Omega Carlink OMEGA-CARLINK User manual

Model:
OMEGA-CARLINK
Installation And Testing Guide
If you have not already, visit omegacarlink.com and register as a Carlink
dealer for access to install tesng and conguraon tools. Sooner is
beer since registraons are processed manually and are not instant.
Keep track of the SIM number located on the card included with this
system. It is needed to test / acvate the deivce later.
Choose a discreet yet ideal mounng locaon for the module. This
is a cellular device and performance is dependant on cellular signal
strength.
Route wiring from the mounng locaon and make all necessary wiring
connecons - SEE “CONNECTING THE DEVICE” ON PAGE 2.
Aer a few minutes, check the indicator lights to make sure the unit
has cellular service. Both the green and orange lights should be on
solid.
Login into your dealer account at omegacarlink.com to acvate the de-
vice, congure the installed opons, and perform the installaon test.
Be sure to have the SIM number available.
Complete the installaon by reassembling the vehicle’s interior.
IMPORTANT: Be sure to give the acvaon code and app info to the
vehicle’s owner. For more info, see the dealer portal guide by logging in
to your dealer account at omegacarlink.com.
Quick Reference Install Guide
1
2
3
4
5
6
7
8
SMARTPHONE INTERFACE
Detailed instructions continued on following pages ->
IM_OMEGA-CARLINK 10/20/11

2
Step 1: Determine a mounting location
Find a discreet and secure mounting location for the module. Make sure
the module is free from moisture, excessive heat, direct sunlight, or moving
vehicle parts. Keep cellular signal strength in mind. This system uses the GSM
cellular network to communicate with the CarLink servers.
TIP: Make note of a mobile phone’s signal strength in an open area inside the vehicle cabin.
Then hold the phone in your chosen mounting location to see if there is any negative effect on
service. Adjust the mounting location if necessary.
- Mount at least 12 inches away from the radio and speakers. The cellular trans-
missions of this device could cause radio interference.
- DO NOT SECURE THE DEVICE YET
Step 3a: Connect the device - DIGITAL (typical install)
 Thisdeviceisinitiallyconguredtooperateasasimpleplug-inupgrade
to compatible Omega systems. Any Omega system that supports the iDatalink
data protocol also supports carlink as a plug-in upgrade. This includes all BLADE
compatiblesystems(besurethesystemisupdatedtothelatestrmware).
GREEN Auxiliary output wire (optional):
 Thisisanegativepulse250mAoutput(addarelayifnecessary)con-
gurableformanyapplications.Duringtheinstalltestontheomegacarlink.com
website,youcancongurethisoutputfora1,3,or10secondpulseANDyou
can assign it to any one of the 6 function icons in the phone app.
YELLOW Auxiliary output wire (optional):
 Thisisanegativepulse250mAoutput(addarelayifnecessary)con-
gurableformanyapplications.Duringtheinstalltestontheomegacarlink.com
website,youcancongurethisoutputfora1,3,or10secondpulseANDyou
can assign it to any one of the 6 function icons in the phone app.
GREEN 4-pin data connector:
STEP 1: Before connecting this to the host system’s data port, be sure that the
system is programmed for “iDatalink protocol”. See the system’s programmable
features for more information. BLADE systems will automatically switch to the
iDatalink protocol when a BLADE cartridge is inserted.
STEP 2: Connect the data connector to the host system and wait for the indica-
torlightstoshowproperconnectivity(see“Checkindicatorlights”onpage4).
STEP 3: Activate the host system’s remote start function with the original
remote. This will synchronize the start/stop functions of the Carlink system for
proper operation. You don’t have to allow the remote start to completely start.
You can simply activate it then shut it down within a few seconds.

3
IM_OMEGA-CARLINK 10/20/11
Omega CarLink Wiring Overview - DIGITAL
P/N: ESN: III|||IIIIIIIIIII||IIIIIIIIIIII ICC-ID: 1234567890987654 IIIIIIIIIII|||||||||||IIII||||IIIIII|I|||||||II |||II||| FCC ID: QIPTC65 IC ID: 267W-TC65 CEID: 0682 IMEI: IIIII |||IIIIIIIIII||||||||||||IIIIIIIIIIIIIIIIII|| This device complies with part 15 of the FCC Rules. Opera- tion is subject to the condition that this device does not cause harmful interferece. Assembled in USA
Indicator lights
BROWN - Data BLACK - System Ground (-) Input BLUE - Data RED - Constant 12v (+) Input
ORANGE - Not Used WHITE - Not Used YELLOW - Aux. (-) Output GREEN - Aux. (-) Output

