Olympic VC-19D User manual

1
VC-19D VER. ASM-01217
OPERATOR'S MANUAL
VC-19D Operator’s manual
OLYMPIC

2
VC-19D Operator’s manual
OLYMPIC

3
TABLE OF CONTENTS
Introduction
4
Safety regulations
4
Electric and pneumatic connections
4
Holding - Transportation
5
Maintenance of cooling unit
5
Technical data & Dimensioning
5
Lubrication
5
Panel Adjustments
6
Operation
7
Maintenance
7
VC-19D Assemblying
8
VC-19D Hot Station Head Assembly
9
VC-19D Hot Station Support Base with Ø160 Cylinder Assembly
10
VC-19D Cold Station Head Assembly
11
VC-19D Cold Station Support Base with Ø160 Cylinder Assembly
12
VC-19D Bottom Base Valves Assembly
13
VC-19D Projector
14
VC-19D FRL with components
14
VC-19D Top Valve assembly with components
14
VC-19D Pneumatic Diagram
15
VC-19D Electrical Diagram
16
VC-19D Electronic Board Diagram
17
VC-19D Troubleshooting
18
VC-19D Operator’s manual
OLYMPIC

4
Introduction
The purpose of this manual is to inform the owner of this
machine for its operation, its maintenance and for all the
safety regulations.
Please read carefully all the instructions and follow them in
order to use the machine properly in the production and avoid
any case of injuries.
Our company does not have any responsibility for any changes
happened on the machine by the owner, or actions which are
different to what this manual refers.
SAFETY REGULATIONS
This machine is intended for professional use only.
WARNING!
Only one operator may work on the machine at a
time.
WARNING!
Read and follow carefully all the relative
instructions to avoid serious injury.
Only qualified and authorized personnel must use the
machine.
Operators are expressly forbidden to use the machine
under the influence of alcohol or drugs capable of affecting
physical and mental capacity.
Keep unauthorized persons away from the work area.
Make sure that the machine has been installed in
compliance with the established legislation and
standards.
Always keep this user manual in a place where it can be
readily consulted when working on the machine. Consult it
whenever you are in need of information or explanation.
Do not remove or deface the safety, danger, warning or
instruction signs. Replace any missing or illegible Danger,
Warning or instructions signs.
Never use the machine if you notice any damaged electric
wires.
Never install the machine outdoors or in any place with a
lot of moisture.
WARNING
Use only original spare parts, which can be
supplied by the manufacturer or the local agent.
Otherwise, your machine will not be a CE product.
WARNING
The machine frame must be earthed using the
outside connection point marked according to
the CE norms.
Electric and pneumatic connections
1. Connect the machine (SINGLE PHASE 230V - 50Hz).
2. Before plugging in the machine, check that the main
supply voltage is the same as that indicated on the
label situated on the back side of the machine.
3. Check if the plug and socket have the same technical
type. If not, use the suitable adapter after having
consulted a certified electrician.
4. To disconnect the machine, turn the main switch off and
remove the plug from the outlet.
5. Connect the machine to air pressure 6 - 8bar.
6. Connect the proper pneumatic hose. Set the main
pressure regulator, which is found, on the back part of the
machine to 6 Bar.
VC-19D Operator’s manual
OLYMPIC

5
Holding - Transportation
1. Use the clevy’s existed on the top of the machine with
proper belts to lift the machine.
2 . Pass the trans-pallet's forks under the pallet as shown in
the Figure below.
Technical data & Dimensioning
Maintenance of cooling unit
Clean the condenser (radiator) of the cooling unit once per
month by using air pressure.
Lubrication
Keep the FRL (air-filter-regulator & lubricator) always filled
with oil. We note that with 8 hours of work per day, the
lubricator oil is consumed within 20-25 days approximately. If
this does not occur, adjust the oil flow using the adjuster on
upper part of lubricator. We recommend the use of ISO Class
V632 or ISO 3448 oil. Once per week lubricate all moving
parts of the machine.
Cooling gas type R404A
Cooling gas qty 470gr
Compressor Power 1/2 Hp
COOLING UNIT SPECIFICATIONS
Use only ISO CLASS V632
or ISO 3448 oil
OPERATION Electric - Pneumatic
PRESSURE 6 Bar
VOLTAGE 230V single phase 50Hz
CAPACITY 1200 pairs per 8 hours
POWER CONSUMPTION 1500 W
DIMENSIONS (mm) 920 X 847 X 1686
WEIGHT 385 Kgs
Technical Data
920 mm
1686 mm
847 mm
VC-19D Operator’s manual
OLYMPIC

