Omnitec OmniAire 1000 Series User manual

OmniAire Negative Air / HEPA
Air Filtration Machines
OmniAire 1000 Series
Operation and Maintenance Manual
425.512.0379 | 4640 Campus Place, Suite 100, Mukilteo, WA 98275 USA omnicleanair.com

Revision Date: 09222022 02
Back to Table of Contents
WARNING
SAFETY WARNING INSTRUCTIONS
L’ AVERTISSEMENT
INSTRUCTIONS D’AVERTISSEMENT DE SÉCURITÉ
READ AND SAVE THESE INSTRUCTIONS
This equipment to be operated only by trained personnel.
Do not use near combustible or
explosive material. Fire may occur.
Do not expose to water or rain.
Electrical shock may occur.
Connect only to grounded outlet
with GFCI device.
Disconnect power for cleaning and
servicing.
Disconnect power cord before
moving.
Do not operate if cord or plug is
damaged. Contact a authorized
service facility for examination and/
or repair.
Do not run cord under carpeting.
Do not cover cord with throw rugs,
runners, or similar coverings. Arrange
cord away from trac areas and
where it is not a tripping hazard.
LIRE ET CONSERVER CES INSTRUCTIONS
Cet équipement ne doit être utilisé qu’après avoir lu les instructions.
Ne pas utiliser à proximité de
matériaux combustibles ou explosifs.
Un incendie peut se produire.
Ne pas exposer à l’eau ou à la pluie.
Un choc électrique peut se produire.
Connecter uniquement à une prise
mise à la terre.
Débranchez l’alimentation pour le
neoyage et l’entretien.
Débranchez le cordon d’alimentation
avant de vous déplacer.
Ne pas utiliser si le cordon ou la
fiche est endommagé. Contactez
un centre de service autorisé pour
examen et / ou réparation.
Ne pas passer le cordon sous un
tapis. Ne pas couvrir le cordon avec
des carpees, les coureurs, ou
revêtements simi- laires. Éloigner
le cordon des endroits passants
et où il n’est pas un risque de
déclenchement.
CONFORMS TO UL STD 507
CERTIFIED TO CAN/CSA STD
C22.2 NO. 113-M1984

Revision Date: 09222022 03
Back to Table of Contents
Table of Contents
Introduction...........................................................................................Pg. 04
Application Examples........................................................................Pg. 04
Operations..............................................................................................Pg. 05
Maintenance.........................................................................................Pg. 06
Troubleshooting...................................................................................Pg. 07
Product Specs.......................................................................................Pg. 08
Parts and Accessories.......................................................................Pg. 08
Omni CleanAir Limited Warranty...................................................Pg. 09

Revision Date: 09222022 04
Back to Table of Contents
Introduction
The OmniAire Negative Air Machine series provides high-performance negative air scrubbing
through a variety of performance and feature options. These machines are used for the removal of
toxic mold, asbestos, and lead dust during renovation and abatement projects, and for purifying
air in commercial, factory sites, and medical facilities. These machines are made out of a strong
aircraft-grade aluminum housing with smooth surfaces, for easy sanitation. It can be used with
multiple filter options such as HEPAs, Activated Carbon plus primary/secondary filter. Additional
options include power coated housing and audio alarm. Additional accessories include an intake
manifold, flex ducting, and quick clamps.
Application Examples
Creating Negative Air Pressure
To create negative pressure inside the containment
area, more air has to be exhausted out than leaks
into the containment. Negative air may be required
for a workflow (asbestos abatement for example).
Place the machine inside the containment and hook
a flexible duct to the outlet ring of the machine
exhausting to outside the containment. In this case,
all contaminated air is contained inside the negative
air pressure space. Alternatively, the machine can be
outside the containment space, using a duct and an
intake manifold.
Creating Positive Air Pressure
An alternate workflow is to create positive air pressure in the containment area, which ensures that
treated air is pumped into the containment area.
Carbon Activated Filtering
For VOCs and odor control, an OdorGuard carbon activated filter can be quickly installed. Activated
carbon filters are designed to remove odors and gaseous pollutants from air. These filters are an
eective and quick solution to your VOCs and odor problems.

