Omcan PG-IT-0483-R User manual

Revised - 04/18/2023
Toll Free: 1-800-465-0234
Fax: [phone]
Email: [email protected]
www.omcan.com
Sandwich Grills
Models PG-IT-0483-R, 0483, 0610-R, 0737-R, 0737
Items 11375, 11376, 11377, 11378, 11380
Instruction Manual

2
Page
--------------------------------------------------------------------------- 3 - 4
--------------------------------------------------------------------------- 4 - 6
---------------------------------------------------------------------- 6 - 7
--------------------------------------------------------------------------------------- 7 - 8
----------------------------------------------------------------------------------------- 8 - 9
----------------------------------------------------------------------------------- 9 - 10
---------------------------------------------------------------------------- 11 - 18
---------------------------------------------------------------------- 19 - 20
------------------------------------------------------------------------------------------- 21 - 22
---------------------------------------------------------------------------- 23
Table of Contents
Section
General Information
Safety and Warranty
Technical Specications
Installation
Operation
Maintenance
Parts Breakdown
Electrical Schematics
Notes
Warranty Registration
Model PG-IT-0483-R / Model PG-IT-0483 / Model PG-IT-0610-R
Model PG-IT-0737-R / Model PG-IT-0737

3
General Information
Omcan Manufacturing and Distributing Company Inc., Food Machinery of America, Inc. dba Omcan
and Omcan Inc. are not responsible for any harm or injury caused due to any person’s improper or
negligent use of this equipment. The product shall only be operated by someone over the age of 18, of
sound mind, and not under the inuence of any drugs or alcohol, who has been trained in the correct
operation of this machine, and is wearing authorized, proper safety clothing. Any modication to the
machine voids any warranty, and may cause harm to individuals using the machine or in the vicinity of
the machine while in operation.
CHECK PACKAGE UPON ARRIVAL
Upon receipt of an Omcan shipment please inspect for external damage. If no damage is evident on the
external packaging, open carton to ensure all ordered items are within the box, and there is no concealed
damage to the machine. If the package has suffered rough handling, bumps or damage (visible or concealed),
please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may
initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be
lled out within three days, from the delivery date shown in the shipping documents. Omcan has no recourse
for damaged products that were shipped collect or third party.
Before operating any equipment, always read and familiarize yourself with all operation and safety
instructions.
Omcan would like to thank you for purchasing this machine. It’s of the utmost importance to save
these instructions for future reference. Also save the original box and packaging for shipping the
equipment if servicing or returning of the machine is required.
---------------------------------------------------------------------------------------------------------------------------------------------------
Omcan Fabrication et distribution Companie Limité et Food Machinery d’Amerique, dba Omcan et
Omcan Inc. ne sont pas responsables de tout dommage ou blessure causé du fait que toute personne
ait utilisé cet équipement de façon irrégulière. Le produit ne doit être exploité que par quelqu’un de
plus de 18 ans, saine d’esprit, et pas sous l’inuence d’une drogue ou d’acohol, qui a été formé pour
utiliser cette machine correctement, et est vêtu de vêtements de sécurité approprié. Toute modication
de la machine annule toute garantie, et peut causer un préjudice à des personnes utilisant la machine
ou des personnes à proximité de la machine pendant son fonctionnement.
VÉRIFIEZ LE COLIS DÈS RÉCEPTION
Dès réception d’une expédition d’Omcan veuillez inspecter pour dommages externes. Si aucun dommage
n’est visible sur l’emballage externe, ouvrez le carton an de s’assurer que tous les éléments commandés
sont dans la boîte, et il n’y a aucun dommage dissimulé à la machine. Si le colis n’a subi aucune mauvaises
manipulations, de bosses ou de dommages (visible ou cachée), notez-le sur le bond de livraison avant
d’accepter la livraison et contactez Omcan dans les 24 heures qui suivent, pour que nous puissions engager
une réclamation auprès du transporteur. Un rapport détaillé sur l’étendue des dommages causés à la machine
doit être rempli dans un délai de trois jours, à compter de la date de livraison indiquée dans les documents
d’expédition. Omcan n’a aucun droit de recours pour les produits endommagés qui ont été expédiées ou cueilli
par un tiers transporteur.

