Thank you for purchasing the OMRON Body Composition Monitor.
Before using this unit for the first time, please be sure to read this Instruction Manual
carefully and use the unit safely and properly.
Please keep this Instruction Manual at hand all the time for future reference.
BF206-BT
Bluetooth
®
Body Composition Monitor
IM-BF206-BT-01-02/2010
5328801-9A
HBF-206IT-E_A_M13_100202.pdf
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
20 page x 8 lang x 0.05=8.0 mm
EN

1
EN
BF206-BT
Bluetooth
®
Body Composition Monitor
Intended Use
Medical Purpose
Dear customer,
Thank you for purchasing this high-quality OMRON Body Composition Monitor. The BF-206BT is intended to
measure and display the following body composition:
- Body weight
- Body Fat (in %)
- Skeletal Muscle (in %)
- Visceral Fat (up to 30 levels)
- Body Mass Index (BMI)
- Body Age
In addition, the calculation of the Resting Metabolism Rate (in kcal) determines the daily calorie requirement and
can act as a reference for weight reduction programme.
The unique OMRON 4-sensor technology provides one of the most accurate methods of body measurements.
Suitable Users
The BF206-BT is intended to measure the people matching the following conditions.
• Height: 100.0 to 199.5 cm
• Weight: 150 kg or less
• Age: All users*
* The age range is different according to the measurement parameter.
Please refer to “Setting Items” in the Technical Data Section.
Precautions for Use
Please read this instruction manual carefully before use and for further information on the individual functions.
Contents
Before using the unit
Notes on Safety......................................................................................................2
Information on Body Composition.......................................................................3
Operating instructions
1. Know Your Unit ...............................................................................................5
2. Inserting and Replacing the Batteries ..........................................................5
3. Setting the Date and Time..............................................................................6
4. Setting and Storing Personal Data................................................................7
5. Taking a Measurement ...................................................................................9
6. Measuring Weight Only................................................................................12
7. Viewing the Last Measurement Results .....................................................13
8. Transferring the Data....................................................................................14
9. About the Wireless Communications Function.........................................16
Care and maintenance
10. How to Take Care of and Store the Unit......................................................16
11. Error Displays ...............................................................................................17
12. Troubleshooting............................................................................................17
13. Technical Data...............................................................................................18
Before using the unit
HBF-206IT-E_A_M.book Page 1 Wednesday, March 10, 2010 12:04 PM

2
Notes on Safety
Symbols and definitions are as follows:
Danger:
• Never use this unit in combination with medical
electronic devices such as:
(1) Medical electronic implants such as
pacemakers.
(2) Electronic life support systems such
as an artificial heart/lung.
(3) Portable electronic medical devices such as an
electrocardiograph.
This unit could cause these devices to malfunction,
posing a considerable health risk to users of these
devices.
Warning:
• Do not begin a weight reduction or exercise
program without consulting a doctor or healthcare
provider first.
Self-diagnosis could damage your health.
• Do not use the unit on slippery surfaces, such as a
wet floor.
• Keep the unit out of the reach of young children.
• Do not jump onto the unit, or hop up and down on
the unit.
• Do not use this unit when your body and/or feet are
wet, such as after taking a bath.
• Stand on the unit bare-footed. Attempting to stand
on it with socks on may cause you to slip and result
in injury.
• Do not step on the edge or display area of the unit.
• People with disabilities, or who are physically frail,
should always be assisted by another person when
using this unit. Use a handrail or so when stepping
on the unit.
• If battery fluid should get in your eyes, immediately
rinse with plenty of clean water. Consult a doctor
immediately.
Caution:
• This unit is intended for home use only. It is not
intended for professional use in hospitals or other
medical facilities. This unit does not support the
standards required for professional use.
• Do not disassemble, repair, or remodel the unit.
• Do not use mobile phones near the unit except for
wireless communications.
• Do not use batteries not specified for this unit. Do
not insert the batteries with the polarities in the
wrong direction.
• Replace worn batteries with new ones immediately.
• Do not dispose of batteries in fire.
• If battery fluid should get on your skin or clothing,
immediately rinse with plenty of clean water.
• Remove the batteries from this unit when you are
not going to use it for a long period of time
(approximately three months or more).
• Do not use different types of batteries together.
• Do not use new and worn batteries together.
• Always wash your feet before using the unit if you
are suffering from a foot infection or other skin
disease.
Failure to do so could infect others.
When the unit will be used by several people, wipe
the unit with a damp cloth moistened with mild
detergent after using it. Then wipe it dry.
General Advice:
• Do not place this unit on a cushioned floor surface
such as on a carpet or a mat. Correct measurement
may not be possible.
• Do not place this unit in highly humid environments
and protect it from splashing water.
• Do not place this unit near heat sources or below
air conditioners and avoid direct sunlight.
• Do not step on the display or buttons of this unit.
• Do not use this unit for purposes other than
described in this manual.
• As this unit is a precision instrument, do not drop,
vibrate, or apply strong shock.
• Disposal of used batteries should be carried out in
accordance with the national regulations for the
disposal of batteries.
• Do not wash the unit with water.
• Do not wipe the unit with benzene, gasoline, paint
thinner, alcohol, or other volatile solvents.
• Do not place this unit where it will be exposed to
chemicals or corrosive vapors.
Read and follow the “Important information regarding
Electro Magnetic Compatibility (EMC)” in the
Technical Data Section.
Danger: Improper use may cause danger resulting in death or serious injury.
Warning: Improper use may result in possible death or serious injury.
Caution: Improper use may result in injury or property damage.
HBF-206IT-E_A_M.book Page 2 Wednesday, March 10, 2010 12:04 PM

