OKU EP-8 User manual

English Stud Gun EP-8, EP-9, EP-10
Stud Gun
Automatic Stud Gun EP-8, EP-9, EP-10
Operating instructions
(ID-No. 00035102)
00100192 EP-8 (gun for manual use)

00101758 EP-8 (gun for machine)

00100193 EP-9 (gun for manual use)

00100262 EP-9 (gun for machine) assembled:

00100194 EP-10 (gun for manual use) Date: _________________

00100263 EP-10 (gun for machine) Name: _________________

OKU GmbH, 73650 Winterbach, Germany
1

English Stud Gun EP-8, EP-9, EP-10
Table of content s
......................................................................................................................2Table of contents
...........................................................................................31 Preface and general information
...........................................................................................................................31.1 General
..............................................................................................................31.2 Scope of supply
...................................................................................................................31.3 Intended use
............................................................................................................................41.4 Liability
.........................................................................................................................41.5 Warranty
.................................................................................................................52 Safety information
....................................................................................52.1 Personnel responsible for safety
...................................................................................................................52.1.1 Operator
..................................................................................................52.1.2 Qualified personnel
.............................................................................................62.2 General safety instructions
.....................................................................................62.3 Layout of the safety instructions
......................................................................................................................83 Technical Data
.......................................................................................................................83.1 Stud types
...................................................................................................83.2 Dimensions and weight
...............................................................................................................93.3 Noise emission
.........................................................................................................93.4 Ambient conditions
....................................................................................................................104 Commissioning
..................................................................................................104.1 Pneumatic connection
............................................................................................................115 Operation of the gun
..........................................................................................................115.1 Insertion of studs
..................................................................................................125.2 Faults during insertion
...........................................................................................125.2.1 Studs inserted to deep
..........................................................................................125.2.2 Studs jut out off the tire
..................................................................125.3 Conversion of machine gun to manual gun
..................................................................................................156 Faults and troubleshooting
..............................................................................................167 Lubrication and maintenance
....................................................................................................................167.1 Lubrication
.........................................................................................................167.1.1 Lubricating oil
..................................................................................................167.1.2 Lubricating grease
.............................................................................................................177.2 Greasing points
.................................................................................................................177.3 Maintenance
.................................................................................................188 Shutdown and dismounting
..........................................................................................................199 Spear and wear parts
...............................................................................................................199.1 Requirements
..........................................................................................................199.2 Handling of order
.................................................................................199.3 Explanation to the spare parts list
.............................................................................................................199.4 Spare parts-set
..........................................................................209.5 Exploded drawing EP-8, EP-9, EP-10
...............................................................................219.6 Spare parts list EP-8, EP-9, EP-10
...........................................................................................................................2310 Appendix
.....................................................................................2310.1 CE-Declaration of Conformity
....................................................................................................................2410.2 Copyright
...............................................................................2410.3 Manufacturer and contact person
OKU GmbH, 73650 Winterbach, Germany
2

English Stud Gun EP-8, EP-9, EP-10
1 Preface and general information
1.1 General
The operating instructions is used for safe operation of the Stud Guns (in the
following referred to as “gun“) type Automatic Stud Gun EP-8, EP-9 and EP-10
(ID-No. 100192, 100193, 100194, 101758, 100262, 100263)). The safety in-
structions included hereinafter must be observed.
The operating instructions must be available for anybody who is working with
the gun and the included instructions must be carefully attended to.
The operating instructions must always be complete and perfectly readable.
1.2 Scope of supply
The delivery normally consists of a stud gun, the operating instruction and 1
separating finger for multi-flange studs fingers (only EP-8 and EP-9). The
parts included in your delivery are stated in the accompanying papers.
These papers shall be checked for conformity, immediately after receipt of the
goods. OKU GmbH does not provide any guarantee and/or accept any liability
for defects complained belatedly.
Therefore:
•Contact the forwarder immediately to complain visible transit dam-
ages.
•Contact OKU GmbH immediately to complain visible defects and/or
incompleteness of delivery.
1.3 Intended use
The gun is intended to be used only for the insertion of single and multi-flange
spikes into tyres of cars.
Any other use shall be deemed to be inappropriate!
OKU GmbH, 73650 Winterbach, Germany
3

English Stud Gun EP-8, EP-9, EP-10
1.4 Liability
The information, data and notes of this operating instruction were up-to-date
when passing for press. The specifications, illustrations and descriptions in-
cluded hereinafter do not apply for any previously supplied guns.
We do not accept liability for damages and operating troubles caused by:
•inappropriate use.
•unauthorized modification of gun.
•improper operation of the gun.
•operating errors.
•disregard of this operating instructions.
1.5 Warranty
Conditions of warranty: see Standard Terms and Conditions of OKU GmbH.
Assert warranty claims against OKU GmbH immediately after detection of the
defect.
Warranty claims expire in each case in which liability claims cannot be made.
OKU GmbH, 73650 Winterbach, Germany
4