4
Safety and Warranty
General Information
GENERAL PRECAUTIONS
• The machine must be operated only by highly trained personnel who are fully aware of the safety measures
described in this manual.
• In case of a change in operator, training is to be provided in advance.
• Before starting cleaning and maintenance operations, turn off and disconnect the plug from the socket.
• Cleaning and maintenance requires great concentration.
Avant d’utiliser n’importe quel équipement, toujours lire et vous familiariser avec toutes les opérations
et les consignes de sécurité.
Omcan voudrais vous remercier d’avoir choisi cette machine. Il est primordial de conserver ces
instructions pour une référence ultérieure. Également conservez la boîte originale et l’emballage pour
l’expédition de l’équipement si l’entretien ou le retour de la machine est nécessaire.
---------------------------------------------------------------------------------------------------------------------------------------------------
Omcan Empresa De Fabricacion Y Distribucion Inc. Y Maquinaria De Alimentos De America, Inc. dba
Omcan y Omcan Inc. no son responsables de ningun daño o perjuicío causado por cualquier persona
inadecuada o el uso descuidado de este equipo. El producto solo podra ser operado por una persona
mayor de 18 años, en su sano juicio y no bajo alguna inuencia de droga o alcohol, y que este ha sido
entrenado en el correcto funcionamiento de esta máquina, y ésta usando ropa apropiada y autorizada.
Cualquier modicación a la máquina anúla la garantía y puede causar daños a las personas usando la
máquina mientras esta en el funcionamiento.
REVISE EL PAQUETE A SU LLEGADA
Tras la recepcion de un envio Omcan favor inspeccionar daños externos. Si no hay daños evidentes en el
empaque exterior, Habra el carton para asegurararse que todos los articulos solicitados ésten dentro de la
caja y no encuentre daños ocultos en la máquina. Si el paquete ha sufrido un manejo de poco cuidado, golpes
o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro
de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. Un informe detallado sobre
los daños causados a la máquina debe ser llenado en el plazo de tres días, desde la fecha de entrega que se
muestra en los documentos de envío. Omcan no tiene ningun recurso por productos dañados que se enviaron
a recoger por terceros.
Antes de utilizar cualquier equipo, siempre lea y familiarizarse con todas las instrucciones de
funcionamiento y seguridad.
Omcan le gustaría darle las gracias por la compra de esta máquina. Es de la mayor importancia para
salvar estas instrucciones para futuras consultas. Además, guarda la caja original y el embalaje para el
envío del equipo si servicio técnico o devolución de la máquina que se requiere.

5
Safety and Warranty
• A regular check of the electric supply cord is necessary; a worn-out or damage cord should not be used.
• If the machine has malfunctions, do not use it and do not repair it; please call the Omcan Service Center at
1-800-465-0234.
• The grill is used for cooking, heating, toasting, and to grill foodstuffs. Do not use the machine for other uses
or for any products other than foodstuffs.
The manufacturer is not liable in the following cases:
1. If the machine has been tampered or adjusted by non-authorized personnel.
2. If some parts have been substituted with non original spare parts.
3. If the instructions contained in this manual are not followed.
4. If the machine surface is not cleaned with the right product.
SAFETY DEVICES
The electrical safety devices installed on the machine, described in this manual, complies with EC 73/23,
89/336, 89/109. Even though the griller is provided with electrical and mechanical protections when the
machine is working and for maintenance and cleaning operations, there are still risks that cannot be eliminated
completely. These risks are scalds caused by the loading and unloading of the product, or other kind of injuries
due to the maintenance operations.
The unit complies with:
• UL 197, 8° edition.
• NSF 4, 1991 edition.
RESIDENTIAL USERS: Vendor assumes no liability for parts or labor coverage for component failure
or other damages resulting from installation in non-commercial or residential applications. The right
is reserved to deny shipment for residential usage; if this occurs, you will be notied as soon as
possible.
1 YEAR PARTS AND LABOUR BENCH WARRANTY
Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule a drop off to either
an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the
equipment.
Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not
improper use.
Please see https://omcan.com/disclaimer for complete info.
WARNING:
The packaging components are classied as normal solid urban waste and can therefore be disposed of
without difculty.

