[1] CONFIGURATION
Option (PS3 expansion kit)
<AR-NC7/NC8>
<AR-PK6>
d-copia3501/4501/351
Network function: AR-NC7
Network and
Document filing function: AR-NC8
CD-ROM
Product key sheet
BOOT ROM
MAIN ROM
HDD expansion PWB
(AR-NC8 only)
Print server card
Network utility CD-ROM
Product key sheet
Win95/Win98/WinMe/WinNT4.0/Win2K/WinXP
Application
PostScript
PCL5e(SPDL)
PCL6(SPDL2)
Others
Adobe
PostScript
PPD
Printer Driver
1284 Port Ethernet Port
Host I/O Manager
1284
Soft
NIC USB
PCI
PJLFontStatus
File Manager Memory
Print Manager
TIFF
Firmware
PDF
PostScript
PCL6(SPDL2)
PCL5e(SPDL)
AUTO
USB 1284
USB Port
GDI(Graphic Module)
Serial
PCU
Engine
ImageBus
Engine I/F Manager
Print Spooler
Roman
Kanji
Printer software, firmware diagram
Y105610-1 Sevice Manual 1-1

[2] SPECIFICATIONS
1. Printer specifications
* An optional PS3 expansion kit is needed.
2. Printer driver functions
(1) Windows driver functions
a. General
*1: For printing, PS driver bundled with the Windows is required.
*2: Since the function is of PS driver bundled with Windows, spec-
ification may vary according to the OS.
Memory capacity
(standard)
Standard 128MB
DIMM slots for
additional memory
One (128 MB to 256 MB memory can be
mounted.)
Page description
language
PCL6, PCL5e, PS3 emulation*
Resident font For PCL: Outline fonts: 80
Barcode fonts (option): 28
Bitmap font: 1
PostScript compatible fonts (option): 136
Interface IEEE-1284 compatible parallel interface
(P1284B connector)
USB1.1 (Windows98/ME/2000/XP/
Server 2003)
USB2.0 (Windows2000/XP/Server 2003)
LAN connection 10Base-T/100Base-TX
Supported protocols:
IPX/SPX, TCP/IP, EtherTalk, NetBEUI
Operating system IBM PC/AT or compatible computer:
Windows 95/98/Me,
Windows NT 4.0 (ServicePack5 or later),
Windows 2000 Server/Professional,
Windows XP Professional/Home Edition,
Windows Server 2003
Macintosh series*: Mac OS 8.6 to 9.2.2,
10.1.5, and 10.2 to 10.2.8 (except 10.2.2),
10.3 to 10.3.3
Continuous print
speed
Same as the engine speed of the machine
(Print speed during printing of the second
sheet and following sheets when using A4
(8-1/2" x 11") plain paper and performing
continuous one-sided printing of the same
page; excluding use of offset output.)
Resolution Data processing: 600 x 600 dpi
Printing: 600 x 600 dpi,
1200 dpi equivalent x 600 dpi
Function PCL5e PCL6 PS PPD file *1
(for Windows XP)
Copies 1-999
Orientation Portrait
Landscape
Portrait
Landscape-A
Landscape-B
(*2)
Duplex 1-sided
2-sided
(Left /top/ right
binding)
1-sided
2-sided
(Long / short
binding)
(*2)
Booklet Invoice on Letter
Letter on Ledger
A5 on A4
A4 on A3
B5 on B4
Letter on Letter
Ledger on Ledger
A4 on A4
A3 on A3
B4 on B4
Yes
(2up booklet only)
(*2)
Binding edge Left / top / right No
N-up 2/4/6/8/9/16 2 / 4 / 6 / 9 / 16
(*2)
N-up order Z / Reversed Z /
N / Reversed N
Z (*2)
N-up border Yes / No Always Yes (*2)
2-1 Service Manual Y105610-1

