OKAI EA10A User manual

The manufacturer reserves the right to change and release product firmware
updates and to keep this manual up to date.
https://www.okai.co

EA10A
Instruction Manual

Contents
1-1.Technical Data 03
1-2.Symbol Explanations
1-3.List of finished product and parts
1.Introduction
2.Intended Use
3.Safety Instructions
3-1.General safety instructions
05
06
07
08
3-2.Battery safety precautions 11
3-3. Safety instructions for battery charger
4.How To Use
4-1.Using the product for the first time
4-2.Charging the battery
4-3.Ride preparation
12
12
24
24
5.Maintenance,Cleaning and Service
5-1.Maintain
5-2.Clean
5-3.Storage and transportation
25
25
25
6.Handling
7.Explanation Of Error Codes
26
26
01
02
08
25
11

Thank you for purchasing the OKAI electric scooter.
1.Introduction
Thank you for purchasing the OKAI electric scooter.
OKAI sincerely hopes that you can ride the scooter safely and enjoy a comfortable riding
experience. Since riding a scooter carries certain risks, please read this practical manual
carefully before riding, and adequately prepare before going on the road. Please keep
the instruction manual in case you need it from time to time. If you give the electric
scooter to others, please also provide them with this user manual. Failure to comply
with this user manual may cause serious injury to people or cause damage to the
product. OKAI does not assume any responsibility for this. In order to be concise and
easy to read, the OKAI E-Scooter will be referred to as “product” in the following
Content.
02

03
1-1.Technical Data
Item Content EA10A
Vehicle
Specifications
Battery
Specifications
Motor
Specifications
Dimensions(Unfolding):
length,width,height 1145*533*1045mm
1145*554 *614mm
20%
26.5KG
Dimensions(folding):
length,width,height
N.W.
25KM/H
≤40Km
Maximum Speed
*Range
Maximum Gradient
Adapted Terrain Pavement
Operating Temperature 0~40℃
Storage Temperature —20～40℃
IP Rating Finished product IPX5
36V
5A
40Pcs
Rated Voltage
Max Charging Current
BMS Negative point port
Battery Quantity
Rated Capacity 10.4AH（10 series 4 parallel）
Swappable battery?(Yes or No) Yes
Charging cabinet version /
Motor Size 10inch
Max Torque 20N.m
Rated Voltage 36V
Rated Power 350W
Max Power 560W
Motor Control Mode Brushless gearless motor
Braking DistanceBrake ＜4 .5M
Charging Time 2A＜6H；3A＜4H

04
Item Content EA10A
Brake Brake Type The front wheel is equipped with a mechanical drum brake
The rear wheel is equipped with a mechanical drum brake
+ electronic brake
2.4000-2.4835GHz
20mW
Tire
Charger
User
Characteristics
Bluetooth
Vacuum tires
Front ：10inch Rear: 10inchTire Size
Tire Material
Input Voltage
Output Voltage 42V
100-240V
Output current 2A
Max Load 100KG
AGE Recommended >14 years old
Height Required 120-200cm
Brake light Light off/low light flashing alternately
Riding mode Zero start (Rear drive)
Certification
Frequency band
Maximum frequency
band power
FCC，UL testing report
Packing Manner of packing
G.W.
1pc/ctn
32.5KG
*Range: When fully charged, with a load of 75kg, an ambient temperature of 25°C, driving on a flat road at
a constant speed of 60% of the maximum speed.
*Factors affecting Range include: speed, ambient temperature, climbing, number of starts and stops, etc.

05
1-2.Symbol Explanations
Indicates a hazard signal with a high degree of danger. If not avoided, death or
serious injury may occur.
A hazard signal that indicates a moderate hazard. If not avoided, death or
serious injury may occur.
A hazard signal that indicates a lower hazard. If not avoided, mild or moderate
injury may occur.
This symbol marks additional information and instructions about the product
and its use.
This symbol stands for "conforms to EU standards", meaning "conforms to"
EU Directive. The manufacturer makes a ce mark to confirm that the product
complies with applicable European directives and regulations.
Please read the instruction manual carefully before use.
This product is a second-class protection product.
This product can only be used by people weighing more than 30 kg and less
than 100 kg.
Wear personal protective equipment(PPE).
The product can only be used by one person at a time.
It can only be used on flat and dry roads.
Please do not use this product after taking alcohol, sedatives or psychotropic drugs.
Minimum age: 14 years old.
Do not enter the road with these signs.
Positive and negative display.
DANGER !
WARNING !
CAUTION !
14岁
以上

06
1-3.List of finished product and parts
Size: length 1145*width 533*height 1045MM
Front fork
10-inch drum
brake front
wheel group
Meter
Grips
Speed up
Hook up
Kickstand
Cushion
Foldable seat tube
Rear fender
10-inch drum
brake motor
Rear assembly
Pedal
The bell
brake lever
Brake lever
Foldable front
steering tube
Side reflector
Basket
mounting
screw hole
Safety buckle
Folder