6
Technical Specications
Model PG-IT-0483-R PG-IT-0483 PG-IT-0610-R PG-IT-0737-R PG-IT-0737
Top Grill
Dimensions
10” x 9”
254 x 229mm
10” x 14”
254 x 356mm
10” x 8.75”
254 x 222mm
Bottom Grill
Dimensions
10” x 9”
254 x 229mm
10” x 14”
254 x 356mm
10” x 19”
254 x 483mm
Current 15A 13A
Thermostat
Control 50 - 300ºC / 120 - 570ºF
Power 1.7 kW 3 kW
Electrical 110V / 60Hz / 1 220V / 60Hz / 1
Top Grill Ribbed
Bottom Grill Ribbed Smooth Ribbed Smooth / Ribbed
Weight 40 lbs. / 18 kgs. 35 lbs. / 16 kgs. 53 lbs. / 24 kgs. 56 lbs. / 25 kgs. 70 lbs. / 31.8 kgs.
Packaging
Weight 43 lbs. / 19.5 kgs. 38 lbs. / 17 kgs. 55 lbs. / 25 kgs. 70 lbs. / 32.8 kgs. 75 lbs. / 34 kgs.
Opened
Dimensions
11.4” x 14.4” x 19.8”
290 x 365 x 500mm
15” x 14.4” x 19.8”
380 x 365 x 500mm
21” x 12.75” x 19.8”
533 x 324 x 500mm
Closed
Dimensions
11.4” x 14.4” x 9”
290 x 365 x 235mm
15” x 14.4” x 9”
380 x 365 x 235mm
21” x 12.8” x 7”
533 x 324 x 178mm
Item Number 11375 11376 11377 11378 11380
1
2
34
5
6MAIN COMPONENTS
1. Lower cooking grill.
2. Thermostat.
3. Pilot lamp.
4. Feet.
5. Collection tray.
6. Upper cooking grill.
Fig. 1: Main
components
Safety and Warranty
In any case, for suitable recycling, we suggest disposing of the products separately (differentiated
waste) according to the current norms.
DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!

7
Technical Specications
WARNING: The electrical characteristics for which the appliance is designed are indicated on the
reference plate applied on the side of the machine; check to make sure it corresponds with the
electrical supply before connecting.
Installation
ASSEMBLY
The package of the grillers includes (see Fig. 2:):
a. Cardboard box and internal protections.
b. The machine.
c. This manual.
d. Scraper or brush (f) in accordance with the model.
e. EC conformity declaration.
PACKAGING DISPOSAL
The components of the packaging are urban solid waste; therefore they can be easily disposed. If the machine
has to be installed in countries where specic regulations are in force, packaging must be disposed in
compliance with them.
SETTING UP OF THE MACHINE
The machine must be installed on a work table suitable for the grills overall dimensions as shown. It must be
adequately large, level, dry, smooth, resistant, stable and at a height of 80 cm from the ground. The machine
must be installed in a room with a maximum of 75% humidity and a temperature between +5°C and +35°C.
Fig. 2:
Unpacking
components
c)
a)
d)
e) f)
b)

