OHDIOLAB ATOM+ User manual

ATOM+
User Manual

WHAT’S IN THE BOX
Atom+
Charging Case Atom+Earbuds Ear Tips (S, M, L)
USB-C
Charging Cable Carry Pouch
1

OVERVIEW
LED Indicator & Microphone
Multi-Function Button
Charging Pins
Battery LED Indicators
Type-C Charging Port
2

FIRST TIME USE
•Activate the earphones by placing both earbuds into the
charging case.
•Before using for the first time, charge the battery to full for
optimum battery capacity and lifetime.
•Use only the original USB-C charging cable provided to avoid
any damage.
HOW TO PAIR
1. Power on the earbuds by removing them from the charging case. The earbuds will turn
on automatically and enter into pairing mode. Alternatively, press and hold both buttons
simultaneously until the earbud LED flashes white.
2. Search for ‘
T1
’ in the Bluetooth menu on your mobile device and tap to pair.
3

WEARING
•Insert each earbud into your ear and adjust them
so that they fit comfortably.
•Ensure the microphones are pointed towards your
mouth.
•Choose the most suitable ear tip size (S/M/L) for
your ears for a comfortable fit and better sound
experience.
CLEANING
•Gently clean the areas with a lightly damp cloth.
•Do not use any alcohol or chemicals other than water to clean as they may damage the
products.
4

RESET
Resetting the earbuds clears the list of paired devices and resets all settings.
1. Power off both earbuds by press and hold the buttons simultaneously for 3 seconds
until the LED blinks red light and off.
2. Press and hold the buttons of both earbuds again for 10 seconds until LED flicker red
and white and then stop blinking.
3. Put both earbuds back into the charging case and wait for a few seconds.
4. Earbuds are now reset.
The earbuds will need to be paired to your mobile device again. Remember to
remove/forget the pairing in the Bluetooth menu on your mobile device.
5

CHARGING
Charging the Earbuds
•Place both earbuds into their corresponding slots in the
charging case to start charging.
•Earbuds LED indicator will flash red light while charging and
changes to white once fully charged.
Charging the Charging Case
•Connect the supplied USB-C cable into the charging port and
plug it into a USB power supply or certified wall charger to
charge the case.
•It takes up to 1.5 hours to fully charge the earbuds and the
charging case.
•Battery LED indicators are at the front of the charging case.
Each LED light indicates there is 25%, 50%, 75%, 100% battery
in sequence.
Charging
Port
6

POWER CONTROL
Power On
Remove both earbuds from the charging case.
Alternatively, press and hold the button for 1s.
Power Off
Place both earbuds back into the charging case.
Alternatively, press and hold the button for 3s.
VOICE CONTROL
Activate Voice Assistant
Press and hold the button on either Left or Right earbud for 2s.
7

PHONE CONTROL
Answer/Hang Up Call
Press the button once to answer, press again to hang up.
Reject a Call
Press and hold the button for 1s.
Mute On/Off
While on a call, press the button 2 times to mute or unmute.
Switch Audio Output
While on a call, press and hold the button for 1s to switch audio output between your
smartphone and earbuds.
Re-dial Last Calling Number
Press the button 4 times.
8

MUSIC CONTROL
Play/Pause Music
Press the button once on either Left or Right earbud.
Play Next Song
Press the button 2 times on either Left or Right earbud.
Play Previous Song
Press the button 3 times on either Left or Right earbud.
9

SPECIFICATIONS
•Model: Atom+
•Bluetooth Version: 5.0
•Bluetooth Profile: HSP, HFP, A2DP, AVRCP
•Connection Range: Up to 15 meters
•Waterproof Level: IPX6
•Playtime
•Music Time: Up to 7 hours*
•Talk Time: Up to 8 hours*
•Standby Time: Up to 52 hours
•Charging Time: Approx. 1 hours
•Battery Type: Lithium-ion
•Connector Type: USB-C
•Battery Capacity
•Charging Case: 600mAh
•Earbud: 50mAh
•Dimensions
•Earbud: L27 x W15 x H16 mm
•Charging Case: L44 x W44 x H35 mm
•Net Weight: 40g
10
*Duration of use may vary depending on the connected mobile device, features being used, settings, signal strength,
operating temperature, frequency band, and other methods of use.

PRECAUTIONS & USAGE
•Do not disassemble, adjust, or repair the product arbitrarily.
•Do not use the product while driving or when your hearing is needed to perceive dangers
from your surroundings.
•Do not blast music at an uncomfortable high volume as it may result in hearing loss.
•Do not use the product in strong electromagnetic interference and radiation
environments.
•Charge the product again if not used for over 1 month.
WARNING
•Do not expose the product to extreme temperatures (under 0°C or over 45°C).
•Do not store the product in a wet or dusty environment.
•Do not place heavy objects on the product.
•Do not drop the product from a high place.
•Do not submerge the product in the water.
•Do not disassemble, adjust, or repair the product arbitrarily.
•Do not use any cleaning agents containing alcohol, ammonia, benzene, or abrasives.
11

Complies with
IMDA Standards
DA108378
Designed in Germany
Made in China
