OMEGA AIR TD 420M User manual

Installation and operating
manual
Please read the following instructions carefully before installing the product. Trouble free and
safe operating of the product can only be guaranteed if recommendations and conditions stated
in this manual are respected.
TD 420M
230V / 24Vdc

2
Table of content
1. Components .................................................................................................................................... 3
2. Technical data.................................................................................................................................. 4
2.1 Technical specification ............................................................................................................ 4
2.2 Parts list and dimensions......................................................................................................... 4
2.3 Materials.................................................................................................................................. 4
2.4 Admissable fluids..................................................................................................................... 5
2.5 Types........................................................................................................................................ 5
2.6 Order number.......................................................................................................................... 5
3. Safety instructions........................................................................................................................... 6
3.1 Hazardes classes...................................................................................................................... 6
3.2 Structure of the warning ......................................................................................................... 6
4. Appropriate use............................................................................................................................... 7
5. Installation....................................................................................................................................... 7
6. Storage information ........................................................................................................................ 9
7. Operation ...................................................................................................................................... 10
7.1 Inlet valve .............................................................................................................................. 11
7.2 Approximate calculation of discharge capacity..................................................................... 11
7.3 Troubleshooting .................................................................................................................... 12
8. Maintenance.................................................................................................................................. 12
9. Warranty exclusion........................................................................................................................ 12
10. Disposing ................................................................................................................................... 13

3
1. Components
1
Nipple
2
High pressure needle valve
3
Elbow
4
Electromagnetic valve
5
Connector gasket
6
Timer

4
2. Technical data
2.1Technical specification
Operating temperature
1,5 - 150 °C
35 - 302 °F
Ambient temperature
1,5 - 65 °C
35 - 149 °F
Operating pressure (4)
0 - 420 bar(g)
0 –6091 psi
Protection class
IP65
Supply voltage
230V (±10%), AC, 50/60Hz
Coil power
8W
Cable dimensions
3 x 0,75mm2
Mass (timer + valve)
0,35kg
Mass (fittings + needle valve)
0,23kg
Valve
Direct acting solenoid valve, 2/2, Normally closed
Connector
DIN EN 175301-803 form A
Time ON
0,5s - 10s
Time OFF
0,5min - 45min
Indicator
LED light
(3)Standard version (TD420M 230V AC)
(4) Version TD420M 24V DC only up to a pressure 400 bar(g) (5800 psi)
2.2Parts list and dimensions
(5) Version TD420M 115V AC have on housing of
electromagnetic valve a NPT 1/4’’ female thread.
*(5)
2.3Materials
Controller housing
PA6 GF30
Screws
Steel-zinc plated
Coil
Epoxi coated
Valves
Stainless steel 1.4305
Valve sealing
PEEK
Fittings
Stainless steel 1.4571
Internal strainer mesh
Stainless steel
A
Nipple
B
Needle valve
C
Elbow
D
Electromagnetic valve
E
Timer

5
2.4Admissable fluids
Fluid group 2: Air, N2, He, Heliox (up to 21% oxygen), Ar
and mixtures of these gases
(1) For any other technical gas please contact us or your local dealer
2.5Types
Type
Voltage
Power
MAX. Pressure
[barg]/[psig]
Medium
Flow coefficient
Kvs [l/min]
TD420M 230V AC
230V AC 50/60Hz
8W
420 / 6091
Air, water, oil
0.3
TD420M 115V AC
115V AC 50/60Hz
16W
420 / 6091
Air, water, oil
0.3
TD420M 24V DC(5)
24V DC
18W
400 / 5800
Air, water, oil
0.3
(5) Version TD420M 115V AC have on housing of electromagnetic valve a NPT 1/4’’ female thread.
2.6Order number
TYPE
ORDER NUMBER
OMEGA AIR
ORDER NUMBER
BAUER
TD 420M (230V)
3402211
N45147
TD 420M (115V)
3403494
N45148
TD 420M (24Vdc)
3402212
N44102
There is Technical datasheet available. For additional technical specification, contact manufacturer.

