Olympus RECMIC DR-2100 User manual

INSTRUCTIONS
RecMic
Thank you for purchasing an
Olympus RecMic.
Please read these instructions for information
about using the product correctly and safely.
Keep the instructions handy for future reference.
EN
To ensure successful recordings, we recommend that you
test the record function and volume before use.

2
EN
Introduction
• The contents of this document may be changed in the future without advanced
notice. Contact Olympus authorized dealer or Customer Support Center for the
latest product information.
• The illustration of the RecMic shown in this manual may differ from the actual
product. For questions regarding this document and information presented,
please contact Olympus Professional Authorized Dealer or Olympus Customer
Support Center.
• Any liability due to damages including but not limited to loss of data due to
product defect or repair performed by Olympus, Olympus authorized repair
center, or third party, is excluded.
• OLYMPUS CORPORATION holds the copyrights for instructions (this manual).
Trademarks and registered trademarks
• Microsoft and Windows are trademarks or registered trademarks of Microsoft
Corporation.
• Macintosh and Mac OS are trademarks or registered trademarks of Apple Inc.
• Do not disassemble, repair or modify the unit yourself.
• Keep young children and infants away from the RecMic. The cable can be a
strangulation hazard.
• Disconnecting the cable while the RecMic is recording/deleting could
damage the unit making it unusable.
• Do not leave the RecMic exposed to high humidity, high temperature or
direct sunlight.
Other product and brand names mentioned herein may be the trademarks or
registered trademarks of their respective owners.
Safety precautions

3
EN
Main features
This product is equipped with the following features.
sNew design and location of buttons enable single-handed control without
ever having to visually check the placement of buttons. RecMic fits easily
into your hand providing effortless control coupled with superb dictation
experience.
sEquipped with a directional microphone that eliminate undesired
background noise and allows clear and precise recordings.
sAll buttons are programmable to allow for easy and personal
customization.
sRecMic is USB Audio Device, It can be used as a USB microphone and/or
USB speaker when connected to a PC.
sRecMic can save a recording as a file on a PC in PCM format.
sPowerful built-in speaker provides hi-fidelity acoustic playback.
• Do not store the RecMic in humid or dusty environments.
• If the RecMic is wet, wipe it immediately with a dry cloth.
• Do not use alcohol or lacquer thinner to clean the unit.
• Do not subject the RecMic to severe shocks or vibrations.
• Leaving magnetic cards near the RecMic’s speaker may lead to unusual
behaviors of the data stored in the card.
Safety precautions

4
EN
Operating environment
Windows
Operating System:
Microsoft Windows XP Professional/Home Edition SP3x86/Professional/
Home Edition SP2x64
Microsoft Windows Vista Ultimate/Enterprise/Business/Home Premium/
Home Basic SP2 (both of x86/64)
Microsoft Windows 7 Ultimate/Enterprise/Professional/Home Premium
(both of x86/64)
Microsoft Windows 8 /Pro/Enterprise (both of x86/64)
CPU/RAM:
At least meeting the minimum requirements for the operating system in use
USB port:
One or more free ports
Make sure that your computer meets the minimum requirements listed
below.
Please check with your system administrator or your Olympus Professional
Dealer.
Macintosh
Operating System:
Mac OS X 10.4.11 - 10.8
CPU/RAM:
At least meeting the minimum requirements for the operating system in use
USB port:
One or more free ports
Note
• When connecting the RecMic through an USB hub the operation may become unstable. In
such cases, refrain from using a USB hub.

5
EN
Identification of parts
1Built-in microphone
2Recording three color LED (red,
green and blue)
3Insert Recording LED (green)
4Volume down button
5Volume up button
6NEW (New) button
7Insert / Overwrite button
8REW (Rewind) button
9FF (Fast Forward) button
0Slide REC (Record)/STOP (Stop)/
PLAY (Play)/REV (Review) switch
!LEFT (Left) button
DR-1200 DR-2100
DR-2200
DR-2300
-
=
1
2
4
6
8
!
$
%
0
3
5
7
9
#
&
^
*
(
@
q
@RIGHT (Right) button
#Trackball
$F1 (Function 1) button
%F2 (Function 2) button
^F3 (Function 3) button
&F4 (Function 4) button
*Built-in speaker
(USB cable
)BACK (Back) button
-REC (Record) button
=PLAY (Play)/PAUSE (Pause)
button
qBarcode slot
)

6
EN
Specifications
4External dimensions:
154 mm × 44.6 mm × 31.6 mm
(without protrusions)
4Weight:
201 g (DR-1200), 183 g (DR-2100),
201 g (DR-2200), 206 g (DR-2300)
4Cable length:
2.5 m
4Plug shape:
USB connector A type
The RecMic is part of the Olympus Professional Dictation System. Your certified
professional dealer has been fully trained on the entire Olympus Professional
Dictation range, including dictation, transcription devices and software. For
technical assistance and guidance relating to installation and set up, please
contact your professional dealer from whom you purchased the system.
Technical assistance and support
4Recording format:
PCM 16 bit 44.1 kHz mono
4Input level:
86 dBSPL (-45 dBv)
4Microphone frequency response:
100 Hz to 14 kHz
4Overall frequency response:
300 Hz to 10 kHz
4Output power:
320 mW (8 Ω speaker)
“CE” mark indicates that this product complies with the European requirements for safety, health,
environment and customer protection. CE-mark products are for sale in Europe.
For customers in Europe
This symbol [crossed-out wheeled bin WEEE Annex IV] indicates separate collection of waste electrical and
electronic equipment in the EU countries. Please do not throw the equipment into the domestic refuse.
Please use the return and collection systems available in your country for the disposal of this product.
Specifications and design are subject to change without notice.