3
EN
Information on Body Composition
Principle of body composition calculation
Body fat has low electric conductivity
The BF206-BT measures the body fat percentage by the Bioelectrical Impedance (BI) method. Muscles, blood
vessels and bones are body tissues with a high water content that conducts electricity easily. Body fat is tissue that
has little electric conductivity. The BF206-BT sends an extremely weak electrical current of 50 kHz and less than
500 μA through your body to determine the amount of fat tissue. This weak electrical current is not felt while operating
the BF206-BT.
In order for the scale to determine body composition, it uses the electrical impedance, along with your height,
weight, age and gender information to generate results based on OMRON’s data of body composition.
Recommended measurement times
Understanding the normal changes in your body fat percentage can help you in preventing or reducing obesity.
Being aware of the times when the body fat percentages shift within your own daily schedule will assist you in
obtaining an accurate trending of your body fat. It is recommended to use this unit in the same environment and
daily circumstances. (See chart)
Avoid Taking Measurements Under the Following Conditions:
- Immediately after vigorous exercise, after a bath or sauna.
- After drinking alcohol or a large amount of water, after a meal (about 2 hours).
If a measurement is taken under these physical conditions, the calculated body composition may differ significantly
from the actual one because the water content in the body is changing.
What is BMI (Body Mass Index)?
BMI uses the following simple formula to indicate the ratio between weight and height of a person.
BMI = weight (kg) / height (m) / height (m)
The OMRON BF206-BT uses the height information stored in your personal profile number or when entering
information in the Guest Mode to calculate your BMI classification.
If the fat level revealed by BMI is higher than the international standard, there is an increased likelihood of common
diseases. However, not all types of fat can be revealed by BMI.
Daily activities
Waking up
Breakfast
Lunch
Taking a bath or
eating dinner
Going to bed
2 hours
2 hours
2 hours
Recommended time
Recommended time
Recommended time
Recommended time
Before going to bed and about 2
hours or more after dinner or bath
Before lunch and about 2 hours or
more after breakfast
After waking up
In the afternoon about 2 hours or
more after lunch and before taking
a bath or eating dinner
Avoid measurement immediately
after eating or bathing.
HBF-206IT-E_A_M.book Page 3 Wednesday, March 10, 2010 12:04 PM

4
Information on Body Composition
What is Body Fat Percentage?
Body fat percentage refers to the amount of body fat mass in regards to the total body weight expressed as a
percentage.
Body fat percentage (%) = {Body fat mass (kg) / Body weight (kg)} × 100
The device uses BI method to estimate your body fat percentage.
Depending on where fat is distributed in the body, it is classified as visceral fat or subcutaneous fat.
What is Visceral Fat Level?
Visceral fat = fat surrounding internal organs
Too much visceral fat is thought to be closely linked to increased levels of fat in the
bloodstream, which can lead to common diseases such as hyperlipidemia and
diabetes, which impairs the ability of insulin to transfer energy from the bloodstream
and using it in cells. In order to prevent or improve conditions of common diseases,
it is important to try and reduce visceral fat levels to an acceptable level. People
with high visceral fat levels tend to have large stomachs. However, this is not
always the case and high visceral fat levels can lead to metabolically obese.
Metabolically obese (visceral obesity with normal weight) represents fat levels that
are higher than average, even if a person’s weight is at or below the standard for
their height.
What is Subcutaneous Fat?
Subcutaneous fat = fat below the skin
Subcutaneous fat not only accumulates around the stomach but also around the
upper arms, hips and thighs, and can cause a distortion of the body's proportions.
Although not directly linked to increased risk of disease, it is thought to increase
pressure on the heart and other complications. Subcutaneous fat is not displayed in
this unit, but is included in the body fat percentage.
What is Skeletal Muscle?
Muscle is divided into two types, muscle in internal organs, such as the heart, and skeletal muscle attached to
bones that is used to move the body. Skeletal muscle can be increased through exercise and other activity.
Increasing the ratio of skeletal muscle means that body can burn energy more easily, which means that it is less
likely to turn to fat, and makes it easier to lead an energetic lifestyle.
What is Resting Metabolism?
Regardless of your activity level, a minimum level of caloric intake is required to sustain the body’s
everyday functions. Known as the resting metabolism, this indicates how many calories you need to
ingest in order to provide enough energy for your body to function.
What is Body Age?
Body age is based on your resting metabolism. Body age is calculated by using your weight, body fat percentage
and skeletal muscle percentage to produce a guide to judge whether your body age is above or below the average
for your actual age. To know your body age is useful to improve your health condition.
The reason calculated results may differ from actual body fat percentage
The body fat percentage measured by this unit may significantly differ from the actual body fat percentage in
the following situations:
Elderly people (over 81 years old) / People with a fever / Body builders or highly trained athletes / Patients
undergoing dialysis / Patients with osteoporosis who have very low bone density / Pregnant women / People
with swelling
These differences may be related to changing ratios of body fluid and/or body composition.
Sample Visceral Fat
(MRI image)
Visceral Fat
Subcutaneous Fat
Spine
Sample Subcutaneous Fat
(MRI image)
Visceral Fat
Subcutaneous Fat
Spine
HBF-206IT-E_A_M.book Page 4 Wednesday, March 10, 2010 12:04 PM