8
Operation
To check the machine functioning, just turn the “start” regulator knob clockwise (placing yourself in front of the
knob), and starting from the minimum, observe if the pilot lamp turns on. When the pilot lamp is on, it means
that the machine is functioning.
1. Thermostat.
2. Pilot lamp, it indicates that the grill is on.
FIRST USE OF THE MACHINE
When the machine is delivered, the steel surfaces are protected with a nylon anti-scratch lm and residuals
of glue. This lm and glue has to be removed before starting the machine. Do not use sharpening tools,
ammable or abrasive substances. The insulating materials used during the manufacturing and the residuals of
grease and glue may produce smoke during rst operation. It is necessary to start the machine outdoors, for a
minimum of 15-20 minutes before normal use.
WARNING: When you place the product on the grid to cook, it will be hot. Pay attention to cooking operations
to avoid burning dangers.
Fig. 3:
Control
switches
positioning.
2
1
Installation
ELECTRICAL CONNECTIONS
The machine is equipped with a power supply cord. To connect the machine, follow the indication of the rating
plate. Check that unit is grounded. Check that the features on the rating plate correspond to the features
shown in the consignment and delivery note, and that the disconnecting plug and the socket are easy to reach
when the machine is functioning.

9
Operation
To load the product follow this procedure:
1. Place yourself in a correct position (see Figure 4), avoiding any contact with the machine.
2. Choose the correct temperature using the knob.
3. When the grill is hot, place the product and start the cooking.
4. At the end of the cooking, remove the food and residuals from the grill.
5. If the grill is inactive for a long period (one or two hours), place the knob to 0°C and unplug.
If the machine has been turned off longer than 30 min., allow at least 10 min. for it to reach cooking
temperature again. If you are not using the machine, but you think you are going to need it soon, set the
temperature at 120 F, this will allow the machine to reach cooking temperature faster.
Fig. 4: Proper
operation
position.
30 - 36”
76.2 - 91.44cm
Maintenance
• Cleaning the machine should be performed at least once a day and, if necessary more often.
• Never clean the machine by means of water jets, or submerge the machine.
• The cleaning of the grill can be performed when it is hot, scrape with a metallic brush on the cooking grid
several times.
ATTENTION: Do not to touch the cooking surface because this could cause burns.

10
Maintenance
• Use the same care when emptying the collecting tray to make gravy.
• It is recommended to perform these cleaning operations when the temperature has dropped but the
residual grease which sticks to the grill is still a liquid.
• Do not pour water or other liquids on the grid when it is hot, because the rapid changes of temperature can
damage the grills surface.
WARNING: Before performing any cleaning operation, turn off and disconnect the plug from the electrical
socket.
Periodically check whether the power cord is worn-out and, if this is the case, please call the Omcan Service
Center at 1-800-465-0234 to have it replaced.
DISPOSAL OF THE MACHINE
If you decide to put the machine out of service, disconnect it from the socket. To dismantle the machine contact
a specialized disposal centre, paying attention to the different materials used.