b. Paper Input
*1: For printing, PS driver bundled with the Windows is required.
c. Paper Output
*1: For printing, PS driver bundled with the Windows is required.
d. Graphic
*1: For printing, PS driver bundled with the Windows is required.
*2: Since the function is of PS driver bundled with Windows, spec-
ification may vary according to the OS.
e. Font
f. Others
*1: For printing, PS driver bundled with the Windows is required.
*2: Since the function is of PS driver bundled with Windows, spec-
ification may vary according to the OS.
Function PCL5e PCL6 PS PPD file *1
(for Windows XP)
Paper size A3 / B4 / A4 / B5 /
A5 / Ledger /
Legal / Foolscap /
Letter / Executive
/Invoice/8k / 16k
/COM10/C5/
Monarch/DL
ISO B5 /
Japanese post card /
Custom
Paper type Plain
Letter Head
Pre-Print
Pre-Punch
Recycle
Color
Label
Heavy Paper
Transparency
Envelope
Custom
paper type
7 type No
Source
selection
Automatic
Tray 1/2/3/4
Bypass-tray
LCT
Cover Yes/No
User can select from
1-sided/2-sided/
No print
No
Insert page Yes/No
User can select from
1-sided/2-sided/
No print
No
Transparency
inserts
No
Yes (Blank)
Yes (Printed)
No
Function PCL5e PCL6 PS PPD file *1
(for Windows XP)
Output tray
selection
Center tray
Finisher
•Top tray
•Offset tray
Saddle Stitch
Finisher
•Offset tray
Mailbin stacker
•Mailbin top tray
•Mailbin (1-7)
Duplex module
•Left tray
Staple Finisher
•No staple
•1 staple
•2 staples
Saddle Stitch
Finisher
•No staple
•1 staple
•2 staples
Saddle Stitch
Finisher
•No staple
•1 staple
•2 staples
Offset cancel Yes/No
Function PCL5e PCL6 PS
PPD file *1
(for Windows
XP)
Resolution
setting
600/300 dpi 600dpi 600dpi
Halftone
setting
No No Screen frequency
8.0 to 360.0
in 0.1 steps
Screen angle
0.0 to 360.0
in 0.1 steps
No
Graphics
mode
Raster
HP-GL2
Raster
Vector
No No
Smoothing Yes/No
Toner save Yes / No
enhancement
No Yes/No No
Negative
No No Yes / No
Mirror image No No Horizontal
Vertical
Horizontal
(*2)
Zoom No No 25-400%
(XY zoom)
1-1000%
(*2)
Fit to page Yes / No No
Function PCL5e PCL6 PS PPD file *1
(for Windows XP)
Download
font
Bitmap
TrueType
Bitmap
Type1
TrueType
Auto
Outline
Bitmap
Native TrueType
(*2)
Function PCL5e PCL6 PS PPD file *1
(for Windows XP)
Configuration
setting
Yes
Watermark Yes Yes
(functionality is
limited)
Line width
setting
No
Form overlay Yes No
Print hold Yes No
Confidential print Yes No
Sample print Yes No
Print accounting Yes No
Quick sets Yes No
Auto
configuration
Yes No
Job end
notification
Yes No
Tandem print Yes
Carbon print Yes No
Multi-
enlargement
No
XY zoom No Yes No
Cover insert +
pamphlet
Yes No
Document filing Yes No
Y105610-1 Sevice Manual 2-2

(2) Macintosh driver functions
a. General
*1: Since the function is of PS driver bundled with Macintosh,
specification may vary according to the OS.
b. Paper input
*1: Since the function is of PS driver bundled with Macintosh,
specification may vary according to the OS.
c. Paper output
d. Graphic
*1: Since the function is of PS driver bundled with Macintosh,
specification may vary according to the OS.
e. Font
*1: Since the function is of PS driver bundled with Macintosh,
specification may vary according to the OS.
Function Macintosh PPD file
(for Mac OS X ver10.2.8)
Copies 1-999
Orientation Portrait
Landscape-A
Landscape-B (*1)
Duplex 1-sided
2-sided
Pamphlet
(Right /left /top binding)
Booklet Yes
N-up 2/4/6/9/16 (*1)
N-up order Z / reversed Z / N / reversed N (*1)
N-up border None / Single hairline / Single thin line /
Double hairline / Double thin line (*1)
Function Macintosh PPD file
(for Mac OS X ver10.2.8)
Paper size A3 / B4 / A4 / B5 / A5 /
Japanese Postcard /
Ledger / Legal / Foolscap / Letter /
Executive / Invoice/ 8K / 16K/
COM10/C5/Monarch/DL
Paper type Plain / Letter Head / Pre-Print /
Pre-Punch / Recycle / Color /
Label / Heavy Paper / Transparency /
Envelope
Custom paper
type
7
Source selection Automatic
Tray 1/2/3/4
Bypass-tray
Different 1st
page
Yes / No (*1)
Cover / insert
page
No
(On OS9, user can select from: No/First
Page/Last Page)
(*1)
Transparency
inserts
No
Yes (Blank)
Yes (Printed)
Function Macintosh PPD file
(for Mac OS X ver10.2.8)
Output tray
selection
Center tray
Finisher
•Top tray
•Offset tray
Saddle Stitch Finisher
•Offset tray
Mailbin stacker
•Mailbin top tray
•Mailbin (1-7)
Duplex module
•Left tray
Staple Finisher
•No staple
•1 staple
•2 staples
Saddle Stitch Finisher
•No staple
•1 staple
•2 staples
Offset Yes/No
Function Macintosh PPD file
(for Mac OS X ver10.2.8)
Resolution
setting
600dpi
Halftone setting No
Graphics mode No
Smoothing Yes/No
Toner save Yes/No
enhancement
Yes/No
Negative image No
Mirror image No
Zoom 1-100000 (*1)
Fit to page No
Function Macintosh PPD file
(for Mac OS X ver10.2.8)
Download font No
(Selectable only on MacOS9.x.x -
LaserWriter) (*1)
2-3 Service Manual Y105610-1

