CIMR-G7C
Varispeed G7
World first three level inverter architecture
• 3 level control (400 V class)
• Current vector control and V/F with or without PG
• Torque control (closed loop and open loop)
• Silent operation
• Rotary and stationary autotuning
• High slip braking function
• Energy saving function standard
• LCD operator
• Embedded OMRON PLC functionality with
PLC option card
• Standard RS-485 communications - Modbus
• Fieldbus options: DeviceNet, PROFIBUS, CANOpen,
LONworks, ethernet
• PC configuration tool CX-drive and DriveWorksEZ.
• CE, UL, and cUL marking
• Customised application software
Ratings
• 200 V Class three-phase 0.4 to 110 kW
• 400 V Class three-phase 0.4 to 300 kW
System configuration
C22
R52
C24
PE
C16
U11
U8
R6
C26 C28
JP3
U6
U7
T1
U9
+
+
R15
R15
R25
R15
R20
R30
R7
R5
C5
R21
U14
C17
R14
R28
RR11
JP1
C1
U10
C3
R5
R1
R2
R36
R3
C21
R35
R70
R120
R75
R78
R114
C2
2
+
+
U1
+
C35 R99
U12
R95
R39
R40
R57
R56
D6
R6
U15
R54
R55
R8
TR2
11
R11
R110
R107
R113
TR1
C13
U13
C10
SI-N
CODENo.
U17
73600-C0210
JP5JP6RT4
R10
R10
R105
R102
C12
C11
R94
R97
R96
C20
R95
C39
R131
Y1
U10
C33
Communication
option cards
Monitor option card
3G3IV-PCN329-E
Inverter to PC cable
3G3IV-PCN126/326
Digital operator
extension cable
JVOP-161-OY
Digital operator
(LED display)
JVOP-160 OY
Digital operator
(LCD display)
CX-Drive
DriveWorkEZ
Line filter Braking accessories
Feedback speed
control card
PLC option card
Varispeed
G7
Reference
option cards
Y203-EN2-02-Katalog.book Seite 249 Mittwoch, 24. Mai 2006 2:22 14

250 Frequency inverters
Specifications
Type designation
200 V class1
1. The main circuit of 200 V class inverters uses 2-level control method.
Model CIMR-G7C20P4 20P7 21P5 22P2 23P7 25P5 27P5 2011 2015 2018 2022 2030 2037 2045 2055 2075 2090 2110
Max. applicable
motor output2
2. Standard 4-pole motors are used for max. applicable motor output. Choose the inverter model whose rated current is allowable within the motor rated
current range.
kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75 90 110
Output
characteristics
Inverter capacity kVA 1.2 2.3 3.0 4.6 6.9 10 13 19 25 30 37 50 61 70 85 110 140 160
Rated current A3.2 6 8 12 18 27 34 49 66 80 96 130 160 183 224 300 358 415
Max. voltage 3-phase, 200/208/220/230/240 V (proportional to input voltage)
Max. output frequency 400 Hz (programmable)
Power
supply
Rated input voltage and
frequency 3-phase 200/208/220/230/240 V, 50/60 Hz3
3. When using the inverter of 200 V class 30 kW or more with a cooling fan of three-phase 230 V 50 Hz or 240 V 50/60 Hz power supply, a transformer for
the cooling fan is required.
Allowable voltage
fluctuation +10%, -15%
Allowable frequency
fluctuation ±5%
Harmonic
wave
prevention
DC reactor Option Provided
12-pulse input Not available Available4
4. A 3-wired transformer is required at 12-pulse input.
400 V class1
1. The main circuit of 400 V class inverters uses 3-level control method.
Model CIMR-G7C40P4 40P7 41P5 42P2 43P7 45P5 47P5 4011 4015 4018 4022 4030 4037 4045 4055 4075 4090 4110 4132 4160 4185 4220 4300
Max. applicable
motor output2
2. Standard 4-pole motors are used for max. applicable motor output. Choose the inverter model whose rated current is allowable within the motor rated
current range.
kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75 90 110 132 160 185 220 300
Output
characteristics
Inverter
capacity kVA 1.4 2.6 3.7 4.7 6.9 11 16 21 26 32 40 50 61 74 98 130 150 180 210 250 280 340 460
Rated current A1.8 3.4 4.8 6.2 9 15 21 27 34 42 52 65 80 97 128 165 195 240 270 325 370 450 605
Max. voltage 3-phase, 380/400/415/440/460/480 V (proportional to input voltage)
Max. output
frequency 400 Hz (programmable)
Power
supply
Rated input voltage
and frequency 3-phase 380/400/415/440/460/480 V, 50/60 Hz
Allowable voltage
fluctuation +10%, -15%
Allowable frequency
fluctuation ±5%
Harmonic
wave
prevention
DC reactor Option Provided
12-pulse input Not available Available3
3. A 3-wired transformer is required at 12-pulse input.
CIMR – G7 C 4 0P4 0
Inverter Protective enclosure
0: Open chassis type (IP00)
1: Enclosed type (IP20 / NEMA1)
Max. applicable motor output
0P4: 0.4 kW
022: 22 kW
300: 300 kW
G7 series
Specifications
C: European standard
specifications
Voltage
2: 200 V class
4: 400 V class
"P" indicates a decimal
point
[ ]
~
~
Y203-EN2-02-Katalog.book Seite 250 Mittwoch, 24. Mai 2006 2:22 14

Varispeed G7 251
Enclosures
Commom specifications
200 V
class
Model CIMR-G7C20P4 20P7 21P5 22P2 23P7 25P5 27P5 2011 2015 2018 2022 2030 2037 2045 2055 2075 2090 2110
Enclosed type
(IEC IP20) Available as standard Available for option Not
available
Open chassis type
(IEC IP00) Available by removing the upper and lower cover of
enclosed type Available as standard
400 V
class
Model CIMR-G7C40P4 40P7 41P5 42P2 43P7 45P5 47P5 4011 4015 4018 4022 4030 4037 4045 4055 4075 4090 4110 4132 4160 4185 4220 4300
Enclosed type
(IEC IP20) Available as standard Available for option Not available
Open chassis type
(IEC IP00) Available by removing the upper and lower cover of
enclosed type Available as standard
Model number
CIMR-G7CSpecification
Control characteristics
Control method Sine wave PWM Closed loop vector control, open loop vector control 1&2, V/f control, V/f with PG control
Torque characteristics 150% at 0.3 Hz (open loop vector control 2)
150% at 0rpm (closed vector control)
Speed control range 1:200 (open loop vector control 2)
1:1000 (closed loop vector control)
Speed control accuracy ± 0.2% (open loop vector control) ± 0.02% (closed loop vector control)
(25 °C ± 10 °C)
Speed control response 10 Hz (open loop vector control 2)
30 Hz (control with PG)
Torque limits Provided (4 quadrant steps can be changed by constant settings.) (Vector control)
Torque accuracy ± 5%
Frequency range 0.01 to 400 Hz
Frequency accuracy
(temperature characteristics)
Digital references: ± 0.01% (-10 °C to +40 °C)
Analog references: ± 0.1% (25 °C ±10 °C)
Frequency setting
resolution
Digital references: 0.01 Hz
Analog references: 0.025/50 Hz (11 bits plus sign)
Output frequency
resolution 0.001 Hz
Overload capacity and
maximum current 150% of rated output current for 1 minute 200% of rated output current for 0.5 second
Frequency setting signal 0 to +10 V, -10 to +10 V, 4 to 20 mA, pulse train
Accel/decel time 0.01 to 6000.0 s (4 selectable combinations of independent acceleration and deceleration time settings)
Braking torque Approximately 20%
(Approximately 125% with braking resistor option, braking transistor built into Inverters of 15 kW or less)
Main control functions
Restarting after momentary power loss, speed search, overtorque/undertorque detection, torque limits, 17-speed control
(maximum), 4 acceleration and deceleration times, S-curve acceleration/deceleration, 3-wire control, auto-tuning
(rotational or stationary), dwell function, cooling fan ON/OFF control, slip compensation, torque compensation,
auto-restart after fault, jump frequencies, upper and lower limits for frequency references, DC braking for starting and stopping,
high-slip braking, advanced PID control, energy-saving control, MEMOBUS communications
(RS-485/422, 19.2 kbps maximum), 2 motor parameter sets, fault reset and parameter copy function.
Protective functions
Motor protection Protection by electronic thermal overload relay.
Instantaneous
overcurrent protection Stops at approx. 200% of rated output current.
Fuse blown protection Stops for fuse blown.
Overload protection 150% of rated current for 1 minute
200% of rated current for 0.5 second
Overvoltage protection 200 Class Inverter: stops when main-circuit DC voltage is above 410 V.
400 Class Inverter: stops when main-circuit DC voltage is above 820 V.
Undervoltage protection 200 Class Inverter: stops when main-circuit DC voltage is below 190 V.
400 Class Inverter: stops when main-circuit DC voltage is below 380 V.
Momentary power loss ride
through By selecting the momentary power loss method, operation can be continued if power is restored within 2 s.
Cooling fin overheating Protection by thermistor.
Stall prevention Stall prevention during acceleration, deceleration and running independently.