5
EN
1. Know Your Unit
About the Alarm
The alarm will beep under the following conditions:
• When the power is turned on: Blip!
• When 0.0 kg is displayed and the unit is ready to take a measurement: Blip! Blip!
• When a measurement is completed: Blip, Beep!
• When an error message “Err” appears: Blip! Blip! Blip! Blip! Blip! (A rapid series of short beeps.)
• When data has been sent successfully: Blip! Blip!
• When data failed to be sent: Beep! Beep! Beep! (A series of three long beeps.)
2. Inserting and Replacing the Batteries
1. Open the battery cover on the back of
the unit.
1) Press the tab on the battery cover in the
direction of the arrow to release the cover
as illustrated.
2) Pull the tab of the cover upwards.
2. Install the batteries in correct polarity
as marked inside the battery
compartment.
3. Close the battery cover.
Display and Buttons
Main Unit
Battery Low Indicator
Display
The illustration shows all display items.
(When used, the unit does not display all
the items at the same time.)
Err/OK/P Indicators
Foot Electrodes
Feet (x4) WEIGHT/OFF Button
Turns the power ON and selects
weight only measurement.
Foot Electrodes
Personal Profile Number Button
Turns the power ON and selects
body composition measurement.
UPLOAD Button
GUEST/ MEMO Button
Turns the power ON and
selects Guest mode.
SET/MODE Button
Tab
Battery Life and Replacement
When the battery low indicator ( ) appears,
replace all four batteries with new ones.
Items stored in memory are retained even if the
batteries are removed.
• Replace the batteries after turning off the power.
• Disposal of used batteries should be carried out
in accordance with the national regulations for
the disposal of batteries.
• Four AA alkaline batteries will last
approximately six months (when measurements
and data transfers are made four times a day).
• Because the supplied batteries are for trial use
only, they may have a shorter life.
Operating instructions
HBF-206IT-E_A_M.book Page 5 Wednesday, March 10, 2010 12:04 PM

6
3. Setting the Date and Time
When the power is turned on for the first time, it is necessary to set the date and time.
1. Press the WEIGHT/OFF button to
turn on the power.
When the power is turned on for the first time,
the year digits blink.
2. [TO SET THE YEAR]
1) Press the GUEST/ MEMO button to
adjust the year and press the SET/MODE
button to confirm.
• Setting range: 2010 to 2030
• Press continuously to rapidly advance in
increments of 10.
3. [TO SET THE MONTH AND DAY]
1) Press the GUEST/ MEMO button to
adjust the month and press the SET/MODE
button to confirm.
2) Press the GUEST/ MEMO button to
adjust the day and press the SET/MODE
button to confirm.
• Press continuously to rapidly advance in
increments of 10.
4. [TO SET THE HOUR AND MINUTE]
1) Press the GUEST/ MEMO button to
adjust the hour and press the SET/MODE
button to confirm.
• This is the 24-hour clock.
2) Press the GUEST/ MEMO button to
adjust the minute and press the SET/
MODE button to confirm.
• Press continuously to rapidly advance in
increments of 10.
The current settings for the year, month and
day, hour and minute appear in this sequence
on the display. The power is automatically
turned off.
This completes the setting.
Notes:
• If you need to correct while you are making settings:
Press the WEIGHT/OFF button to turn the power off and on again. The year digits blink, proceed from step 2 of
the procedure.
• If the power goes off while you are making settings:
The power is automatically turned off if no information is entered for 3 minutes when setting the date and time.
Press the WEIGHT/OFF button to turn the power off and on again.
• If you have to correct the date and time you have set:
Press the WEIGHT/OFF button, and press the SET/MODE button for 2 seconds or longer after “0.0 kg” appears
on the display.
The year digits blink, proceed from step 2 of the procedure.
Power Switch
The power will automatically switch off in the following conditions:
1. If the monitor is not used within one minute of “0.0 kg” appearing on the display.
2. If no information is entered for 3 minutes when setting the date and time.
3. If no information is entered for 3 minutes when entering personal data.
4. If the monitor is not used for 3 minutes after the measurement results or last (previous) measurement
results are displayed.
5. 30 seconds after the result is displayed when measuring weight only.
6. 10 seconds after “Err” appears on the display.
Note: “OFF” appears on the display when the power is turned off.
HBF-206IT-E_A_M.book Page 6 Wednesday, March 10, 2010 12:04 PM