f. Others
(3) Compatibility
(4) Printable area
The print area of this product is shown below.
If a printer driver for Windows or Macintosh is used for printing, the
printable area will be smaller. The actual printable area depends
on the printer driver to be used.
(in mm)
3. Printer function memory limitation matrix
*1: Expansion of 256MB is limited to 224MB by the hardware restriction (Max. 352MB).
*2: When the standard chart of the printer is used.
Function Macintosh PPD file
(for Mac OS X ver10.2.8)
Configuration setting Yes
Watermark Yes
Form overlay No
Print hold Yes
Confidential print Yes
(PIN selection)
Sample print Yes
Print accounting Yes
Quick sets No
Auto configuration No (OS9: Yes)
Job end notification No
Tandem print Yes
Carbon print No
Multi-enlargement No
XY zoom No
Cover insert + pamphlet No
Document filing Yes
PCL 5e
compatibility
Target for PCL5e is to be compatible with HP
LaserJet 4050.
Small margin difference, rendering difference
by different font family, default and transfer
function difference is not to be included in the
compatibility.
All the PJL commands are not necessarily
included in the compatibility.
PCL6
compatibility
Target for PCL6 is to be compatible with HP
LaserJet 4050.
Small margin difference, rendering difference
by different font family, default and transfer
function difference is not to be included in the
compatibility.
All the PJL commands are not necessarily
included in the compatibility.
PostScript
Compatibility
PostScript is targeted to be compatible with
Adobe PostScript as performed in HP LaserJet
4050.
Small margin difference, rendering difference
by different font family, default and transfer
function difference is not to be included in the
compatibility.
Paper size A B C D E
A3 297 420 4 289 4
B4 257 364 4 242 4
A4 210 297 4 202 4
B5 182 257 4 168 4
A5 148 210 4 140 4
Japanese postcard 100 148 4 92 4
Ledger 279 432 4 271 4
Legal 216 356 4 208 4
Foolscap 216 330 4 208 4
Letter 216 279 4 208 4
Executive 184 267 4 183 4
Invoice 140 2162 4 132 4
Com-10 (envelope) 105 241 4 97 4
C5 (envelope) 162 229 4 154 4
Monarch (envelope) 98 191 4 90 4
DL (envelope) 110 220 4 102 4
ISO B5 (envelope) 176 250 4 168 4
C
C
E
E
B
D
A
Paper size
Printable area
Standard
memory
Option
memory
capacity
Total memory
capacity
Hold job disable Hold job enable
ERDH
capacity
Number of
pages (*2)
Hold Job
Area capacity Number of
pages (*2)
Standard 128MB –128MB 20MB 87 10MB 56
Expansion-1 128MB 128MB 256MB 84MB 367 42MB 236
Expansion-2 128MB 256MB 352MB (*1) 132MB 577 66MB 371
Y105610-1 Sevice Manual 2-4

1AR-NC7 installation
<Before installation>
•To enable the network function, the product key must be
acquired. (For the method of acquiring the product key, contact
the dealer.)
Parts included
(1) Turn off the switch of the main unit.
1) Turn the power switch of the main unit to the “OFF”position.
2) For a model with the fax function, turn off also the fax power
switch.
3) Remove the power plug of the main unit from the outlet.
(2) Remove the control PWB unit.
1) If cables are connected to the control PWB, remove all cables.
3-1 Service Manual Y105610-1
[3]INSTALLATION

2) Remove the five screws that secure the control PWB unit to
the main unit.
3) While holding the two handles, pull the control PWB unit out
until the stopper is engaged.
4) Remove the flat cable connector.
5) While using your finger to unlock the stopper, pull the control
PWB unit out of the main unit.
(3) Mount the network function ROMs and a print
server card to the control PWB unit.
1) Remove the ROMs (MAIN and BOOT ROMs) from the control
PWB unit and replace them with the network function ROMs
(MAIN and BOOT ROMs).
The MAIN and BOOT ROMs are indicated with “MAIN”and
“BOOT”on the labels on the ROMs respectively.
When mounting the network function ROMs, insert them to the
same positions in the same orientations as those before
replacement until they click and ensure that the inserted
ROMs are locked with the sockets.
2) Remove the screws that secure the cover and remove the
cover.
Then, insert the connector of the print server card to the con-
nector of the control PWB unit.
3) Secure the print server card using the screws that have been
removed from the cover.
(4) Reattach the control PWB unit.
1) Reattach the control PWB unit to the main unit.
2) Reconnect the flat cable connector that has been removed in
step (2)-4).
3) Push the unit into the main unit and secure it with the five
screws.
4) Reconnect the cables that have been removed in step (2)-1) to
the original positions of the control PWB unit.
Then, connect the LAN cable to the connector of the print
server card.
If another peripheral device must be installed, carry out the
following steps at the end of the installation work.
(5) Turn on the main switch of the main unit.
1) Insert the power plug of the main unit to the outlet.
2) Turn the main switch of the main unit to the “ON”position.
3) For a model with the fax function, turn on also the fax power
switch.
(6) Enable the network function.
1) To enable the network function, use the keys on the operation
panel to enter the product key.
For entry of the product key, see the section of key operator
programs of the operation manual for the main unit.
After completing product key entry, turn off the power switch of
the main unit.
For a model with the fax function, turn off also the fax power
switch.
Turn on the power switch of the main unit again and, for a
model with the fax function, turn on also the fax power switch.
2) Carry out the network setting for the print server card.
Use a key operator program to carry out the network setting
for this machine.
For this network setting, the customer’s network environment
must be checked. Consult the network administrator to carry
out the setting.
2) 3)
5)
5)
3)
2)
4)
3)
2)
1)
3)
Y105610-1 Sevice Manual 3-2