07
2.Intended Use
·An electric scooter is intended for sport and entertainment purposes, not for use as a
means of transportation, but the transportation faction of the product once you drive it
into public areas (as permitted by the laws and regulations of your region and
country)also carries potential safety risks for all vehicles. Drive strictly in accordance
with the instructions in this manual to ensure the safety of yourself and others to the
utmost extent, and to ensure compliance with national first-level traffic laws and
regulations of various provinces and cities, such as traffic regulations, etc.
·Please note: Once you drive an electric scooter on public roads or other public places
(as permitted by the laws and regulations of your region and country regarding the use
of electric scooters on public roads or other public places), even if you fully comply with
this safe driving guide operation, you may also face risks caused by illegal driving/im-
proper operation by others, or other vehicles. Just like when walking or riding a bicycle,
you may also be injured by other vehicles. As with any vehicle, the faster you drive an
electric scooter, the longer the distance required to brake, and emergency braking on
smooth surfaces may also cause the wheels to slip and lose balance or even fall over.
Therefore, it is very important to be vigilant when driving, maintain a proper speed, and
maintain a reasonable and safe distance from other people and vehicles. When driving
on unfamiliar terrain, stay alert and drive at a low speed.
·Please respect the pedestrian's right of way when driving. Avoid frightening pedestri-
ans, especially children.
·When driving in countries and regions where there are currently no national standards
and regulations related to electric scooters, such as China, please be sure to comply with
the safety requirements for drivers in this manual. Zhejiang Oukai Automobile Industry
Co., Ltd. will not bear any direct or joint liabilities for any financial losses, losses of life,
legal disputes, or any other unfavorable events that occur due to the violation of the
recommended uses indicated in this manual.
·To avoid potential injury, do not lend the electric scooter to people who can't operate
it. If you give the electric scooter to a friend to use, please be responsible for your
friend's safety, teach them to operate the scooter, and tell them to wear protective
equipment.
·Please perform a basic inspection of the electric scooter before each driving. If you find
that there are loose parts, the battery life is obviously reduced, the tires are excessively
worn, the steering makes abnormal noises or malfunctions, etc., please stop using the
scooter immediately, and do not force it to drive.

08
3.Safety instructions
3-1 General safety instructions
This section lists the safety instructions that should be followed when using this product
It may be dangerous to use this product! Learn to use the product step by step and
spend enough time on practicing. Please follow all the tips and warnings set forth in this
manual to reduce risks but cannot eliminate all risks. Therefore, even if you have
enough practices, guidance or expertise, you may still lose control, collide or fall over,
which may cause serious consequences.
1. An instruction to keep the printed instructions for further reference and to be read
carefully before use.
2. Maximum speed allowed: 25 km/h.
3. Pregnant women, the disabled, and those who suffer heart, head, back or neck
diseases (or have undergone operations on these parts) should not use this product.
4. Do not use this product after taking alcohol, sedatives or psychoactive drugs, so as
not to affect your judgment.
5. Keep a distance of at least 1m from pedestrians, other vehicles and any obstacles.
6. This product can only be used when the environment permits it and the personal
safety of bystanders is guaranteed.
7. Pay attention to the obstacles in front places and those far away, the unobstructed
view will be helpful for safe use!
8. This product may be used by only one person. It is f orbidden to use this product with
others. Don't make sharp turns when driving the scooter at high speed.
9. Avoid sudden acceleration or sudden braking; do not lean your body for acceleration.
10. Excessive forward or backward is strictly prohibited.
11. Do not misuse this product.Do not use this product on roadsides, ramps, in skate
parks, empty swimming pools, or any place similar to sliding plates.
12. Do not use this product to cross obstacles, slopes, ice or snow, nor climb up or down
steep slopes,stairs or escalators.Do not expose this product in the rain.
13. Do not use this product in places where the depth of the puddle exceeds 2cm,
because water may enter the motor.
14. Don't jump on this product.Don't try to use this product to do any acrobatics or
juggling.
15. In order to avoid distraction when driving the scooter,please do not wear
earphones, earplugs,make or answer calls, take pictures or videos or do any activities
that are not related to driving, so that you may monitoring the external environment
well while driving the scooter.
16. Be sure to hold both handles when riding.
17. Do not use this product at night or in places with poor light.