7
EN
4. Setting and Storing Personal Data
For the correct measurement of body composition, it is necessary to set your personal data (birth date, gender,
height). The monitor saves up to four personal profiles.
1. Press the Personal Profile Number
button to select your personal profile
number.
The current date appears on the display, then
the display changes to the birth date (1940).
Note: When the date of birth, rather than
current date, is displayed, the settings
for that personal profile number are
finished. Please use a different
number or delete your personal profile
information. Refer to Section 4,
Deleting the Personal Data to delete
the personal data.
2. [TO SET THE BIRTH DATE]
Setting range: 1900 to 2030
Press continuously to rapidly advance in
increments of 10.
1) Press the GUEST/ MEMO button to
adjust the birth year and press the SET/
MODE button to confirm.
2) Press the GUEST/ MEMO button to
adjust the birth month and press the SET/
MODE button to confirm.
3) Press the GUEST/ MEMO button to
adjust the birth day and press the SET/
MODE button to confirm.
3. [TO SET THE GENDER AND
HEIGHT]
Set the gender (MALE) or (FEMALE) and
height in the same way.
After all the settings are displayed for your
confirmation, “0.0 kg” appears on the display.
This completes the setting.
You can now take measurements of your body
composition.
Selecting Measurement Unit
You can change the measurement units used for the height and weight settings.
1. Press the WEIGHT/OFF button to
turn on the power.
The current date appears on the display, then
the display changes to “0.0 kg”.
2. Keep the GUEST/ MEMO button
pressed for 2 seconds until “lb” and
“kg” blink on the display.
3. Press the GUEST/ MEMO button
to select “kg” or “lb”.
This will also automatically change “cm” and
“inch”.
4. Press the SET/MODE button to
confirm.
All height and weight measurements are displayed
using the new measurement units. The change
remains in effect until you change it again.
HBF-206IT-E_A_M.book Page 7 Wednesday, March 10, 2010 12:04 PM

8
4.Setting and Storing Personal Data
Changing the Personal Data
1. Press the Personal Profile Number
button to select your personal profile
number.
The birth date appears on the display, then
the display changes to “0.0 kg”
Wait until “0.0 kg” appears on the display.
2. Change the personal data.
1) While “0.0 kg” is displayed, press the
SET/MODE button.
The birth year blinks on the display.
2) Refer to step 2 and 3 in Section 4, Setting
and Storing Personal Data to change the
personal data.
3. Press the WEIGHT/OFF button to
turn off the power or take a
measurement. (Refer to section 5
“Taking a Measurement”.)
Deleting the Personal Data
1. Press the Personal Profile Number
button to select the personal profile
number you want to delete.
The birth date appears on the display, then
the display changes to “0.0 kg”.
Wait until “0.0 kg” appears on the display.
2. Delete the personal data.
1) While “0.0 kg” is displayed, press the
SET/MODE button.
The birth year blinks on the display.
2) Press and hold the GUEST/ MEMO
button until “- - - -” and “DEL” blink on the
display.
3) Press the SET/MODE button.
“DEL OK?” blinks on the display.
4) Press the SET/MODE button.
“Clr” appears on the display and the birth
year setting appears on the display.
Note: To cancel deleting, press the
GUEST/ MEMO button.
3. Press the WEIGHT/OFF button to
turn off the power.
HBF-206IT-E_A_M.book Page 8 Wednesday, March 10, 2010 12:04 PM

9
EN
5. Taking a Measurement
Measurement should be taken on a level and hard surface.
1. Press the Personal Profile Number
button to turn on the power.
The birth date appears on the display, then the
display changes to “0.0 kg”.
Note: If you step onto the unit before “0.0 kg”
appears on the display, an error
message “Err” will appear.
If the following display is indicated:
Your personal data is not stored in the personal
profile number you have selected. Please see
Section 4 to store personal data.
2. Start measurement.
1) Step on the unit bare-footed and place your
feet on the foot electrodes with your weight
evenly distributed.
2) During body composition measurement,
“ “ moves to show the measurement is
progressing.
3) After the measurement is complete, your
weight is displayed again. At this point you
may step off the unit.
Postures to Avoid During Measurement
Incorrect posture may result in inaccurate measurement of body composition.
If you do not have personal data
stored on the unit (GUEST
mode):
1) Press the GUEST/ MEMO
button to turn on the power.
The current date appears on the
display, then “GUEST” appears
and the birth year (1940) blinks on
the display.
2) Set the birth date, gender and
height. Read steps 2 and 3 in
Section 4, Setting and Storing
Personal Data.
Bluetooth
BF206-BT
WEIGHT/OFF1234
The unit will then start to measure your
body composition.
The display will show your weight and then
the weight result will blink twice.
Standing on edge of the unit Knees bent Crouching
HBF-206IT-E_A_M.book Page 9 Wednesday, March 10, 2010 12:04 PM