6
Cooling Unit
Hot Station Temperature °C Cold Station Temperature °C
5
10
15
20
25
30
0SEC
Timer
5
10
15
20
25
30
0SEC
Timer
Head Lock
VC-19D
Cooling Unit
M A D E I N G R E E C E
2. Cold Station Temperature: Set the temperature from 9 to
11°C (find the suitable temperature for the minimum
condensation).
4. Head Lock: Heads’ lock ON/OFF.
6. Cold station Time: Set the timer from 5 to 30 sec. Less
time at cold station will result in a more shallow angle.
Panel Adjustments
1
35
46
2
Panel Adjustments
1 Hot Station Temperature: Set the temperature from 60 to
110°C. Temperature is a basic factor for the crimping.
Choose the higher temperature (according the material you
use) for higher crimping result. (Suggested Temperature
110°C).
To adjust thermoregulator press the DOWN arrow. When
the digits start blinking use the UP and DOWN arrows to
adjust the temperature.
Then you press instantly the button.
3. Hot station Set the timer from 5 to 30 sec. By Time:
increasing the time a higher crimping is succeeded.
5. Cooling unit ON/OFF.
VC-19D Operator’s manual
OLYMPIC

7
Operation
Step 1. Place the vamp in the hot station mould as shown in
Figure 1
Step 2. Press the pedal to hold the vamp (Figure 2). Before
continuing the procedure be sure that the vamp is in the right
crimping position.
For correct placing release the pedal, correct the place of the
vamp and press it again.
2
13
Step 3. Press the START buttons simultaneously and release
the pedal to complete the procedure. The machine will revert
to its initial position after the end of the setting time.
Maintenance
Once a week lubricate the rod of the cylinders ASM-00694
with oil type SAE 30.
Once a week check the oil level of the air pressure lubricator
P1 and add oil type ISO Class V632 or ISO 3448 or something
similar.
Once a month clean the radiator.
Every six months check the good operation of the lubricator.
Note: The lubricator must drip approximately one drop every 20
operation cycles.
Repeat the procedure in the hot and
cold station in order to stabilize the
materials
Tip: Hot and cold is necessary either for leather or synthetic
vamps and helps maximize and retain the final shape of the
vamp and finally the shoe
VC-19D Operator’s manual
OLYMPIC

8
ASSEMBLING VC-19D
Hot Station Head Assembly p ( age 9)
Hot Station Support Base with Main Cylinder (page 10)
Cold Station Head Assembly p( age 11)
Cold (page 12)Station Support Base with Main Cylinder
Bottom Valve Assembly (Page 13)
Projector with rest of Pneumatics (Page 14)
VC-19D Operator’s manual
OLYMPIC

