PURPOSE OF THE MANUAL
This manual is an integral part of the HMI
unitHIGH VISION and has been drawn up by the
manufacturer in its original language (Italian) to
provide all the information necessary for an adequate
and safe use of the unit throughout its life cycle: from
transport to delivery, use and maintenance, up until
disposal .
Before carrying out any operation, users and
technicians must carefully read the instructions and
strictly comply with them.
In the case of doubts in correctly interpreting them,
contact the manufacturer to obtain the necessary
clarifications. The regular operation of the unit over
time will be ensured and the occurrence of dangerous
situations for people and things will be avoided only
by observing what is reported below.
The manual provides warnings and instructions
relating to safety regulations for the prevention
of accidents. In any case, operators must observe
the safety regulations imposed on them by the
regulations in force with the utmost attention. Any
changes to the safety regulations that may take place
over time must be acknowledged and implemented.
It is recommended to read this manual carefully
before putting the unit into operation.
With a view to continual improvement, OLI eBike
Systems may change some characteristics of the
components used without prior notice. This does not
affect the validity of the information contained in this
document. If inconsistencies are found between what
is described in the manual and the use of the unit,
please notify the manufacturer.
The updated copy of this manual is available on
the website www.oli-ebike.com.
CONSERVATION OF THE MANUAL
The manual must accompany the unit throughout its
lifecycle and must be available to all the operators
and technicians who may need it.
The manual must follow the unit if it is transferred to
a new user or owner.
READING THE MANUAL
To consult the manual you can use:
› the initial index;
› the menu on the left side of each page;
› the references indicated with see “chapter name” on
page.00 .
GENERAL INFORMATION
If using a digital format, to make the most of the
interactive navigation functions, we recommend
opening it with the free Adobe reader software
(https://get.adobe.com/it/reader/).
The icon indicates additional interactive areas
other than those listed above.

GENERAL
INFORMATION
DESCRIPTION
INSTALLATION
USE
TROUBLESHOOTING
MAINTENANCE AND
ASSISTANCE
OLI eBike Systems | High Vision
MANUFACTURER
OLI eBike System is at your disposal for any problem
or information.
Communications and requests can be sent to:
OLI eBike Systems
contact details
Tel [phone]
site
For any need concerning the use, maintenance or
request for spare parts, please specify the unit
identification data shown on the manufacturer's
plate.
CERTIFICATION
The unitHIGH VISION was made in compliance with
the relevant Community Directives applicable at the
time of its being placed on the market, and therefore
it meets the safety requirements of the machinery
directive 2006/42 / EC and the UNI EN 15194: 2018
standard.
The unit complies with the laws in force.
Being a product undergoing significant technical
and regulatory development, OLI eBike Systems
reserves the right to update it as quickly as possible
to the latest technological knowhow and the official
applicable standards (UNI, EN, ISO) that become
available from time to time.
All the products described in this manual have been
manufactured according to the operating procedures
defined by the Quality System of OLI eBike Systems,
a division of OLI®spa. The company’s Quality System,
certified in accordance with the UNI EN ISO 9001
Standard, is able to ensure that the entire production
process, from the formulation of the order to
technical assistance following delivery, is carried
out in a controlled and adequate manner in order to
guarantee the quality standards of the product.
www.oli-ebike.com
Via delle pesche, 891
47522 Cesena (FC) ITALY
[e-mail]
studioimmagina.com 00_102020
04