10
5.Taking a Measurement
3. Check the measurement results.
The results display rotates automatically.
To stop the automatic rotation of results, or to view other measurement values, press the
SET/MODE button.
The display changes with each press of the
SET/MODE button, as shown below.
Note: Use the bar indicator as a guide to measurement.
Skeletal Muscle Percentage Classification
[WEIGHT] [BODY FAT PERCENTAGE]
[RESTING METABOLISM]
Visceral Fat Level Classification
[BODY AGE]
[SKELETAL MUSCLE PERCENTAGE]
[VISCERAL FAT LEVEL]
[BMI]
Body Fat Percentage
Classification
HBF-206IT-E_A_M.book Page 10 Wednesday, March 10, 2010 12:04 PM

11
5.Taking a Measurement
EN
Interpreting the Body Fat Percentage Result
Based on NIH/WHO guidelines for BMI
Based on Gallagher et al., American Journal of Clinical Nutrition, Vol.72, Sept. 2000
Interpreting the Visceral Fat Level Result
According to OMRON HEALTHCARE figures
Interpreting the BMI Result
The above-mentioned indices refer to the values for obesity judgment proposed by WHO, the World Health Organization.
Interpreting the Skeletal Muscle Percentage Result (for adults)
According to OMRON HEALTHCARE figures
4. Press the WEIGHT/OFF button to turn off the power.
Gender Age – (Low) 0 (Normal) + (High) ++ (Very High)
Female
20-39 < 21.0% 21.0 - 32.9% 33.0 - 38.9% 39.0%
40-59 < 23.0% 23.0 - 33.9% 34.0 - 39.9% 40.0%
60-80 < 24.0% 24.0 - 35.9% 36.0 - 41.9% 42.0%
Male
20-39 < 8.0% 8.0 - 19.9% 20.0 - 24.9% 25.0%
40-59 < 11.0% 11.0 - 21.9% 22.0 - 27.9% 28.0%
60-80 < 13.0% 13.0 - 24.9% 25.0 - 29.9% 30.0%
Visceral Fat Level Level Classification
1 - 9 0 (Normal)
10 - 14 + (High)
15 - 30 ++ (Very High)
BMI BMI (Designation by the WHO)
BMI < 18.5 Underweight
18.5 BMI < 25 Normal
25 BMI < 30 Overweight
30 BMI Obese
Gender Age – (Low) 0 (Normal) + (High) ++ (Very High)
Female
18-39 < 24.3% 24.3 - 30.3% 30.4 - 35.3% 35.4%
40-59 < 24.1% 24.1 - 30.1% 30.2 - 35.1% 35.2%
60-80 < 23.9% 23.9 - 29.9% 30.0 - 34.9% 35.0%
Male
18-39 < 33.3% 33.3 - 39.3% 39.4 - 44.0% 44.1%
40-59 < 33.1% 33.1 - 39.1% 39.2 - 43.8% 43.9%
60-80 < 32.9% 32.9 - 38.9% 39.0 - 43.6% 43.7%
>
_
_
>
_
_
>
_
_
>
_
_
>
_
_
>
_
_
>
_
_
>
_
_
>
_
_
>
_
_
>
_
_
>
_
_
>
_
_
>
_
_
>
_
_
HBF-206IT-E_A_M.book Page 11 Wednesday, March 10, 2010 12:04 PM

12
6. Measuring Weight Only
1. Press the WEIGHT/OFF button to
turn on the power.
The current date appears on the display, then
the display changes to “0.0 kg”.
Note: If you step onto the unit before “0.0 kg”
appears on the display, an error
message “Err” will appear.
2. When the “0.0 kg” is displayed, step
onto the unit.
3. Check the measurement result.
Your weight is displayed and blinks twice to
indicate that measurement is completed.
4. When the measurement is completed,
step down from the unit and turn off
the power.
HBF-206IT-E_A_M.book Page 12 Wednesday, March 10, 2010 12:04 PM