9
VC-19D Hot Station Head Assembly
126
178
1097
151
1163
156
12
138
178
45
125
9948
74
124
81
146
11
145
150
39
35 149
80
7
147
9946
543
178
1098
BOM ID PartNo Description Qty
7CAS-00150 HOT MOULD HEAD INTERCHANGE PART 1
11 CAS-00154 VC-19 HOT STATION MOULD 1
12 CAS-00155 VC-19 HOT STATION MALE MOULD 1
35 ELE-00516 HEATING SENSOR 6x35 (L=80CM) 1
39 ELE-00660 HEATING ELEMENT Φ20X110 1
45 GEN-00486 SLIDING BODY 2
74 LAS-01129 SUPPORT INTERNAL SIDE PLATE 2
80 LAS-01137 VC-19 MOULD STOPPER 1
81 LAS-01146 HEAD PUSHING INOX PLATE 1
124 PNE-01090 FISH-EYE, UNIVERSAL JOINT M16x1.5 2
125 PNE-01164 CB-DOUBLE EAR FLANGE Φ100 1
126 PNE-01169 Φ80 DOUBLE EAR FLANGE 1
138 CAS-00160 VC-19D MALE MOULD HOLDING BASE 1
145 REV-00530 VC-19 CYLINDER JOINT PIN 2
146 REV-00531 VC-19 ROTATING BASE PIN 2
147 REV-00535 VC-19 HOLDING WASHER Φ50 1
149 REV-00538 VC-19 Φ50 HOUSING SHAFT 1
150 REV-00541 Φ20 PIN 2
151 REV-00542 VC-19 Φ16 PIN 2
156 REV-00558 VC-19D SLIDING BODY GUIDE 2
178 PNE-09916 ELBOW MALE ADAPTOR 4-1/8" 5
1163 PNE-01163 CYLINDER Φ100x100 1
9946 PNE-09946 CYLINDER Φ80x100 1
9948 PNE-09948 CYLINDER Φ50Χ50 1
543 REV-00453 RESTRICTOR, 1/8 (M) - 1/8 (F) - Φ1.0 1
1097 PNE-01097 STRAIGHT MALE ADAPTOR 6-1/8" 1
1098 PNE-01098 ELBOW MALE ADAPTOR 6-1/8" 1
VC-19D Operator’s manual
OLYMPIC

10
VC-19D Hot Station Support Base with Main Cylinder
132
99 103
96
115
112
107
118
178
694
152
50
155
1015
9
1238
144
46
153
BOM ID PartNo Description Qty
9CAS-00151 VC-19D SUPPORT MOULD BASE 1
46 GEN-00488 VC-19 MOULD SUPPORT COVER 1
50 LAS-00589 PISTON GUIDE, VC-2014 1
96 PNE-00059 NIPPLE, TAPER, 1/4 (M) - 1/4 (M) 1
99 PNE-00074 NON-RETURN VALVE, 1/4 1
103 PNE-00094 SILENCER, 1/4, PLASTIC, BLUE 1
107 PNE-00171 REDUCING NIPPLE 1/4-1/2 1
112 PNE-00213 CAP ALLEN, +OR 1/4 1
115 PNE-00725 SOLENOID VALVE 1/4 5/2 1Ρ 1
118 PNE-00951 REDUCER, TAPER, 3/4-1/2 1
BOM ID PartNo Description Qty
132 PNE-09925 ELBOW MALE ADAPTOR 8-1/4" 1
144 REV-00376 NUT, CUSTOM, M36X2.0 1
152 REV-00543 GUIDE INTERNAL THREADED WASHER 1
153 REV-00544 WASHER, CUSTOM, Φ20 4
155 REV-00557 GUIDE CYLINDER 1
178 PNE-09916 ELBOW MALE ADAPTOR 4-1/8" 2
694 ASM-00694 MAIN CYLINDER Φ160 1
1015 PNE-01015 CYLINDER Φ40 1
1238 ASM-01238 HOT STATION COVER 1
VC-19D Operator’s manual
OLYMPIC

