OleumTech DH1 User manual

6. Connect PC to Gateway
a. USB to Serial Adapter (SX1000-CC9)
b. Gateway Configuraon Cable (SX1000-CC1)
7. Idenfy COM Port for use in BreeZ® (Device Manager)
8. Select a Gateway in BreeZ® Project Tree
9. Update Gateway with BreeZ® Project File
10. Confirm Gateway “Configuraon Download OK” in
Build Tab Window in BreeZ®
11. Save Project File onto Gateway (For Backup)
4. Configuraon Sequence - connued2. Required Items
- DH1 - Base Unit Wireless Gateway
- External Power Source for Base Unit (9-30 VDC)
- Antenna for Gateway (Bulkhead, Omni, or Yagi)
- Antenna Cable (N to MMCX Connector)
- N to N Antenna Cable and Lighng Arrestor (Oponal)
- External Enclosure for Base Unit (NEMA)
- DIN Rail (35 mm)
- USB to Serial Adapter (SX1000-CC9)
- Gateway Configuraon Cable (SX1000-CC1)
- BreeZ® Configuraon Soware v5.0 or Higher
- PC
- Screwdriver Set + Technician’s Screwdriver
- Any Addional Tools for Installaon
- RS485 I/O Expansion System (Oponal)
CAUTION: Field wiring connecons shall be made in accordance
with Arcle 504 of the Naonal Electrical Code, ANSI/NFPA70.
CAUTION: The Base Unit must be installed within an enclosure
that requires a tool to access. This is to prevent inadvertent
disconnecon of any of the power wiring, signal wiring or
communicaon cables.
ATTENTION: Le Base Unit doit être installé dans une enceinte qui nécessite
un oul d'accès. Ce est pour éviter toute déconnexion accidentelle de l'un
des câbles câblage de puissance, câblage ou de communicaon signaux.
WARNING: Ensure installaon of the Gateway meets applicable
state and naonal electrical code requirements. The installaon
of the Base Unitshould only be performed by a qualified installer or a
factory representave.
AVERTISSEMENT: Veiller à l'installaon de la passerelle répond Etat et
des exigences naonales de code de l'électricité. L'installaon de la
Base Unit ne doit être effectuée par un installateur qualifié ou un
représentant de l'usine.
WARNING: To prevent ignion of flammable or combusble
atmospheres, disconnect power before servicing.
AVERTISSEMENT: Pour éviter l'inflammaon d'atmosphères inflammables
ou combusbles, débrancher l'alimentaon avant l'entreen.
WARNING: EXPLOSION HAZARD – Substuon of components
impair suitability for Zone 2.
AVERTISSEMENT: RISQUE D'EXPLOSION - Le remplacement de composants
nuire à la conformité pour la Zone 2.
WARNING: EXPLOSION HAZARD – Do not separate/disconnect
connectors when energized.
AVERTISSEMENT: RISQUE D'EXPLOSION - Ne pas séparer / débrancher les
connecteurs lorsque excité.
WARNING: EXPLOSION HAZARD – Do not service when an
explosive atmosphere is present.
AVERTISSEMENT: RISQUE D'EXPLOSION - Ne pas service lorsque une
atmosphère explosive est présente.
WARNING: EXPLOSION HAZARD – Do not use reset switch in
hazardous area.
AVERTISSEMENT: RISQUE D'EXPLOSION - Ne pas uliser le commutateur
de réinialisaon en zone dangereuse.
1. Before You Begin
1. Download and install latest BreeZ® Soware v5.0 or
higher to a PC (see secon 3)
2. Check for latest Base Unit Firmware on Download Center
3. Create a BreeZ® Project File
*4. If upgrading Firmware, follow these instrucons:
a. Physically Connect Gateway to PC
b. Supply power
c. Open Connect screen and click “Flash”
d. Locate new Firmware file and click “Open”
e. DO NOT DISCONNECT OR TURN POWER OFF while
upgrading Firmware (It may take a few minutes for
upgrading process to finish)
f. Wait unl LED turns off
5. Power up Gateway (9-30Vdc) and wait unl boot-up
sequence is complete
(LED will turn off once boot-up is complete)
3. Configuraon Sequence
80-3103-001_J
This guide provides basic informaon to assist you in quickly
geng started. Go to www.OleumTech.com to download the
full User Guide for detailed installaon and other informaon.