11
Parts Breakdown
Model PG-IT-0483-R 11375
Model PG-IT-0483 11376

12
Model PG-IT-0483-R 11375
Item No. Description Position Item No. Description Position Item No. Description Position
AM980 Bottom Plate Ribbed for 11375 1 AM993 Brass Brake for 11375 15 AN004 Wire Protecting Spring D.14 for 11375 33
AM982 Upper Plate Ribbed for 11375 2 AM994 Lifting Pin 12x243 for 11375 16 AN005 Distance Ring Int.14x4 F.10.5 for 11375 37
AM983 Base for 11375 3 AM995 Pin PD D10x247 for 11375 17 AN006 Distance Ring.EST.14x12.3 F.10.5 for
11375 37
AM984 Bottom for 11375 4 AM996 Handle Pin 10x236 for 11375 18 19372 Terminal Block for 11375 38
AM985 Spring Cover for 11375 5 63480 Right Spring for 11375 19DX AN007 ETL Cable with Light Complete for 11375 40
AM986 Stainless Steel Tub for 11375 6 63481 Left Spring for 11375 19SX AN008 USA Cord 125 V 20A for 11375 41
AM988 Stainless Steel Cover DX 45° for 11375 7 AM997 Black Handle L.235,5 for 11375 20 16469 Wire Panini Brush Red Handle for 11375 42
AM989 Stainless Steel Cover DX 90° for 11375 7/15 AM998 Black Drawer Knob for 11375 21 AN009 Gland for 11375 43
16470 Top Heating Element 700W 115 V for
11375 8 37282 Upper Knob Black for 11375 22 AN010 Clamp PA 268 RO CETL Plate with Screws for 11375 45
18828 Bottom Heating Element 110V for 11375 9 18001 Knob for 11375 23 AN011 Timer Grill for 11375 47
16474 Thermostat 110/220-50/60 for 11375 10 AM999 Foot for 11375 24 AN012 Monster for 11375 50
23747 Pilot Light 110V for 11375 11 AN000 Flange Screw Zigr. M06x12 for 11375 26 78769 Mostr.Gradiata Dim.8x7cm for 11375 50A
21103 Insulating Panel 110 ZK for 11375 12 37273 Washer Dia.6 for 11375 26A, 36 AN013 Monster Tim for 11375 51
AM990 Panel Protection for 11375 13 AN001 Antirib for 11375 30 78810 Boccola Flangiata D.12 per Molle for
11375 65
AM991 Right Lifting Rod 25x8x363 W/Peg for
11375 14DX AN002 Low Hex.Nut DIN 439 M6 for 11375 30A AN014 Screw TC + 4.8 04x010 Zinc. for 11375 70
AM992 Left Lifting Rod 25x8x363 W/Peg for
11375 14SX AN003 Screw TE DIN 933 M6x14 T.F. for 11375 30B AN015 Hex Spacer Pin ETL for 11375 71
Parts Breakdown

13
Parts Breakdown
Model PG-IT-0483 11376
Item No. Description Position Item No. Description Position Item No. Description Position
AM979 Bottom Plate Flat for 11376 1 AM993 Brass Brake for 11376 15 AN004 Wire Protecting Spring D.14 for 11376 33
AM981 Upper Plate Smooth for 11376 2 AM994 Lifting Pin 12x243 for 11376 16 AN005 Distance Ring Int.14x4 F.10,5 for 11376 37
AM983 Base for 11376 3 AM995 Pin PD D10x247 for 11376 17 AN006 Distance Ring.Est.14x12,3 F.10,5 for
11376 37
AM984 Bottom for 11376 4 AM996 Handle Pin 10x236 for 11376 18 19372 Terminal Block for 11376 38
AM985 Spring Cover for 11376 5 63480 Right Spring for 11376 19DX AN007 ETL Cable with Light Complete for 11376 40
AM986 Stainless Steel Tub for 11376 6 63481 Left Spring for 11376 19SX AN008 USA Cord 125 V 20A for 11376 41
AM988 Stainless Steel Cover DX 45° for 11376 7 AM997 Black Handle L.235,5 for 11376 20 16469 Wire Panini Brush Red Handle for 11376 42
AM989 Stainless Steel Cover DX 90° for 11376 7/15 AM998 Black Drawer Knob for 11376 21 AN009 Gland for 11376 43
16470 Top Heating Element 700W 115 V for
11376 8 37282 Upper Knob Black for 11376 22 AN010 Clamp PA 268 RO CETL Plates with Screw for 11376 45
18828 Bottom Heating Element 110V for 11376 9 18001 Knob for 11376 23 AN011 Timer Grill for 11376 47
16474 Thermostat 110/220-50/60 for 11376 10 AM999 Foot for 11376 24 AN012 Monster for 11376 50
23747 Pilot Light 110V for 11376 11 AN000 Flange Screw Zigr. M06x12 for 11376 26 78769 Mostr.Graduata Dim.8x7cm for 11376 50A
21103 Insulating Panel 110 ZK for 11376 12 37273 Washer Dia.6 for 11376 26A, 36 AN013 Monster Tim for 11376 51
AM990 Panel Protection for 11376 13 AN001 Antirib for 11376 30 78810 Boccola Flangiata D. 12 per Molle for
11376 65
AM991 Right Lifting Rod 25x8x363 W/Peg for
11376 14DX AN002 Low Hex.Nut DIN 439 M6 for 11376 30A AN014 Screw TC+ 4.8 04x010 Zinc. for 11376 70
AM992 Left Lifting Rod 25x8x363 W/Peg for
11376 14SX AN003 Screw TE DIN 933 M6x14 T.F. for 11376 30B AN015 Hex Spacer Pin ETL for 11376 71