3) According to the customer’s network environment, install the
printer driver software using the supplied CD-ROM.
For installation of the driver software to the computer and
server and its setting, follow the installation guide.
Installation of the driver software to the computer and server and
its setting must be performed by the customer or based on discus-
sion with the customer.
(7) Check the operation of the network function.
When installation of the printer driver is complete, carry out test
page printing to check to see if printing and output can be per-
formed normally.
(When test printing is complete, use the list print of a key operator
program to print the network settings for this machine and keep
the print carefully.)
Caution:
For acquisition of the product key, the application number
written on the separate product key sheet is needed. Keep
this sheet taking care not to lose it.
2. AR-NC8 installation
<Before installation>
•To enable the network function, the product key must be
acquired. (For the method of acquiring the product key, contact
the dealer.)
Parts included
(1) Turn off the switch of the main unit.
1) Turn the power switch of the main unit to the “OFF”position.
2) For a model with the fax function, turn off also the fax power
switch.
3) Remove the power plug of the main unit from the outlet.
(2) Remove the control PWB unit.
1) If cables are connected to the control PWB, remove all cables.
2) Remove the five screws that secure the control PWB unit to
the main unit.
3) While holding the two handles, pull the control PWB unit out
until the stopper is engaged.
4) Remove the flat cable connector.
5) While using your finger to unlock the stopper, pull the control
PWB unit out of the main unit.
(3) Mount the network function ROMs and a print
server card to the control PWB unit.
1) Remove the ROMs (MAIN and BOOT ROMs) from the control
PWB unit and replace them with the network function ROMs
(MAIN and BOOT ROMs).
The MAIN and BOOT ROMs are indicated with “MAIN”and
“BOOT”on the labels on the ROMs respectively.
When mounting the network function ROMs, insert them to the
same positions in the same orientations as those before
replacement until they click and ensure that the inserted
ROMs are locked with the sockets.
1)
2)
2)
3)
3)
4)
5)
5)
3-3 Service Manual Y105610-1

2) Remove the screws that secure the cover and remove the
cover.
Then, insert the connector of the print server card to the con-
nector of the control PWB unit.
3) Secure the print server card using the screws that have been
removed from the cover.
(4) Reattach the control PWB unit.
1) Reattach the control PWB unit to the main unit.
2) Reconnect the flat cable connector that has been removed in
step (2)-4).
3) Push the unit into the main unit and secure it with the five
screws.
4) Reconnect the cables that have been removed in step (2)-1) to
the original positions of the control PWB unit.
Then, connect the LAN cable to the connector of the print
server card.
(5) Remove the right cabinet of the main unit and the
HDD cover.
•If the saddle finisher or the like is installed at the right side of the
main unit, remove it in advance.
1) Remove the two screws that secure the right cabinet of the
main unit and then remove the right cabinet.
2) Remove the two screws that secure the HDD cover and then
remove the HDD cover.
(6) Mount the HDD expansion PWB to the main unit.
1) Remove the reuse band that secures the connector from the
frame of the main unit.
2) Taking care not to catch the two connectors of the main unit,
orient the HDD expansion PWB as shown in the illustration
and gently insert it all the way into the main unit along the rails.
3) Use the supplied screw to secure the HDD expansion PWB to
the main unit.
4) Connect the two connectors of the main unit to the HDD
expansion PWB.
(7) Reattach the HDD cover and the right cabinet of
the main unit.
1) Reattach the HDD cover that has been removed in step (5) to
its original position and secure it using the two screws.
2) Reattach the right cabinet of the main unit to its original posi-
tion and secure it using the two screws.
If another peripheral device must be installed, carry out the
following steps at the end of the installation work.
1)
2)
3)
3)
1) 2)
1)
2)
3)
4)
4)
Y105610-1 Sevice Manual 3-4