DESCRIPTION
INSTALLATION
USE
TROUBLESHOOTING
MAINTENANCE AND
ASSISTANCE
OLI eBike Systems | High Vision
studioimmagina.com 00_102020 05
GENERAL
INFORMATION
WARRANTY
The unit is covered by a warranty on materials for
a period of 36 months from the date shown on the
shipping document. The buyer loses the right to the
warranty in the case of incorrect use or when he
or she has made changes or repairs to the supplies
without the manufacturer's authorization.
Upon receipt of the product, the recipient must check
that there are no defects or damages resulting from
transport and / or incompleteness in the supplies.
Any complaints must be reported immediately to the
manufacturer by means of a written communication
countersigned by the carrier.
Labour services, such as sending a technician, are
excluded from the warranty.
In no case can compensation for damages be
demanded.
For further information on the conditions of
assistance under warranty, please refer to the sales
contract.
Products shipped for repair under warranty
must be returned carriage paid to the
manufacturer's factory.
RETURNS
In case of return, if you have kept the original
packaging, reuse it for shipping.
Otherwise, place the unit in a box trying to protect it
as well as possible from any impacts resulting from
transport.
SAFETY RULES
In order to minimize the causes that can create
dangerous situations for users and others, we invite
you to adopt appropriate rules of conduct.
In particular, the following points should be observed
when using the eBike:
› consult your doctor before starting an exercise
program;
› observe the traffic regulations relating to pedal-
assisted bicycles;
› do not get distracted by looking at the display when
riding the bicycle;
› do not use the display as a handle;
› exclusively use the HMI unit and the supplied
keypad;
› remove the battery before carrying out any type
of intervention.
The manufacturer declines all responsibility in
case of damage to persons or things deriving
from improper use of the unit or failure to observe
the instructions given in the manual.

INSTALLATION
USE
TROUBLESHOOTING
MAINTENANCE AND
ASSISTANCE
OLI eBike Systems | High Vision
DESCRIPTION
GENERAL
INFORMATION
GENERAL DESCRIPTION
HIGH VISION is an HMI unit that allows you to analyse
and view data relating to the eBike and the training
in progress.
The unit consists of a sturdy, injection-moulded ABS
body housing the LCD display and a keypad containing
the keys that allow for control and navigation.
The unitHIGH VISION is exclusively intended
for use as an HMI on an eBike. Uses other than
those foreseen and not compliant with what is
described in this manual, as well as being considered
improper and prohibited, can create dangerous
conditions for people and things.
The manufacturer declines all responsibility for
improper use of the product.
The unit consists of the following components:
display
keypad
up
down
power
DESCRIPTION
studioimmagina.com 00_102020
06

INSTALLATION
USE
TROUBLESHOOTING
MAINTENANCE AND
ASSISTANCE
OLI eBike Systems | High Vision
studioimmagina.com 00_102020 07
DESCRIPTION
GENERAL
INFORMATION
TECHNICAL DATA
Display type Dot matrix LCD
Operating temperature -5°C / 40°C
Storage temperature -20°C / 60°C
Degree of protection IP 67
SIZES AND OVERALL DIMENSIONS
82mm 54mm 13mm
73mm
32mm
75mm

DESCRIPTION
USE
TROUBLESHOOTING
MAINTENANCE AND
ASSISTANCE
OLI eBike Systems | High Vision
INSTALLATION
GENERAL
INFORMATION
DISPLAY INSTALLATION
1 > Insert the display holder rings on the handlebar.
2 > Install the display on the support, tightening the
M4 fixing screws.
1.5 - 3 Nm
INSTALLATION
studioimmagina.com 00_102020
08

DESCRIPTION
USE
TROUBLESHOOTING
MAINTENANCE AND
ASSISTANCE
OLI eBike Systems | High Vision
studioimmagina.com 00_102020 09
INSTALLATION
GENERAL
INFORMATION 3 > Position the display on the supports paying
attention to the angle (15 ° - 35 ° with respect to the
horizontal plane) and tighten the fixing screws with
the nuts.
1.5 - 3 Nm
2.5

DESCRIPTION
USE
TROUBLESHOOTING
MAINTENANCE AND
ASSISTANCE
OLI eBike Systems | High Vision
INSTALLATION
GENERAL
INFORMATION
KEYPAD INSTALLATION
1 > Position the keypad while paying attention to the
angle (15 ° - 35 ° with respect to the horizontal plane),
so as to allow the user to operate it comfortably while
moving.
2 > Tighten the fixing screws.
1.5 - 3 Nm
3
3 > Insert the display cable into the frame to be able
to connect it to the power unit.
studioimmagina.com 00_102020
10

DESCRIPTION
USE
TROUBLESHOOTING
MAINTENANCE AND
ASSISTANCE
OLI eBike Systems | High Vision
studioimmagina.com 00_102020 11
INSTALLATION
GENERAL
INFORMATION
TRANSPORT, PACKAGING AND STORAGE
The unit is supplied with dedicated packaging which
avoids damage from transport.
Upon receipt of the goods, the customer must check
whether the model and quantity received correspond
to the data in the order confirmation.
The components must be stored indoors in dry
environments, protected from atmospheric agents
and at temperatures above -10 ° C.
It is the user's responsibility to properly
dispose of the packaging in compliance with
the laws in force.

