Old Adirondack 39 Tree Bench with Optional Back User manual

Old Adirondack™Inc.
Natural Cedar Furniture
NOTE: WHITE CEDAR
Eastern White Cedar is one of nature’s
most unusual woods, Because most
cedar grows near swampy water basins,
it has a slow rate of decay and a natural
resiliency to rot and disease.
As it continues to dry and cure, Eastern
White Cedar normally will check or
develop the cracks that help create the
wood’s natural character. Also, while it
continues to dry, Eastern White Cedar’s
natural wood oils may develop a dust on
the surface of the wood, which is the
crystallization of the wood oils. These are
normal and natural processes in cedar
and in no way affect the strength or
durability of the furniture. This dust can
be easily removed with a dry cloth.
Occasionally, cedar will warp slightly or
check/crack during transportation, which is normal for natural cedar furniture.
Most of the time, this does not impact the assembly or durability of the product.
#39 Tree Bench with Optional Back
Hand crafted in the USA
Thank you for purchasing this Old Adirondack™Inc. furniture. Enjoy!
Old Adirondack™Inc. uses Eastern White Cedar from the Adirondack Mountains that is
carefully selected, harvested, and shaped. Fresh pale tan or light gold cedar has an odor that acts
as a mild insect repellent and turns to a gray color over time. Water based or oil stains will delay
the weathering process and latex paint coats evenly and lets the wood breathe. We ship it in its
natural color. Some minor assembly is required. Hardware needed for assembly is included.
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY
DO NOT TAKE OFF STRETCH WRAP FOR SLAT-PATTERN BACK
UNTIL THE BACK IS FULLY ASSEMBLED!

Old Adirondack™Inc.
www.oldadirondack.com Natural Cedar Furniture
Tools and Parts
Required Tools: Hammer or Rubber Mallet Wrench
Included Parts:
6 – Bench slats 6 - Legs
For Optional Back Accessory: 6 – Back Sections (pattern varies)
Included Hardware: Tapping Board
For #39 Bench For #39B Back Accessory
1 - Tapping board 24 – 1 ¼ “ Screws
12 – 4-1/2” Carriage bolts 3 – Holders
12 – 3/8” Nuts
12 – 3/8” Washers
Other Garden Accessory Products
#447 –Adjustable Arbor #121M – Garden Bench #440 – Small Arbor
#124T – Large Garden Table #43/44 –Planter Set and Extension #120M–Garden Chair

Old Adirondack™Inc. pg 3
Natural Cedar Furniture 1-800-342-3373
Facts and Suggestions for your cedar furniture
General
- Read each step carefully before starting. Make sure each
step of instruction is performed in the correct order.
- Work in a spacious area. The shipping box may be used
as a work surface after removing all staples.
- When inserting dowel ends into holes, twist dowel end
into place, with its “shoulder” in the hole.
Hammering and Nailing
- Eastern white cedar is a soft wood and may be damaged by striking it with a metal hammer,
therefore use a rubber mallet OR a hammer with the included tapping board when securing
dowels into holes.
OR
Care and Maintenance
- It is not necessary to finish or treat white cedar for outdoor use; it will slowly turn gray
within 6-12 months and typically provides 15 - 25 years of service in its natural state.
- Sandpaper may be used on an unfinished product to smooth holes and remove stains or
markings; we recommend 80-grit sandpaper for best results.
Appearance options
- You can achieve many different looks with white cedar all of which take advantage of its
natural rot resistance and slight cracking. Light sanding before finish work is beneficial.
o Clear oil or solvent based wood preservatives and treatments can be used if you
desire to hold to the original new milled wood appearance. This technique will
require reapplication every 1-2 years.
o Gray transparent stains are available that duplicate the weathered cedar look
immediately revealing the character of the wood.
o Semi-transparent stains in either oil or latex base can make the cedar appear to look
like teak or oak etc. depending on the stain’s color or they can introduce a washed
color look. The grain of the wood and knots will be visible with this approach
o Opaque stains in either oil or latex base generate a painted look. A primer is
beneficial, and multiple coats may be necessary to obtain total coverage.
o To obtain an antique look, begin by using opaque dark brown/gray stain with dense
coverage. Then use other opaque color stains on top of the dark color to provide the
desired color. Finally, sand and make wear spots on the finish color to allow the dark
color to be seen creating the shabby “chic” old look.
Rubber Mallet Hammer with Ta
pp
in
g
Boar
d
Dowel En
d
Shoulde
r

