Okayo C 7206 User manual

Okayo Portable PA System
Operating Instructions
C 7206 Basic PA
C 7207 PA with UHF Wireless Mic
C 7210 PA with UHF Wireless Mic & MP3 Player
C 7192 Wireless Handheld Microphone
C 7193 Condenser Wireless Handheld Microphone
C 7195A Beltpack Transmitter
This operating guide also includes instructions for the following portable PA accessories:
C 7187: Additional UHF wireless microphone receiver
C 7196: Beltpack charging pod
C 7197A: Lapel microphone to suit beltpack transmitter
C 7198A: Headset microphone to suit beltpack transmitter
C 7213: Wall mount bracket
S 5078: Replacement battery 2.9Ah.
Manufactured for Altronic Distributors Pty Ltd.

Okayo Portable PA System
2
This new release from Okayo is exclusive to Altronics. Not much larger than a shoebox and weighing just 4kg it is very
compact and produces a clean crisp sound from its powerful 30W amplifier. The inbuilt battery will provide several
hours of use away from mains power. Alternatively the unit may be powered from the mains by the AC/DC adapter pro-
vided.
Three versions are available. All models include the same amplifier, power supply, battery and charging circuit. The
amplifier includes a 6.35mm mic input plus 3.5mm auxiliary input, both with volume controls. Tone and master vol-
umes are also provided.
C 7206 Base Model: As above. Provision for 2 UHF modules.
C 7207 UHF Model: Includes a 96 channel UHF mic receiver for roaming applications. Provision for an additional
UHF module.
C 7210 UHF & MP3 Model: Includes UHF receiver plus an MP3 player which accepts both USB stick or SD card.
Provision for an additional UHF module.
Interface with 50W Okayo Portable PA: When fitted with UHF receivers these 30W units will receive any signal
transmitted from the larger 50W Okayo (with transmitter link module fitted). This allows them to be used as “slaves” in
a large system providing additional sound coverage as required. In this application any number of “slave” units can be
used. This provides almost unlimited scope for small or large venues.
Features
• Compact design, weighs only 4kg
• Inbuilt carry handle
• Sets up in seconds
• Desk, stand or wall mount (with optional C 7213 bracket)
• Inbuilt battery
• High performance 30W RMS amp
• Models available with UHF wireless mic receiver (794-806MHz)
• Includes power supply for mains operation.
Operation
Power & Charging Functions (All models)
The portable PA system uses an 18V power supply which plugs into the 2.1mm DC socket on the rear (see figure 2 for
location) or via the internal battery pack. When operating for the first time the internal battery will require charging
for up to 8 hours. Charging will occur whenever the unit is plugged into the mains supply. The charge status indicator
(shown in figure 2) will illuminate red when charging. Once battery is 80-90% charged the indicator will flash red and
green. Once charging is complete the indicator will illuminate green.
When in use without mains power the LED built into the power switch provides indication of battery status:
100% to 30% capacity: no illumination
30% to 10% capacity: red illumination
<10% capacity: flashing red illumination
If battery fails to hold charge:
The internal battery requires changing. To do this, ensure unit is not plugged into mains power supply. Unscrew the
battery access panel on the rear of the unit. Remove battery and disconnect terminals. Reconnect new battery ensur-
ing correct polarity, red positive (+), black negative (-). Screw battery access panel to the unit and reconnect to power
supply for charging. A full charge will take up to 8 hours.

Okayo Portable PA System
3
Figure 1: Front
1. UHF receiver module (fitted on C 7207
& C 7210 models. Module available
separately as C 7187)
2. Blanking plate for additional UHF
receiver module if required.
3. Speaker.
1.
2.
3.
Figure 2: Rear
1. Handle
2. MP3/USB/SD Player (C 7210 only)
3. Level adjustmen & input/output module
5. Charging indicator
5. Battery compartment
6. Main power on/off switch
7. DC input socket
8. Battery access panel
9. 5/8” thread insert to fit mic stand.
1.
2.
3.
5.
4.
6.
7.
8.
9. (bottom)