HOME
MENU
ADVANCED
OLI eBike Systems | High Vision
USE
DESCRIPTION
INSTALLATION
TROUBLESHOOTING
MAINTENANCE AND
ASSISTANCE
GENERAL
INFORMATION
studioimmagina.com 00_102020
12
COMMANDS
To navigate the software there are 3 keys that can be
used with short press or with a press of more than 2
seconds.
Throughout this manual, the following icons are used
to indicate the type of key and press for each action.
key short press / <1 second (1 ") long press /> 2 seconds (2 ")
power allows you to:
scroll on the Home screen from one
main screen to another;
scroll between the Home screen and
the Menus;
confirm the action during the
changes.
allows you to:
turn the display on or off;
from the Menu and Advanced section,
return to the last displayed Home
screen.
up allows you to scroll through the menu
items, going up
from any main screen allows you to
change the operating mode of the
lights
down allows you to scroll through the menu
items, going down
from any main screen allows you to
activate Walk mode
down+up - from the main screens, pressing the
two keys simultaneously allows access
to the Menu
USE

HOME
MENU
ADVANCED
OLI eBike Systems | High Vision
USE
DESCRIPTION
INSTALLATION
TROUBLESHOOTING
MAINTENANCE AND
ASSISTANCE
GENERAL
INFORMATION
studioimmagina.com 00_102020 13
NAVIGATION DIAGRAM
HOME MENU
ADVANCED
Race
Distance
POWER ONPOWER OFF
Time
Pace
Power
Summary
System Info
Battery Info
Back
Advanced
Reset Trip
Weight
Gender
Mod. Night
Back
Unit
Language
Brightness

HOME
MENU
ADVANCED
OLI eBike Systems | High Vision
USE
DESCRIPTION
INSTALLATION
TROUBLESHOOTING
MAINTENANCE AND
ASSISTANCE
GENERAL
INFORMATION
studioimmagina.com 00_102020
14
POWER ON
To turn on the display, depending on the type of
battery installed:
› press and hold the power-on key until the power-on
screen with the manufacturer's logo is displayed or
press the on key on the battery.
Wait a few seconds to display the first Home screen.
POWER OFF
To turn off the display, depending on the type of
battery installed:
› press and hold the power-on key until the power-
off screen appears or press the off key on the
battery.
Wait a few seconds for the system to shut down
completely.
If the eBike is not used for a certain amount of
time, depending on the type of battery, the
system will switch off automatically.
ON
OFF Shutting down

MENU
ADVANCED
OLI eBike Systems | High Vision
USE
DESCRIPTION
INSTALLATION
TROUBLESHOOTING
MAINTENANCE AND
ASSISTANCE
GENERAL
INFORMATION
studioimmagina.com 00_102020 15
HOME
HOME
After powering on, the first Distance screen of the
Home section is displayed.
The Home section consists of 6 screens.
To scroll through the screens you need to press the
power-on key .
From any screen in the Home section, you can:
› adjust the assistance level by pressing the up
and down keys ;
› enter Walk mode by holding down the down key ;
› adjust the brightness of the eBike lights by holding
down the up key for 2";
› enter the Menu section by holding down the up +
down keys at the same time for 2".
Walk mode
MENU
Distance Time Pace Power Race Summary
assistance
level
1
3
0
2
4
5
eBike light adjustment
auto off auto on offon

