Oliso smart iron TG1600Pro+ User manual

MAX
user manual
smartiron®
for model TG1600Pro+

2
When using your iron, basic safety precautions should always be followed, including the following:
read all instructions before using this product
important safety instructions
special instructions
Use iron only for its intended use.
To protect against a risk of electric shock, do not immerse the iron in water or other liquids.
The iron should always be turned to “O” before plugging or unplugging from the outlet.
Never yank cord to disconnect from the outlet; instead, grasp plug and pull to disconnect.
Do not allow cord to touch hot surfaces. Let iron cool completely before putting away.
Loop cord loosely around iron when storing.
Always disconnect iron from the electrical outlet when filling with water or emptying and when not in use. The plug must be removed
from the socket-outlet before the water resevoir is filled with water.
The iron is not to be used if it has been dropped, if there are visible signs of damage, or if it is leaking.
Do not operate iron with a damaged cord or if the iron has been dropped, damaged. To avoid the risk of
electric shock, do not disassemble the iron. Take it to a qualified serviceperson for examination and repair.
Incorrect reassembly can cause a risk of electric shock when the iron is used.
Close supervision is necessary for any appliance being used by or near children. Do not leave iron unattended while
connected or on an ironing board. Children should be supervised to ensure that they do not play with the appliance.
The iron must be used and rested on a stable surface.
Burns can occur from touching hot metal parts, hot water, or steam. Use caution when you turn a steam iron
upside down - there may be hot water in the reservoir.
If the malfunction indicator goes on, the flatiron is not operating normally.
Disconnect from the power supply and have the flatiron serviced by a qualified service personnel.
When placing the iron on its stand, ensure that the surface on which the stand is placed is stable.
To avoid a circuit overload, do not operate another high wattage appliance
on the same circuit.
If an extension cord is absolutely necessary, a 15-ampere cord should be used. Cords rated for less amperage can result in a risk of fire
or electric shock due to overheating. Care should be taken to arrange the cord so that it cannot be pulled or tripped over.
This iron uses hot steam! To reduce the risk of electric shock, this appliance has a polarized plug (one blade is wider than the other).
This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician to install the proper outlet. Do not change the plug in any way.
Never direct fill the iron from a water tap while the iron is plugged into a power source.
FOR HOUSEHOLD USE ONLY.
1
2
3
4
5
please save these instructions
1
2
3
4
5
6
7
8
9
10
11
12
The appliance is not intended for use by persons (including children) with reduced physical sensory or mental capabilities, or lack
of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
13

1
2
3 4
5
6
910
status light11
spray nozzle
8
steam burst9
fabric selector7
soleplate
scorch guards™
360° pivot cord13
get to know your oliso®smart iron®
11 127 8
side view top view back view
flip funnel™ 51
3
4
detailer tip spray mist10water tank62
13
3
itouch®handle12
steam selector

4
3 simple steps to start
step 2
Plug in.
Choose a
fabric setting
then set desired
steam level.
step 1
fill unplugged
Open the flip funnel™
and add water to the
tank with the fill cup or
directly from a faucet.
2 fill cups equal the max
capacity of the water tank.
step 3
iron
When the green light
stops blinking and is solid,
the iron is ready for use.
Touch the handle
and begin using.
set up

5
your gentle touch
activates the itouch®
handle to quickly
lower iron into place
For more information regarding the auto shut-o safety feature see page 6.
itouch®
+auto-lift® system
instantly raises iron
up when itouch®
handle is released
auto-lift®
itouch®+ auto-lift®
touch
touch
activated
handle
activating itouch®
release

Simply touch the handle of the iron to restart it.
30
seconds
iron position after ironing
TG1600Pro+
If the oliso® smart iron® is not being used while it is plugged in, the status
light will flash red and the iron will turn itself o.
store iron properly
auto shut-off system
6
30
minutes
30
minutes
horizontal
lifted
vertical
knocked
over
1
Turn the fabric selector to o.
Slide the steam selector to o ( ).
2 Unplug the appliance. (Do not hold iron
while unplugging or the scorch guards™
will not stay extended. Iron should always
be stored with scorch guards™ extended
to prevent leaking).
4 Important: Empty water from the water
tank after each use. To do this, open the
flip funnel™ and tilt the iron to the left
over a water receptacle until the tank is
empty.
5
For easy storage, the power cord can
be wound loosely around the iron
once it has cooled.
3 Allow to cool thoroughly before storing.