4
This system can be installed as a stand-alone system or to control ana-
log activation inputs on an older host system that does not support the iDatalink
protocol for CarLink. To be connected this way, you will need to cut off the
GREEN 4-pin data connector.
NOTE: As an analog system, it cannot report alarm violations but it will still give 2-way conr-
mations for all control functions.
BLACK Ground wire (required):
This provides chassis ground to the device. It should be connected
directly to the metal structure of the vehicle. Strip the end of the wire and crimp
on the supplied ring terminal. Route this wire to a solid grounding point, like an
existing bolt in the vehicle and securely ground the wire.
GREEN Auxiliary output wire (optional):
 Thisisanegativepulse250mAoutput(addarelayifnecessary)con-
gurableformanyapplications.Duringtheinstalltestontheomegacarlink.com
website,youcancongurethisoutputfora1,3,or10secondpulseANDyou
can assign it to any one of the 6 function icons in the phone app.
YELLOW Auxiliary output wire (optional):
 Thisisanegativepulse250mAoutput(addarelayifnecessary)con-
gurableformanyapplications.Duringtheinstalltestontheomegacarlink.com
website,youcancongurethisoutputfora1,3,or10secondpulseANDyou
can assign it to any one of the 6 function icons in the phone app.
BROWN Auxiliary output wire (optional):
Thisisanegativepulse250mAoutput(addarelayifnecessary)con-
gurableformanyapplications.Duringtheinstalltestontheomegacarlink.com
website,youcancongurethisoutputfora1,3,or10secondpulseANDyou
can assign it to any one of the 6 function icons in the phone app.
RED Constant power wire (required):
This is the power supply wire to the device. It must be connected to a
FUSED constant +12V source. This can be found in the ignition switch harness,
a fuseblock, or at the vehicle’s battery. Be certain that this wire has +12V under
all circumstances and when the ignition key is in the ON and OFF positions.
BLUE: NOT USED
ORANGE: NOT USED
WHITE: NOT USED
Step 3b: Connect the device - ANALOG

5
IM_OMEGA-CARLINK 10/20/11
Omega CarLink Wiring Overview - ANALOG
BROWN - Aux. (-) Output ORANGE - Not Used
P/N: ESN: III|||IIIIIIIIIII||IIIIIIIIIIII ICC-ID: 1234567890987654 IIIIIIIIIII|||||||||||IIII||||IIIIII|I|||||||II |||II||| FCC ID: QIPTC65 IC ID: 267W-TC65 CEID: 0682 IMEI: IIIII |||IIIIIIIIII||||||||||||IIIIIIIIIIIIIIIIII|| This device complies with part 15 of the FCC Rules. Opera- tion is subject to the condition that this device does not cause harmful interferece. Assembled in USA
WHITE - Not Used YELLOW - Aux. (-) Output GREEN - Aux. (-) Output
Indicator lights
BLACK - System Ground (-) Input BLUE - Not Used RED - Constant 12v (+) Input NOTE: Be sure to add 5A fuse

6
Step 6: Check the indicator lights
Locate the indicator lights on the end of the module. They are next to the
main harness. After powering up the device, you will notice the GREEN and
ORANGEindicatorlightswillashtheneventuallyturnonsolid.Solidlightsindi-
cate proper connectivity and you can proceed to the installation test.
GREEN light (power / processing):
8Off: No power, the device is OFF.
8Blinking: The device is working on current operations
4Solid: The device is operating properly
ORANGE light (cellular connectivity):
8Off: The cellular radio is OFF.
8Slow Blinking: The device is searching for the cellular network.
8Fast Blinking: The device has found cellular service and is waiting
to register to the network.
8Solid w/ Fast Blinking every 1 second: The device is registered to the
cellular network but is awaiting acknowledgement.
4Solid: Cellular service has been found with good signal strength and the
device is connected to the network with acknowledgement.
Step 7: Test installation and activation
Make sure you have the “Quick Reference Guide” with you and login to your1.
dealer account at www.omegacarlink.com. You will need the ICC ID (aka
SIM)toactivatethedevicefortesting.Thisislocatedonthelabelafxedto
the “Quick Reference Guide” as well as on the module label.
Once you are logged in, click “Install or Diagnose” and follow the easy on-2.
screen instructions. You will also see a link for the “Dealer Portal Guide”
which gives you step by step instructions and additional info if needed.
Upon successfully completing the installation tests successfully, you will be3.
given a 4 digit activation PIN for the vehicle owner. WRITE THE PIN IN THE
SPACE PROVIDED ON THE QUICK REFERENCE GUIDE. You can also
send the PIN to the vehicle owner by email or SMS text message.
If you know the phone number and carrier of the vehicle owner’s smart-4.
phone, you can push the mobile app to their phone via SMS text. They can
alsoeasilyndtheappintheirphone’sappstore/marketplace.
Step 8: Complete the installation
 Aftersuccessfullycompletingtheinstallationcongurationandtest,se-
curely mount the module in the selected location with tie straps, high grade hook
& loop tape, or any other reliable mounting method, and reassemble the vehicle’s
interior.
BE SURE TO GIVE THE QUICK REFERENCE GUIDE TO
THE VEHICLE OWNER. THEY CANNOT ACTIVATE OR USE
THE DEVICE WITHOUT THE ICC ID AND PIN.

7
Useful Information
CarLink
Login Website: www.OmegaCarLink.com
Omega Research & Development, Inc.
Corporate Website: www.CarAlarm.com
Corporate Phone: [phone]
Tech Support Phone (hardwire/wiring only): 800-921-TECH (8324)
Tech Support Web: www.WireSheet.com
IM_OMEGA-CARLINK 10/20/11
