Omega B2300 User manual

INSTRUCTION
MANUAL
PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USE
English
OMGMAN 082009 RevA
www.omegajuicers.comwww.omegajuicers.comEat well, drink well and live well with OmegaEat well, drink well and live well with Omega
B2300, B2400 & B2500
BLENDER

Specifications 3
Caution & Safeguards 4
Control Panel 5
Blade Agitator Assembly 5-6
Care and Cleaning 6-7
Troubleshooting 7
Exploded Views 7-12
Parts lists 7-12
Warranty 13
TABLE OF CONTENTS

Dimensions:
W 9-1/4in x D 8-1/4in x H 22in
W 190mm x D 210mm x H 559mm
Shipping Dimensions:
W14-1/2in x D 12-1/2in x H 22inW
370mm x D 320mm x H 325mm
Shipping Weight:
18 lbs
8.172 kg
Power Requirements:
Volts: 120/240 VAC
Amps: 13/6 A
Hz: 50/60
On Board Circuit Breaker: 120V/10A
Specifications
B2300 B25 00
B2400

Caution & Safeguards
1. To protect against risk of electrical shock, do not put motor base in
water or other liquid.
2. Unplug the power cord from the wall outlet when the unit is not
in use, before putting on or taking off parts, and before cleaning other
than washing the container.
3. Never contact moving parts.
4. Do not use outdoors.
5. Do not let the power cord hang over edge of table or counter, or
touch hot surfaces.
6. Keep hands and utensils out of the container while the motor
is running to prevent the possibility of severe personal injury and/or
damage to the unit. A rubber scraper may be used, but only when the
unit is not running.
7. The blade is very sharp and requires carefull handling. Never try to
remove blade while container is sitting on the motor base. Do not op
erate with loose or damaged blades. To reduce the risk of personal in
jury, never place blade assembly on motor base without blender
container properly attached.
8. Always operate with the lid in place.
9. NEVER bang the container against a surface to loosen the ingredi
ents. Remove the container from the base and use a rubber spatula to
remove thick mixtures from the bottom of your container.
10. NEVER shake or rattle a container in use while seated on
the motor base.
11. NEVER remove the container before the machine has come to a
complete stop.
12. NEVER start the motor before the container is in place.
13. Keep children away when the blender is in use.
The power cord comes equipped with a three-prong (grounding) plug
which mates with a standard three-prong wall outlet (Figure A). Please use
approved 2 prong adapters(Figure B) when a ground is not available. Do
not cut or remove the round grounding prong from the power cord.
4

Control Panel Model
B2300 B2400 B2500
High/Low Switch
On/Off Switch
On/Off Switch
Variable Speed Knob
Pulse Switch
On/Off Switch
Variable Speed Knob
Timer Knob
Blade Agitator Assembly
Use caution when handling the blade; it is sharp. Use a soft cloth to grab
the blade when inserting the blade assembly through the container.
Retainer Nut and Blade Removal
•The retainer nut is easily removed using the disassembling tool (DT).
Turn container upside down and insert the disassembling tool on the
holes of the nut. Push the tool counterclockwise to loosen nut (Step 1).
Once loosened, remove by hand.(Disasembly tool sold separately)
•To release the blade use the other end of the DT while grabbing the
gear with backup pliers and turn counterclockwise (Step 2)
Care and Cleaning
Motor Base
1. Unplug the power cord.
2. Wipe outside surface with a damp soft cloth or sponge, which has
been rinsed in a mild solution of liquid dish soap and warm water. NEVER
IMMERSE MOTOR BASE IN WATER OR OTHER LI UID.
3. Wipe dry with a clean, soft cloth.
Control Panel
Gently wash the front panel with a soft cloth and low pH balance soap,
being careful not to scratch the Display Window.
NOTE: Be sure to wring excess water out of cloth or sponge when cleaning
around the controls, drive socket or any electrical part.

Lid
Separate the lid and plug, then wash in warm soapy water. Rinse clean
under running water and dry. Reassemble before use.
Container
1. To clean: Fill pitcher 1/4 full with warm water and add a couple of
drops of dish soap. Return container to motor base and firmly position
the two part lid. Run machine for 30 seconds. Empty container. Repeat
this step.
Troubleshooting
Problem Probable Cause Probable Solution
Loud noise from
the container
•Container blades
do not spin
•Increased vibration
•Leaking from
bottom of container
• Broken or worn drive
socket. Replace drive
socket.
• Check blade assembly
for damaged compo
nents and replace.
• Tighten retainer nut on
the bottom of the
container
achine starts
then shuts off
•otor
•Reset button
•Depress reset button
•Call Omega Customer
Service
achine starts
then shuts off
•Power failure
•Power supply cord
damage
•Check to make sure
there is power to the
machine
•Check the power
supply cord and the
connection to the
power outlet
6

