Ice Shaver

Model IC-CN-1450-E

Item 47468

Instruction Manual

2

Page

--------------------------------------------------------------------------- 3 - 4

--------------------------------------------------------------------------- 4 - 6

-------------------------------------------------------------------------- 6

--------------------------------------------------------------------------------------- 6 - 7

----------------------------------------------------------------------------------------- 7 - 8

----------------------------------------------------------------------------------------- 8

------------------------------------------------------------------------------------- 8

----------------------------------------------------------------------------- 9 - 10

---------------------------------------------------------------------------- 11

------------------------------------------------------------------------------------------- 12 - 14

---------------------------------------------------------------------------- 15

Table of Contents

Section

General Information

Safety and Warranty

Technical Specications

Installation

Operation

Maintenance

Troubleshooting

Parts Breakdown

Electrical Schematics

Notes

Warranty Registration

Model IC-CN-1450-E

3

General Information

Omcan Manufacturing and Distributing Company Inc., Food Machinery of America, Inc. dba Omcan

and Omcan Inc. are not responsible for any harm or injury caused due to any person’s improper or

negligent use of this equipment. The product shall only be operated by someone over the age of 18, of

sound mind, and not under the inuence of any drugs or alcohol, who has been trained in the correct

operation of this machine, and is wearing authorized, proper safety clothing. Any modication to the

machine voids any warranty, and may cause harm to individuals using the machine or in the vicinity of

the machine while in operation.

CHECK PACKAGE UPON ARRIVAL

Upon receipt of an Omcan shipment please inspect for external damage. If no damage is evident on the

external packaging, open carton to ensure all ordered items are within the box, and there is no concealed

damage to the machine. If the package has su󰀨ered rough handling, bumps or damage (visible or concealed),

please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may

initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be

lled out within three days, from the delivery date shown in the shipping documents. Omcan has no recourse

for damaged products that were shipped collect or third party.

Before operating any equipment, always read and familiarize yourself with all operation and safety

instructions.

Omcan would like to thank you for purchasing this machine. It’s of the utmost importance to save

these instructions for future reference. Also save the original box and packaging for shipping the

equipment if servicing or returning of the machine is required.

---------------------------------------------------------------------------------------------------------------------------------------------------

Omcan Fabrication et distribution Companie Limité et Food Machinery d’Amerique, dba Omcan et

Omcan Inc. ne sont pas responsables de tout dommage ou blessure causé du fait que toute personne

ait utilisé cet équipement de façon irrégulière. Le produit ne doit être exploité que par quelqu’un de

plus de 18 ans, saine d’esprit, et pas sous l’inuence d’une drogue ou d’acohol, qui a été formé pour

utiliser cette machine correctement, et est vêtu de vêtements de sécurité approprié. Toute modication

de la machine annule toute garantie, et peut causer un préjudice à des personnes utilisant la machine

ou des personnes à proximité de la machine pendant son fonctionnement.

VÉRIFIEZ LE COLIS DÈS RÉCEPTION

Dès réception d’une expédition d’Omcan veuillez inspecter pour dommages externes. Si aucun dommage

n’est visible sur l’emballage externe, ouvrez le carton an de s’assurer que tous les éléments commandés

sont dans la boîte, et il n’y a aucun dommage dissimulé à la machine. Si le colis n’a subi aucune mauvaises

manipulations, de bosses ou de dommages (visible ou cachée), notez-le sur le bond de livraison avant

d’accepter la livraison et contactez Omcan dans les 24 heures qui suivent, pour que nous puissions engager

une réclamation auprès du transporteur. Un rapport détaillé sur l’étendue des dommages causés à la machine

doit être rempli dans un délai de trois jours, à compter de la date de livraison indiquée dans les documents

d’expédition. Omcan n’a aucun droit de recours pour les produits endommagés qui ont été expédiées ou cueilli

par un tiers transporteur.

4

Safety and Warranty

General Information

When using electrical appliances, basic safety precautions should be followed to reduce the risk of re, electric

shock and injury to persons or property. Read all instructions before operating the machine for the rst time.

1. To prevent personal injury or properly damage read and follow all instructions and warnings.

2. When using electrical appliances, basic safety precautions should always be followed.

3. To protect against re, electric shock, and injury to persons, do not immerse cord, plugs, or other electric

parts in water or other liquids.

Avant d’utiliser n’importe quel équipement, toujours lire et vous familiariser avec toutes les opérations

et les consignes de sécurité.

Omcan voudrais vous remercier d’avoir choisi cette machine. Il est primordial de conserver ces

instructions pour une référence ultérieure. Également conservez la boîte originale et l’emballage pour

l’expédition de l’équipement si l’entretien ou le retour de la machine est nécessaire.