English Stud Gun EP-8, EP-9, EP-10
2 Safety information
2.1 Personnel responsible for safety
2.1.1 Operator
Operator is called any natural or legal person who is using the gun and/or on
behalf of whom the gun is used.
The operator and/or his safety officer must ensure,
•observance of the relevant regulations, instructions and laws,
•only qualified personnel is working with the gun,
•personnel having the operating instructions available at any time,
•to prohibit non-qualified personnel from working with the gun.
2.1.2 Qualified personnel
As qualified personnel are to be considered persons who were authorised by
the safety officer of the plant to perform the necessary activities and who are
able to recognise and avoid potential hazards because of their education, ex-
perience, instructions and their knowledge about corresponding standards and
rules for the prevention of accidents as well as operating conditions
(see IEC 364, definition for qualified personnel).
OKU GmbH, 73650 Winterbach, Germany
5

English Stud Gun EP-8, EP-9, EP-10
2.2 General safety instructions
These safety instructions do not claim to be exhaustive. In case of any ques-
tions, please, contact OKU.
At the time of delivery the gun is state of the art and reliable.
The gun is a source of danger for persons, for the gun itself and for other ma-
terial assets of the operator, if
•it is operated by unqualified personnel.
•it is used inappropriately.
Operate the gun only when it is in good condition.
Any upgrade, modification or redesign of the gun is basically prohibited. In this
case, please confer with OKU.
2.3 Layout of the safety instructions
The safety instructions described hereinafter are arranged consistently.
Beware of personal injury
Pictogram Meaning Signal words Notes
Warning for hazardous
electrical voltage
Warns of imminent danger.Danger!
Consequences of disregarding:
Death or very severe injuries
Warns of a potential, very haz-
ardous situation.
Consequences if disregarded:
Death or very severe injuries
Warning for general dan-
ger
Warning!
Warns of a potential hazard-
ous situation.
Consequences if disregarded:
Light or minor injuries
Warning for a general dan-
ger
Caution!
OKU GmbH, 73650 Winterbach, Germany
6

English Stud Gun EP-8, EP-9, EP-10
Warning of material damage
Icons used Meaning Signal words Notes
Warns of potential material
damage.
Consequences if disregarded:
Ambient damage or damage of
the gun.
Warning of material dam-
age
Stop!
Other information
Icons used Meaning Signal words Notes
Designates a general, useful
note.
Adherence hereof will ease the
use of the gun.
General note Note!
OKU GmbH, 73650 Winterbach, Germany
7

English Stud Gun EP-8, EP-9, EP-10
3 Technical Data
3.1 Stud types
The gun can be used for the insertion of single-flange and multi-flange studs
into car tires. Factory setting is for the insertion of single-flange studs.
To operate the gun with multi-flange studs you’ll be needed to convert the gun
(not possible for EP-10). Exchange the separating finger (20) of the single-
flange studs for the provided separating fingers of the multi-flange studs, as
described in chapter 6.7.
Type ID.-No. Stud sizes
EP-8 (gun for manual use) 100192 Ø8 from a length of 11 mm
Multi-flange studs with a Ø8 and a
length of 10 mm can be inserted
with gun EPK-8 only.
EP-8 (gun for machine) 101758
EP-9 (gun for manual use) 100193 Ø8 from a length of 11 mm
Ø9 from a length of 11 mm
EP-9 (gun for machine) 100262
EP-10 (gun for manual use) 100194 Single-flange studs with an Ø10,
Ø9 from a length of 13 mm only.
EP-10 (gun for machine) 100263
3.2 Dimensions and weight
The following values are valid for the gun without any accessories and can dif-
fer according to the respective extra equipment.
Length ca. 282 mm
Width ca. 60 mm
Height ca. 194 mm
Weight ca. 1,8 kg
OKU GmbH, 73650 Winterbach, Germany
8

English Stud Gun EP-8, EP-9, EP-10
3.3 Noise emission
The sound pressure level at the work station of the operator can reach up to
83 dB(A). Provide suitable ear protection for the operator.
3.4 Ambient conditions
Use the gun only in closed and dry rooms.
The permissible ambient temperature during operation is from 10 °C to 40 °C.
OKU GmbH, 73650 Winterbach, Germany
9

