Omcan 37864 User manual

Revised - 03/26/2018
Toll Free: 1-800-465-0234
Fax: [phone]
Email: [email protected]
www.omcan.com
Ice Maker
Model IC-CN-0012
Item 37864
Instruction Manual

2
Page
--------------------------------------------------------------------------- 3 - 4
--------------------------------------------------------------------------- 4 - 5
-------------------------------------------------------------------------- 5
----------------------------------------------------------------------------------------- 6 - 7
----------------------------------------------------------------------------------- 8 - 11
----------------------------------------------------------------------------- 11 - 19
---------------------------------------------------------------------------- 20 - 21
---------------------------------------------------------------------------- 22
---------------------------------------------------------------------------- 23
Table of Contents
Section
General Information
Safety and Warranty
Technical Specications
Operation
Maintenance
Troubleshooting
Parts Breakdown
Electrical Schematics
Warranty Registration
Model IC-CN-0012

3
General Information
Omcan Manufacturing and Distributing Company Inc., Food Machinery of America, Inc. dba Omcan
and Omcan Inc. are not responsible for any harm or injury caused due to any person’s improper or
negligent use of this equipment. The product shall only be operated by someone over the age of 18, of
sound mind, and not under the inuence of any drugs or alcohol, who has been trained in the correct
operation of this machine, and is wearing authorized, proper safety clothing. Any modication to the
machine voids any warranty, and may cause harm to individuals using the machine or in the vicinity of
the machine while in operation.
CHECK PACKAGE UPON ARRIVAL
Upon receipt of an Omcan shipment please inspect for external damage. If no damage is evident on the
external packaging, open carton to ensure all ordered items are within the box, and there is no concealed
damage to the machine. If the package has suffered rough handling, bumps or damage (visible or concealed),
please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may
initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be
lled out within three days, from the delivery date shown in the shipping documents. Omcan has no recourse
for damaged products that were shipped collect or third party.
Before operating any equipment, always read and familiarize yourself with all operation and safety
instructions.
Omcan would like to thank you for purchasing this machine. It’s of the utmost importance to save
these instructions for future reference. Also save the original box and packaging for shipping the
equipment if servicing or returning of the machine is required.
---------------------------------------------------------------------------------------------------------------------------------------------------
Omcan Fabrication et distribution Companie Limité et Food Machinery d’Amerique, dba Omcan et
Omcan Inc. ne sont pas responsables de tout dommage ou blessure causé du fait que toute personne
ait utilisé cet équipement de façon irrégulière. Le produit ne doit être exploité que par quelqu’un de
plus de 18 ans, saine d’esprit, et pas sous l’inuence d’une drogue ou d’acohol, qui a été formé pour
utiliser cette machine correctement, et est vêtu de vêtements de sécurité approprié. Toute modication
de la machine annule toute garantie, et peut causer un préjudice à des personnes utilisant la machine
ou des personnes à proximité de la machine pendant son fonctionnement.
VÉRIFIEZ LE COLIS DÈS RÉCEPTION
Dès réception d’une expédition d’Omcan veuillez inspecter pour dommages externes. Si aucun dommage
n’est visible sur l’emballage externe, ouvrez le carton an de s’assurer que tous les éléments commandés
sont dans la boîte, et il n’y a aucun dommage dissimulé à la machine. Si le colis n’a subi aucune mauvaises
manipulations, de bosses ou de dommages (visible ou cachée), notez-le sur le bond de livraison avant
d’accepter la livraison et contactez Omcan dans les 24 heures qui suivent, pour que nous puissions engager
une réclamation auprès du transporteur. Un rapport détaillé sur l’étendue des dommages causés à la machine
doit être rempli dans un délai de trois jours, à compter de la date de livraison indiquée dans les documents
d’expédition. Omcan n’a aucun droit de recours pour les produits endommagés qui ont été expédiées ou cueilli
par un tiers transporteur.