11
VC-19D Cold Station Head Assembly
35
1098
147
178
543
9946
15
126
1240
74
1097
80
151
1163
150
156
138
125
81
9948
124
146
45
13
14
145
BOM ID PartNo Description Qty
13 CAS-00156 COLD STATION MALE MOULD 1
14 CAS-00158 COLD STATION MOULD, NORMAL 1
15 CAS-00159 COLD MOULD HEAD INTERCHANGE PART 1
35 ELE-00516 HEATING SENSOR 6x35 (L=80CM) 1
45 GEN-00486 SLIDING BODY 2
74 LAS-01129 SUPPORT INTERNAL SIDE PLATE 2
80 LAS-01137 MOULD STOPPER 1
81 LAS-01146 SHORT HEAD PUSHING INOX PLATE 1
124 PNE-01090 FISH-EYE, UNIVERSAL JOINT M16x1.5 2
125 PNE-01164 CB-DOUBLE EAR FLANGE Φ100 1
126 PNE-01169 Φ80 DOUBLE EAR FLANGE 1
BOM ID PartNo Description Qty
138 CAS-00160 VC-19D MALE MOULD HOLDING BASE 1
145 REV-00530 CYLINDER JOINT PIN 2
146 REV-00531 ROTATING BASE CONNECTION PIN 2
147 REV-00535 HOLDING WASHER Φ50 1
150 REV-00541 Φ20 PIN 2
151 REV-00542 Φ16 PIN 2
156 REV-00558 SLIDING BODY GUIDE 2
178 PNE-09916 ELBOW MALE ADAPTOR 4-1/8" 5
543 REV-00453 RESTRICTOR, 1/8 (M) - 1/8 (F) - Φ1.0 1
1163 PNE-01163 CYLINDER Φ100x100 1
1240 ASM-01240 EVAPORATOR INSERT 1
9946 PNE-09946 CYLINDER 80x100 1
9948 PNE-09948 CYLINDER Φ50Χ50 1
1097 PNE-01097 STRAIGHT MALE ADAPTOR 6-1/8" 1
1098 PNE-01098 ELBOW MALE ADAPTOR 6-1/8" 1
178
VC-19D Operator’s manual
OLYMPIC

12
VC-19D Station with Main Cold Support Base Cylinder
132 99 103
96
112
115 107 118
50
694
152
1015
155
52
163
8
144
178
1239
46
BOM ID PartNo Description Qty
8CAS-00151 VC-19D SUPPORT MOULD BASE 1
46 GEN-00488 VC-19 MOULD SUPPORT COVER 1
50 LAS-00589 PISTON GUIDE 1
52 LAS-00822 VC-16 LIQUID HOLDER 1
96 PNE-00059 NIPPLE, TAPER, 1/4 (M) - 1/4 (M) 1
99 PNE-00074 NON-RETURN VALVE, 1/4 1
103 PNE-00094 SILENCER, 1/4, PLASTIC, BLUE 1
107 PNE-00171 REDUCING NIPPLE 1/4-1/2 1
112 PNE-00213 CAP ALLEN, +OR 1/4 1
115 PNE-00725 SOLENOID VALVE 1/4 5/2 1Ρ 1
118 PNE-00951 REDUCER, TAPER, 3/4-1/2 1
132 PNE-09925 ELBOW MALE ADAPTOR 8-1/4" 1
144 REV-00376 NUT, CUSTOM, M36X2.0 1
152 REV-00543 GUIDE INTERNAL WASHER 1
155 REV-00557 GUIDE CYLINDER Φ22 1
163 RUB-00131 RUBBER CAP 4
178 PNE-09916 ELBOW MALE ADAPTOR 4-1/8" 2
694 ASM-00694 ΜΑΙΝ CYLINDER Φ160 1
1015 PNE-01015 CYLINDER Φ40 1
1239 ASM-01239 COLD STATION COVER 1
VC-19D Operator’s manual
OLYMPIC