(8) Turn on the main switch of the main unit.
1) Insert the power plug of the main unit to the outlet.
2) Turn the main switch of the main unit to the “ON”position.
3) For a model with the fax function, turn on also the fax power
switch.
(9) Enable the network function.
1) To enable the network function, use the keys on the operation
panel to enter the product key.
For entry of the product key, see the section of key operator
programs of the operation manual for the main unit.
After completing product key entry, turn off the power switch of
the main unit.
For a model with the fax function, turn off also the fax power
switch.
Turn on the power switch of the main unit again and, for a
model with the fax function, turn on also the fax power switch.
2) Carry out the network setting for the print server card.
Use a key operator program to carry out the network setting
for this machine.
For this network setting, the customer’s network environment
must be checked. Consult the network administrator to carry
out the setting.
3) According to the customer’s network environment, install the
printer driver software using the supplied CD-ROM.
For installation of the driver software to the computer and
server and its setting, follow the installation guide.
Installation of the driver software to the computer and server and
its setting must be performed by the customer or based on discus-
sion with the customer.
(10) Check the operation.
When installation of the printer driver is complete, carry out test
page printing to check to see if printing and output can be per-
formed normally.
(When test printing is complete, use the list print of a key operator
program to print the network settings for this machine and keep
the print carefully.)
Check to see if the HDD expansion PWB is properly mounted and
if the document filing function is enabled.
Caution:
For acquisition of the product key, the application number
written on the separate product key sheet is needed. Keep
this sheet taking care not to lose it.
3. AR-PK6 installation
<Before installation>
•To enable the PS expansion function, the product key must be
acquired. (For the method of acquiring the product key, contact
the dealer.)
•For models on which the printer and network functions cannot
be used, a printer expansion ROM and a Print Server Card must
be installed in advance.
Parts included
•CD-ROM: 1pc.
•Product key sheet: 1 sheet
(1) Enable the PS expansion function.
To enable the PS expansion function, use the keys on the opera-
tion panel to enter the product key.
For entry of the product key, see the online manual included in the
supplied CD-ROM or the section of key operator programs of the
operation manual for the main unit.
After completing product key entry, turn off the power switch and
the main power switch of the main unit and then turn on the power
switch and the main power switch of the main unit again.
(2) Check the operation of the PS expansion function.
1) Use the keys on the operation panel to execute test page
printing and print the PS FONT LIST as a test print.
For test printing, see the online manual included in the CD-
ROM.
2) Installation of the driver software to the computer server and
its setting must be performed by the customer or based on dis-
cussion with the customer.
For installation of the driver software, see the installation
guide.
3) Finally, execute printing from the computer server and check
that printing is performed normally.
Caution:
For acquisition of the product key, the application number
written on the separate product key sheet is needed. Keep
this sheet taking care not to lose it.
3-5 Service Manual Y105610-1

[4] CONFIGURATION REPORT (TEST PAGE)
Model name
Y105610-1 Sevice Manual 4-1

[5] SETTING
1. Key operator program
A. Printer settings
(1) Default settings
These programs are used to adjust the settings of various printer
functions.
Prohibit notice page printing
This program is used to disable notice page printing.
Normally this program is set to not print a notice page.
Print density level
This program is used to adjust the lightness or darkness of prints.
Five levels are provided for density adjustment. These are repre-
sented by numbers displayed on the touch panel. Among the dis-
played numbers, a smaller value indicates lighter density and a
larger value indicates a darker density.
Prohibit test page printing
This program is used to disable test page printing.
When the program is turned on, the PRINTER TEST PAGE in the
custom settings cannot be printed.
A4/letter size auto change
If this program is set, and printing onto 8-1/2" x 11" size paper is
selected but not available, the printer will automatically substitute
A4 size paper in place of 8-1/2" x 11" paper if A4 paper is avail-
able.
∗8-1/2" x 11" paper cannot be automatically selected in place of
A4.
NOTE: When 8-1/2" x 11" size is specified for a document
attached to an E-mail that has been transmitted from a
foreign country and A4 size paper is not installed in the
printer, printing cannot be done without operator
intervention. If this program is set, printing will be
executed without intervention if a paper tray is loaded with
A4 paper.
(2) Interface settings
These programs are used to control data transmitted to the paral-
lel port, USB port or network port of this printer.
Hexadecimal dump mode
This program is used to output the print data from a computer in
the hexadecimal dump format with corresponding characters
(ASCII). This program is used to check proper transmission of
print data from the computer to the printer.
Output example of hexadecimal dump mode
I/O timeout
This program is used to set the length of time to wait for an I/O to
complete a job on the parallel port or the network port. If the data
stream to the port does not transmit data for a length of time
exceeding the timeout, the job will cancel and the next job will start
processing.
The I/O timeout setting is used to set the amount of time after
which an I/O timeout will occur when waiting for print data.
Default setting: 20 seconds
NOTE: The allowable range of the time is 1 to 999 seconds.
Enable parallel port
This program is used to enable or disable printing from the parallel
port.
Default setting: Enable
DEFAULT SETTINGS
INTERFACE SETTINGS
PROHIBIT NOTICE PAGE PRINTING
PRINT DENSITY LEVEL
PROHIBIT TEST PAGE PRINTING
A4/LETTER SIZE AUTO CHANGE
HEXADECIMAL DUMP MODE
I/O TIMEOUT
ENABLE PARALLEL PORT
PARALLEL PORT EMULATION SWITCHING
ENABLE USB PORT
USB PORT EMULATION SWITCHING
ENABLE NETWORK PORT
NETWORK PORT EMULATION SWITCHING
PORT SWITCHING METHOD
PARALLEL PORT ECP SETTING
IP ADDRESS SETTING
ENABLE TCP/IP
ENABLE NetWare
ENABLE EtherTalk
ENABLE NetBEUI
RESET THE NIC
TANDEM SETTING
PING COMMAND
PRINTER SETTINGS
NETWORK SETTINGS
Level 2Level 1 Level 3
Enter Key Operator Code
5-1 Service Manual Y105610-1