B2300
Item# Part Description
1 EJ101-A Lid plug for 82oz/2500cc (square)
EJ101-B Lid plug for 64oz/2000cc (round)
2 EJ102 Lid for 82oz/2500cc
EJ102B Lid for 64oz/2000cc
3 EJ222 Agitator assembly (cutting unit)
4 EJ103B-1 Container 64oz/2000cc
EJ103C-1 Container 82oz/2500cc
5 EJ225-S Heavy duty stainless steel retainer nut
6 EJ214 Sound reducing centering pad
7 EJ202 Drive socket
8 EJ204 Upper housing
9 EJ219 otor rubber washer
10 EJ220 otor
11 EJ207 Fan blade
12 EJ201 Power supply cord
13 EJ209 Rubber feet
14 EJ206 otor cover
15 EJ205 Bottom housing
16 EJ208 Clamp wire plate
17 EJ212H Lbt Pcb
18 EJ221A Control plate
20 EJ210 On/Off switch
21 EJ227 Gasket
22 EJ104A Tamper for 64oz/2000cc & 84oz/2500 cc
EJ105 Disassembly tool

8

B2400
Item# Part Description
1 EJ101-A Lid plug for 82oz/2500cc (square)
EJ101-B Lid plug for 64oz/2000cc (round)
2 EJ102 Lid for 82oz/2500cc
EJ102B Lid for 64oz/2000cc
3 EJ222 Agitator assembly (cutting unit)
4 EJ103B-1 Container 64oz/2000cc
EJ103C-1 Container 82oz/2500cc
5 EJ225-S Heavy duty stainless steel retainer nut
6 EJ214 Sound reducing centering pad
7 EJ202 Drive socket
8 EJ204 Upper housing
9 EJ219 otor rubber washer
10 EJ220 otor
11 EJ207 Fan blade
12 EJ201 Power supply cord
13 EJ209 Rubber feet
14 EJ206 otor cover
15 EJ205 Bottom housing
16 EJ208 Clamp wire plate
17 EJ212P Lbt Pcb
19 EJ221B Control plate
21 EJ210-1 Speed knob
22 EJ210 On/Off switch
EJ211 Pulse switch
23 EJ227 Gasket
24 EJ104A Tamper for 64oz/2000cc & 82oz/2500cc
EJ105 Disassembly tool

10

B2500
Item# Part Description
1 EJ101-A Lid plug for 82oz/2500cc (square)
EJ101-B Lid plug for 64oz/2000cc (round)
2 EJ102 Lid for 82oz/2500cc
EJ102B Lid for 64oz/2000cc
3 EJ222 Agitator assembly (cutting unit)
4 EJ103B-1 Container 64oz/2000cc
EJ103C-1 Container 82oz/2500cc
5 EJ225-S Heavy duty stainless steel retainer nut
6 EJ214 Sound reducing centering pad
7 EJ202 Drive socket
8 EJ204 Upper housing
9 EJ219 otor rubber washer
10 EJ220 otor
11 EJ207 Fan blade
12 EJ201 Power supply cord
13 EJ209 Rubber feet
14 EJ206 otor cover
15 EJ205 Bottom housing
16 EJ208 Clamp wire plate
17 EJ212T Lbt Pcb
19 EJ221C Control Plate
22 EJ12 Speed knob
23 EJ12 Variable Speed knob
24 EJ210A On/Off switch
25 EJ227 Gasket
26 EJ104A Tamper for 64oz/2000cc & 82oz/2500cc
EJ105 Disassembly tool

12

Limited Warranty:
Two (2) Year Replacement Domestic
One (1) Year Replacement Commercial
Omega and Asbury Service Warranty & Parts (ASW&P) warrants to the
original purchaser of the B2300, B2400 and B2500 and all parts thereof to
be free from defects in material and workmanship while under normal
use and service for a period of two (2) years from the date of purchase
for domestic use and one (1) year form the date of purchase for com-
mercial use. (Warranty registration must be completed and received
within 10 days of purchase for warranty activation.) Omega’s obliga-
tion under this warranty shall be limited to the replacement of the
blender base and/or the container assembly. Omega will not be held re-
sponsible for spoilage of products, loss of sales or consequential damages.
At the time of a warranty claim the customer will be responsible for ade-
quate packaging and the associated shipping charges of the defective
product to be delivered to Asbury Service Warranty & Parts service center.
ASW&P will cover the cost to replace the defective item including associ-
ated shipping costs to return a new replacement product to the customer
after satisfactory evaluation of the original. Should the end user require a
replacement ahead of the warranty review process the published list
price of the item must be secured ahead of shipment. Upon satisfactory
evaluation the end user will be credited for the item. In the event a war-
ranty claim is denied, a letter of such will follow. All warranty replacement
items are subject to the terms and time limits of the original purchased
product. Other conditions and limitations may apply and can be found
on the back of the warranty registration card (supplied separately).

14