MENU
ADVANCED
OLI eBike Systems | High Vision
USE
DESCRIPTION
INSTALLATION
TROUBLESHOOTING
MAINTENANCE AND
ASSISTANCE
GENERAL
INFORMATION
studioimmagina.com 00_102020
16
HOME
General screen layout
The screens in the Home section differ from each
other in the type of information displayed. eBike light adjustment
automatic / on / off
see “eBike light adjustment “on
pg. 22
assistance level
see “Assistance level “on pg. 20
navigation bar
present on each screen, indicates
the current screen
power graph display
upper bar: motor power
lower bar: cyclist power
battery
charge percentage
current eBike speed
in kilometres / hour (km / h)
variable parameter
parameters indicated in the screens
motor power
cyclist power
distance travelled from the start of the lap
time elapsed since the start of the lap
pedal pace
energy burned by the cyclist
average consumption of the eBike
total distance travelled
average speed

MENU
ADVANCED
OLI eBike Systems | High Vision
USE
DESCRIPTION
INSTALLATION
TROUBLESHOOTING
MAINTENANCE AND
ASSISTANCE
GENERAL
INFORMATION
studioimmagina.com 00_102020 17
HOME
The first 4 screens differ only for the variable
parameter which is described below.
To reset the datasee “Reset trip “on pg. 24 .
For other screen datasee “General screen layout “on
pg. 16 .
Distance screen
Indicates the distance travelled in
kilometres (km) since the last reset.
Time screen
Indicates the time elapsed in motion since
the last reset. The value is expressed in
hours: minutes: seconds.
Pace screen
Indicates the instantaneous speed of
rotation of the rotating pedals per minute
(rpm).
Energy screen
Indicates the energy consumed by the
cyclist in kilocalories (kcal) since the last
reset.

MENU
ADVANCED
OLI eBike Systems | High Vision
USE
DESCRIPTION
INSTALLATION
TROUBLESHOOTING
MAINTENANCE AND
ASSISTANCE
GENERAL
INFORMATION
studioimmagina.com 00_102020
18
HOME
"Race" screen
It is the fifth screen of the Home section.
In this screen, the values in watts (w) of the motor
power and cyclist power are expressed in full.
Indicates the instantaneous power
delivered by the motor in watts (w).
Indicates the instantaneous power
expressed by the cyclist in watts (w).
Power graph display
upper bar: motor power
lower bar: cyclist power
Indicates the average energy consumption
in watt-hours per kilometre (Wh / km),
calculated since the last reset.
This data allows you to adjust the level and, therefore,
the consumption of the eBike according to the need.
By calculating the relationship between this data and
the battery capacity, the exact distance possible for
each charge is obtained.
To reset the datasee “Reset trip “on pg. 24 .
For other screen datasee “General screen layout “on
pg. 16 .
pace
current
speed
assistance
level
battery
capacity
average
consumption
Kms that can
be travelled

MENU
ADVANCED
OLI eBike Systems | High Vision
USE
DESCRIPTION
INSTALLATION
TROUBLESHOOTING
MAINTENANCE AND
ASSISTANCE
GENERAL
INFORMATION
studioimmagina.com 00_102020 19
HOME
Summary screen
It is the sixth screen of the Home section.
This screen summarizes the variable parameters of
the previous screens.
Indicates the distance travelled in
kilometres (km) since the last reset.
Indicates the time elapsed in motion since
the last reset. The value is expressed in
hours: minutes: seconds.
Indicates the average speed in kilometres per
hour (km / h) measured since the last reset.
Indicates the average energy consumption
in watt-hours per kilometre (Wh / km),
calculated since the last reset.
Indicates the energy consumed by the cyclist
in kilocalories (kcal) since the last reset.
Indicates the total distance travelled by
the eBike in kilometres (km). Non-
resettable value.
To reset the data of these parameterssee “Reset trip
“on pg. 24 .
For other screen datasee “General screen layout “on
pg. 16 .

MENU
ADVANCED
OLI eBike Systems | High Vision
USE
DESCRIPTION
INSTALLATION
TROUBLESHOOTING
MAINTENANCE AND
ASSISTANCE
GENERAL
INFORMATION
studioimmagina.com 00_102020
20
HOME
Assistance level
From any screen in the Home section it is possible to
change the assistance level by pressing the up key
to increase it and the down key to decrease it.
The table shows the multiplication factor for each
level of assistance.
level multiplicative factor
0 0% (motor inactive)
150%
2 100%
3200%
4300%
5400%
The assistance percentages of the levels are
indicative because they can be customized by the
eBike manufacturer.
