ow of primary air must be regulated so there is no detachment of the ame when the
burner is cold or a return of the ame when the burner is hot.
The pilot air is regulated when the appliance is tested and inspected for the gas it is set for.
If you are going to change to a different type of gas, regulate the air by means of the adjusting bush until the ame
stops sputtering and becomes an intense blue colour.
BURNER TECHNICAL DATA TABLE
Burner max 3,5 kW- min. 1,15 kW
12,8 kWh/kg
G30
BUTANE
30 mbar
12,8kWh/kg
G31
PROPANE
37 mbar
9,45 kWh/m
3
st.
G20
NATURAL GAS H
20 mbar
Burner injector 1/100 mm
Min. output adjustment 1/100 mm
Consumption
Primary air h=mm
90
50
kg/h 0,276
open
90
50
kg/h 0,272
open
145
adjustable
m3 st./h 0,370
open
Burner max 5,5 kW- min. 1,55 kW
Burner injector 1/100 mm
Min. output adjustment 1/100 mm
Consumption
Primary air h=mm
115
60
kg/h 0,434
open
115
60
kg/h 0,427
open
175
adjustable
m3 st./h 0,582
20
Burner max 7,5 kW- min. 2,5 kW
Burner injector 1/100 mm
Min. output adjustment 1/100 mm
Consumption
Primary air h=mm
135
75
kg/h 0,591
20
135
75
kg/h 0,582
20
205
adjustable
m3 st./h 0,794
20
Coup de feu
Burner max 7 kW- min. 4 kW
Burner injector 1/100 mm
Min. output adjustment 1/100 mm
Pilot Injector 1/100 mm
Consumption
130A
100
20
kg/h 0,552
130A
100
20
kg/h 0,544
195
adjustable
35
m3 st./h 0,740
Oven Burner max 7,3 kW- min. 2,2 kW
Burner injector 1/100 mm
Min. output adjustment 1/100 mm
Pilot Injector
Consumption
Primary air h=mm
145
75
1x19
0.570 kg/h
12
145
75
1x19
0.570 kg/h
12
205
adjustable
1x27
0.772 m3 st./h
12
Oven Burner max 11 kW- min. 3,5 kW
Burner injector 1/100 mm
Min. output adjustment 1/100 mm
Pilot Injector
Consumption
Primary air h=mm
175
100
1x19
0.859 kg/h
13
175
100
1x19
0.859 kg/h
13
270
adjustable
1x27
1.164 m3 st./h
13