13
EN
7. Viewing the Last Measurement Results
Up to 30 measurement results are automatically stored for each personal profile number and the last (previous)
measurement results can be displayed for this unit.
Note: When using the Guest mode, measurement results are not stored.
1. Press the Personal Profile Number
button to turn on the power.
2. Take a measurement.
If you want to compare the results with the last
(previous) values, measure your body
composition.
3. Press GUEST/ MEMO button.
The last weight value is displayed.
If you have measured your body composition in
step 2, each press of the GUEST/ MEMO
button alternates between the current
measurement result and the last (previous)
result.
Notes:
• If there are no results for the last
measurement, “- - - -” is displayed.
• If you have not measured your body
composition in step 2, current measurement
results cannot be displayed even if you press
the GUEST/ MEMO button.
4. Press the SET/MODE button to cycle through the other measurement values.
Note: Refer to Section 8 if you want to transfer the data.
5. Press the WEIGHT/OFF button to
turn off the power.
Last bod
y
fat percenta
g
e
Last visceral fat level
L
ast rest
i
ng meta
b
o
li
sm
L
ast bod
y
a
g
e
L
ast
BMI
L
ast we
i
g
h
t
L
ast s
k
e
l
eta
l
musc
l
e
percen
t
age
Care and maintenance
HBF-206IT-E_A_M.book Page 13 Wednesday, March 10, 2010 12:04 PM

14
8. Transferring the Data
You can transfer measurement data to a Bluetooth®wireless technology device.
You can transfer up to 30 sets of stored measurement results for each personal profile number.
The content and display for the measurement results may vary depending on the application used to view them.
For details, refer to the manual provided with the application you are using.
Registering the Unit with the Destination Device (Pairing)
What is Pairing:
This refers to the procedure for registering the unit with the device so that it can be used to transfer data.
Pairing is required when a device is connected to the unit for the first time, or if the same device is used to
transfer data for a different personal profile number.
Follow the procedure below to pair the unit with the destination device.
Refer to “Transferring the Data” for information about transferring the data with a device that has already been
paired with the unit.
1. Display the measurement results.
• Pairing (Registration) after taking a
measurement:
Follow the steps in Section 5, to display the
measurement results.
• Pairing (Registration) without taking a
measurement:
Follow the steps in Section 7, to display the
results for the last measurement.
• Pairing (Registration) when using GUEST
mode:
You can also register a device after taking a
measurement using GUEST mode.
Follow the steps in Section 5, to display the
measurement results.
2. Enable pairing (registration) on the
device.
Set the application on the device ready for
pairing.
For details, refer to the manual provided with
the application you are using.
3. Press the UPLOAD button for
2seconds or longer.
Use the application to pair the unit with the
device.
For details, refer to the manual provided with
the application you are using.
Note: If you press the UPLOAD button
while pairing, pairing will be stopped
and the display will revert to the
previous screen.
If the pairing completes successfully, the “P”
indicator lights and the alarm will beep (Blip!
Blip!).
Notes:
• If the pairing process does not complete
within approximately one minute, it will end
without paring the unit with the device.
• If the pairing process does not complete
successfully, then the “Err” indicator lights
and the alarm will beep three times (Beep!
Beep! Beep!).
Check the application on the connected
device, then repeat the procedure from step
2 to try again.
HBF-206IT-E_A_M.book Page 14 Wednesday, March 10, 2010 12:04 PM

15
8.Transferring the Data
EN
Transferring the Data
1. Display the measurement results.
• Transferring data after taking a
measurement:
Follow the steps in Section 5, to display the
measurement results.
• Transferring data without taking a
measurement:
Follow the steps in Section 7, to display the
results for the last measurement.
• Transferring data when using GUEST
mode:
You can also register a device after taking a
measurement using GUEST mode.
Follow the steps in Section 5, to display the
measurement results.
Note: When using GUEST mode, you
cannot send results stored on the
unit, you can only send the
measurement results for the current
measurement.
2. Enable data transfers.
Set the application on the destination device
to transfer mode.
For details, refer to the manual provided with
the application you are using.
3. Press the UPLOAD button.
The display changes to the data transmission
screen, and the unit starts transferring the data.
Note: If you press the UPLOAD button
while the data is being transferred,
the transfer will be stopped and the
display will revert to the previous
screen.
If the data is sent successfully, the “OK”
indicator lights and the alarm will beep (Blip!
Blip!).
Note: If the data transmission fails, then
the “Err” indicator lights and the
alarm will beep three times (Beep!
Beep! Beep!).
Check the application on the
connected device, then repeat the
procedure from step 2 to try again.
The screen will return to the screen displayed
before data transmission started after
10 seconds.
4. Press the WEIGHT/OFF button to
turn off the power.
About Data FULL Indicator
Up to 30 sets of measurement results can be stored for each personal
profile number.
If the number exceeds 30, the oldest results are deleted.
If the Data FULL indicator blinks or remains lit, transfer data to a device
as soon as possible to avoid losing measurement results.
blinks: 24-29 sets of measurement results have been stored.
lit: 30 sets of measurement results have been stored.
Note: The Data FULL indicator is not displayed when only 0 to 23 measurements results are stored.
Data FULL Indicator
HBF-206IT-E_A_M.book Page 15 Wednesday, March 10, 2010 12:04 PM