13
VC-19D Bottom valve assembly
BOM ID PartNo Description Qty 44 GEN-00093 MANIFOLD CAP RUBBER BOTTOM 6 87 PNE-00016C SCREW M3 FOR 5/2 VALVE 12 95 PNE-00059 NIPPLE, TAPER, 1/4 (M) - 1/4 (M) 1 97 PNE-00072 PLUG, MALE, PARALLEL, 1/8 2 100 PNE-00081 1/4 VALVE MANIFOLD, 2 STATION 1 101 PNE-00082 MANIFOLD, 1/4, 4 STATION 1 102 PNE-00094 SILENCER, 1/4, PLASTIC, BLUE 4 110 PNE-00188 REDUCER (TAPER) 1/8-1/4 1 111 PNE-00213 CAP ALLEN, +OR 1/4 2
BOM ID PartNo Description Qty 113 PNE-00608 SAFETY VALVE, 1/4, P.T. 6 bar 1 117 PNE-00896 SILENCER 1/4 4 120 PNE-01001 FITTING, STRAIGHT, 1/8-Φ8 3 127 PNE-01186 MANIFOLD HOLES 5 1/8-1/4 1 128 PNE-09916 ELBOW MALE ADAPTOR 4-1/8" 1 130 PNE-09919 STRAIGHT MALE ADAPTOR 4-1/8" 10 157 REV-00559 MALE DUAL CONNECTOR 1/4 1 461 ASM-00461 VALVE ELECTRIC PILOT 5/2 G1/8, 24V 6
102
100
44
117
157
130
101 95
97
128
127
461
87
120
110
111
113
19
7
2
3
16
15 11
9
10
18
8
12
17 14
13
BOM ID PartNo Description Qty
2GEN-00093 CAP 6
3ASM-00461 VALVE 5/2 G1/8, 24V 6
7PNE-00094 SILENCER, 1/4, PLASTIC, BLUE 2
8PNE-09919 STRAIGHT MALE ADAPTOR 4-1/8" 6
9PNE-00072 PLUG, MALE, PARALLEL, 1/8 2
10 PNE-00059 NIPPLE, TAPER, 1/4 (M) - 1/4 (M) 1
11 PNE-00213 CAP ALLEN, +OR 1/4 2
12 PNE-01040 MANIFOLD, 1/4, 6 STATIONS 1
BOM ID PartNo Description Qty
13 PNE-00608 SAFETY VALVE, 1/4, P.T. 6 bar 1
14 PNE-09923 ELBOW MALE ADAPTOR 4-1/4" 1
15 PNE-00082 MANIFOLD, 1/4, 4 STATIONS 1
16 PNE-00896 SILENCER 1/4 1
17 PNE-09921 STRAIGHT MALE ADAPTOR 8-1/4" 2
18 PNE-01097 STRAIGHT MALE ADAPTOR 6-1/8" 4
19 PNE-09925 ELBOW MALE ADAPTOR 8-1/4" 2
VC-19D Operator’s manual
OLYMPIC

14
VC-19D Projector
42
158
1236
159
41
BOM ID PartNo Description Qty
41 ELE-00672 VC-19 LED POINTER 1
42 ELE-00674 LED PROJECTOR DRIVER 1
158 REV-00561 VC-19D PROJECTOR ARM HOLDER 1
159 REV-00562 VC-19D LED PROJECTOR HOLDER 1
1236 ASM-01236 1/2 ARTICULATED PATTERN 1
178 116
461
104
BOM ID PartNo Description Qty
104 PNE-00096 CONNECTOR, Y, MALE, 1/8 - Ø4 2
116 PNE-00741 SILENCER, SPRING REGULATOR, 1/8 2
178 PNE-09916 ELBOW MALE ADAPTOR 4-1/8" 1
461 ASM-00461 VALVE ELECTRIC PILOT 5/2 G1/8, 24V 1
VC-19D FRL with components
VC-19D Top Valve with components
304
303
91
114
84
132
BOM ID PartNo Description Qty
84 PNE-00001 FRL G1/4 SIZE 300 1
91 PNE-00023 MALE-FEMALE ELBOW 1/4" 1
303 PNE-00204 OFF SET MALE TEE 4050 1/4 1
114 PNE-00619 MALE HOSE ADAPTER (TAPER) 9-1/4 1
304 PNE-09921 STRAIGHT MALE ADAPTOR 8-1/4" 1
132 PNE-09925 ELBOW MALE ADAPTOR 8-1/4" 1
VC-19D Operator’s manual
OLYMPIC