---------------------------------------------------------------------------------------------------------------------------------------------------

Omcan Empresa De Fabricacion Y Distribucion Inc. Y Maquinaria De Alimentos De America, Inc. dba

Omcan y Omcan Inc. no son responsables de ningun daño o perjuicío causado por cualquier persona

inadecuada o el uso descuidado de este equipo. El producto solo podra ser operado por una persona

mayor de 18 años, en su sano juicio y no bajo alguna inuencia de droga o alcohol, y que este ha sido

entrenado en el correcto funcionamiento de esta máquina, y ésta usando ropa apropiada y autorizada.

Cualquier modicación a la máquina anúla la garantía y puede causar daños a las personas usando la

máquina mientras esta en el funcionamiento.

REVISE EL PAQUETE A SU LLEGADA

Tras la recepcion de un envio Omcan favor inspeccionar daños externos. Si no hay daños evidentes en el

empaque exterior, Habra el carton para asegurararse que todos los articulos solicitados ésten dentro de la

caja y no encuentre daños ocultos en la máquina. Si el paquete ha sufrido un manejo de poco cuidado, golpes

o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro

de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. Un informe detallado sobre

los daños causados a la máquina debe ser llenado en el plazo de tres días, desde la fecha de entrega que se

muestra en los documentos de envío. Omcan no tiene ningun recurso por productos dañados que se enviaron

a recoger por terceros.

Antes de utilizar cualquier equipo, siempre lea y familiarizarse con todas las instrucciones de

funcionamiento y seguridad.

Omcan le gustaría darle las gracias por la compra de esta máquina. Es de la mayor importancia para

salvar estas instrucciones para futuras consultas. Además, guarda la caja original y el embalaje para el

envío del equipo si servicio técnico o devolución de la máquina que se requiere.

5

Safety and Warranty

4. Close supervision is necessary when this appliance is used by or near children.

5. Always unplug from socket when not in use and before cleaning.

6. Do not operate any appliance with a damaged cord or plug, after the appliance malfunctions, or has been

damaged in any manner.

7. The use of accessory attachments is not recommended, may cause re, electric shock, or injury.

8. Do not use the appliance outdoors.

9. Do not let cord hang over the edge of a table or counter, or touch hot surface.

10. Do not place on or near a hot has or electric burner, or in a heated oven.

11. Always remove from wall socket by pulling on plug, never pull on cord to avoid rise of fraying or splitting

cord.

12. Do not use appliance in any way other than its intended use. Do not attempt to repair this appliance

yourself.

13. A short power-supply cord is provided to reduce risks of becoming entangled in or tripping over a longer

cord.

14. Do not use an socket or extension cord if the plug ts loosely or if the outlet or extension cord feels hot.

15. Avoid contact with moving parts.

16. Blade is sharp, use extreme caution during assembly, while operating, disassembly and cleaning.

17. Do not use if blade is broken, cracked or loose.

18. Do not leave appliance unattended while it is operating.

19. Do not run this appliance continuously for move than 5 minutes as overheating may occur. Allow motor to

cool down before repeat usage.

20. Do not run machine without ice in the hopper as damage to appliance may occur.

21. Never place ngers or utensils into the feed or discharge areas to reduce the risk of severe injury to

persons or damage to the crusher.

22. Children should be supervised to ensure that they do not play with the appliance.

23. This appliance is not intended for use by persons (including children) with reduced physical, sensory or

mental capabilities, or lack of experience and knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a person responsible for their safety.

24. The ice crusher is commercial machine which is intended to be used in sta󰀨 kitchen areas in shops, o󰀩ces

and other working environments.

25. Warning: Don’t use your ice crusher outdoors. Avoid direct sunlight and make sure that there is at least

15cm of space between the back and sides of your unit and the wall.

26. Do not tip the machine over.

27. The blade must be replaced by original blade.

NOTE: strongly recommend to repair the machine by professional technician.

Warning: The blade is very sharp, operate with care.

RESIDENTIAL USERS: Vendor assumes no liability for parts or labor coverage for component failure

or other damages resulting from installation in non-commercial or residential applications. The right

is reserved to deny shipment for residential usage; if this occurs, you will be notied as soon as

possible.

1 YEAR PARTS AND LABOUR BENCH WARRANTY

6

Technical Specications

Installation

Model IC-CN-1450-E

Ice Crushing Capacity per Hour 176.4 lbs. / 80 kgs.

Electrical 110V / 60Hz / 1

Power 300 W / 0.4 HP

Number of Blades 2

Rotate Speed 1450 RPM

Dimensions 8.3" x 15.7" x 11.8" / 210 x 400 x 300mm

Packaging Dimensions 17.7" x 16.7" x 25.2" / 450 x 425 x 640mm

Item Number 47468

UNPACK THE MACHINE

Remove all exterior and interior packaging materials. Check that the ice tray and instruction manual are

included. If any parts are missing, please contact our customer service.