16
9. About the Wireless Communications Function
10. How to Take Care of and Store the Unit
This Bluetooth®Body Composition Monitor does not require any maintenance.
How to Clean the Unit
• Always keep the unit clean before use.
• Wipe the unit with a soft dry cloth.
If necessary, use a cloth moistened with water or detergent and squeeze it well before wiping the unit, then wipe
dry with a dry cloth.
• You can use cleaning alcohol to clean the electrodes, but do not use it on other parts of the unit.
• Do not use benzene or thinner, to clean the unit.
Care and Storage
• Do not store the unit in the following conditions:
- Humidity, where moisture or water may get into the unit
- High temperatures, direct sunlight or dusty places
- Places with the risk of sudden shocks or vibrations
- In places where chemicals are stored or where corrosive gas is present.
• Do not carry out repairs of any kind yourself. If a defect occurs, consult the OMRON distributor or Customer
Services as mentioned on the packaging.
Hereby, OMRON HEALTHCARE Co.,Ltd, declares that this Body Composition Monitor is in
compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
The declaration of conformity may be consulted at www.omron-healthcare.com.
This Product operates in the unlicensed ISM band at 2.4GHz. In case this Product is used
around the other wireless devices including microwave oven and wireless LAN, which operate
same frequency band of this Product, there is a possibility that interference occurs between
this Product and such other devices. If such interference occurs, please stop the operation of
other devices or relocate this Product before using this Product or do not use this Product
around the other wireless devices.
The Bluetooth®word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
and any use of such marks by OMRON HEALTHCARE Co.,Ltd. is under license. Other
trademarks and trade names are those of their respective owners.
Look for the Continua Certified logo. It’s your assurance that a device will reliably communicate
and exchange information with similarly certified products, to help you better manage your
health and wellness.
HBF-206IT-E_A_M.book Page 16 Wednesday, March 10, 2010 12:04 PM

17
EN
11. Error Displays
12. Troubleshooting
Error Display Cause Correction
Your soles are not in firm contact with the
electrodes.
Press your soles firmly to the electrodes, then
measure. (Refer to Section 5.)
The posture for measurement is wrong
or the soles are not in firm contact with
the electrodes.
Measure without moving the soles. (Refer to
Section 5.)
The soles are too dry. Moisten the soles with a wet towel, then repeat
measurement.
Device error.
Insert the batteries again and repeat
measurement.
If this error still occurs, consult your OMRON
service representative.
You stepped on or moved the unit before
the display indicated “0.0 kg”.
Step on the unit after the display indicates
“0.0 kg”.
You moved your body while measuring
body weight. Do not move while measuring body weight.
Your weight is more than 150 kg (330.0 lb).
Body weight of more than 150 kg (330.0 lb) is
out of the measuring range of this unit. You
cannot use this unit.
Problem Cause Correction
The displayed value of body
composition is abnormally high or low. Refer to “Information on Body Composition”.
“- - - -” is displayed for some items of
the measurement results.
Values of body composition are out
of measurable range.
• Please ensure that birth date,
gender and height settings stored
as personal data are correct. (Refer
to Setting Items in Section 13.)
• The unit cannot measure body
composition outside its
measurement range, even if the
settings are correct.
The power turns off after the body
weight is confirmed and before your
body fat percentage, visceral fat level,
skeletal muscle percentage, BMI and
resting metabolism is measured.
You did not select the correct
personal profile number or the
GUEST mode. (The personal
profile number or “GUEST” is not
displayed on the display unit.)
Select the correct personal profile
number or the GUEST mode.
(Refer to Section 5.)
Nothing is displayed when the power
is turned on.
Batteries are not inserted. Insert the batteries.
The polarities of batteries are not
aligned correctly.
Insert the batteries in correct
alignment.
The batteries are worn out. Replace all four batteries with new
ones. (Refer to Section 2.)
Data cannot be sent.
(“Err” indicator lights.)
The destination device for the data
is too far away.
After checking that there are no
sources of interference nearby,
move the device to a distance
within 5 m of the unit.
Pairing (registering) has not been
completed.
Perform pairing (registration).
(Refer to Section 8.)
The application on the connected
device is not ready.
Check the application then try
sending the data again.
If the “Err” indicator still lights after
checking the application, contact
the service (support) center of the
application provider.
HBF-206IT-E_A_M.book Page 17 Wednesday, March 10, 2010 12:04 PM