Okayo Portable PA System
4
Figure 4: UHF Wireless Mic Module
Fitted to C 7207 and C 7210 or available as a separate
module (C 7187)
1. LCD screen
2. A/B diversity indicator
3. RX audio indicator
4. AF audio level indicator
5. Frequency set button
6. Up/down frequency adjustment buttons
7. Power switch & mic level control
1. 2. 3. 4. 5. 7.6.
Figure 3: Level Adjustment & Input/Output Module
1. Master volume level
2. Tone (bass/treble) level
3. Aux input level
4. Wired mic level
5. 6.35mm mic input
6. 3.5mm aux output
7. 3.5mm aux input
1. 2. 3. 4. 5. 6. 7.
Level Adjustments & Input/Output Connection (All models) - Figure 3.
System inputs, outputs and levels can be controlled via this module. Master volume adjusts overall system level from
all inputs (ie: UHF, MP3 module, aux input and wired microphone). Tone control affects all system inputs, when set to
mid way tone control output will be flat.
3.5mm input jack is provided for an external audio source. This allows connection of a CD player, iPod or other audio
source. A 3.5mm output jack is provided for use with external zone amplifiers or other PA systems if required. This
output signal is combined from all inputs (ie: UHF, CD/MP3 player, 3.5mm aux stereo input and wired microphones).
Wireless Microphone Module - Figure 4.
The portable PA system can be equipped with one or two UHF microphone modules. Each module features 96 selec-
table channels for interference free operation with multiple microphones or PA systems.
1. Turn the power switch/volume knob clockwise to turn the receiver unit on
2. The LCD screen will display “On” then revert to the factory default channel or the channel last selected.
3. To select a channel press the “SET” button. Using the UP/DOWN frequency adjustment buttons you can set the
receiver to match the channel used by the transmitter.
4. Adjust the volume level to the desired position.
5. The module is now ready to receive signal from either a handheld of beltpack transmitter. When receiving a signal
the A/B diversity indicator will illuminate red or green to show the diversity status. The RX indicator will illuminate
when signal from the transmitters is being received. The AF indicator displays audio level when users are speaking into
the microphone.

Okayo Portable PA System
5
MP3/USB Audio Player Module (C 7210 Only) - Figure 5
This easy to use module accepts USB memory stick or SD memory card for playback of MP3 files. The module is
equipped with CD player style functions ie: track skip/search, repeat, play/pause etc. The unit also has the ability to
vary the pitch of the playback for use in aerobics classes, gymnasiums etc.
Operation of MP3/USB Audio Player Module:
1. Switch on the PA at the main power switch and press the power button on the MP3 module. The module can be
switched off independantly of the PA system if required (to save battery power).
2. Insert your USB or SD memory card into the appropriate slot. The unit will automatically scan the memory for MP3
files and begin playback.
3. Press prev or next buttons to scan through the files on the memory. Playback will commence immediately whenever
the prev or next buttons are pressed. To pause playback at any time, press the play/pause button (>II).
4. Press stop to cease playback at any point. Pressing play again will start playback from the first file on the memory
stick/card.
5. To repeat a file press the repeat button during playback. Pressing repeat again will repeat all files on a memory
stick/card. Pressing repeat a third time cancels the repeat function.
6. Volume level control is provided to adjust the output level, this is overridden by the portable PA’s master volume
level.
7. Pitch control adjustment allows each MP3 track to be sped up or slowed down according to requirements.
When both USB stick and SD card are installed into the device, the USB has priority. If the power is switched off with-
out pressing stop, the last played track will be memorised & begin playing at switch on. Pressing stop again results in
the first track on the USB or SD memory device beginning playback.
NOTE: SD card slot is spring loaded. To eject the card, push inwards first and the card will be released from
the mechanism. Do not pull on the card as this may cause damage to the unit.
1. 2. 4. 6.5.
3.
Figure 5: MP3/USB Audio Player Module
1. Power button
2. LCD screen
3. SD card slot
4. Pitch control
5. USB socket
6. Level control
7. Play / Pause button
8. Stop button
9. Repeat
10. Next track
11. Previous track
8.9.10.11. 7.

Fitting Additional C 7187 UHF Wireless Microphone Receiver Module
1. Ensure portable PA is NOT connected to mains power. Disconnect all input cables.
2. Unscrew the blanking panel on the front panel (see figure 1).
3. Slide the UHF wireless microphone module in, ensuring the board slots into the connector at the rear of the empty
expansion bay.
4. Screw the module into the panel. The module is now ready for operation.
Transmitter Operation
All portable PA’s equipped with a UHF wireless microphone module are compatable with the C 7192 handheld and
C 7195 beltpack transmitters. All transmitters are sold separately.
C 7192 Handheld Microphone Transmitter - Figure 6.
1. Ensure microphone is switched off before inserting batteries.
2. Remove lower housing and battery clip. Insert 2 x AA batteries (alkaline or rechargeable’s are recommended).
3. Press and hold the power switch for 2-3 seconds (located on the base of the microphone). The power LED will illu-
minate red and “ON” will be displayed on the LCD screen. Note: power switch is more easily accessed with lower
housing removed.
4. A selection switch on the rear of the microphone provides three level settings (mute, mid & high) depending on the
application or environment in which the portable PA is to be used. Mute setting allows microphone to be put on stand-
by without switching the power off.
5. The LCD screen will display the channel selected. To determine which frequency this channel is operating on, press
the UP or DOWN frequency adjustment buttons.
6. Press the frequency set button for 1-2 seconds. The LCD screen will flash the currently selected channel number.
You can cycle through the channels by pressing the UP or DOWN frequency adjustment buttons. Press the frequency
set button again to lock in your channel selection.
7. The battery status is displayed on the left of the screen. When battery capacity is critical the icon will flash 3 times
Okayo Portable PA System
6
1. 2. 4. 6.5.
3.
Figure 6: Handheld UHF Wireless Microphone (C 7192)
1. Protective screen head
2. Rubberised body
3. Frequency set button
4. LCD screen
5. Up/down frequency adjustment buttons
6. LED power indicator
7. Power switch
8. Charging port connection
8.7.