4
Safety and Warranty
General Information
• Turn the unit off and unplug before performing any cleaning, maintenance or repairs.
• Do not operate the unit with a damaged power cord. If a damaged power cord is found, immediately turn
the unit off and unplug it. Do not operate again until trained personnel have xed the problem.
• Only operate the unit on a at, level ground. Do not place the unit near any heat sources.
• Only use original spare parts for repairs.
1 YEAR PARTS AND LABOUR BENCH WARRANTY
Avant d’utiliser n’importe quel équipement, toujours lire et vous familiariser avec toutes les opérations
et les consignes de sécurité.
Omcan voudrais vous remercier d’avoir choisi cette machine. Il est primordial de conserver ces
instructions pour une référence ultérieure. Également conservez la boîte originale et l’emballage pour
l’expédition de l’équipement si l’entretien ou le retour de la machine est nécessaire.
---------------------------------------------------------------------------------------------------------------------------------------------------
Omcan Empresa De Fabricacion Y Distribucion Inc. Y Maquinaria De Alimentos De America, Inc. dba
Omcan y Omcan Inc. no son responsables de ningun daño o perjuicío causado por cualquier persona
inadecuada o el uso descuidado de este equipo. El producto solo podra ser operado por una persona
mayor de 18 años, en su sano juicio y no bajo alguna inuencia de droga o alcohol, y que este ha sido
entrenado en el correcto funcionamiento de esta máquina, y ésta usando ropa apropiada y autorizada.
Cualquier modicación a la máquina anúla la garantía y puede causar daños a las personas usando la
máquina mientras esta en el funcionamiento.
REVISE EL PAQUETE A SU LLEGADA
Tras la recepcion de un envio Omcan favor inspeccionar daños externos. Si no hay daños evidentes en el
empaque exterior, Habra el carton para asegurararse que todos los articulos solicitados ésten dentro de la
caja y no encuentre daños ocultos en la máquina. Si el paquete ha sufrido un manejo de poco cuidado, golpes
o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro
de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. Un informe detallado sobre
los daños causados a la máquina debe ser llenado en el plazo de tres días, desde la fecha de entrega que se
muestra en los documentos de envío. Omcan no tiene ningun recurso por productos dañados que se enviaron
a recoger por terceros.
Antes de utilizar cualquier equipo, siempre lea y familiarizarse con todas las instrucciones de
funcionamiento y seguridad.
Omcan le gustaría darle las gracias por la compra de esta máquina. Es de la mayor importancia para
salvar estas instrucciones para futuras consultas. Además, guarda la caja original y el embalaje para el
envío del equipo si servicio técnico o devolución de la máquina que se requiere.

5
Safety and Warranty
Technical Specications
Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule a drop off to either
an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the
equipment.
Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not
improper use.
Please see www.omcan.com/warranty.html for complete info.
WARNING:
The packaging components are classied as normal solid urban waste and can therefore be disposed of
without difculty.
In any case, for suitable recycling, we suggest disposing of the products separately (differentiated
waste) according to the current norms.
DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!
Model IC-CN-0012
Maximum Production 44 lbs. / 20 kgs. per day
Maximum Ice Storage 26.5 lbs. / 12 kgs.
Ice Shape Cube
Electrical 115V / 60Hz / 1
Power 210W
Current 3A - 3.6A
Refrigerant R134a
Weight 81.6 lbs. / 37 kgs.
Packaging Weight 101.4 lbs. / 46 kgs.
Dimensions 14.6” x 23.6” x 33.1” / 370 x 600 x 842mm
Packaging Dimensions 16.3” x 26.1” x 39.4” / 413 x 665 x 1000mm
Item Number 37864

6
Operation
MAJOR FUNCTIONS
1. The operating procedure is completely automatic.
2. When the ice storage bin is full of ice cubes the machine stops making ice automatically. It starts making
ice again after ice cubes are removed.
3. The different colors of the LED display indicate various work modes.
4. A sensitive probe and accurate timer enhance the performance of the ice maker.
5. A compressor protection system is built in.
CONTROLLER DISPLAYS
Instructions for LEDs and buttons:
1. Red LED: Ice full indicator light. When this LED is lit, the ice storage bin is full of ice or there is something
between the sensor in the ice storage bin. The unit will stop making ice. When ice cubes are taken out of
the ice storage bin making the ice-full probe free, the red LED will keep ashing for 3 minutes. Then the
unit will restart and return to the ice making mode.
2. Green LED: Ice making indicator light. When this LED is lit, the unit is working in the ice making mode
controlled by a temperature probe on the evaporator. When the green LED is ashing, the unit is working in
the ice making mode controlled by a xed timer.
3. Yellow LED: Ice harvest indicator light. When this LED is lit, the unit is working in the ice harvest mode
controlled by the ice-full probe. When the green LED and yellow LED is lit, it means the unit is working in
the cold preservation stage.
4. Mode button: Mainly for service. When this button is pressed, it can change from ice making mode to ice
harvest mode, or from ice harvest mode to ice making mode. You can judge the mode from the status of
the green and yellow LEDs.
5. Adjust button: Mainly for service. When this is pressed over 3 seconds, the unit will enter the Ice Size
Adjustment mode. The mode can be judged from the status of the yellow LED.
ICE SIZE ADJUSTMENT
1. Press and hold the “Adjust” button for at least 3 seconds. The unit will enter the Ice Size Adjustment mode.
The “HARVEST” LED (yellow) will be blinking continuously during the ice size adjustment.
2. While in the Ice Size Adjustment mode, press the “Clean” button or the “Mode” button for the desired ice
size.
Smaller ice setting: By pressing the “Clean” button, you can decrease the size of the ice cubes. The “ICE”
LED (green) will ash as you lower the ice size and will nally be blinking at the setting of smallest ice size.
Larger ice setting: By pressing the “Mode” button, you can increase the size of the ice cubes. The “BIN FULL”
LED (red) will ash as the larger size is set and will blink when the setting of largest ice size has been reached.
After 10 seconds without any operation, the unit will return to the previous mode.
NOTE:
• If during the ice size adjustment mode the “BIN FULL”, “ICE” and “HARVEST” LEDS blink all at once, this