18
13. Technical Data
Note: Subject to technical modification without prior notice.
This device fulfills the provisions of the EC directive 93/42/EEC (Medical Device Directive).
Product Bluetooth®Body Composition Monitor
Model BF206-BT (HBF-206IT-E)
Display
Body Weight: 0 to 150 kg with an increment of 0.1 kg
(0.0 to 330.0 lb with an increment of 0.2 lb)
Body Fat percentage: 5.0 to 60.0% with an increment of 0.1%
Skeletal Muscle percentage: 5.0 to 50.0% with an increment of 0.1%
BMI: 7.0 to 90.0 with an increment of 0.1
Resting Metabolism: 385 to 3999 kcal with an increment of 1 kcal
Body Age: 18 to 80 years old with an increment of 1 year
Visceral Fat Level: 30 levels with an increment of 1 level
Body fat percentage and Skeletal muscle percentage classification:
– (Low) / 0 (Normal) / + (High) / ++ (Very High) 4 levels with 3 sublevels each
Visceral fat level classification:
0 (Normal) / + (High) / ++ (Very High) 3 levels with 3 sublevels each
Memory Display memory: Last (previous) measurement results
Unit stored memory: Up to 30 sets
Transmission Protocol
Bluetooth
®
wireless technology Version 2.1 + EDR Class 2
Setting Items Personal data information:
The following information for up to 4 people can be stored.
Height: 100.0 to 199.5 cm (3' 4" to 6' 6 3/4")
Birth Date: 1st January, 1900 to 31st December, 2030
Gender: Male/Female
* Measurement Units: kg (cm) / lb (feet•inch)
* The age range for the Body Fat percentage is 10 to 80 years old.
* The age range for the Skeletal Muscle percentage, Skeletal Muscle percentage
classification, Resting Metabolism rate, Visceral Fat level, Visceral Fat level
classification and Body age is 18 to 80 years old.
* The age range for the Body Fat percentage classification is 20 to 80 years old.
Weight Accuracy
0.0 kg to 40.0 kg: ± 0.4 kg
(0.0 lb to 88.2 lb:
± 0.88 lb)
40.0 kg to 150.0 kg:
± 1%
(88.2 lb to 330.0 lb:
± 1%)
Accuracy (S.E.E.) Body Fat percentage: 3.5%
Skeletal Muscle percentage: 3.5%
Visceral Fat Level: 3 levels
Power Supply 4 AA alkaline batteries (LR6)
Battery Life Approximately six months (When AA alkaline batteries are used with four
measurements and data transfers a day at a room temperature of 23°C.)
Operating Temperature /
Humidity
+10°C to +40°C, 30% to 85% RH
Storage Temperature/
Humidity/Air Pressure
-20°C to +60°C, 10% to 95% RH, 700 hPa - 1060 hPa
Weight Approximately 1.8 kg (3.97 lb) (including batteries)
External Dimensions Approx. 300 (W) × 38 (H) × 290 mm (D)
(Approx. 11 3/4" (W) × 1 1/2" (H) × 11 3/8" (D))
Package Contents
Bluetooth
®
Body Composition Monitor, 4 AA alkaline batteries (LR6), instruction
manual, Guarantee Card
= Type BF
HBF-206IT-E_A_M.book Page 18 Wednesday, March 10, 2010 12:04 PM

19
13.Technical Data
EN
Correct Disposal of this Product
(Waste Electrical & Electronic Equipment)
This marking shown on the product or its literature, indicates that it should not be disposed with other
household wastes at the end of its working life. To prevent possible harm to the environment or human health
from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to
promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government
office, for details of where and how they can take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product should not be mixed with other commercial wastes for disposal.
This product does not contain any hazardous substances.
Disposal of used batteries should be carried out in accordance with the national regulations for the disposal of
batteries.
Important information regarding Electro Magnetic Compatibility (EMC)
With the increased number of electronic devices such as PCs and mobile (cellular) telephones, medical
devices in use may be susceptible to electromagnetic interference from other devices.
Electromagnetic interference may result in incorrect operation of the medical device and create a potentially
unsafe situation.
Medical devices should also not interfere with other devices.
In order to regulate the requirements for EMC (Electro Magnetic Compatibility) with the aim of preventing
unsafe product situations, the EN60601-1-2 standard has been implemented. This standard defines the levels
of immunity to electromagnetic interferences as well as maximum levels of electromagnetic emissions for
medical devices.
This medical device manufactured by OMRON HEALTHCARE conforms to this
EN60601-1-2:2007 standard for both immunity and emissions.
Nevertheless, special precautions need to be observed:
Do not use mobile (cellular) telephones and other devices, which generate strong electrical or electromagnetic
fields, near the medical device. This may result in incorrect operation of the unit and create a potentially unsafe
situation. Recommendation is to keep a minimum distance of 7 m.
Verify correct operation of the device in case the distance is shorter.
Further documentation in accordance with EN60601-1-2:2007 is available at OMRON HEALTHCARE
EUROPE at the address mentioned in this instruction manual.
Documentation is also available at www.omron-healthcare.com.
HBF-206IT-E_A_M.book Page 19 Wednesday, March 10, 2010 12:04 PM