Old Adirondack™Inc.
www.oldadirondack.com Natural Cedar Furniture
Assembly
Step 1: Place three Bench slats upside down as
shown below. You need:
Step 2: Place a Leg with the predrilled holes between two Bench
Slats. Note: The angled side of the Leg faces the inside. You need:
Step 3: Insert two provided bolts through the predrilled holes in
the bench brace and the Leg (You may need to use a hammer or rubber
mallet). Put a washer and nut on the end of each bolt and hand tighten
only. Repeat for the other Leg.
You need: 4 carriage bolts, 4 washers,
4 nuts
Step 4: Repeat for the other 3 Bench slats and Legs. Two Legs should NOT be attached.
You need: , , 4 carriage bolts, 4 washers, 4 nuts
Three Bench slats
Insert Leg Bolt two Legs
Angled side
Bolts
Washers & Nuts
L
e
g

Old Adirondack™Inc. pg 5
Natural Cedar Furniture 1-800-342-3373
Attach remaining 2 Legs in desired location
Step 5: Place the two sub-assembled benches
together around the desired location and put the
remaining two Legs on the bench as in steps 2 & 3.
You need: 4 carriage bolts, 4 washers, 4 nuts
Step 6: Tighten all the bolts firmly, but do not over tighten.
Congratulations on assembling your Tree Bench! You need:
OPTIONAL TREE BENCH BACK – ASSEMBLY
[NOTE: Remember – 1) the top rails of the back sections are SHORTER than the bottom rails
AND 2) the pre-drilled holes should be on the back or inside part of the Tree Bench Back]
LEAVE THE STRETCH WRAP ON THE SLAT-BACK VERSION
OF THE TREE BENCH BACK!
Step A: Insert holders into three of the holes on the
bottoms of the Back Sections. Note: all back posts are
drilled for these, so you can insert the holders in the
holes where support is most needed. Note: All posts are
drilled; only three holders are included. It is
recommended to alternate the posts that use the
Holders.
Step B: Connect all sections. Be sure that all dowel and hole joints are firmly in place.
Dowels can be turned to even the amount of “shoulder” that shows on each end. Each dowel
should be tapped lightly to properly insert the dowel in the hole.

Old Adirondack™Inc.
www.oldadirondack.com Natural Cedar Furniture
Step C: After all sections are together as desired, insert the screws
into the pre-drilled holes on each bench post. It is best to screw them in
lightly at first, until all of the screws are in. This enables slight
adjustment. After you’re satisfied with the alignment, go back and
finish putting in the screws.
Step D (Optional for Slat-Back ): There are several options for positioning the slats on
each back:
Figure 1: You can put them all together, leaving space on the ends.
Figure 2: You can even out the spacing using all 6 slats. Or, you can remove 1 or more
slats on the back and even out the remaining spacing.
ONCE FULLY ASSEMBLED, YOU MAY REMOVE THE STRETCH WRAP
ON THE SLAT-BACK VERSION OF THE TREE BENCH BACK!
Enjoy your Tree Bench!
Fi
g
ure 1
Fi
g
ure 2

OLD ADIRONDACK, INC. 7 Station Road PO Box 663 Willsboro, NY 12996 1-518-963-7184
Old Adirondack™Inc.
Natural Cedar Furniture
Old Adirondack is a leader in the craftsmanship of natural cedar furniture.
Using local Northern White Cedar in an environmentally responsible manner,
we manufacture a full line of indoor and outdoor furniture.
Old Adirondack traces its history back to the Great
Camps of the Adirondack Park when Jackie Pedro,
caretaker at Flat Rock Camp, first designed and
refined rustic lodge and camp furniture. We have
successfully produced and marketed our products for
almost 25 years.
HAND CRAFTED EXCELLENCE
Old Adirondack has a 26,500 square foot production
plant specifically designed for furniture manufacture.
Each piece is carefully constructed, using the highest
standards for quality craftsmanship. The company
holds the only patent for the folding Adirondack
Chair.
PRIDE & TEAM SPIRIT
Team spirit, pride in one’s work, and company loyalty
and commitment are important components of the “lean
manufacturing” work environment, which focuses on a
team approach to manufacturing, rather than the more
traditional assembly line structure.

Warranty
Five (5) Year Limited Warranty
All of Old Adirondack’s Furniture comes with a manufacturer’s five (5) year limited warranty. If
any piece of furniture is proved to be defective by reason of improper workmanship and/or
material we will replace, at our discretion, that part or the whole product at no charge to you or
your customer. To obtain warranty service, either the consumer or the dealer must deliver the
part in question or the entire product to the address below at their expense. A copy of the original
sales receipt is appreciated when requesting warranty work. This warranty does not cover
defects caused by: modification, alteration or repair of the enclosed product by anyone other than
Old Adirondack™Inc. This warranty also does not cover return shipment of the product to
Old Adirondack. Write to Old Adirondack, PO BOX 663, Willsboro, NY 12996 or call at 800-
342-3373 to obtain answers to any questions regarding this warranty.