7
Operation
indicates that the unit is in the regular (middle) setting of the ice size.
• When the machine is in the cleaning stage or ice full stage, the ice size adjustment mode cannot be
accessed.
During the ice-making stage, the hot gas solenoid valve is closed. The hot refrigerant gas is pumped out off
the compressor to the condenser. The hot gas is cooled by fan forced air to the warm liquid refrigerant after
passing through the condenser. The drier & lter reduces the possible dirt and humidity in the refrigerant. The
evaporator is cooled by the refrigerant. Some ice can be formed on the evaporator during the water spraying
process in the evaporator. Low pressure refrigerant gas may go back to the compressor from the evaporator.
During the ice harvest stage, the solenoid valve is opened. The hot refrigerant gas is pumped out off the
compressor to the evaporator through the hot gas valve. As the hot gas is not cooled by the condenser, the
refrigerant makes the evaporator (ice mold) slightly warm. So some ice touching the evaporator is thawed. All
of ice can slide down to the ice storage bin.
WATER SYSTEM
When the water supply pipe is connected with the main water supply, water will ll the water trough through the
oater valve until enough water inside water trough makes oater valve close. During the ice-making stage,
water is pumped from the water trough to the water distribution tube. The distributed water ows to the surface
of the evaporator. Most parts of water go back to the water trough. Some water is frozen on the evaporator
step by step. The oater valve will open and fresh water is
CIRCUIT DESCRIPTION
First time usage: As the icemaker is properly installed, switch on the water tap, let the water trough ll
(reach full on the level), then press the ON/OFF button on the front panel. The icemaker will start working
automatically In this status, the time is xed to about 3 minutes. This function is also helpful to protect the
compressor from avoiding restart within 3 minutes. At this status, the Red, Green, Yellow LEDs are lit together.
Ice-making status: The compressor, motor fan and pump are powered on. The hot gas solenoid valve is
powered off. When this green LED is lit, the unit is working in the ice making mode controlled by a temperature
probe on the evaporator. When the green LED is ashing, the unit is working in the ice making mode controlled
by a xed timer. The fan motor is also controlled by a condenser sensor. When the ambient temperature is too
low, the motor fan will stop working for good condensation to the refrigerant.
Ice harvest status: The pump is powered off. The hot gas solenoid valve, compressor and motor fan is
powered on. The fan motor is also controlled by a condenser sensor. When the ambient temperature is too
low, the motor fan will stop working for good condensation to the refrigerant. The Yellow LED indicates the ice
harvest status.
Ice full status: If the ice bin is lled with ice or the full sensor is covered, the machine stops making ice
automatically. In this status, the compressor stops working. The RED LED indicates the ice full status.