14
Model PG-IT-0610-R 11377
Parts Breakdown

15
Parts Breakdown
Model PG-IT-0610-R 11377
Item No. Description Position Item No. Description Position Item No. Description Position
AN016 Bottom Surface Ribbed for 11377 1 AN027 Lifting Pin D.12x367 for 11377 16 AN004 Wire Protecting Spring D.14 for 11377 33
AN017 Upper Plate Ribbed for 11377 2 AN028 Pin Bilan.10x373 Zinc.White for 11377 17 AN037 Spacer Ring 14x17 F. 10.5 for 11377 37
AN018 Base for 11377 3 AN029 Handle Pin 10x363/M6 for 11377 18 19372 Terminal Block for 11377 38
AN019 Bottom for 11377 4 AN030 Right Spring for 11377 19DX AN038 Cabl. CETL Compl. for 11377 40
AN020 Spring Cover for 11377 5 AN031 Left Spring for 11377 19SX AN008 USA Cord 125 V 20A for 11377 41
AN021 Stainless Steel Trash Collecting Tray
for 11377 6 AN032 Black Handle P. L.362,5 for 11377 20 16469 Wire Panini Brush Red Handle for 11377 42
AN022 Stainless Steel Cover 45° for 11377 7 AM998 Black Drawer Knob for 11377 21 AN009 Gland for 11377 43
AN023 Stainless Steel Cover 90° for 11377 7/15 17756 Top Plate Knob Black for 11377 22 AN010 Clamp PA 268 RO CETL Plates with
Screws for 11377 45
AN024 Top Heating Element 700W 115V for
11377 8 18001 Knob for 11377 23 AN011 Timer Grill for 11377 47
AN025 Bottom Heating Element 850W 115V
for 11377 9A AM999 Foot for 11377 24 AN039 Monster Court Sir. for 11377 50
16474 Thermostat 110/220-50/60 for 11377 10 37273 Washer Dia.6 for 11377 26A, 36 78769 Mostr.Graduata Dim.8x7cm for 11377 50A
23747 Pilot Light for 11377 11 78800 Screw 6x16 TPSCE for 11377 27 AN040 Mostrina Tim Sirm. for 11377 51
37268 Insulating Panel 110 ZK for 11377 12 78801 Screw 8x18 TPSCE for 11377 28 78810 Boccola Flangiata D.12 per Molle for
11377 65
AN026 Panel Protection Short Insulation for
11377 13 AN033 Grain 8x12 P. Flat PD CRT HER for 11377 29 AN014 Screw TC+ 4.8 04x010 Zinc. for 11377 70
AM991 Right Lifting Rod 25x8x363 W/Peg for
11377 14DX AN034 Anti-Rib. Court for 11377 30 AN015 Hex Spacer Pin ETL for 11377 71
AM992 Left Lifting Rod 25x8x363 W/Peg for
11377 14SX AN035 Nut EX. UNI 5587 M6 High for 11377 30A
AM993 Brass Brake for Grill for 11377 15 AN036 Hex.Screw DIN 933 M6x16 for 11377 30B

