OmniCure AC7 Series User manual

OmniCure® AC7 Series
: Quick Start Guide
WARNING:
Never look at operating LED! The light could severely damage the cornea and
retina of the eye if the light is observed directly. Eye shielding must be used at all times as well
as clothing to protect exposed skin. efer to user guide for more det
ails.
SETUP / Unpack
•Carefully unpack the unit and accessories from shipping carton.
•When removing the LED Head, ensure that the
optical window is not placed directly on
a surface to avoid any damage.
1.1 System Requirements
In addition to the UV LED Head, you will require the following components:
Power supply
Power cable
You will also require a PLC controller unless you are using an existing controller. These may
be sourced separately or ma
y be purchased from Excelitas Technologies
1.2 onnecting the Power Supply and PL ontroller
Note: All connectors are via screw style fastener --
do not over tighten the connector
screws.
Note:
The following is a generic procedure, illustrated with the comm
described above; please refer to specific documentation related to your power supply
and controller.
Tip:
After securing the power cable to the power supply, it is recommended to “tie
off” the female connector cable on to the mounting
brackets or process rigging as a
form of strain relief.
1.
2.
1. Attach the male end of the
power cable to the power
supply unit, and connect
the female end of the
power cable to the UV LED
Head
2. Attach the male end of the
PLC cable to the UV LED
Head (see Figure 1).
3. Make sure the power
supply unit is turned off.
: Quick Start Guide
Never look at operating LED! The light could severely damage the cornea and
retina of the eye if the light is observed directly. Eye shielding must be used at all times as well
ails.
