Omega Engineering OSXL650 User manual

WITH BUILT-IN
PAT E N T E D
LASER CIRCLE
SIGHTING
TM
omega.com
e-mail: [email protected]
For latest product manuals:
omegamanual.info
User’s Guide
Shop online at
OSXL650
and OSXL653
Low Cost Professional
Infrared Thermometer

Servicing North America:
U.S.A.: One Omega Drive, Box 4047
ISO 9001 Certified Stamford, CT 06907-0047
Tel: [phone]
FAX: [phone]
e-mail: [email protected]
Canada: 976 Bergar
Laval (Quebec) H7L 5A1, Canada
Tel: [phone]
FAX: [phone]
e-mail: [email protected]
For immediate technical or application assistance:
U.S.A. and
Canada:
Sales Service: 1-800-826-6342/1-800-TC-OMEGA
®
Customer Service: 1-800-622-2378/1-800-622-BEST
®
Engineering Service: 1-800-872-9436/1-800-USA-WHEN
®
Mexico: En Espa n˜ol: [phone]-7803
FAX: [phone]
e-mail: [email protected]
[email protected]
Servicing Europe:
Czech
Republic:
Frystatska 184, 733 01 Karviná, Czech Republic
Tel: [phone]
FAX: [phone]
Toll Free: 0800-1-66342
e-mail: [email protected]
Germany
Austria
Daimlerstrasse 26, D-75392 Deckenpfronn, Germany
Tel:+ 49 (0)7056 9398-0
FAX: [phone]
Toll Free in Germany: 0800 639 7678
e-mail: [email protected]
United
Kingdom: One Omega Drive, River Bend Technology Centre
ISO 9002
Certified
Northbank, Irlam, Manchester
M44 5BD United Kingdom
Tel: [phone]
FAX: [phone]
Toll Free in United Kingdom: 0800-488-488
e-mail: [email protected]k
OMEGAnet
®
On-Line Service Internet e-mail
omega.com [email protected]
It is the policy of OMEGA Engineering, Inc. to comply with all
worldwide safety and EMC/EMI regulations that apply. OMEGA is
constantly pursuing certification of its products to the European New
Approach Directives. OMEGA will add the CE mark to every
appropriate device upon certification.
The information contained in this document is believed to be
correct, but OMEGA accepts no liability for any errors it contains,
and reserves the right to alter specifications without notice.
WARNING:
These products are not designed for use in, and
should not be u
sed for, human applications.

4-4 Advanced Functions
2
3
3
3
4
6
6
6
7
7
10
10
11
11
12
1-3 Warnings and Cautions
7.Emissivity Table
i
Low Cost Professional Infrared Thermometer

NOTES:
Low Cost Professional Infrared Thermometer

(OSXL653).
larger than the unit’s optical field of view.
Patented laser circle sighting.
Low Cost Professional Infrared Thermometer
Audible alarms (OSXL653).
Temperature data storge (OSXL653).

You may receive harmful laser radiation exposure if you
do not adhere to the warnings listed below:
• Use of controls or adjustments or performance of
procedures other than those specified here may
result in hazardous radiation exposure.
• Do not look at the laser beam coming out of the
lens or view directly with optical instruments - eye
damage can result.
• Use extreme caution when operating the laser
sighting.
• Never point the laser beam at a person.
• Do not attempt to open the thermometer. There are
no user serviceable parts.
• Keep out of the reach of all children.
Refer to the inside back cover for product warning label.
2
1-3 Warnings and Cautions
CAUTION
Low Cost Professional Infrared Thermometer

3
Low Cost Professional Infrared Thermometer

-32 to 538°C (-25 to 1000°F)
From -32 to -20°C (-25 to -4°F)
From -20 to 100°C (-4 to 212°F)
100 to 538°C (-212 to 1000°F)
YES - Laser Circle
Max//Min/Avg/ T YES (OSXL653)
Auto-measuring YES
Data Storage 10 points (OSXL653)
Audible Alarm YES (OSXL653)
0 to 50°C (32 to 212°F)
10 to 90%RH
Adj. 0.1 to 1.0 (OSXL653).
0.95 Fixed (OSXL650).
187g Approx.
4
to
Low Cost Professional Infrared Thermometer

Wavelength (Color):
Operating Distance: Up to 10 ft.
Max. Output Optical <1mW at 75°F ambient
Power: temperature,
Class II Laser Product
European Classification: Class 2, EN60825-1
FDA Classification: Complies with 21 CFR Chapter 1,
Subchapter J
Beam Diameter: 5 mm
Beam Divergence: <2mrad
Laser Configuration: Dot and Circle
Power Switch: Slide switch, ON-OFF
Power Indicator: Laser icon on display
Power: Supplied by the thermometer
Identification Label: Located on the right side of the
thermometer
Warning and Located on the left side of the
Certification Label: thermometer
630 to 670 nanometers (red)
3.Specifications con’t.
Laser Sighting
5
Low Cost Professional Infrared Thermometer

Optical Lens
ID and Field
of View Label
Laser Circle
Sighting
LCD displays either the current temperature in degree
Celsius or Fahrenheit. The unit will HOLD the last
reading for about 6 seconds after the trigger is
released; the word HOLD appears. Make sure the
target area is larger than the field of view of this
instrument. The laser circle sighting indicates the
perimeter of the thermometer’s field of view. During
the measurement session, the display back light
stays on.
6 Low Cost Professional Infrared Thermometer