Safety and Warranty

Within the warranty period, contact Omcan Inc. At 1-800-465-0234 to schedule a drop o󰀨 to either

an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the

equipment.

Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not

improper use.

Please see https://omcan.com/disclaimer for complete info.

WARNING:

The packaging components are classied as normal solid urban waste and can therefore be disposed of

without di󰀩culty.

In any case, for suitable recycling, we suggest disposing of the products separately (di󰀨erentiated

waste) according to the current norms.

DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!

7

Installation

Operation

Warning: Keep children away from the foam and other package materials, which is dangerous.

1. Find a location for your ice crusher where it’s protected from direct sunlight and other sources of heat (i.e.

stove, furnace, radiator). Place the ice crusher on a level surface. Make sure that there is at least 15cm

of space between the back and sides of your ice crusher and the wall. Don’t place anything on your ice

crusher.

2. The appliance must be positioned where the plug is accessible.

NOTE: Improper installation may cause injury to people or objects.

1. The socket must be grounded.

2. The fuse on the PCB must be >10A.

3. If the power cord need to be changed, it must be changed by a certied technician.

4. Voltage uctuation can’t exceed ±10% than the rated voltage, or a voltage stabilizer is needed.

Clean the interior with lukewarm water and a soft cloth, the blade is very SHARP, operate with care. Don’t pour

water directly in the hopper to clean which will damage the motor. Unplug the ice crusher before cleaning.

The use of any appliance must follow basic guidelines, in particular:

• High humidity environment will increase the risk of short circuit or electric shock. If in doubt, cut o󰀨 the

power of the ice crusher.

• Please do not directly pull down the power cord to turn o󰀨 the machine, turn o󰀨 the machine by the switch.

• The ice crusher cannot be used by children without adult supervision.

OPERATION

• The ice crusher is only used to crush ice, it can’t be used for other purposes.

• Operate the machine by following the steps as below.

1. Lift the hopper lid’s handle before plugging in. Make sure your socket is suitable for the ice crusher and the

ground wire is reliable. The machine operates 110V and 120V. Place the ice tray under the outlet to catch

the crushed ice.

2. Pour ice cubes in hopper. Do not allow ice cubes to protrude from the hopper’s rim.

3. Flip power switch on.

4. Use constant pressure to press the ice cubes into the hopper with the lid’s handle for the blade to begin

crushing ice. Lift the hopper lid once the ice cubes are nished.

5. Turn o󰀨 the switch and unplug the ice crusher.

6. Wipe the ice crusher dry for your next use to prevent any contamination during storage. Store in a dry

place.

8

Operation

Maintenance

Troubleshooting

PREPARING THE ICE CRUSHER FOR LONG-TERM STORAGE

• Turn o󰀨 the machine, unplug the power cord, wipe o󰀨 the water on the power cord, and gather the power

cord up.

• Wipe the surface of the machine and the outer surface of the hopper, and open the handle upwards, which

is conducive to the internal moisture distribution.

• Keep the machine in a safe place and keep it out of reach of children.

CLEANING OF INTERNAL AND EXTERNAL PARTS

Note: Unplug the power plug before performing any cleaning or maintenance procedures. Do not use

alcohol to clean the ice crusher, as this may cause plastic parts to crack.

EXTERIOR

Use a clean, soft cloth to wipe the outside of the ice machine at least once a week, and then use a damp cloth

moistened with a neutral detergent to remove grease or other impurities.

ICE TRAY (AFTER EACH USE)

Immerse the ice tray in a mixture of neutral detergent and water for at least 3 minutes, then rinse with water

and dry.

HOPPER (AFTER EACH USE)

Open the handle, allow it to dry naturally, and then close it after drying. There is a sharp blade inside, operate

with care.

Issues Check items Possible causes Solutions

Does not work. Power cord. Did not plug in or damaged. Plug in or replace the power cord.

Socket. Socket is out of shape. Change to another socket.

Motor. Motor burnt. Replace the motor.

Power supply. Power switch damaged. Replace the switch.

Low voltage or no power. Contact power supply department.

Micro switch. Micro switch damaged. Replace the micro switch.

