U-Line CLR6O Building instructions

SERVICE AND PARTS
MANUAL
For Product ManufacturedWith
HFC-134A Freon
CLRGO Clear Ice Maker
U-Line Corporation
U-Line Corporation U-LineCorporation
8900 North55th Street PO Box 245040
Milwaukee,WI 53223 Milwaukee,
WI 53224-9540
www.u-line.com
Phone [phone] FAX [phone]
Service
& PartsTech Lines Phone[phone] FAX [phone]
*@.@@ d

U-LINE
SERVICE AND PARTS
MANUAL
For Product ManufacturedWith
HFC-134A Freon
CLR6O Clear Ice Maker
U-Line Corporation
U-Line Corporation U-LineCorporation
8900 North 55th Street PO Box 245040
Milwaukee, WI 53223 Milwaukee, WI 53224-9540
www.u-line.com
Phone [phone] FAX [phone]
Service
& PartsTech Lines Phone[phone] FAX [phone]
g$&~@~@@

fenrice and ?arts Manual

Three generations of pride in quality manufacturing and design improvements are built
into all U-Line products.
We are proud and excited to announce the latest edition to the U-Line family of products,
the CLRGO, a Gopound clear ice maker. We have been developing this product for over
two years and are excited about the quality and features which are unmatched by any
other model in its class. In addition to producing more ice than all other models in its
class, the U-Line CLRGO offers new, patented technology. We have reduced water con-
sumption by 50%per pound of ice compared to some other models on the market. The
CLRGO hasthe easiest self cleaning process of any model in its class. All clear ice mak-
ers require periodic cleaning due to minerals in the water. We have simplifiedthis
processthrough our electronic control which means ease and convenience for our cus-
tomers. This model also uses a commercial-grade water circulation pump which is per-
manently sealed and lubricated, this pump increases the life and performance of the ice
maker. This pump requires no maintenance.
Finally, we have developed an exclusive drain pump for those installations in which a floor
drain is not available. The U-Line P60pump is a fully submersible, self lubricating pump
that requires no maintenance. Itis sealed to prevent water overflow in the event of a
power failure or drain line restriction and is fully integrated intothe automatic shut off
feature of the CLRGO with a "quick connect" plug right into the power cord. The P60
pump isavailable only through U-Line or our Distributors and Dealers.
This service manual contains specific instructions for servicing U-Line's newest model the
CLRGO
- Clear Ice Maker.

Service and Parts Manual

Introduction .................................................... 3
Limited Warranty
................................................ 7
Warranty Claims Procedure
......................................... 8
...............................................
Safety Precautions 9
Leveling and Installation Requirements ................................ 10
Leveling the Unit
............................................ 10
Installation Requirements
...................................... 10
.......................................... Gravity Drain Installation 11
Connecting a Drain Pump
......................................... 12
Automatic Clean Cycle Instructions
................................... 13
Automatic Clean Cycle
........................................ 13
Interior Storage Bin Cleaning
................................... 13
U-Line CLR Sequence of Operation
................................... 14
Automatic Shut-off
.......................................... 14
Thermistor ................................................... 16
Check Procedure w/LED Light on Control Board
...................... 16
Low Side Pressure Changes
.................................... 17
ElectricalSpecifications
........................................... 18
Compressor Pins
........................................... 18
Refrigeration System Diagnosis Guide
............................. 19
Ice Thickness Adjustment ......................................... 20
Ice Production Rates
............................................ 21
Troubleshooting ................................................ 22
Wiring Diagrams ............................................... 26
Parts Listing
.................................................. 27
CLR6O . Clear Ice Maker Assembly Parts Breakdown ............... .2 7.29
Howto Order Replacement Parts
............................... -30
Fax PartsOrder Form ........................................ 31