before switching the microphone off automatically.
8. To turn the microphone off press the power switch for 2-3 seconds until the LCD screen displays “OFF”
9. When using with rechargeable NiMH batteries, connect a DC 5V plugpack (Altronics M 8909 or M 8909A plus
M 9187 tip adaptor) to the charging port on the base of the microphone. Charging time is dependant on the capacity
of batteries used, typically 10-12 hours charging is required. If battery icon is flashing when charger is connected,
ensure rechargeable batteries are inserted in the microphone. If batteries have failed both the battery icon and screen
backlight will flash.
During normal charging the battery icon will cycle through the charge “block” icons. Once full capacity is reached the
full battery icon and all “blocks” will be displayed. Note: microphone is unable to be used during charging process.
Troubleshooting
• Power LED does not illuminate after pressing power switch
Check batteries are charged and inserted correctly.
When pressing power switch ensure you hold it down for 2-3 seconds
• LCD shows “Err” when switching off
Contact your place of purchase for information on resetting your microphone.
• LCD panel displays garbled information
Remove batteries and re-insert them
• No sound output
Check frequency of transmitter is the same as the portable PA receiver
Check volume level of both transmitter and portable PA receiver
Ensure microphone is within range of the receiver
Check for sources of interference, large metal objects etc within range of the microphone
• Signal disturbance
When operating two transmitters in the same area, ensure frequencies selected are several channels apart. This
helps to reduce crosstalk between transmitters. Also note that other wireless devices can cause interference,
ensure you adjust your frequency around these devices where possible.
C 7195A Beltpack Transmitter - Figure 7.
Okayo Portable PA System
7
4.
5.
6.
7.
8.
9.
10.
3.
2.
1.
Figure 7: Beltpack UHF Wireless Transmitter (C 7195A)
1. Aerial
2. Mute button (top)
3. On/off switch (top)
4. Mini XLR mic input socket (top)
5. LED power indicator
6. Sensitivity selection switch (side)
7. 3.5mm aux input socket (side)
8. Frequency set button
9. Up/down frequency adjustment buttons
10. Charging jack

Okayo Portable PA System
8
1. Ensure microphone is switched off before inserting batteries.
2. Remove battery clip. Insert 2 x AA batteries (alkaline or rechargeable’s are recommended).
3. Switch the top mounted power switch to ON. The power LED will illuminate red and “ON” will be displayed on the
LCD screen.
4. A selection switch on the side of the beltpack provides three level settings (low, mid & high) depending on the appli-
cation or environment in which the portable PA is to be used. The mute button allows beltpack to be put on standby
without switching the power off.
5. The LCD screen will display the channel selected. To determine which frequency this channel is operating on, press
the UP or DOWN frequency adjustment buttons.
6. Press the frequency set button for 1-2 seconds. The LCD screen will flash the currently selected channel number.
You can cycle through the channels by pressing the UP or DOWN frequency adjustment buttons. Press the frequency
set button again to lock in your channel selection.
7. The battery status is displayed on the left of the screen. When battery capacity is critical the icon will flash 3 times
before switching the microphone off automatically.
8. When using with rechargeable NiMH batteries, you can us the C 7196 charging pod. This allows you to put up to 2
beltpacks on charge at the same time. Charging time is dependant on the capacity of batteries used, typically 10-12
hours charging is required. If battery icon is flashing when charger is connected, ensure rechargeable batteries are
inserted in the microphone. If batteries have failed both the battery icon and screen backlight will flash.
During normal charging the battery icon will cycle through the charge “block” icons. Once full capacity is reached the
full battery icon and all “blocks” will be displayed.
Troubleshooting
• Power LED does not illuminate after switching on
Check batteries are charged and inserted correctly.
• LCD shows “Err” when switching off
Contact your place of purchase for information on resetting your beltpack.
• LCD panel displays garbled information
Remove batteries and re-insert them
• No sound output
Check frequency of transmitter is the same as the portable PA receiver
Check volume level of both transmitter and portable PA receiver
Check mute button is not activated
Ensure beltpack is within range of the receiver
Check for sources of interference, large metal objects etc within range of the beltpack
• Signal disturbance
When operating two transmitters in the same area, ensure frequencies selected are several channels apart. This
helps to reduce crosstalk between transmitters. Also note that other wireless devices can cause interference.
Ensure you adjust your frequency around these devices where possible.