6
3. Safety instructions
Depressurize the system before carrying out any work on the piping.
Installation and maintenance work may only be carried out when the device is not under
pressure.
Installation and maintenance work may only be carried out by trained and experienced
personnel.
Installation and maintenance work may only be carried out when electrical power supply is
disconnected.
Electrical work must always be carried out by qualified electrician.
Do not exceed maximal operating pressure or operating temperature range (see data label).
Do not use the device in hazardous areas with potentially explosive atmospheres.
Use original spare parts only.
Use the device for the appropriate purpose only.
3.1Hazardes classes
Important instructions regarding personal protection and safe operation are indicated in the manual
in distinct hazard classes. The hazard classes explain how states or individual steps of an operation
sequence are dangerous and can cause damage.
Hazard class
Description
DANGER
Indication of an immediate imminent danger. If the warning is not observed, this
will result in death or serious injuries.
WARMING
Indication of a potentially dangerous situation. If the warning is not observed, this
can result in death or serious injuries.
CAUTION
Indication of a potentially dangerous situation. If the warning is not observed, this
can result in minor injuries.
NOTICE
Indicate of a potentially dangerous situation. If the waning is not observed, this can
result in material damage.
3.2Structure of the warning
The warnings describe the type and source of danger, the consequences of not heeding these
warnings, and measures to be taken to avert danger. A warning is always structured according to the
following pattern:
Type and source of danger.
Consequences of not heeding the warning.
Measures for averting the danger.

7
4. Appropriate use
TD420M series condensate drain is intended exclusively for the following purpose:
Draining condensate from compressed air system (air compressors, air receivers/pressure
vessels, air dryers and air filters).
Any other form of use or one going beyond this shall be considered as inappropriate. We shall have
no liability whatsoever for any damage incurred as a result.
5. Installation
Warning due to a sudden release of pressure!
High pressure could be dangerous and hazardous to the operator.
Before installing the device, check that the system is not under
pressure. Wear necessary personal protective equipment and keep
follow the safety rules when working with pressure equipment.
Condensate drainer can be assembled in many
ways. However, you must follow the arrows on
valves from inlet pointing to the outlet. You have
to screw the parts together. The bottle in the
picture left indicates where you have to use the
seal, such as Loctite 542. On other joints you can
also use a seal, although friction sealing will be
enough (well tighten the joints).
1)
2)
Maximum torque for
tightening screws

8
Connecting several condensate collecting points to one condensate drain device causes operating
problems (1). Make sure that each condensate collecting point has its own condensate drain (2).
After installation or maintenance, the test button should be pressed to empty condensate that has
been collected while the ball valve has been closed.
5.1Installation instructions
When you install device follow this instructions.
1. First step is to connect a nipple (1) and high-pressure valve (2). For sealing you can use a
seal, such as Loctite 542. You must follow the arrows on valves from inlet pointing to the
outlet.
2. Next step is to connect high pressure valve (2) with elbow (3). See picture on page 7. There
can also use a seal. You must follow the arrows on valves from inlet pointing to the outlet.
3. Then is needed to connect a second nipple (1) with elbow (3). There is not need a seal,
because sealing is guaranteed with coned 60°. An assembly is made with fittings and
pressure valve.
4. We need to connect this assembly with electromagnetic valve (4). There you can also use a
seal, such as Loctite 542. You must follow the arrows on electromagnetic valves from inlet
pointing to the outlet.
5. Next step is to use a connector gasket (5) and put this on the electromagnetic valve (4). And
then we can put timer (6) on the connectors of electromagnetic valve (4).
6. The end step is to connect an electric cable with timer. See instructions in chapter electrical
installation.
7. This assembly you can mount on the filter housing.

9
5.2Electrical installation
Recommended wire lengths (mm)
230V
24Vdc
1
Neutral
+24Vdc
2
Line
0V
3
Protective Earth
Danger due electrical voltage!
Electric could be dangerous and hazardous to the operator.
Be careful not to pinch wires by cover! Be careful to clamp all strains of wires into respective terminal
blocks (use ferrules)!
Electrical connection should be made as shown above. It depends on orientation of the cover.
6. Storage information
The following storage must be considered for proper operation:
Store the components and elements indoors in a dry place.
Store them in original packing until they are used.

10
7. Operation
For operation with TD420m follow next steps.
1. Connect condensate drain device with the filter housing. You must follow the arrows on
pressure valves and electromagnetic valves from inlet pointing to the outlet.
2. Connect outlet of the condensate drain to outflow.
3. Full open a high-pressure valve. High pressure valve must be open full all time, if we want
that device operate correct. For more, see chapter Inlet valve.
4. Connect a condensate drain device to the electric network.
5. Set time Ton and Tof. Instruction for this you can find below and in chapter Approximate
calculation of discharge capacity
6. Make a test by pressing a test button.
1 –Inlet from compressed air system to
condensate drain
2 –Outlet from condensate drain to
condensate collecting pipeline
Condensate drain consists of two timers, Ton and Toff. The Ton timer regulates the time duration of
discharging. The Toff timer regulates period between two discharges. At the moment, when the
device is connected to mains power supply, it activates the discharging process, which is noticed by
the sound of valve being open. Condensed water flows through inlet connection 1 and is discharged
through valve and outlet connection 2. After the set time Ton passes, the valve closes and green LED
light is turned on until the time Toff passes, when new cycle begins. Cycles repeats continuously.
The time between discharges Toff can be set from 1/2 to 45 minutes.
The time of discharge Ton can be set from 1/2 to 10 seconds.
For right settings refer to chapter Approximate calculation of discharge capacity