Revision Date: 09222022 05
Back to Table of Contents
Operations
Your OmniAire unit will run 24x7 continuously for years with proper preventative maintenance and
prompt replacement of the proper filters. Even when the HEPA filter is fully loaded, the filter is still
removing particulates from the air at the rated eciency yet at a reduced airflow. This will aect
the ability of the machine to provide positive or negative
pressure within the containment. When the unit’s HEPA filter
is nearing full capacity, the “change filter” light on the front
panel will turn on. At this time you should replace the HEPA
filter so that you can maintain the airflow needed.
Prior to operating the machine, always check that the HEPA
filter is securely in place Tighten filter tabs if necessary. The
HEPA filter is secured with four filter tabs as shown in the
photo. It is critical that the HEPA seal is in place to ensure all
air passes through the HEPA. These tabs are secured with
1/4-20 Nylock nuts, which require a 7/16” wrench or socket.
Do not operate the unit without a HEPA filter in place.
Refer to the figure below for location and description of
controls available for each of the three models. To operate
the machine, turn the dial from O to the desired speed (Pro model), or flip the switch to the High or
Low speed (Prime and Plus models).
Power Indicator (Pro) Pressure Gauge (Pro)
Pressure Port (all models)
Change Filter Indicator
(all models)
Hour Meter (Plus, Pro)
Power/Speed Dial
Selector (Pro)
Power/Speed Switch
(base model, Plus)

Revision Date: 09222022 06
Back to Table of Contents
Maintenance
Preventative Maintenance
The motor and blower do not require maintenance and your OmniAire machine will run for years with
proper regular replacement of the filters. In addition, the unit’s power cord should be inspected for cuts
or other damage on a regular basis.
Prefilter Replacement
The primary/secondary filter should be changed when the orange side shows it is loaded with dust.
Changing the filter can be done while the machine is running. Ensure that the orange side of the
prefilter is facing the HEPA filter.
HEPA Filter Replacement
During your projects, your HEPA filter purifies the air and gradually becomes loaded with sub-micron
particulates. Even when the HEPA filter is fully loaded, the filter is still removing particulates from the
air at the rated eciency yet at a reduced airflow. This will aect the ability of the machine to provide
positive or negative pressure within the containment.
To replace the HEPA filter unplug the machine and remove the screen/manifold to remove the prefilter.
You will see 4 filter tabs holding the HEPA filter in place (see photo above). These tabs are secured with
1/4-20 Nylock nuts, which require a 7/16” wrench or socket.
Remove all 4 filter tab retaining nuts and remove the filter tabs and set aside. Slide the HEPA filter out
along the filter guides and remove it from the machine. ALWAYS TREAT THE USED HEPA FILTER AS
HAZMAT AND PROCESS IT ACCORDING TO YOUR ESTABLISHED HAZMAT PROCEDURES.
To replace the HEPA filter ensure that the gasket on the HEPA filter faces inwards toward the flange,
slide the filter in place along the filter guides and re-install the filter tabs and filter tab securing nuts.
The nuts should initially be tightened to where the stud is flush with the end of the nut. This will
compress the gasket on the filter approximately 1/2 of the thickness. This allows for the filter to be
reseated and tightened at a later time if necessary.