09
18. When you encounter pedestrians or other obstacles, check if you can pass safely.
19. Please use this product and its accessories at an appropriate temperature. Pay
attention to the temperature requirements for battery charging.
20. Please always wear personal protective equipment (to protect wrists, knees, head
and elbows) suitable for your weight and size to avoid injury. In working areas, local
laws or regulations may have minimum requirements for helmets. In addition, it is
suggested that safety mirrors be worn.
21. According to French traffic rules, reflective clothing and helmet is strongly required
during cycling.
22. Do not hang this product with other products or vehicles.
23. When being not used, this product should be parked with the kickstand.
24. Any load added to the handle will affect the stability of the scooter.
25. WARNING! The braking distance will be extended under humid conditions.
26. WARNING! If any mechanical parts are subject to great external pressure and wear,
different materials and parts may react differently to wear. If a part exceeds the
expected service life, it may suddenly break, which may cause injury. Cracks, scratches
and discoloration in the area affected by external pressure indicate that the part has
exceeded its service life and should be replaced in time.
27. WARNING! Please keep the plastic cover away from children to avoid suffocation.
28. Please spend enough time practicing how to use this product, so as to avoid
accidents caused by lack of skills.
29. If training is required, the seller may provide corresponding training tutorials
30. When you are approaching pedestrians or cyclists, you may flip / turn the bell for
reminding them.
31. When passing a protected passage, please get off and walk through it.
32. Pay attention to protect your own safety and the safety of others in all cases.
33. Do not use this product for other purposes such as carrying people and objects.
34. Using the brake for a long time may cause heating, and thus do not touch it.
35. Regularly check all kinds of bolts, especially the axle, folding system, steering system
and brake shaft.
36. It is prohibited to refit this product, including steering tubes, steering sleeves,
steering rods, folding mechanisms and rear brakes.
37. Accessories and any additional items which are not approved by the manufacturer
shall not be used.
38. When riding, the noise should not exceed 70dB.
39. When using the product, users must wear shoes.
40. This appliance can be used by children aged from 14 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall not be made by children
without supervision.

10
41. Traffic in the city has many obstacles to cross such as curbs or steps. It is
recommended to avoid obstacle jumps. It is important to anticipate and adapt your
trajectory and speed to those of a pedestrian before crossing these obstacles. It is also
recommended to get out of the vehicle when these obstacles become dangerous due to
their shape, height or slippage.
42. Get closer to your seller so he can refer you to an appropriate training organization.
43. Avoid high traffic areas or overcrowded areas.
44. In any case, anticipate your trajectory and your speed while respecting the code of
the road, the code of the sidewalk and the most vulnerable.
45. Notify your presence when approaching a pedestrian or cyclist when you are not
seen or heard.
46. Cross the protected passages while walking.
47. In all cases, take care of yourself and others.
48. Power-off the vehicle during charging.
49. Do not divert the use of the vehicle.
50. This vehicle is not intended for acrobatic use.
51. Caution, the brake may become hot in use. Do not touch after use.
52. Regularly check the tightening of the various bolted elements, in particular the
wheel axles, the folding system, the steering system and the brake shaft.
53. Eliminate any sharp edges caused by use.
54. Do not modify or transform the vehicle, including the steering tube and sleeve, stem,
folding mechanism and rear brake.
55. The self-tightening nuts as well as the other self-tightening fastenings may lose their
efficiency and that they may need to be retightened.
56. WARNING! As with any mechanical component, a vehicle is subject to high stresses
and wear. The various materials and components may react differently to wear or
fatigue. If the expected service life for a component has been exceeded, it may break
suddenly, therefore risking causing injuries to the user. Cracks, scratches and discolor-
ation in the areas subject to high stresses indicate that the component has exceeded its
service life and should be replaced.
57. In order to prevent theft of scooter, it is recommended that the user be equipped
with a physical lock.
58. WARNING!Risk of Fire and Electric Shock ‒ No User Serviceable Parts.
59. Prolonged exposure to UV rays, rain and the elements may damage the enclosure
materials, store indoors when not in use.
Failure to use common sense and heed the above warnings will increase the
risk of serious injury or even death, so be careful!