English Stud Gun EP-8, EP-9, EP-10
4 Commissioning
Precautions to be taken before start working with the gun
•Check gun for proper condition.
•Do never operate a damaged gun.
4.1 Pneumatic connection
Attention!
The pneumatic connection is to be made by qualified
personnel with extensive knowledge in handling of
pneumatic systems.
Screw provided coupling (1) onto the hand grip. Plug compressed air hose into
coupling. The gun requires compressed air with approx. 7-8 bar working pres-
sure. The maximum operating pressure amounts to 10 bar.
Coupling (1) for com-
pressed air connection
(gun for manual use)
Coupling (1) for com-
pressed air connection
(gun for machine)
OKU GmbH, 73650 Winterbach, Germany
10

English Stud Gun EP-8, EP-9, EP-10
5 Operation of the gun
5.1 Insertion of studs
Without feeding unit: fill the feeding pipe (13) with approx. 10 studs (flange
leading).
With feeding unit: connect the gun with the feeding hose of the studs until
feeding pipe (13) is filled with studs (flange leading).
Moisten tire with low surface tension water. To get this, mix normal tap water
with some drops of usual dish liquid.
Tip!
Use only less dish liquid to avoid that the inserted
stud is pulled out again when extracting the gun.
Insert spreader fingers (23) into one of the moistened tyre holes. Operate the
trigger (28) and keep it pressed. The stud is pressed into the tire. Release trig-
ger (28); the gun is now loosen from the tire and the stud is inserted.
Tip!
Put some pressure onto the gun when inserting the
studs. With some practice and skill you’ll soon find
the respective pressure which shall be applied to
reach a steady result.
OKU GmbH, 73650 Winterbach, Germany
11

English Stud Gun EP-8, EP-9, EP-10
5.2 Faults during insertion
5.2.1 Studs inserted to deep
Reduce the pressure applied on the gun during insertion.
5.2.2 Studs jut out off the tire
Put more pressure onto the gun when inserting the studs.
5.3 Conversion of machine gun to manual gun
If you are using a studding machine (AS-ZN, EP-ZN or EPK-ZN) and want to
dismantle the gun from the base frame to use it manually you’ll firstly have to
convert the gun, i.e. to release the trigger:
Caution!
Disconnect the gun from the compressed air sup-
ply.
OKU GmbH, 73650 Winterbach, Germany
12

English Stud Gun EP-8, EP-9, EP-10
Release trigger: Slip off O-ring (30) from bushing (32) and dowel pin (29) ap-
pears. The dowel pin can be easily pushed out of the bore. The trigger (28) is
released and can be removed. Turn the trigger by 90° and insert it back into
the bushing. Then insert the dowel pin into the bore of the bushing. Slip the O-
ring over and place it into the groove.
Dowel pin (29)
Bushing (32)
Trigger (28) O-ring (30)
Bushing (32)
O-ring (30)
Trigger (28)
Dowel pin (29)
Images similar
OKU GmbH, 73650 Winterbach, Germany
13

English Stud Gun EP-8, EP-9, EP-10
Stop!
The gun must be set back to its initial state should
you want to use it on the studding machine.
OKU GmbH, 73650 Winterbach, Germany
14

English Stud Gun EP-8, EP-9, EP-10
6 Faults and troubleshooting
Caution!
When unscrewing the intermediate piece (17), it
must be held tight, because of the strong com-
pression spring which is in the gun. If not, it can be
ejected and pose great danger.
No. Cause Trouble shooting
Deformed or dirty stud jammed in feeding
pipe (13) or gun head.
Unscrew Union nut (18) and take the head
(26) off the gun. Now remove the jammed
stud.
6.1
Stud in feeding pipe (13) in wrong position
(with shank leading)
6.2 Remove feeding tube and shake out stud
Remove O-Ring (30) and dowel pin (29) and
then trigger (28). Clean and lubricate trigger
slightly with oil.
Check if compression spring (3) broken, if so
replace compression spring.
6.3 Trigger (28) get caught
Unscrew Union nut (18) and take the head
(26) off the gun. Remove spring lock (21)
and replace spreader finger (23)
6.4 Worn spreader fingers (23)
Unscrew Union nut (18) and take the head
(26) off the gun. Unscrew both hexagon
head cap screws (27) (Caution!), hold the
intermediate piece (17) (pressure of inner
springs). Remove intermediate part and
circlip (15). Extract push rod (12) together
with the springs (10, 11), retaining ring (14)
piston disk (6) and lip seal (7). Unscrew
hexagon nut (4) and replace worn push rod.
Assemble the gun is reversed order and
replace hexagon nut if necessary.
6.5 Worn push rod (12)
Unscrew Union nut (18) and take the head
(26) off the gun. Remove spring lock (21),
Union nut and O-ring (19). Replace centring
finger (24).
6.6 Worn centring finger (24)
Unscrew Union nut (18) and take the head
(26) off the gun. Remove spring lock (21),
Union nut and O-ring (19). Drive off spring
pin (22) with a drift punch until it is possible
to remove the separating finger (20). Re-
place separating finger, consider that the
separating finger may not jam it should re-
main movable.
6.7 Worn separating finger (20)
OKU GmbH, 73650 Winterbach, Germany
15