Revision Date: 09222022 07
Back to Table of Contents
Troubleshooting
Your OmniAire Negative Pressure Machine is designed and manufactured to provide years of trouble-
free performance. If there is a problem, please reach out for technical support and we are happy to
help.
The machine does not start
1. Check that the unit is plugged in and there is 115VAC (or 230VAC) available. On the Pro model, when
selecting a speed the red indicator light should come on. On the Prime and Plus models, select
either LOW or HIGH speed to turn on the unit.
2. Contact Omni CleanAir technical support to troubleshoot further.
The machine just hums when turned on
1. Unplug the unit.
2. Remove the HEPA filter and push the blower wheel by hand. If it does not move freely or if you
hear a grinding/ scrapping noise as you spin it, then the blower wheel is touching the side of the
blower housing. This may be due to an impact of some kind and the motor mounts have been bent.
Remove the motor/blower assembly and replace the bent motor mounts.
3. If the blower spins freely, check the capacitor. With the HEPA filter still removed from the machine,
ensure that the wiring connected to the capacitor is plugged in and not broken. Re-plug the unit
into the power outlet keeping the switch in the OFF position. Then push the blower wheel, remove
your arm, and as it is spinning turn the speed selector switch to LOW. [ENSURE NO CLOTHING OR
HAIR IS CLOSE TO THE MOTOR.] If the machine keeps running, the capacitor needs to be replaced.
The machine will run for a few minutes then turn o
1. The machine must have a HEPA filter (or bag filter or Vapor Trap filter) installed to operate properly.
If you are trying to run it without a filter in place, the motor will overheat within a few minutes and
the thermal overload will engage and shut it down. Let the motor cool o for 30 minutes, install the
filter and try running the machine again.
2. If the filter is in place and the machine still shuts o aer a few minutes then the motor is faulty.
Replace the motor.
The machine vibrates excessively when running
1. This is an indication that the motor bearings are worn out. If the machine continues running, at
this point the vibration will cause the center hub of the blower wheel to separate from the wheel
requiring replacement of both the motor and blower. Replace the motor. Wiring diagram can be
provided.

Revision Date: 09222022 08
Back to Table of Contents
Family OA1000
Plus Model OA1000 PLUS
Pro Model OA1000 PRO
HEPA Filter 6" depth 99.97% OAH1616-6
HEPA Filter 12" depth 99.7% OAH1616
HEPA Filter 12" depth 99.99% OAH1616G
HEPA Filter 12" depth 99.99%,
High Capacity OAH1616G-HC
Prefilter (box of 20) OAP1818
OdorGuard 600 Carbon Filter OG1616
Parts and Accessories
Family OA1000
CFM TrueCFMTM - Prime Model
CFM TrueCFMTM - Plus Model
CFM TrueCFMTM - Pro Model
Noise (6 foot distance) 68b - 72 db
Weight (lbs) 96
Power Consumption (115 VAC) 115VAC/60Hz/4.4A
Power Consumption (230 VAC) 230VAC/50-60Hz/ 2.4A
Size 19”W x 23”H x 31.5” L
Product Specifications
Available Models
300 CFM to 1000
CFM based on
speed seings and
filter selection
OA1000 PRIME, OA1000 PLUS, OA1000 PLUS-A, OA1000 PRO, OA1000 PRO-P
Intake Manifold Kit 10"
(Manifold, clamp, duct) OAIM1000-10KIT
ABS Plastic Intake Manifold,
10" Dia. OAIM10
Quick Clamp, 8"-10" Dia.
Flexible Duct, 10" Dia. x 25' L QCW12
8"-10" Dia. Flexible Duct,
10" Dia. x 25' L OAD10
Flexible Duct, 10" Dia. x 25' L,
Wire & Fiber Reinforced OAD10R