8
Maintenance
ADJUSTMENT AND REPLACEMENT
All maintenance to be performed by a certied technician only (call omcan at 1-800-465-0234)
Replace Controller, fuse and the sensor of temperature
• Remove the rear cover, front panel,
• Locate the Electronic controller,
• Pull out the temperature sensors (one at the evaporator, another at the condenser).
• Loosen the screws connecting the Electronic controller, replace a new one. Reverse the above step to
replace.
• If you need to replace the fuse, open the front panel of the control box, you will nd the fuse.
• Take out the fuse, replace a new one. Reverse the above step to reassemble.
ELECTRICAL SHOCK HAZARD
Disconnect electrical power before
beginning removal of parts

9
Maintenance
• If you need replace the temperature sensors, pull out the temperature sensors, open the panel of the
controller box, pull out the other side, replace a new one. Reverse the above steps to reassemble.
Replace the water system components
Please see the water system drawing. The water leakage should be checked after this kind of operation.
Replacing the water pump
• Disconnect electrical power.
• Remove the rear cover.
• Unplug the lines connector with the water pump, the water outlet tube of pump and the water inlet tube of
pump.
• Loosen the screws, replace a new one.
• Reverse the above steps to reassemble.
Replace the cooling system components
• Replace the condensing components, See the cooling system diagram.
• Replace the compressor and the compressor kit (includes relay, thermal protect).
The cube size has been adjusted before leaving
the factory. Adjust accordingly.
Before replacing the water system components, it is necessary
to drain the system rst.

10
Maintenance
• If you only need to replace the compressor kit, remove the rear panel, locate the compressor, take the clip,
open the cover, replace the old compressor,
• Reverse the above steps to reassemble.
• If you need to replace the compressor, remove the rear cover, and cabinet, locate the compressor.
• Unplug the lines and take out the grounded line, add the low side access valve, open the Process/Suction,
evacuate refrigerant, take out the compressor, replace a new one, joint together, then recover refrigerant,
weigh in the nameplate charge.
• Reverse the above steps to reassemble.

11
Maintenance
Troubleshooting
Replace the fan motor and fan blade
• Remove the front panel, rear and cabinet.
• Locate the fan motor, unplug the lines connected to the fan motor, loosen the screws of the bracket that
holds the fan motor.
• Replace a new one, If you only need to replace the fan blade, loosen the screws holding the fan blade,
take out the damaged fan blade, replace with a new one.
• Reverse the above steps to reassemble.
Replace the hot gas valve, drier and evaporator
• Remove the rear cover.
• Locate the drier and hot gas valve, add low side access valve, recover refrigerant, replace the drier and hot
gas valve, evacuate and weigh in the nameplate charge.
• Reverse the above steps to reassemble.
• If you need to replace the evaporator.
• Remove the rear, locate the evaporator, add the low side access valve, open the process/suction, weld
open the two welds, replace a new one. Recover refrigerant, evacuate and weigh in the nameplate charge.
• Reverse the above steps to reassemble.
BEFORE MAINTENANCE
• Make sure the user uses a 115 VAC, 60Hz. only 15amp electrical supply, and make sure that it is properly
grounded to protect the maintainer against electrical shock.
• Check out if the leads loose? Turn off? Short circuit? If you have such problems, foreclose in turn.
ELECTRICAL SHOCK HAZARD
Turn the unit off and unplug it before
beginning to remove any parts.

12
Troubleshooting
BEFORE MAINTENANCE
• Make sure the user uses a 115 VAC, 60Hz. only 15amp electrical supply, and make sure that it is properly
grounded to protect the maintainer against electrical shock.
• Check out if the leads loose? Turn off? Short circuit? If you have such problems, foreclose in turn.
BASIC CHECKING
If the icemaker has some trouble through the basic checking. The service technician must then check it
thoroughly, then maintain accordingly.
HEARING CHECK
• Listen for the user’s depiction about the icemaker during a test run. Try to understand what is the defect
and how did the user operate the icemaker before calling for service.
• Is the running sound is normal?
VISUAL CHECK
• Check the pipe of cooling system, especially the welding points. If there is some oil, the gas is leaking out
so that no ice making or less ice is produced.
• If the cycle of the ice making and harvest is normal?
• Check the water system, especially the connections. If there is some water leaking?
• Check if the water lter needs to be replaced.
• Check if the icemaker is installed according to the user manual.
• Check if the icemaker needs to be cleaned.
PHYSICAL CHECK
• Touch the hot gas pipe (with the evaporation weld), feeling the temperature. At the ice making stage it
should feel cool. At the ice harvest stage it should feel hot.
• Touch the capillary tube (the drier nearby), does it feel lukewarm?
TROUBLESHOOTING GUIDE
This troubleshooting guide in the user manual should be read before attempting any service. Be sure to turn to
this guide only when the trouble shooting in user manual can’t help you solve the problem.