English Stud Gun EP-8, EP-9, EP-10
7 Lubrication and maintenance
7.1 Lubrication
Stop!
Observe the effective directions for the use and
safety of the applied lubricants!
7.1.1 Lubricating oil
Distinguishing Designation ISO-Viscosity Manufacturer
mark acc. to Index
DIN 51502 DIN 51519
Normal lubri-
cating oil
AVIA (AVILUB RS 22)
BP (BP Energol CS 22)
ESSO (Coray 22)
SHELL (SHELL Carnea Oel 22)
AN 22 ISO VG 22
7.1.2 Lubricating grease
Designation Designation Consistency Worked pene- Manufacturer
acc. to
DIN 51825
Index tration as per
NLGI Class as per DIN ISO 2137
DIN 51818
Lubricating
grease for
bearing
KP2K-20 NLGI-2 265-295
AVIA (AVIALITH 2)
BP (Energrease L2)
ESSO (Beacon 2)
KLÜBER (CEN-
TOPLEX 2 EP)
MOBIL (Mobilux 2)
SHELL (Alvania R 2)
OKU GmbH, 73650 Winterbach, Germany
16

English Stud Gun EP-8, EP-9, EP-10
7.2 Greasing points
The following points of the gun need to be greased regularly. You will find a
maintenance-set including grease and corrosion preventive-oil-spray in the
spare parts list in chapter 9.6.
To grease the gun it must be partially dismounted (see hereto chapter 6
“Faults and trouble shooting”. We recommend taking the opportunity and
greasing the gun when replacing the wear parts.
No. Designation Service to be Consumables Frequency Notes
done Measured values
Lubricate with
oil
Lubricating oil
DIN 51501-L-AN 22
Oil trigger
slightly
1 Trigger quarterly
Piston disk
Lip seal
Lubricate with
grease
Lubricating grease
DIN 51825-KP2K-20
Grease piston
surface slightly
2 yearly
2
1
7.3 Maintenance
We are working with water to insert the studs, therefore the head of the gun
shall be sprayed regularly with anticorrosive material to avoid corrosion and
extend lifetime of the gun.
OKU GmbH, 73650 Winterbach, Germany
17

English Stud Gun EP-8, EP-9, EP-10
8 Shutdown and dismounting
OKU takes back your gun. We recommend you have OKU professionally dis-
mantle the gun and dispose of it.
Tip!
Be part of the environmental protection by recy-
cling valuable materials.
What? Where?
Return to the manufacturer or for-
warder
Transport material Pallets
Packing material
Cardboard boxes to waste paper
plastic to plastic recycling or waste
material
reuse wood-wool or waste material
Dispose according to the valid regu-
lations
Lubricants Oil, grease
Used materials:
aluminium
aluminium cast
grey cast iron
steel
brass
plastic
Separate valuable substances and
dispose
Components
OKU GmbH, 73650 Winterbach, Germany
18

English Stud Gun EP-8, EP-9, EP-10
9 Spear and wear parts
9.1 Requirements
Stop!
Spare and wear parts must be in accordance with
the technical requirements stipulated by the manu-
facturer.
9.2 Handling of order
To ensure punctual handling of orders, please state always the OKU-ID.-No.
of the spare part you need when ordering. You’ll find the OKU-Id.-No. on the
drawing of the gun and the spare parts list.
9.3 Explanation to the spare parts list
The numbering of the spare parts in the exploded drawing corresponds to the
item numbers of the spare parts list.
9.4 Spare parts-set
To the gun there is available a spare parts-set including the most important
wear parts. It contains all in the spare parts list with Àmarked parts inclusive
grease and corrosion preventive-oil-spray.
OKU-Id.-No. spare parts-set EP-8: 20015505
OKU-Id.-No. spare parts-set EP-9: 20015506
OKU-Id.-No. spare parts-set EP-10: 20015507
OKU GmbH, 73650 Winterbach, Germany
19

English Stud Gun EP-8, EP-9, EP-10
9.5 Exploded drawing EP-8, EP-9, EP-10
OKU GmbH, 73650 Winterbach, Germany
20