#
VC-19D Pneumatic Diagram
FRLFRL
Ø80
Ø160
Ø100
Ø80
Ø160
Ø100
Ø50 Ø50
Ø40 Ø40
AA
B
BB B
L L
K K
CC
DD
EE
F
G
G
F
I
I
JM
SV2
SV4
BB BB BB
SV4 SV3 SV2 SV1 SV4 SV2
P/N DESCRIPTION
A PNE-09948 CYLINDER ACE Φ50Χ50
B ASM-00461 VALVE 5/2 1/8, 24V
C PNE-09946 CYLINDER ACE 80x100
D ASM-00694 CYLINDER SI 160x240
E PNE-00725 VALVE 1/4 5/2 1Ρ
F PNE-00074 NON-RETURN VALVE, 1/4, FEMALE
G PNE-01163 CYLINDER ACE Φ100x100
I PNE-01015 CYLINDER ACQ 40X120
J PNE-00001 FRL G1/4 SIZE 300
K REV-00453 RESTRICTOR,1/8 (M)-1/8 (F)-Φ1.0
L PNE-00741 SILENCER, REGULATOR, 1/8
HOT STATION COLD STATION
VC-19D Operator’s manual
OLYMPIC

#
VC-19D Operator’s manual
VC-19D Electrical diagram
P3
20 N
HOT
P1
19 N
CO LD
b1
13
14 15 16 17
b3
b2 b4 b5
18
N
b6
>
L
SV3 CYLINDER Ø160x240
CYLINDER Ø160x240
SV2
SV1 CYLINDER Ø40x75
SV5 CYLINDER Ø40x20
SV6 CYLINDER Ø40x20
SV7 CYLINDER Ø40x20
>
L
SV15
SV16
SV14
SV18
SV19
SV20
CYLINDER Ø160x240
CYLINDER Ø160x240
CYLINDER Ø40x75
CYLINDER Ø40x20
CYLINDER Ø40x20
CYLINDER Ø40x20
B
K1
L1 L2 L3
T1 T2 T3
A2
A1
K2
L1 L2 L3
T1 T2 T3
A2
A1
R
MMMM
PCB
24VAC
L1
F5F5
F4F4
b
F2F2
F3F3
230V AC24V AC
Tr1
5
6
F1F1
F1F1
3
4
L
N
PE
L3
L2
11
31 34
S1
+
11
TH1
8764 1211
TH1
8764 12
TH2
12118764
TH2
12118764
S2
+
TH2
12118764
S2
+
TH2
12118764
S2
+
7
N1
N2
-
-
SW1
2
1
230 VAC
50Hz
12
8
SW3
C9
8
9
SW2 SW2
35
32
SYMBOL Part No Description
SW1 ASM-00807 MAIN SWITCH
SW2, SW3 ELE-00670 SWITCH 24V
b ELE-00002 STOP BUTTON
Tr ELE-00021 TRANSFORMER, 230V – 24V 12V 100 VA
K1, K2 ELE-00028 RELAY
TH1, TH2 ELE-00264 THERMOREGULATOR R38S
N1, N2 ELE-00664 DRIVER 1W 230V
R ELE-00660 HEATING ELEMENT 230V 900W
M ASM-01228 VC-19D COOLING UNIT
L1 ELE-00407 LED BAR
L2, L3 ELE-00663 PUNT 1 LED 32 ROSSO 1W 3,8VDC
B ELE-00331 BRIDGE 10A/1000V
F1 ELE-00336 CHINT NB1 63C10A
F2, F3 ELE-00378 FUSE 6A 5X20
F4, F5 ELE-00377 FUSE 4A 5X20
S1, S2 ELE-00516 HEAD TEMPERATURE SENSOR
C1 - C9 COIL 24 VAC
U PCB-00028 M-USE
T1, T2 ELE-00076 POTENTIOMETER 10kΩ
P1, P2 ELE-00615 FOOT SWITCH BLACK
b1, b3, b4, b6 ELE-00001 START BUTTON
b2, b5 ELE-00506 STOP BUTTON
HOT STATION COLD STATION
b2
IN7 b2 IN7
IN2 b1b1 IN2 b1 IN3 b3b3 IN3 b3
b5
IN8 b5 IN8
IN5 b4b4 IN6 b6b6 IN6 b6
13 14 15
16
17
N
18
23
22
21
Τ1
TIMER1
23
22
21
Τ1
TIMER1
26
25
24
Τ2
TIMER2
P1
N
19
IN1
P2
N
20
P2
N
20
IN4IN4 P2
N
20
IN4
C1C1
L
C2 C3
L28
L
L30
L
L27
L29
C4C5C6C7C8
33
36
VC-19D Operator’s manual
OLYMPIC