11
P Periods Ton and Toff are set by knobs on the
condensate drain device.
After some weeks of operation, when you check
electromagnetic valve test, you can may adjust
the periods, if notice that only air is discharged
when the test button is pressed, then the Toff
may be increased. On the other hand, if a lot of
condensate is discharged every time, we press
the test button then the Toff must be shortened.
Made this test shortly before draining.
Be aware that amount of condensate is higher in
summer and when compressed air consumption
is increased.
By pressing TEST button valve opens for Ton.
The green LED lights on during off period. But
during discharging, it is switched off.
7.1Inlet valve
The function of inlet valve is that you can make a service on condensate service or that you can
replace it. Inlet valve must be full open during operation.
Risk of material damaged!
Inadequate condensate drain intervals lead to the flooding of the filter and damage the downstream
pressure devices.
7.2Approximate calculation of discharge capacity
𝑄[l/min]=𝐾𝑉𝑆[l/min]∙√𝑝[bar]
1 bar ∙( 𝑇𝑂𝑁[s] 𝑇𝑂𝑁[s]+𝑇𝑂𝐹𝐹[min]∙60)
Q[l/min] Discharge capacity
KVS [l/min] Flow coefficient of valve for water/ condensate
p[bar] Pressure drop across valve (It equals to system pressure in case
of condensate drains.)
TON [0.5 s –10 s] Duration of one discharge of condensate
TOFF [0.5 min –45 min] Period between discharges of condensate
Risk of material damaged!
Please take the relevant climate zone into account when dimensioning yours specific TDxxM series
application.
Ton
Toff

12
7.3Troubleshooting
If having a trouble with condensate drain device:
1. Test the device with pressing test button. Try several times.
2. If it not better and the device not draining water or air, disassemble and clean the valve and
fittings.
3. Check time Ton and Tof.
4. Check the electrical installation, if all contact are connected.
5. Replace timer or electromagnetic valve. For this change contact us or your local dealer.
8. Maintenance
Service:
Sealing elements are subject to wear, which depends on various operating parameters such as
pressure, temperature, dirt content, etc.
Warning due to a sudden release of pressure!
Pressure could be dangerous and hazardous to the operator.
Depressurize the filter before carrying out any work on the filter.
Never remove any parts of the filter, when the filter is still pressurized!
Before beginning maintenance work follow these steps:
1. Close ball valve
2. Depressurize the unit (push test button)
3. Cut off the power supply
Once per week make a visual check of the fittings and valve with timer controller. Next to a visual
check we must do timer and electromagnetic valve test by pressing the test button on timer
controller. If necessary disassemble and clean the valve and fittings.
After installation or maintenance (testing the settings, tightness or any other work), the test button
should be pressed to empty condensate that has been collected while the ball valve has been closed.
9. Warranty exclusion
The guarantee shall be void if:
The installation and operating manual was not followed with respect to installation, initial
commissioning and maintenance.
The unit was not operated properly and appropriately.
The unit was operated when it was clearly defective.
Non-original spare parts or replacement parts were used.
The unit was not operated within the permissible technical parameters.
Unauthorized constructional changes were made to the unit or if the unit has been
opened/disassembled by an unauthorized person.

13
10. Disposing
Environmental damage in case of faulty disposal!
The device might be contaminated by the filtered substances.
1. Be mindful of the local regulations.
2. Heed the notes on hazardous substances for the filtered gas and appropriate disposal
regulations when disposing.
3. Waste separation!
Metallic components to be turned into scrap metal,
plastic parts should be recycled,
lubricants and other auxiliary materials are subject to the provisions regarding
the treatment of special refuse,
dispose of the remaining components after sorting them with respect to the
nature of the materials.
4. The type plate is to remove mechanically.
5. Ensure that materials are only disposed of by licensed specialised companies.

14
OMEGA AIR d.o.o. Ljubljana
Cesta Dolomitskega odreda 10
SI-1000 Ljubljana, Slovenia
T: [phone]
F: [phone]
[email protected]