16
Model PG-IT-0737-R 11378
Model PG-IT-0737 11380
Parts Breakdown

17
Parts Breakdown
Model PG-IT-0737-R 11378
Item No. Description Position Item No. Description Position Item No. Description Position
AN041 Bottom Plate Rib/Rib for 11378 1 63480 Right Spring for 11378 19DX 37273 Washer Dia.6 for 11378 36
AM982 Upper Plate Ribbed for 11378 2DX 63481 Left Spring for 11378 19SX AN005 Distance Ring Int.14x4 F.10.5 for 11378 37A
78795 Left Top Surface-Grooved for 11378 2SX AM997 Black Handle L.235,5 for 11378 20A AN006 Distance Ring.Est.14x12.3 F.10.5 for
11378 37B
AN043 Stainless Steel Base for 11378 3 AM998 Black Drawer Knob for 11378 21A 19372 Terminal Block for 11378 38
AN044 Fund Top for 11378 4 78799 Pomello P. Sup. Nero for 11378 22A AK103 Protection Spiral Wires for 11378 40
AN045 Spring Cover for 11378 5 18001 Knob for 11378 23 AN054 Power Cord 3x12 AWG, US Plug for
11378 41
AN046 Stainless Steel Collecting Tray for 11378 6 AM999 Foot for 11378 24 16469 Wire Panini Brush Red Handle for 11378 42
AM989 Stainless Steel Cover DX 90° for 11378 7DX AN048 Screw TE M6x12 Flang. Knurled Black
for 11378 26 AN055 Cable Gland PG 13.5+Nut for 11378 43
AN047 LH Stainless Steel Cover 90° for 11378 7SX AN000 Flange Screw Zigr. M06x12 for 11378 26 AN011 Timer Grill for 11378 47
78192 Top Element for 11378 8 78800 Screw 6x16 TPSCE for 11378 27 AN056 Monster PD Sir. for 11378 50
16473 Bottom Heating Element 220V for 11378 9 78801 Screw 8x18 TPSCE for 11378 28 78769 Mostr.Graduata Dim.8x7cm for 11378 50A
16474 Thermostat 110/220-50/60 for 11378 10 AN033 Grain 8x12 P. Flat CRT HER for 11378 29 AN057 Face Plate W. Tim for 11378 51
23747 Pilot Light 110V for 11378 11 AN049 Nut M.6 Extra Low Zinc. for 11378 30A 78808 Monst. Pers/Neutra. Timer for 11378 51A
21103 Insulating Panel 110 ZK for 11378 12 AN036 Hex.Screw DIN 933 M6x16 for 11378 30A 78810 Flanged Bushing D12 for Spring for
11378 65
AM990 Panel Protection for 11378 13 AN050 Screw M6x16 TE Inox A2 for 11378 30B AN058 Screw TC- 5x8 Inox A2 for 11378 72
AM991 Right Lifting Rod 25x8x363 W/Peg for
11378 14DX AN002 Low Hex.Nut Din 439 M6 for 11378 30B AN059 Screw TBL M4x12 Washed Combi for 11378 73
AM992 Left Lifting Rod 25x8x363 W/Peg for
11378 14SX AN001 Antirib for 11378 30DX AN060 Serrated Washers D.4 Zinc for 11378 74
AM993 Brass Brake for Grill for 11378 15 AN051 Anti-Rib SX for 11378 30SX AN061 Hex Nut M4 Medium Z.White for 11378 75
AM994 Lifting Pin 12x243 for 11378 16 AN052 Screw M4x5 TC Z.Bianca x Thermostat
for 11378 31 AN062 Nut M6 Low Zinc. for 11378 76
AM995 Pin D10x247 for 11378 17 AN053 Self-Tapping Screws TC+ 4.2x06.5 for
11378 32 AN063 Screw TE M4x3.5 Z.White for Timer for 11378 77
AM996 Handle Pin 10x236 for 11378 18 AN004 Wire Protecting Spring D.14 for 11378 33