13
Troubleshooting
THE MACHINE DOES NOT MAKE ICE
Problem Check part or point Possible Cause Probable Correction
The machine doesn’t
operate
Plug The icemaker is
unplugged.
Plug the icemaker in.
Socket Socket is damaged Check and replace.
Power switch The icemaker power
button is set at OFF.
Switch the icemaker
power button to ON.
Fuse The fuse is blown. Replace fuse.
Wiring connection Some wiring connection
is incorrect or loose.
Check and re-connect.
Voltage The voltage of the power
supply is low.
Add manostat.
Ice full probe The ice full probe is not
working.
Replace with a new one.
Ice full probe The ice full probe is
covered by something.
Clear the probe and
make the ice-full probe is
free of obstructions.
Wiring Some wiring is damaged. Replace with a new one.
Electric component Some electrical
component has failed.
Find the controller,
press the mode button
to change the mode. It
is helpful to judge which
part is out of function.
Controller The controller has failed. Replace with a new one.

14
Troubleshooting
Water System Water supply tap The water supply tap is
turned off.
Turn on the water supply
tap.
Water supply pipe The water supply pipe is
not properly connected or
may be kinked.
Reconnect the water
supply pipe.
Water line The water line leaks. Plug in again.
The water line is blocked. Clean it, see user manual
“ice making system
cleaning”
Water supply pressure is
low.
Adjust the water supply
pressure within the stated
range.
Water inlet The water inlet is blocked. Check and clear it
Water pump Water pump damaged. Replace water pump.
The room temperature is
out of the stated range,
the water pump stops
automatically.
Make the temperature
return within the stated
range.
The lines of the water
pump are loose.
Plug in again.
The housing of water
pump leaks.
Replace water pump.
Drainage tray on top of
the compressor
Drainage tray on top of
the compressor is full.
Drain off water by
unscrewing lower
drainage nut.
The compressor doesn’t
start
Wiring connects It’s loose. Plug tightly, or replace.
The start relay/thermal
protect
It’s damaged. Replace the start relay/
thermal protect of the
compressor.
The startup coil / running
coil
It’s turned off. Replace the compressor.
The motor of the
compressor has short
circuited.
Replace the compressor.
Condenser The condenser may be
dirty.
Clean the condenser.
Fan The fan may be dirty or
damaged
Clean or Replace the fan.
The Electronic controller The controller is damaged Replace the Electronic
controller.

15
Troubleshooting
The compressor runs but
makes no ice
Refrigerant Refrigerant leaks
completely.
Add low side access
valve, locate leak, recover
refrigerant, replace drier,
evacuate and weigh in
the data plate charge.
Capillary tube Capillary tube is blocked. Add low side access
valve, recover refrigerant,
replace hot gas valve,
replace drier, evacuate
and weigh in the
nameplate charge.
Vent The vent is obstructed
around the ice machine.
Clean the vent.
Hot gas valve Hot gas valve is
damaged.
Replace.
The Electronic controller The mode of making ice
doesn’t turn to harvest.
Replace the Electronic
controller.
The unit is working in the
cold preservation stage
mode.
Work in normal mode.
LOW PRODUCTION
Problem Check part or point Possible Cause Probable Correction
Cooling System Refrigerant Refrigerant leaks partially. Recharge.
Condenser The condenser may be
dirty.
Clean the condenser.
The ambient temperature The ambient temperature
is too high or too low.
Check the ambient and
air ow.
Fan The fan is dirty or
damaged.
Clean or replace.
Hot gas valve Hot gas valve
performance is poor, little
ice is produced.
Replace the hot gas
valve.
Electronic controller The setting temperature
of Electronic controller is
low.
See the service manual
"adjust the size of ice
cubes".
Sensor The sensor of
temperature is damaged
Replace the temperature
sensor.

16
Troubleshooting
Water System Water distribution tube The water distribution
tube is blocked.
Clean the water
distribution tube.
Water line The water quality is too
poor. The water line is
blocked.
Use a lter apparatus
installed in front of the
water inlet valve.
Silica gel tubes The silica gel tubes
are distorted, leads to
blocking.
Make the silica gel tubes
resile.
Floater valve The oater valve
leaks. Leads to low ice
production.
Repair or replace.
Wheel The icemaker is not
properly leveled.
See installation.
ICE CUBES ARE NOT SATISFACTORY
Problem Check part or point Possible Cause Probable Correction
Cubes are too small Condenser The condenser is dirty or
the air grills are covered.
Clean the condenser.
Leave space around the
machine.
The ambient temperature The ambient temperature
is too high.
Adjust the ambient
temperature.
Electronic controller The setting temperature
is high.
See the service manual
"adjust the size of ice
cubes".
Refrigerant Refrigerant leaks. Recharge.
Cubes are too big Electronic controller The setting temperature
of Electronic controller is
low.
See the service manual
"adjust the size of ice
cubes".
Sensor Temperature sensor
of the evaporator is
damaged.
Replace the temperature
sensor.
The ambient and water
temperature
The ambient temperature
and water temperature
are too low.
Adjust the temperature.

