Ohenry 10’x40’ High Peak Frame Tent
Ohenry Productions Inc. 3859 Chappel Hill Rd. Waco, TX. 76705
[phone] Oce [phone] Fax

Ohenry 10’x40’ Frame Tent
Ohenry Productions Inc. 3859 Chappel Hill Rd. Waco, TX. 76705
[phone] Oce [phone] Fax

Fittings
4 Corner Fitting
23 Way Crown
1 HP Ridge Top “T”
6Side T Joint
2Ridge Top T’s
10 Premium Base Plates
68 Canopy Pins
10 24” Stakes
10 1” Ratchet Straps
10 Guy Ropes
3 High Peak Masts
Poles
12 9’ 4” Speaders
4 6’ 10” Hip Rafters
6 4’ 11” Rafters
2 4’ 4” Top Spreaders
10 6’ 8” Legs
Ohenry Productions Inc. 3859 Chappel Hill Rd. Waco, TX. 76705
[phone] Oce [phone] Fax
Part Identication
3 Way Center Crown Premium Base Plate
Side T
Ridge Top T
Corner Fitting Canopy Pin
Center Mast High Peak Top “T”)

6’ 10” Hip Rafter
Ohenry Productions Inc. 3859 Chappel Hill Rd. Waco, TX. 76705
[phone] Oce [phone] Fax
6’ 10” Hip Rafter
9’ 4” Spreader
4’ 11” Rafter
9’ 4” Spreader
4’ 11” Rafter
4’ 11” Rafter
9’ 4” Spreader
9’ 4” Spreader
9’ 4” Spreader
9’ 4” Spreader
9’ 4” Spreader
9’ 4” Spreader
4’ 4” Spreader
4’ 4” Spreader

Ohenry Productions Inc. 3859 Chappel Hill Rd. Waco, TX. 76705
[phone] Oce [phone] Fax
“OHENRY WEST COAST FRAME TENT” ASSEMBLY INSTUCTIONS
10’ wide – 20’ wide
All tubing is labeled for easy Identication.
Please verify the parts with the chart provided before you begin assembly.
Assembly Steps:
1. Lay out the Spreader pipes and Corner Fittings in a square or rectangle (refer to previous page). Lay out Hip Rafters and Rafters
and Side T Joints. Place Center Crown(s) in the center of the tent.
2. Start assembling the frame by inserting and pinning the Hip Rafters into the Center Crown(s). If assembling a rectangular frame
insert and pin the appropriate Spreader into the Center Crown and continue to the next Ridge Top T or Center Crown. Insert and pin
Rafters into the Crowns and Ridge Top T’s. Insert and pin all Corner Fittings and Side T Joints to the bottom of the Hip Rafters and
Rafters.
3. Start at one corner of the frame and insert and pin the Corner Fitting to the Spreader. Continue in one direction around the frame
inserting and pinning each tting to the Spreaders.
4. Unfold the tent cover on the ground next to the assembled frame. Place the cover on the frame. Be sure to center the cover
while the upper structure is still on the ground.

5. Lift one side of the tent and attach the legs (with base plates) and insert the pins. It is recommended that two people be available
when lifting the frame to install legs.
6) Push the square mast up through one of the 3-way
crowns on each end of tent from the bottom.
7) Push the removeable mast top into the hole in the
center of the tent, then insert the top piece back into the
mast and secure with a canopy pin
8) Push the mast up until the holes in the bottom of
mast align with the holes in the bottom of the 3-way
crown.
9) Secure mast to 3-way crown with canopy pins. Re-
peat steps 6-9 for the center High Peak top T.

Ohenry Productions Inc. 3859 Chappel Hill Rd. Waco, TX. 76705
[phone] Oce [phone] Fax
10. Lift the other side of the tent and attach the legs (with base plates).
11) Next you will attach the end of the ratchet strap which has the metal clip (ratchets are included with your tent top) to the
rings in the tent top at the corners and depending on size, the other locations on the tent top perimeter which have rings attached.
Next attach the other end of each ratchet which has a ring attached to the base as shown in the photograph below. Tighten ratchet
enought to have a slight tension. Do the same for each leg. Be sure tent is aligned correctly on the frame, and then retighten all the
ratchets attached to the tent top and base plates as shown.
12) At each leg, now drive a tent stake into the ground about 5’ from the edge of the tent. Attach the Guy Ropes provided with
your tents and tighten securely to the tent stake. provided. In the event of high winds, the cover should be removed
from the frame to prevent damage to your tent. Your tent should be vacated during inclement weather.
