Z2000/C2020 Tank Gauge Setup Guide – PD02/0001 Rev.01 Feb/2017
Z2000 / C2020 Tank Gauge Set-Up
To Calib ate the Gauge, Open the f ont cove 4 sc ews, Connect the Tank
Probe, and Power the unit.
Toggle the calib ation switch, top ight ma ked CAL (LK2)
The fi st sc een to show is a “Cube Tank” Middle Button Sc olls th ough Tank Type Options
Hidden Button Sc olls th ough settings.
Hidden Button
Choose the
Featu e
you equi e
, then set the
values by using the hidden button to select the
value to change, then use the othe two buttons
to Dec ease (LEFT) o Inc ease (RIGHT)the value.
You Must Sc oll to YES and use the
H
idden
button to Confi m YES fo all Sc eens
Now Use the
Right Button
to Sc oll ac oss to
Alarm T igge points and SG setting
1
2
3
7
6
4 5
You must sc oll to YES and
Confi m YES with Left
hand Hidden Button to
save you values.
Left
(hidden Button) selects Option
Right two buttons change value as in 5
above.

Z2000/C2020 Tank Gauge Setup Guide – PD02/0001 Rev.01 Feb/2017
Z2000 / C2020 Tank Gauge Set-Up Stage 2
10
9
8
Now Use the
Right Button
to Sc oll ac oss to
Senso Selection. The senso should be
connected at this point. This should be
Automatic and ead eithe Voltage o Cu ent
If it needs to be changed, Use the Right Button
to Set Voltage o Cu ent as equi ed.
Fo fine tune
Calib ation, the Senso Settings can be
adjusted to suit the individual senso .
For oltage sensor, the Ze o Value and the Max Value can
be adjusted up o down to suit.
(Both must be adjusted the same amount)
If Gauge eads LOW, inc ease these values. (max +0.05)
If Gauge eads HIGH, dec ease these values (max -0.05)
For Current sensor, the Ze o Value can be
adjusted up o down to suit. (Max self adjusts)
If Gauge eads LOW, inc ease these values.
If Gauge eads HIGH, dec ease these values
High Accuracy Calibration Adju tment (Advanced etting )
Sensor “Span”.
As Standard, this comes set for 2.55 M.
Change this to suit the sensor range
you have
C22 = 2.55 M C23 = 3.0 M
C25 = 5.0 M C27 = 10.0 M
Cu se (Hidden button) YES
END Toggle the switch.
Gauge etu ns to
Standa d Readings
11
Sensor Offset.
How fa f om the bottom of the tank is the
senso positioned. Ente this he e.
As standa d we would ecommend 50 mm
which is 0.05 M Cu se Confi m YES
Now use Right Button to Sensor Type screen
12