This iron is designed to be used with
regular tap water. If your water is
over 12 grams of hardness, we
recommend using either inexpensive
bottled spring water or mixing half
tap water with half distilled water.
If storing the iron for more
than two days, please
remember to empty your
tank.
100% distilled water
as this can cause the iron to spit and leak.
Alternatively, fill directly from a
faucet holding the iron
horizontally.
Make sure iron is unplugged.
unplug ironswitch o open port fill (cup included) Two fill cups equal the max
capacity of the water tank.
Fill the tank past the MAX fill
line on the side of the iron.
Close the port when done.
If you need to add water during ironing, unplug the iron and repeat the above steps.
After filling, make sure the iron is fully reheated before ironing.
step 1 step 2 step 3
DO NOT
NEVER USE
filling water tank
max fill line alternative filling
7
MAX
water
recommendations emptying
the tank
anti-scale

The oliso® smart iron® uses a status light to display the iron’s
status. To ensure correct temperature, wait until the light
displays solid green before ironing.
red
heat o ready auto o
(heat)
optimizing
temperature
flashing green solid green flashing red
to select a fabric setting. To use continuous steam or steam burst, the
temperature must be set to the cotton or linen range.
dry iron steam iron
Turn the fabric temperature selector
8
fabric selector
status light
fabric selector
min.

dry ironing zero-drip
For a strong
burst of steam
from the
soleplate.
Helps iron
heavy fabrics
or dicult
areas.
press steam
button in Handheld
steamer for
curtains and
hanging clothes.
press steam
button in press spray button in
9
Rapid response™triple play®steam
continuous steam selector
Slide the steam selector to set the amount of continuous steam. The iron can only produce steam when the
fabric selector knob is set to linen + cotton
before activating the steam control. Steam will be
produced as soon as the iron is lowered. Steam will
stop when iron lifts up.
Allow the iron to heat up (solid green status light)
horizontal burst vertical steam spray
The oliso® smart iron® has a
zero-drip feature which shuts o
steam any time the iron’s scorch
guards™ are extended.
zero-drip
system
To turn o the steam, slide the steam selector o ( ).

problem
maintenance + cleaning
things to check solution
Iron does
not heat
Is fabric selector set to o?
Is iron plugged in correctly?
Is auto shut-o system activated?
Turn the fabric selector knob to a fabric setting.
Check to make sure the plug is fully plugged into the socket.
Touch the handle.
Scorch
Guards™
do not
come out
Iron does
not steam
Is iron plugged in correctly?
Is handle activated?
Check to make sure the plug is fully plugged into the socket.
Move your hand away from the iron, and the itouch® technology will raise the soleplate.
Is iron hot enough?
Is steam selector set to o?
Is steam valve clogged?
The fabric selector must be set to the wool, cotton or linen settings to produce continuous steam.
Steam selector must be turned to a setting.
Move the steam selector from o ( ) to the max ( ) settings a few times to unclog.
Iron
leaks
Is iron is hot enough?
Has steam burst button been overused?
Iron is
emitting a
brown
or white
substance
Is water hardness too high? Switch to either spring water or half tap/half distilled water mixture.
See water recommendations on page 7.
Make sure the fabric selector knob is set to the cotton or linen range to
ensure proper steam production.
Allow 3 seconds between uses of the steam burst function.
The soleplate should be cleaned if starch or other residue builds up. When the iron is cool, wipe the soleplate with a soft, damp cloth.
Do not use abrasive cleaners or scouring pads as this will damage the iron’s soleplate.
Mineral deposits from tap water can occur in the soleplate vents. To clean, fill the water tank and heat the iron to the linen fabric setting. Once the iron is fully heated,
unplug the iron and hold over a sink. Press the steam button repeatedly until water begins to drip out of the soleplate.
Be careful, as this creates large amounts of steam.
To ensure optimal steam production, the steam valve should be regularly cleared of accumulated debris and minerals. This is done by moving the steam selector back
and forth from the o ( ) to the max ( ) steam settings several times.
trouble shooting guide
10
If problems persist please visit oliso.com/faqs