9

Parts Breakdown

Model IC-CN-1450-E 47468

10

Parts Breakdown

Item No. Description Position Item No. Description Position Item No. Description Position

AL659 Handle Sleeve for 47468 1 AL671 Switch Cover for 47468 10 AL680 Power Cord for 47468 19

AL660 Handle for 47468 2 AL672 Screw for 47468 11 AL681 Power Switch for 47468 20

AL664 Dowel for 47468 3 AL673 Blade for 47468 12 AL682 Electric Capacity for 47468 21

AL665 Hexagon Screw for 47468 4 AL674 Rotary Component for 47468 13 AL683 Motor for 47468 22

AL666 Pressure Spring for 47468 5 AL675 Hexagon Screw for 47468 14 AL684 Baseplate for 47468 23

AL667 Hopper for 47468 6 AL676 Screw for 47468 15 AL685 Ice Tray for 47468 24

AL668 Torsional Spring for 47468 7 AL677 Connection Component for 47468 16 AL686 Screw for 47468 25

AL669 Step Screw for 47468 8 AL678 Housing for 47468 17 AL687 Rubber Feet for 47468 26

AL670 Safety Switch for 47468 9 AL679 Nut for 47468 18 AL688 Screw for 47468 27

Model IC-CN-1450-E 47468

11

Electrical Schematics

Model IC-CN-1450-E 47468

12

Notes

________________________________________________________________________________________

13

Notes

________________________________________________________________________________________

14

Notes

________________________________________________________________________________________

15

Warranty Registration

Gracias por comprar un producto Omcan usted. Para registrar su garantía para este producto, complete la información a continuación,

cortar la tarjeta en la perforación y luego enviarlo a la dirección indicada a continuación. También puede registrarse en línea en:

Merci d’avoir acheté un produit Omcan. Pour enregistrer votre garantie pour ce produit, complétez les informations ci-dessous, détachez la

carte au niveau de la perforation, puis l’envoyer à l’adresse spécié ci-dessous. Vous pouvez également vous inscrire en ligne en visitant:

Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear o󰀨 the card at

the perforation and then send to the address specied below. You can also register online by visiting:

OMCAN

PRODUCT WARRANTY REGISTRATION

3115 Pepper Mill Court,

Mississauga, Ontario

Canada, L5L 4X5

https://omcan.com/warranty-registration/

or email to: [email protected]

Purchaser’s Information

Name: Company Name:

Address:

Telephone:

City: Province or State: Postal or Zip: Email Address:

Country: Type of Company:

Restaurant Bakery Deli

Dealer from which Purchased: Butcher Supermarket Caterer

Dealer City: Dealer Province or State: Institution (specify):

Invoice: Other (specify):

Model Name: Model Number: Serial Number:

Machine Description:

Date of Purchase (MM/DD/YYYY): Date of Installation (MM/DD/YYYY):

Would you like to extend the warranty? Yes No



Por correo en Canadá

Pour postale au Canada

For mailing in Canada

Por correo en los EE.UU.

Pour di󰀨usion aux États-Unis

For mailing in the US

OMCAN

PRODUCT WARRANTY REGISTRATION

4450 Witmer Industrial Estates, Unit 4,

Niagara Falls, New York

USA, 14305

Thank you for choosing Omcan | Merci d’avoir choisi Omcan | Gracias por elegir Omcan

Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North

American food service industry. Our success over these many years can be attributed to our commitment

to strengthen and develop new and existing relationships with our valued customers and manufacturers.

Today with partners in North America, Europe, Asia and South America, we continually work to improve

and grow the company. We strive to offer customers exceptional value through our qualied local sales

and service representatives who provide convenient access to over 6,500 globally sourced products.

Depuis 1951 Omcan a grandi pour devenir un des “leaders” de la distribution des équipements et

matériel pour l’industrie des services alimentaires en Amérique du Nord. Notre succès au cours de ces

nombreuses années peut être attribué à notre engagement à renforcer et à développer de nouvelles

et existantes relations avec nos clients et les fabricants de valeur. Aujourd’hui avec des partenaires en

Amérique du Nord, Europe, Asie et Amérique du Sud, nous travaillons continuellement à améliorer et

développer l’entreprise. Nous nous efforçons d’offrir à nos clients une valeur exceptionnelle grâce à

nos ventes locales qualiées et des représentants de service qui offrent un accès facile à plus de 6500

produits provenant du monde entier.

Desde 1951 Omcan ha crecido hasta convertirse en un líder en la distribución de equipos y suministros

de alimentos en América del Norte industria de servicios. Nuestro éxito en estos años se puede atribuir

a nuestro compromiso de fortalecer y desarrollar nuevas relaciones existentes con nuestros valiosos

clientes y fabricantes. Hoy con socios de América del Norte, Europa, Asia y América del Sur, que trabajan

continuamente para mejorar y crecer la empresa. Nos esforzamos por ofrecer a nuestros clientes valor

excepcional a través de nuestro local de ventas y representantes de los servicios que proporcionan un

fácil acceso a más de 6,500 productos con origen a nivel mundial.

Omcan IC-CN-1450-E User manual

Popular Ice Maker manuals by other brands