Okayo Portable PA System
9
Specfications
Portable PA Amplifier
Frequency Response ..............................................70Hz - 16kHz
Output Power ................................................................30W RMS
Signal to Noise Ratio ........................................................> 70dB
Inputs ......................................................6.35mm, Stereo 3.5mm
Outputs ..................................................................Stereo 3.5mm
Controls......Master volume, tone, line volume, wired mic volume
Power ..............................................................................DC 18V
Battery ......................................12V, 2.9Ah x 1 (sealed lead acid)
Operating Life (fully charged) ............................................3-4hrs
Charging Time ..................................................................4-6hrs
Dimensions ..................................................260 x 210 x 290mm
Weight ....................................................................................4kg
MP3/USB Audio Playback Module (C 7210 Only)
Frequency Response ..............................................20Hz - 20kHz
Format ......................................................MPEG layer 3 decoder
Signal to Noise Ratio ........................................................> 60dB
THD ....................................................................................< 1%
Memory ..........USB flash memory stick, SD (Secure Digital) Card
Controls: Play/pause, stop, repeat, prev, next,
pitch adjustment, volume level
Beltpack Transmitter (C 7195A)
Mic Insert ....................................................................Condenser
RF Output ..........................................................................10mW
Spurious Emission..........................................................<250mW
Audio Input ............................................................Mic in, Aux in
AF Controls ....................................Mute switch, hi/mid/lo switch
Battery....1.2V NiMH AA rechargeable x 2 or 1.5V AA Alkaline x 2
Operating Life (fully charged) ..11 hrs (NiMH) or 14 hrs (Alkaline)
Dimensions ........................................................88 x 64 x 24mm
Weight (with batteries)..........................................................170g
Handheld Transmitter (C 7192)
Mic Insert ......................................................................Dynamic
RF Output ..........................................................................10mW
Spurious Emission..........................................................<250mW
AF Controls ......................................................Hi/lo/mute switch
Battery....1.2V NiMH AA rechargeable x 2 or 1.5V Alkaline AA x 2
Operating Life (fully charged) ..11 hrs (NiMH) or 14 hrs (Alkaline)
Dimensions ............................................................46Ø x 264mm
Weight (with batteries)..........................................................280g
UHF Wireless Receiver Module (C 7187)
Antenna Mode ................................................................Diversity
Spurious Rejection ..............................................................70dB
Adjacent Channel Performance ..........................68dB @ 250kHz
Antenna............................................................................Internal
Dimensions ......................................................128 x 88 x 37mm
Weight ..................................................................................110g
Overall System
Frequency Range ..............PLL synthesised control, 794-806MHz
(96 channels)
Dynamic Range ..................................................................110dB
THD ....................................................................Less than 0.5%
Wireless TX Operating Range ......................50-70m (line of sight)
Figure 8: Mounting to mic stand or C 7213 wall bracket.
5/8” Thread
Moulded into
Bottom of Unit
5/8” Thread
Moulded into
Bottom of Unit
5/8” Threaded
Microphone Stand
C 7213 Mounting
Bracket Plate &
Adaptor

Okayo Portable PA System
10
IMPORTANT
Maintenance / Operation Guidelines
Avoid excessive heat: Do not leave transmitters or portable PA receiver in direct sun for extended periods, in front
of heaters or any source of high temperature
Avoid rough handling: Transmitter or portable PA receiver may be damaged if dropped
Fully charge portable PA battery: Ensure battery is fully charged before placing into storage for long periods.
Ensure battery is charged once per month thereafter to ensure long life and optimum battery reliability.
Remove batteries: Remove batteries from transmitters when not in use.
Replace batteries: Ensure replacement batteries are the same or equivalent to existing. Batteries may explode
under charge or unit may malfunction if incorrect batteries are used.
Battery terminals: Ensure battery contacts are clean and free of corrosion before operation. If corrosion occurs it
could be a sign of faulty batteries. Return to your place of purchase if service is required.
&K )UHT &K )UHT &K )UHT &K )UHT &K )UHT &K )UHT
          
          
          
          
          
          
          
          
          
           
           
           
           
           
           
           
Table 1: UHF Wireless Channel Guide