Revision Date: 09222022 09
Back to Table of Contents
Omni CleanAir Limited Warranty
This warranty policy covers equipment (machines and accessories) sold by Omni CleanAir and applies to the OmniClean, OmniTec, and AgriAir
portfolio of brands.
Omni CleanAir warrants that our products are free from defects in workmanship and materials under normal use during the warranty period.
All OmniClean machines including the OCA500, 1200, and 1500 series, excluding consumables come with a standard two (2) year warranty. All
OmniTec and AgriAir machines excluding consumables come with a standard one (1) year warranty. Warranty covers parts and labor only, excluding
consumables. Consumables (HEPA filters, prefilters, carbon filters, and UV light bulbs) carry no warranty other than to be free of defects upon arrival.
Non-Consumable accessories come with a standard ninety (90) day warranty.
The warranty extends to the following parties:
• Customers (individuals or companies) to whom Omni CleanAir directly sells products covered by this policy.
• Customers (both individuals and companies) who purchase Omni CleanAir products from an authorized distributor or reseller.
This limited warranty is not transferable or assignable to any subsequent purchaser and is only applicable in the country where the product was
originally purchased.
The following circumstances are not covered by this warranty policy:
• Damage caused by an act of nature such as flood, fire, wind, earthquake, or lightening.
• Damaged caused during shipping or an impact event with other objects.
• Damaged caused by improper care or negligence.
• Damaged cause by misuse, abuse, mishandling, or misapplication.
• Damaged caused by alteration or adjustments by unauthorized personnel.
Under no circumstances shall Omni CleanAir or any supplier of Omni CleanAir be liable for any loss, damage or expense, including, but not limited
to, loss or damage arising out of the failure of the products to operate for any period of time, inconvenience, the use of rental or replacement
equipment, loss of profits or other economic loss, or general, direct, special, indirect, incidental or consequential damages or property damages.
Many states and localities have their own varied codes and regulations governing sales, construction, installation, and/or use of Equipment for
certain purposes. While Omni CleanAir aempts to assure that its Equipment comply with such codes, it cannot guarantee compliance, and cannot
be responsible how Equipment is installed or used. Omni CleanAir recommends that, before purchasing and using Equipment purchasers review the
Equipment application, and federal, state and local regulations, to be sure that the Equipment installation and use will comply with them.
Omni CleanAir oers extended warranty through the GOLD CARE MEMBERSHIP PROGRAM, for as long as membership status is maintained.
For more information please visit omnicleanair.com/resources/gold-care-membership
To Submit a Warranty Claim or Receive Technical Support
Contact our Technical Support Department at 425 512 0379 or by email at [e-mail]. Hours are Monday-Friday 7:30am-4:00pm
PST. Please have the product model name and serial number available, along with the purchase date and invoice number, if applicable. Our service
technicians will work with you to diagnose your technical issue and recommend a suitable course of action to solve your problems quickly and to
your satisfaction.
If it is determined that your product is defective and under warranty, OmniClean will repair or replace, at our discretion, any faulty parts or
equipment. A Return Merchandise Authorization (RMA) will be issued for the defective product.
Customer to arrange and ship the product to Omni CleanAir at the customer's expense and must use original packaging. For units that have failed
within 30 days, Omni CleanAir will pay the cost of return shipping from the customer's site. If Omni CleanAir determines that the Warranty Claim is
valid, Omni CleanAir will be responsible for shipping the repaired product to the customer upon completion of any repairs or replacements.
In instances where equipment is damaged in transit wither while being returned to Omni CleanAir or aer repairs have been completed, Omni
CleanAir and the customer will need to work together to resolve these situations with the freight carrier(s) involved.
• If a shipment is made on the customer's account with a third party freight carrier, the customer is responsible for filing any claim for
reimbursement and will be responsible for any associated repairs or the replacement of the Equipment is in question.
• If a shipment is made on the Omni CleanAir's account with a third party freight carrier, and the equipment arrives at the customer's
location clearly damaged, it is the responsibility of the Customer to reject the freight carriers delivery. If the customer accepts the
shipment and determines aer the fact that the equipment was damaged during shipment, the customer is responsible to provide
photos, an inspection report, and any other information to Omni CleanAir within 14 days, in order for Omni CleanAir to file a claim
with the third party freight carrier. Once the claim has been filed Omni CleanAir will work with the customer to address the damage
incurred.