18
Model PG-IT-0737 11380
Parts Breakdown
Item No. Description Position Item No. Description Position Item No. Description Position
AN042 Bottom Plate Flat/Ribbed for 11380 1 63480 Right Spring for 11380 19DX 37273 Washer Dia.6 for 11380 36
AM982 Upper Plate Ribbed for 11380 2DX 63481 Left Spring for 11380 19SX AN005 Distance Ring Int.14x4 F.10.5 for 11380 37A
78795 Left Top Surface-Grooved for 11380 2SX AM997 Black Handle L.235,5 for 11380 20A AN006 Distance Ring.Est.14x12,3 F.10,5 for
11380 37B
AN043 Stainless Steel Base for 11380 3 AM998 Black Drawer Knob for 11380 21A 19372 Terminal Block for 11380 38
AN044 Fund for 11380 4 78799 Pomello P. Sup. Nero for 11380 22A AK103 Protection Spiral Wires for 11380 40
AN045 Spring Cover for 11380 5 18001 Knob for 11380 23 AN054 Power Cord, 3x12 AWG, US Plug for
11380 41
AN046 Stainless Steel Collecting Tray Top for
11380 6 AM999 Foot for 11380 24 16469 Wire Panini Brush Red Handle for 11380 42
AM989 Stainless Steel Cover DX 90° for 11380 7DX AN048 Screw TE M6x12 Flang. Knurled Black
for 11380 26 AN055 Cable Gland PG 13,5+Nut for 11380 43
AN047 LH Stainless Steel Cover 90° for 11380 7SX AN000 Flange Screw Zigr. M06x12 for 11380 26 AN011 Timer Grill for 11380 47
78192 Top Element for 11380 8 78800 Screw 6x16 TPSCE for 11380 27 AN056 Monster Sir. for 11380 50
16473 Bottom Heating Element 220V 501 for
11380 9 78801 Screw 8x18 TPSCE for 11380 28 78769 Mostr.Graduata Dim.8x7cm for 11380 50A
16474 Thermostat 110/220-50/60 for 11380 10 AN033 Grain 8x12 P. Flat for 11380 29 AN057 Face Plate W. Tim for 11380 51
23747 Pilot Light 110V for 11380 11 AN049 Nut M.6 Extra Low Zinc. for 11380 30A 78808 Monst. Pers/Neutra. Timer for 11380 51A
21103 Insulating Panel 110 ZK for 11380 12 AN036 Hex.Screw DIN 933 M6x16 for 11380 30A 78810 Flanged Bushing D12 for 11380 65
AM990 Panel Protection for 11380 13 AN050 Screw M6x16 TE Inox A2 for 11380 30B AN058 Screw TC- 5x8 Inox A2 for 11380 72
AM991 Right Lifting Rod 25x8x363 W/Peg for
11380 14DX AN002 Low Hex.Nut DIN 439 M6 for 11380 30B AN059 Screw TBL M4x12 Washed Combi for 11380 73
AM992 Left Lifting Rod 25x8x363 W/Peg for
11380 14SX AN001 Antirib for 11380 30DX AN060 Serrated Washers D.4 Zinc for 11380 74
AM993 Brass Brake for Grill for 11380 15 AN051 Anti-Rib. SX for 11380 30SX AN061 Hex Nut M4 Medium Z.White for 11380 75
AM994 Lifting Pin 12x243 for 11380 16 AN052 Screw M4x5 TC Z.Bianca x Thermostat
for 11380 31 AN062 Nut M6 Low Zinc. for 11380 76
AM995 Pin PD D10x247 for 11380 17 AN053 Self-Tapping Screws TC+ 4.2x06.5 for
11380 32 AN063 Screw TE M4x3,5 Z.White for Timer for 11380 77
AM996 Handle Pin 10x236 for 11380 18 AN004 Wire Protecting Spring D.14 for 11380 33

19
Electrical Schematics
Model PG-IT-0483-R 11375
Model PG-IT-0483 11376
Model PG-IT-0610-R 11377

20
Model PG-IT-0737-R 11378
Model PG-IT-0737 11380
Electrical Schematics
