iConverter®4Tx VT
4-Port 10/100BASE-TX Managed Ethernet Switch
iConverter
4-Port10BASE-Tor100BASE-TXEthernetswitchmodule
SupportsIEEE 802.1QTagVLAN,Q-in-Q Multi-tagging
and Port VLAN
SupportsIEEE802.1p Prioritization QoS
Per port MIB Statistics reporting of 32 variables
IndividualPortBandwidth andPortAccessControl
Flash-upgradablememory
Multiple4TxVT modulescan beinstalledto expandthe
port concentration in a single chassis
UTP port supports auto-crossover, with 10/100 and
HalforFull-Duplex auto-negotiationor forcedsetting
Backplane Ethernet ports for connectivity to adjacent
modules
Management is available with the addition of a
management module to the chassis
SNMPmanagement viaNetOutlook™providesreal-time
port and module information, remote parameter
configurationandtrapnotification
ConformstoIEEE 802.3,10BASE-T and100BASE-TX
specifications
LifetimeWarrantyandfree 24/7TechnicalSupport
TheiConverter 4TxVT10/100 managedEthernetswitchmodule
is a member of the iConverter product family. It provides a
compact 4-Port 10/100 Ethernet switch that is expandable
across the iConverter 19-Module, 5-Module and 2-Module
chassis backplanes, as well as being supported as a
stand-alone switch with the iConverter 1-Module Chassis.
TheiConverter 4Tx VT supports the IEEE 802.1Q and 802.1p
standards. It supports the 802.1Q VLAN packet tagging and
untagging for segregating data in Enterprise networks, and
enabling secure separation of Service Provider network
management and customer data to improve security and
intrusionprotection.
The 802.1Q Q-in-Q stacked tags enable Service Providers to
offer to their customers secure Ethernet Virtual Private Line
services which isolates each customer’s data traffic, as well
astheService Provider’smanagement traffic.
The4Tx VTsupports the802.1p prioritizationforthedeliveryof
Qualityof Service(QoS) toreal-time applicationssuch asvoice
orvideo overEthernet.
The iConverter 4Tx VT features Bandwidth and Port Access
Controls. On a per port basis, the upstream and downstream
traffic can be independently controlled by selecting from eight
levels of bandwidth setting. The PortAccess Control enables
thenetworkadministrator to easilycontrol and denyindividual
port access while maintaining port configuration for easy port
re-enabling.
The ports feature 10/100Mbps, Half/Full-Duplex, and auto-
negotiationwithbothhardwareandsoftwarecontrols. Hardware
control is available for two ports while all four ports are under
software control for these features. RJ-45 crossover support
eliminatesneedforacrossovercable andfacilitatesconnectivity
to different types of network equipment. All four ports support
anautomaticcrossover detectionmode.
TwoEthernet backplaneports provideconnectivity toadjacent
modules for network expansion and for providing additional
10/100UTPports foriConverter modularNIDs.
The4TxVT supportsreportingof MIB statistics. Statisticsare
available for 32 variables per port, reporting a wide range of
real-time packet statistics to provide performance and
operationalmonitoring.

800-675-8410 • 949-250-6510 • www.omnitron-systems.com • [email protected] • 140 Technology Dr. • Irvine, CA 92618
Trademarksareowned bytheir respectivecompanies. iConverterisa registeredtrademark ofOmnitron SystemsTechnology,Inc.
NetOutlook isa trademarkof OmnitronSystemsTechnology,Inc. Specifications subjectto changewithout notice.
©2003-2007Omnitron SystemsTechnology, Inc. Allrights reserved.
091-18481-001B 9/07
Managementis accomplishedbyusing aNetworkManagement
Module (NMM) or a media converter with integrated management
(such as an iConverter 10/100M2) that provides monitoring,
remote configuration and trap notification. The management
modulecan beaccessed viaSNMP,Telnet andvia aserial port.
TheSNMP-basedmanagementisaccomplished viaOmnitron’s
intuitive,graphic-orientedNetOutlook management softwareor
third party SNMP management software. Management via
the Telnet and the serial interfaces have an easy-to-use,
menu-driveninterface.
Someof thereal-time4TxVTparameters thatcanbemonitored
include link and data receive status. Other parameters include
moduletype andmodel,hardware andsoftwarerevisions,serial
numbersand auser-definedidentifier.
The user can override the 4Tx VT module’s physical switch
settingsbyusing SNMPorTelnet toremotely configureswitch-
selectable parameters such as auto-negotiation, Half or
Full-Duplex,andBackplane Selection.
InadditiontoallstandardiConverter SNMPtrapssuchasmodule
insertionandremoval, the4Tx VTmodulescan generatetraps
on port state changes including link-up and link-down. Trap
monitoring of specific events can be selectively enabled or
disabledbythe networkadministrator.
TheiConverter familyofmanagedfiberaccessmediaconverters
are used in Service Provider access networks and Enterprise
LANs. iConverter media converters provide fiber connectivity
with copper to fiber, multimode fiber to single-mode fiber, or
dualfiber tosingle-fiber conversions.
Model Type Connectors Distance
8481-4 RJ-45 x 4 100m
For wide temperature (-40 to 60º C) modules, add a "W" to the end of
the model number. Consult factory for other configurations and extended
temperature (-40 to +75º C) modules.
Model Type 4Tx VT
Protocols 10BASE-T, 100BASE-TX
UTP Connectors RJ-45
Controls BP Enable, Auto/Man,
10/100, FDX/HDX
LED Displays Power, 10/100 UTP Link
Dimensions W:0.85" x D:4.5" x H:2.8"
Weight 8 oz.
Compliance UL, CE, FCC Class A
Power Requirement 0.7A @ 3.3VDC (typical)
Temperature Standard: 0 to 50º C
Wide: -40 to 60º C
Storage: -40 to 80º C
Humidity 5 to 95% (non-condensing)
Altitude -100m to 4000m
MTBF (hrs) 740,000