Parallel port emulation switching
This program is used to specify a printer language to emulate when
the printer is connected to a computer through the parallel port.
NOTE: It is recommended to set "AUTO" (default setting) unless
an error due to this setting occurs frequently.
Enable USB port
This program is used to enable or disable printing from the USB
port.
Default setting: Enable
USB port emulation switching
If the machine is connected using the USB port, select the emu-
lated printer language.
The setting items are the same as those of "Parallel port emulation
switching".
NOTE: It is recommended to set "AUTO" (default setting) unless
an error due to this setting occurs frequently.
Enable network port
This program is used to enable or disable printing from the net-
work port.
Default setting: Enable
Network port emulation switching
This program is used to specify a printer language to emulate
when the printer is connected to a computer through the network
port.
The setting items are the same as those of "Parallel port emulation
switching".
NOTE: It is recommended to set "AUTO" (default setting) unless
an error due to this setting occurs frequently.
Port switching method
The machine can use the three ports shown below for printing.
This program is used to select when switching between ports will
take place. "SWITCH AT END OF JOB" or "SWITCH AFTER I/O
TIMEOUT" can be selected. When "SWITCH AT END OF JOB" is
selected, the port will be automatically selected after each print job
is completed. When "SWITCH AFTER I/O TIMEOUT" is selected,
the port will be automatically selected if the time set in the I/O Tim-
eout program elapses.
•Parallel port
•USB port
•Network port
Parallel port ECP setting
This is used to enable bi-directional communication through the Cen-
tronix interface.
Select "Parallel port ECP setting" to enable data transmission both
from the computer to the printer and from the printer to the computer.
Normally ECP mode is not selected.
B. Network settings
These programs are set when this product is used as a network
printer.
After you complete the setting for one program, you must exit the
key operator programs, turn off the main switch, wait briefly, and
then turn on the main switch again before any other programs can
be set. The program that was set will be effective after the power
is turned on.
NOTE: For setting and modification of "Network settings", be sure
to consult with the network administrator.
IP address setting
When using this product in a network that uses the TCP/IP proto-
col, use this program to set the IP address (IP address, IP subnet
mask, and IP gateway) of this product. The program is set to
ENABLE DHCP by factory default setting, which obtains the IP
address setting automatically. When using this product on a TCP/
IP network, be sure to turn on the "Enable TCP/IP" program
below.
Enable TCP/IP
When using this product in a network that uses the TCP/IP proto-
col, set this program. Also set the IP address using the program
"IP address setting" above.
Default setting: Enable
Enable NetWare
When using this product in a network that uses the NetWare proto-
col, set this program.
Default setting: Enable
Enable EtherTalk
When using this product in a network that uses the EtherTalk pro-
tocol, set this program.
Default setting: Enable
Enable NetBEUI
When using this product in a network that uses the NetBEUI proto-
col, set this program.
Default setting: Enable
Reset the NIC
This program is used to reset all setting items of NIC (Network
Interface Card) of this product to the factory default settings.
NOTE: If any of the [NETWORK SETTINGS] were changed prior
to execution of this program, you must turn off the power
switch after exiting the key operator program, wait briefly,
and then turn on the power switch to make the factory
default settings take effect.
Tandem setting
This setting is used to configure the IP address and port number of
the client printer when you wish to have two machines (which are
used as TCP/IP network printers) print in tandem.
Tandem printing is not possible if the other machine is a different
model than your machine.
The factory default setting for the port number is [50001]. Unless
you experience difficulty with this setting, it does not need to be
changed.
The tandem function can also be prohibited, or the reception of
tandem data from the other machine can be prohibited. (Normally
this is not necessary.)
To prohibit the tandem function, select "DISABLING OF MASTER
MACHINE MODE".
To prohibit reception of tandem data from the other machine,
select "DISABLING OF SLAVE MACHINE MODE".
NOTE: To use the tandem function when auditing mode is
enabled, the same account number must be entered on
both machines. If the same account number is not
entered, only the server machine may print or the printed
pages may not be added to the correct account.
PING command
This program is used to check if the machine and a computer con-
nected to the network can communicate.
Enter the IP address of the computer that you wish to check and
touch the [START] key. A message will appear indicating whether
or not there was a response from the computer.
Setting items Description
Auto The printer language will switch automatically in
accordance with the data from the computer.
PostScript PostScript emulation is used to print the data
from the computer. (An optional PS3 expansion
kit is needed.)
PCL PCL emulation is used to print the data from the
computer.
If DHCP is used, the IP address assigned to the machine may
be changed automatically on occasion.
If this happens, printing will not be possible.
Y105610-1 Sevice Manual 5-2