5. Installaon Sequence
1. Install Gateway inside a NEMA enclosure
a. Remove Cover Using Two Top Screws.
b. Adjust and Tighten DIN Rail Clamp
c. Reaach Cover
2. Follow best grounding pracces
3. Setup and connect an Antenna with Lightening Arrestor
to Gateway
4. Connect Gateway to third-party Serial device(s)
5. Power up Gateway
6. Power up/reboot any impacted sensors/devices if necessary
7. Verify RF and data communicaons
a. Use Modbus Register Polling and Write features in BreeZ®
b. Verify communicaon from third-party device(s) or
SCADA system
QUICK START GUIDEBASE UNIT - WIRELESS GATEWAY (DH1)

80-3103-001_J
7. Grounding Best Pracces
6. Wiring
©2016 OleumTech Corporaon. All rights reserved. OleumTech and BreeZ are registered trademarks of OleumTech Corporaon in the United States. Other trademarks are the property
of their respecve owners. Specificaons, design, and product descripons subject to change without noce. This device contains proprietary intellectual property protected by US Patent #6967589.
• Baery negave should never be common with earth ground.
• For fiberglass enclosures, the backplane inside may be connected to earth ground. Typically, there is a lug specifically for
this connecon. The equipment inside the enclosure however, should not be common with the backplane in this case.
• For steel enclosures, baery negave should not be common with the enclosure as the enclosure will usually be common
with the pole supporng it (basically earth ground).
A. Where bulkhead (black phantom) antennas are used, the inner surface, outer surface, and inner wall of the hole drilled,
should be isolated from the antenna. Use the rubber washers supplied by manufacturer to isolate the antennas from the
enclosures (use thickest washer on exterior side of enclosure).
B. Where external antennas, such as omni-direconal and yagi, are used, a polyphaser is typically used. The actual connecon
between lightening arrestor and antenna cable should be isolated. The lightening arrestor itself has its own lug designed to
be connected to earth ground.
• Once all wiring and grounding recommendaons have been followed it is important to test the ground resistance at the
grounding rod to assure a good ground. The most effecve grounding method is direct connecon to earth ground with
minimal impedance.
An impedance of less than 5 Ohms recommended.
• For more details on proper grounding electrodes and grounding electrode conductors, consult the Naonal Electrical Code.
CAUTION: Ensure field wiring connecons are in accordance with Arcle 504 of the Naonal Electrical Code, ANSI/NFPA70.
For more details on proper grounding electrodes and grounding electrode conductors, consult the Naonal Electrical Code.
Using a small screwdriver or pin, depress
reset buon for at least 1 seconds to
reset DH2 hardware.
Connect PC to DH2 using
Gateway Configuraon Cable
and USB to Serial Adapter.
8. LED States
# State
1. Boong up
2. Device On or Off
3. BreeZ® connecon (update/connect/firmware)
4. Device Updated/Programmed
5. Device Failure
LED
Long Blink + 5 Short Blinks
Off
Solid green
Long Blink + 5 Short Blinks
Connuous Short Blinks
9. H/W Reset 10. PC Connecon
PC
1 2 3
JP1
RXD/R- DSR/R+ TXD/T- RTS/T+ CTS GND
1 2 3 4 5 6
AVCC AIN1 AIN2 AIN3 AIN4 AGND
1 2 3 4 5 6
DIN1 GND DIN2 GND DO1 GND DO2 GND V+ GND
1 2 3 4 5 6 7 8 9 10
9-30Vdc
GND
TxRx+
TxRx-
BASE UNIT
RS485 HALF DUPLEX
JUMPER & WIRING
1 2 3
JP1
RXD/R- DSR/R+ TXD/T- RTS/T+ CTS GND
1 2 3 4 5 6
AVCC AIN1 AIN2 AIN3 AIN4 AGND
1 2 3 4 5 6
DIN1 GND DIN2 GND DO1 GND DO2 GND V+ GND
1 2 3 4 5 6 7 8 9 10
9-30Vdc
BASE UNIT
RS422/485 FULL DUPLEX
JUMPER & WIRING
GND
Rx+
Rx-
Tx+
Tx-
1 2 3
JP1
RXD/R- DSR/R+ TXD/T- RTS/T+ CTS GND
1 2 3 4 5 6
AVCC AIN1 AIN2 AIN3 AIN4 AGND
1 2 3 4 5 6
DIN1 GND DIN2 GND DO1 GND DO2 GND V+ GND
1 2 3 4 5 6 7 8 9 10
9-30Vdc
BASE UNIT
RS232 FIELD
JUMPER & WIRING
GND
RTS
CTS
RXD
TXD
1 2 3
JP1
RXD/R- DSR/R+ TXD/T- RTS/T+ CTS GND
1 2 3 4 5 6
AVCC AIN1 AIN2 AIN3 AIN4 AGND
1 2 3 4 5 6
DIN1 GND DIN2 GND DO1 GND DO2 GND V+ GND
1 2 3 4 5 6 7 8 9 10
GND
Signal
VS
BASE UNIT
DI1 / DO1
WIRING
BASE UNIT
ANALOG INPUT 1
WIRING
GND
DI
GND
DO
BASE UNIT
POWER
WIRING
GND
9-30Vdc
QUICK START GUIDEBASE UNIT - WIRELESS GATEWAY (DH1)