warranty
Oliso warrants that for a period of three years (TG1600Pro+ Models) from the date of the original purchase, this product will be free from defects in material and
workmanship, when utilized for normal household use. Oliso will repair or replace this product or any component of the product found to be defective during the warranty
period without charge to the customer. If a replacement product is sent, it will carry the remaining warranty of the original product. Replacement will be made with a new
or remanufactured product or component. If the product is no longer available, replacement may be made with a similar product of equal or greater value. This is your
exclusive warranty.
This warranty is valid for the original retail purchaser from the date of initial retail purchase and is not transferable. Keep the original sales receipt. Proof of purchase is
required to obtain warranty performance. Oliso dealers or retail stores selling oliso products do not have the right to alter, modify or in any way change the terms and
conditions of this warranty.
The liability of oliso is limited solely to the cost of repair or replacement of the product at its option. This warranty does not cover normal wear of parts and does not apply
to any product that has been tampered with or used for commercial purposes. This warranty does not cover damage caused by misuse, abuse, use on improper voltage or
current, use contrary to the operating instructions, negligent handling or damage due to faulty packaging or mishandling in transit. This warranty does not cover damage
or defects caused by or resulting from damages from shipping or repairs, service or alteration to the product or any of its parts, which have been performed by a repair
person not authorized by oliso. Further, the warranty does not cover Acts of God such as fire, flood, hurricanes, and tornadoes.
This warranty is extended to the original purchaser of the product and excludes all other legal and/or conventional warranties. The responsibility of oliso is limited to the
specific obligations expressly assumed by it under the terms of the limited warranty. In no event shall oliso be liable for any incidental or consequential damages caused by
breach of any express, implied or statutory warranty or condition.
Except to the extent prohibited by law, any implied warranty or condition of merchantability or fitness for a particular purchase is limited in duration to the duration of the
above warranty. oliso disclaims all other warranties, conditions, or representations, express, implied, statutory or otherwise. In no event shall oliso be liable for any indirect,
special, incidental or consequential losses or damages (including but not limited to interruption of business or loss of business or profit) resulting from the use of or
inability to use the product, any breach of contract, fundamental or otherwise, or for any claim brought against purchaser by any other party. Some states or jurisdictions
do not allow the exclusion or limitation of incidental or consequential damages or limitations on how long an implied warranty lasts, so the above limitations or exclusion
may not apply to you. If you have any question regarding this warranty or would like to obtain warranty service. Please email oliso at [email protected]om, and a
service center address will be provided to you.
8:30am - 4:30pm (Pacific) Monday-Friday 1-800-899-5157
or mail us at 1200 Harbour Way S, STE 215, Richmond, California, 94804, USA.
Please note: Your oliso® smart iron® may look slightly dierent than the irons illustrated here.
For a complete review of current oliso® smart iron® models, please visit oliso.com
11
For more information visit
[e-mail]
oliso.com

for purchasing the
smartiron®
© 2021 Unovo LLC dba OLISO All rights reserved. oliso® logo, smart iron®, itouch®, and auto-lift® are registered trademarks of Unovo LLC dba OLISO.
U.S. Patent No. #6,453,587 B1, #6,925,738 B2, #7,406,783 B2 & # 7,546,701 B2. EU Patent No. #EP1404915B1 & Patents Pending.
SKU #40003001, Printed in China.
reinvented