[6] SIMULATION
1. List
2. Details
Operation/Procedure
(Display message)
Operation/Procedure
1) Enter the number corresponding to the select IN signal YES/
NO setting with 10-key.
2) Press [START] key.
When the printer parallel I/F is used and a trouble is generated in
the communication between the PC and the printer, change the
setting of this simulation.
Operation/Procedure
During check, "CHECKING" is displayed. When check is com-
pleted normally, "OK" is displayed. In case of an error, "NG" is dis-
played.
(Display message)
Code Function (Purpose)
Main Sub
67 2 Used to check the operation of the parallel I/F of
the printer. (This simulation is for production only,
and requires a special tool for execution. Not
used in the market.)
11 Used to set YES/NO of the parallel I/F select
signal of the printer.
16 Used to check the operation of the network card.
67
67-2
Purpose Operation test/Check
Function
(Purpose)
Used to check the operation of the parallel I/F of
the printer. (This simulation is for production only,
and requires a special tool for execution. Not used
in the market.)
Section MFP controller
Item Operation Interface/Communication
WAITING Waiting
READY Check start OK
OK Check end (Normal)
STAGE*NG Check end (Error in stage *. *: 1 - 11)
lWith READY displayed,
press [START] key.
Press [CUSTOM SETTINGS] key.
SIMULATION 67-2
CENTRO PORT CHECK.
CENTRO PORT: READY
SIMULATION 67-2
CENTRO PORT CHECK.
CENTRO PORT: OK (or STAGE7 NG)
67-11
Purpose Setting
Function
(Purpose)
Used to set YES/NO of the parallel I/F select
signal of the printer.
Section MFP controller
Item Operation Interface/Communication
Item Default
0OFF 1
1ON
67-16
Purpose Operation test/Check
Function
(Purpose)
Used to check the operation of the network card.
Section MFP controller
Item Operation Interface/Communication
CHECKING Checking
OK Check end (Normal)
NG Check end (Error)
Check end Press [CUSTOM SETTINGS] key.
SIMULATION 67-11
CENTRO SELECT IN SIGNAL SETTING. SELECT 0-1, AND PRESS
START.
0. OFF
1. ON
SIMULATION 67-16
NETWORK INTERFACE CARD CHECK.
NIC: CHECKING
SIMULATION 67-16
NETWORK INTERFACE CARD CHECK.
NIC: OK (or NG)
6-1 Service Manual Y105610-1

[7] ELECTRICAL SECTION
1. Block diagram
A. MFP CONTROLLER PWB
CPU
N model : RM7065
U model : TX4955
SYSTEM
Controller
Dracula III
SDRAM
ON BOARD
(128MB)
SDRAM
DIMM
128/256MB
MD[63:0]
MAA[12:0]
SysCMD[8:0]
SysAD[63:0]
SysAD[54:34]
Address Buffer Gate
LA[22:2]
MEMD[31:0]
Flash
DIMM
(8MB)
Slot1,2,3
Mask
DIMM
(32MB)
PS Kanji
LDATA[15:0]
Address
Buffer
Data
Gate
EEPROM
(64Kbit)
I/O G/A
(ASIC1)
IOA[17:0]
IOD[15:0]
LVX161284
IEEE1284
I/F
232C
Driver
RIC I/F
Scanner I/F
TD62503F
PCI Bus
ICU ASIC
SDRAM
(32MB)
PM2060i
IDE
Controller
Soft-NIC
General
RTC
LCD
Controller
FAX I/F
Buffer
SysAD[31:0]
SRAM
N : 2Mbit U : 4Mbit
USB
Controller
USB I/F
PM-22A PM-22B
IDE I/F
Engine I/F
CPU Block
CPU
IC20
N model :
RM7065
U model :
TX4955
3.3V INPUT
5V INPUT
CN8
DC-DC Converter
IC718
3.3V(I/O)
N:1.3V / U:1.5V (Core)
OSC
X700
N :74.9MHz
U :66.666MHz
Clock buffer
IC9
Reset IC
PST598DN
IC47
5V
System
Controller
IC700
PONRST
COLDRST CPURST 3_EXTRQST
NMI, INT0*
I/O G/A
IC32
INT1*,INT2*,INT3*
SysCMD[8:0], SysAD[63:0]
Address
Buffer
IC726,
729,732
LA[22:2]
LCX245
IC727,
728,730,731
MEMD[31:0]
SysAD[54:33]
Flash DIMM
CN4,5,6
Mask DIMM
CN7
JTAG
CN10
TDI, TMS, TDO ,TCK, TRST*
Address
Buffer
IC742,
743,744,745
LCX245
IC738,739,
740,741
FAX I/F (CN16)
POF
MSW-MON,WAKE-UP*
2.5V
Reset IC
PST598IN
IC753
3.3V
Y105610-1 Sevice Manual 7-1