17
VC-19D Electronic Board Diagram
PCB-00028 M-USE MAINBOARD ELECTRONIC PCB
1 2 3 4 5 6 7 8 9 10
VC-19D
LEFT
IMPORTANT:
THE SWITCHES MUST BE STRICTLY SET
AS SHOWN (DIP2, DIP4 UP)
SV1 SV2 SV3 SV4 SV5 SV6 SV7 SV8 USB
24VAC
FUSE 15A
FUSE 2A
SV9 SV10
INPUT-1 INPUT-2 INPUT-3 INPUT-4 INPUT-5 INPUT-6 INPUT-7 INPUT-8 TIMER-1 TIMER-2 TIMER-3 TIMER-4 TIMER-5
1 2 3 4 5 6 7 8 9 10
RIGHT
LEFT
RIGHT
PEDAL1 INPUT1
PEDAL2 INPUT4
B U TTON b1 INPUT2
STO P b 2 INPUT7
B U TTON b3 INPUT3
B U TTON b4 INPUT5
STO P b 5 INPUT8
B U TTON b6 INPUT6
INPUTS
SV1 HOT STATION CYLINDER ACQ Φ40x120
HOT STATION CYLINDER ACE Φ100x100
HOT STATION CYLINDER ACE Φ80x100
HOT STATION CYLINDER SI Φ160x240
SV3 COLD STATION CYLINDER ACQ Φ40x120
COLD STATION CYLINDER ACE Φ100x100
COLD STATION CYLINDER ACE Φ80x100
COLD STATION CYLINDER SI Φ160x240
OUTPUTS
SV2
SV4
Cooling Unit
Hot Station Temperature °C Cold Station Temperature °C
5
10
15
20
25
30
0SEC
Timer
5
10
15
20
25
30
0SEC
Timer
Head Lock
VC-19D
Cooling Unit
M A D E I N G R E E C E
VC-19D Operator’s manual
OLYMPIC

18
VC-19D TroubleshootingVC-19D Troubleshooting
Cold StationCold Station Hot StationHot StationOtherOther
Pull-up cylinder
Ø40 is not working
SV3 output led
Fault at pedal
contact
Solenoid L3
Fault at main
board
Pedal2 led on
Pedal1 led off
on
off
Pull-up cylinder
Ø40 is not
working
SV1 output
led
Fault at pedal
contact
Solenoid L1
Fault at main
board
Pedal1 led on
Pedal1 led off
on
off
Pull-up cylinder
Ø40 is not
working
SV1 output
led
Fault at pedal
contact
Solenoid L1
Fault at main
board
Pedal1 led on
Pedal1 led off
on
off
Cylinders Ø160,
Ø80, Ø100 are not
working
SV2 output led
Fault at Butt1
and/or Butt2
Butt1 and/or Butt3 led on
Butt1 and/or Butt3 led off
Solenoid L2
Fault at main
board
on
off
Cooling unit is not
working
Fault at on/off switch SW2
Fault at thermocouple TH2
Upper cylinder Ø50
is not working
Fault at on/off switch
Solenoid C7
Cylinder Ø160 is
not working
SV4 output led
Fault at Butt5
and/or Butt6
Solenoid L4
Fault at main
board
Butt4 and/or Butt6 led on
Butt1 and/or Butt2 led off
on
off
Resistance is not
working
Fault at relay K1
Fault at thermocouple TH1
Fault at relay K2
VC-19D Operator’s manual
OLYMPIC

19
Notes
VC-19D Operator’s manual
OLYMPIC

20
4, Papazoglou str.
GR-17778 Athens
Greece
email: [e-mail]
website: www.hydrotab.gr REV.D
VC-19D Operator’s manual
OLYMPIC