3-3 Safety instructions for battery charger
·Please use the original battery charger provided with the product for charging.
·The battery charger is not suitable for children under 14 years old, people with mental
disorders, those who are disabled, etc., unless they use this product under the
supervision or guidance of their guardians.
·Check again whether the power plug and cable are damaged. If so, they must be
replaced by the manufacturer, a designated service agent or a person with similar
qualifications to avoid danger.
·Before cleaning, storage and transportation, disconnect the battery charger from the
power source and allow it to cool down.
·Protect electrical components from moisture. When the battery charger is cleaned or
used, do not immerse it in water or other liquids to avoid electric shock. Do not put the
battery charger in water. When being charged, this product must be placed in a
well-ventilated place. After the battery is fully charged, immediately disconnect the
charger from the power source.
·Regularly check whether the battery charger is damaged. A damaged battery charger
must be repaired before use. Do not use a battery charger that has been left exposed for
a long time or damaged.
·Do not connect a damaged product to the battery charger. There is a risk of electric
shock!
·Do not disassemble the battery charger. Repairs must be performed by reliable
after-sales service personnel. Incorrect assembly may cause fire or electric shock.
·Do not use the charger near flammable and explosive items, otherwise there is a risk of
fire and explosion.
·Please check the technical data before connecting the battery charger to the power
source. Improper use may cause fire! The battery charger should be used indoors only.
·Do not misuse the battery charger. The battery charger is only suitable for this product.
Use with other products may cause fire or electric shock.
·Make sure that the battery charger and the charging port are properly connected and
not blocked by foreign objects.
3-2 Battery safety precautions
·The battery should not be exposed to excessive heat such as sunlight, fire or the like.
Otherwise there will be a risk of explosion!
·If this product is not used for more than 30 days, please fully charge the battery.
·Fully charge the battery every 90 days. Otherwise, the battery will conduct self-dis-
charge and be damaged.
·If the battery emits a strong smell or becomes hot, stop using the product immediate-
ly. Do not open the product casing and don't try to disassemble the battery by yourself.
·Please dispose of the battery correctly and safely.
11

12
·Keep the charging port clean, dry, and free from dust and humidity. Do not put any
objects on the battery charger, and don't cover it. Otherwise, the battery may overheat.
Do not place the battery charger near any heat sources.
·Be sure to place the power line in places where no one may trip, step on, or damage it,
Otherwise there will be a risk of material damage and personal injury.
·Do not disconnect the battery charger from the power source by pulling the power
line. Please manually remove the plug.
·Do not attempt to charge non-rechargeable batteries.
This section provides information on how to use the product correctly. To ensure user
safety and service life, it is important to follow these instructions.
4-1 Using the product for the first time
4.How to use
1.Open the package, take out the accessories box and the foam in the middle slot.
accessories box
foam in the middle slot

13
2.Remove the head tube and steering tube from the foam. Lift the steering tube up a bit
and insert the head tube into the steering tube.
Lift the preinstalled head module into an upright position. Use the hexagon wrench tool
to tighten the head tube with four M6 screws.
Insert the car head into
the riser.
steering
tube
head tube
3.Remove the top three foam.

14
4.Steering tube installation procedures.
Stand up the steering tube and pull the
folding handle upward to secure the
folding device.
folding
handle
Clamp the retaining ring into the slot
of the folding handle, to serve as the
second safety fixed folding device.
slot of the
folding
handle
retaining
ring
5.Seat tube installation procedures.
Stand up the seat tube to buckle the
folder (refer to step 4).
Insert the seat cushion into the seat
tube retaining groove, and align the
body with a wrench to tighten the
seat screws.

15
7.Use the key to open the pedal cover and connect the battery plug to power up the
vehicle;
Open the front charging port cover on the right side of the vehicle and connect the
charger to charge the vehicle.
6.Get the vehicle out of package.
Use the key to open the battery
pedal.
Insert the adapter into the
charging port on the battery.
charging port
adapter

16
Plug in power
Charging
port
Connect to
the vehicle
charging port
8.Use the key LOGO surface to touch the meter, or touch the LOGO surface of the
key to turn on the meter，or press the unlock button on the key to enter P mode.
Press the left handlebar button to enter cycling mode.

17
9.Remote key (With NFC function):
Function button (left button of hand handle) : After the vehicle is started into P mode,
press to enter riding mode,press and hold the function button for
about 3 seconds to power off;
Press the function button once to turn the headlights on/off while the
vehicle is powered on;
Press twice to switch to E (pedestrian mode) /L (economy mode) /H
(sports mode) while the vehicle is powered on;
Touch the LOGO surface of the key to turn on the
meter, or click the unlock button on the key to turn it on to enter the P
mode, and click the function button on the left handlebar to enter riding
mode.
Press five times in riding mode to switch the speed unit;
APP turns on the cruise function, which maintains a constant speed.
When the vehicle speed is greater than 5km/h, press and hold the
function button for 2 seconds to enter cruise mode at constant speed.
E mode is pedestrian mode, with a maximum speed of 5km/h, which is suitable for
use on pavement;
L mode is economy mode, with a maximum speed of 15km/h;
H mode is sports mode, with a maximum speed of 25km/h;
Brake lever
Speed up
Bells
Function button
When the driving speed exceeds
28km/h, the headlights and
dashboard will flash to alert the user
that they are speeding.
NFC
Speed display
Headlight
Bluetooth
Lock car
display Gear
Speed unit
Fault display
Batter status

18
10.Wear a helmet and protective gear.
11.Please check the vehicle before each use.
If the folding pole is loose
and shaking, tighten as soon
as possible using stacker
fixing screws.
Press the brake lever to
confirm that braking power
is normal.