17
Troubleshooting
The cubes are partially
formed--have ragged
sides
Water quality The water quality is poor. Use a water-soften / lter
apparatus installed in
front of the water inlet
valve.
Evaporator Ice machine is dirty. Clean and sanitize the ice
machine.
Water distribution tube The water distribution
tube is partially blocked.
Clean the water
distribution tube.
The room temperature The room temperature is
out of the stated range,
the water pump stops.
Make the temperature
return within the stated
range.
The ice cubes have
shape deformities
Filter Water ltration element
needs to be changed.
Replace the lter.
Water trough Water trough level is too
low.
Adjust the water oater.
Cubes are partially
formed—are white at the
bottom
The room temperature The room temperature
is out the stated range,
the water pump stops
automatically.
Make the temperature
return within the stated
range.
Water trough Water trough level is too
low.
Adjust the water oater.
OTHER PROBLEMS
Problem Check part or point Possible Cause Probable Correction
The body is electried Ground line The ground line isn't in
the socket.
Please use the socket
meeting the standard.
Lines The lines are not
insulated.
Adjust, reconnect /
replace lines
Electric component The electric component is
not insulated.
Replace this electric
component.
Scales occur frequently
inside the machine
The water quality The rigidity of the water
quality is too high.
Use a water-soften
apparatus installed in
front of the water inlet.

18
Troubleshooting
Loud noise during
operation
Spring of the internal
compressor
The spring of the internal
compressor drops.
Replace the compressor.
Water pump The noise of the water
pump
Replace the water pump.
Pipeline system Pipeline system resonate Clear pipeline system
Feet The feet are not leveled Level and lock the feet.
Fan motor The fan motor is loose,
the clearance of the rotor
is bigger, the fan blade
turns back
Relocate the fan motor /
replace
Water is leaking out of the
unit
The operation Some water drops to the
oor when you open the
door to take out ice from
ice storage bin.
Normal condensation on
the door or some water
from the ice. Take care
when you take out ice.
Water supply connection Water supply connection
is leaking.
Tighten the tting.
Drainage tray on top of
the compressor
Water full probe is out of
function
Replace with a new one.
Water line The water line leaks. Plug in again.
The water distribution
tube doesn’t spray
Lines of the water pump The lines of the water
pump are loose.
Plug in again.
Water pump Water pump is damaged. Replace the water pump.
Water distribution tube The water distribution
tube is blocked.
Clean the water
distribution tube.
Ice full probe The ice full probe is
broken or can not turn
back to the normal
position.
Repair or replace the
probe.
The room temperature The room temperature is
out of the stated range,
the water pump stops.
Make the temperature
returns within the stated
range.

19
Troubleshooting
Harvesting ice is difcult Hot gas valve The hot gas valve is poor. Replace the hot gas
valve.
The hot gas valve is
damaged.
Replace the hot gas
valve.
Ice mold of the
evaporator
The ice mold is dirty, or
polishing degree is poor.
Clean the ice mold, or
replace the evaporator.
Refrigerant Refrigerant leaks. Recharge.
Ice machine Ice machine is not
properly leveled.
Level the ice machine.
The ambient and water
temperature
The ambient and water
temperature is too low.
Adjust the temperature.
Ice cubes size The size is too big. See “Adjust the ice cube
size”.
The evaporator is hot for
more than 4 minutes
Hot gas valve The lines of the hot gas
valve are loose.
Plug in again.
Hot gas valve
performance poor or
broken.
Replace the coil of the
hot gas valve if it is only
because of the coil.
Refrigerant Refrigerant leaks. Recharge.
Electric controller The electric controller is
incorrect.
Check the controller.
REFERENCE
Item Number Model Number Description Manufacturer Model Number
37864 IC-CN-0012 Ice Maker 27 lbs. / 12 kgs. Capacity
115V/60/1 UL cUL AZ-20B

20
Parts Breakdown
Model IC-CN-0012 37864