ROM Block (Flash & Mask)
System
Controller
IC700
420pin-
BGA
I/O G/A
IC32
240pin-
QFP
Address
Buffer
IC726,
729,732
LA[22:2]
LCX245
IC727,
728,730,731
MEMD[31:0]
SysAD[31:0]
SysAD[54:34]
DIMM Slot
CN4:8MB-
Flash
CN5:8MB-
Flash
CN6:8MB-
Flash
CN7:32MB
-Mask
(PS Kanji)
3.3V
VCSW
CODECS0* CODECS1* CODECS2* CODECS3* FONTCS0* FONTCS1* FONTCS2* FONTCS3* FONTCS4* FONTCS5* FONTCS6* FONTCS7*
ROMBUFOE* ROMBUFDIR*
FMCS8:CN4 FMCS10:CN5 FMCS12:CN6 FMCS0:CN7 FMCS2:CN7 FMCS4:CN7 FMCS6:CN7
FET
Q19
DIP SW
SW2
SDRAM Block ( Standard & Option )
System
Controller
IC700
420pin-
BGA
SDRAM
IC4,5,6,7
(ON BOARD)
128MB
MD[63:0]
MAA[12:0]
DIMM Slot
144pin
SO-DIMM
CN3
(128,256
MB)
OSC
X700
N : 74.9MHz
U : 66.666MHz
Clock
buffer
IC9
SDA,SCL
SDQMA[7:0]
MWE MCS0 MRASA MCASA BSEL0A,1A CKEA MWE MCS1A,2A MRASA MCASA BSEL0A,1A CKEA
DRCLK
MEMCLK0
MEMCLK1,2,3,4
7-2 Service Manual Y105610-1

PCI Block ( ICU & Option )
System
Controller
IC700
420pin-BGA
PCI-Bus
ICU ASIC
IC25
304pin-QFP PM2060i
IC725
52pin-QFP
OSC
X2
40.57MHz
OSC
X5
64MHz
Scanner
I/F
CN702
LVDS
IC18
Buffer
IC18
SDRAM
IC27
32MB
CN9 SOFT-NIC
(100Base-T)
PM22-A IC721
160pin-QFP
PM22-B IC723
160pin-QFP
OSC X1
66MHz
Clock buffer
IC29
OSC X3
33.333MHz
IDE I/F
CN701
IDE Controller IC756
144pin-QFP
USB Controller
IC703 100pin-QFP
XTAL X701
24MHz
USB I/F
CN700
I/O G/A
IC32
240pin-QFP
PCIREQx
PCIGNTx
Engine
I/F
CN8
OSC
X4
31.554MHz
Selector
OSC
X703
66.666MHz
I/O Block ( EEPROM & Misc I/O )
I/O G/A
IC32
240pin-QFP
CN1
LVX161284
IC15
232C Driver
IC42
IEEE1284 I/F
CN14
RIC I/F (RS232C)
Engine I/F
System
Controller
IC700
420pin-BGA
LCX373
IC733,
735,737
IOA[15,14,6:1]
LDATA[15:0]
LCX245
IC734,736
IOD[7:0]
DIP-SW
OSC
X7
14.7456MHz
EEPROM
IC36
64Kbit
IOA[13:1]
IOD[7:0]
CN8
LCD
Controller
IC53 TD62503F
IC41
Switcher
3.3V
SRAM
IC55
N:2Mbit U:4Mbit
IOA[18:0]
SW0,SW1
IOD[7:0]
ALE,ALE-H
CN702
Scanner I/F
RTC
NJU6356
IC40
Xtal
32.768kHz
Battery
(BT1)
Switcher
5V
IOA[14:1]
IOD[15:0]
TD62503F
IC38
Y105610-1 Sevice Manual 7-3