Grounding protection Protection by electronic circuits.
Charge indicator Illuminates when the main circuit DC voltage is approx. 10 VDC or more.
Environment
Ambient operating
temperature -10 °C to 40 °C (enclosed wall-mounted type) -10 °C to 45 °C (open chassis type)
Ambient operating
humidity 95% max. (with no condensation)
Storage temperature - 20 °C to + 60 °C (short-term temperature during transportation)
Application site Indoor (no corrosive gas, dust, etc.)
Altitude 1000 m max.
Vibration 10 to 20 Hz, 9.8 m/s2max.; 20 to 50 Hz, 2 m/s2max
Y203-EN2-02-Katalog.book Seite 251 Mittwoch, 24. Mai 2006 2:22 14

252 Frequency inverters
Dimensions
Open chassis type (IEC IP00)
Voltage Max. applicable motor
output kW
Inverter
CIMR-G7C 
Fig Dimensions in mm Approx.
weight kg Cooling method
W H D W1 H1 H2 D1 T1 d
200 V class (3-phase)
0.4 ------
Not available please use the IP20 type removing the upper and lower cover
0.75 ------
1.5 ------
2.2 ------
3.7 ------
5.5 ------
7.5 ------
11 2011
15 2015
18.5 2018
1
250 400 258 195 385 7.5 100 2.3 M6 21
Fan
cooled
22 2022 275 450 258 220 435 24
30 2030 375 600 298 250 575
12.5 3.2 M10
57
37 2037 328
130
63
45 2045 450 725 348 325 700 86
55 2055 87
75 2075 500 850 358 370 820
15 4.5 M12
108
90 2090 575 885 378 445 855 140 150
110 2110
400 V class (3-phase)
0.4 ------
Not available please use the IP20 type removing the upper and lower cover
0.75 ------
1.5 ------
2.2 ------
4.0 ------
5.5 ------
7.5 ------
11 4011
15 4015
18.5 4018
1
275 450 258 220 435
7.5
100
2.3 M6
26
Fan
cooled
22 4022
30 4030
325 550 283 260 535 105 37
37 4037
45 4045
55 4055 450 725 348 325 700 12.5
130
3.2 M10 90
75 4075 91
90 4090 500 850 358 370 820 15
4.5 M12
109
110 4110 127
132 4132 575 916 378 445 855 45.8 140 165
160 4160 175
185 4185 710 1305 415 540 1270 15 126
263
220 4220 280
300 4300 916 1475 730 1440 415
Fig 1
W
W1 4-d
H2
(5) D1
D
H1
H
T1
(5)(5)
Y203-EN2-02-Katalog.book Seite 252 Mittwoch, 24. Mai 2006 2:22 14

Varispeed G7 253
Enclosed type (IEC IP20)
Voltage Max. applicable motor
output kW
Inverter
CIMR-G7C 
Fig Dimensions in mm Approx.
weight kg Cooling method
W H D W1 H1 H2 D1 T1 d
200 V class (3-phase)
0.4 20P4
1 140 280
157
126 266 7
39
5M5
3Self
cooled
0.75 20P7
1.5 21P5
2.2 22P2 177 59 4
Fan
cooled
3.7 23P7
5.5 25P5
2
200 300 197 186 285 8 65.5
2.3 M6
6
7.5 27P5 7
11 2011 240 350 207 216 335
7.5
78 11
15 2015
18.5 2018
3
250 400 258 195 385
100
21
22 2022 275 450 220 435 24
30 2030 375 600 298 250 575
12.5 3.2 M10
57
37 2037 328
130
63
45 2045 450 725 348 325 700 86
55 2055 87
75 2075 500 850 358 370 820
15 4.5 M12
108
90 2090 575 885 378 445 855 140 150
110 2110
400 V class (3-phase)
0.4 40P4
1 140 280
157
126 266 7
39
5M5
3.5 Self
cooled
0.75 40P7
1.5 41P5
177 59 4.5
Fan
cooled
2.2 42P2
3.7 43P7
5.5 45P5
2
200 300 197 186 285 8 65.5
2.3 M6
7
7.5 47P5
11 4011 240 350 207 216 335
7.5
78 10
15 4015
18.5 4018
3
275 450 258 220 435 100 26
22 4022
30 4030
325 550 283 260 535 105 37
37 4037
45 4045
55 4055 450 725 348 325 700 12.5
130
3.2 M10 90
75 4075 91
90 4090 500 850 358 370 820 15
4.5 M12
109
110 4110 127
132 4132 575 916 378 445 855 45.8 140 165
160 4160 175
185 4185
4710 1305 415 540 1270 15 126
263
220 4220 280
300 4300 916 1475 730 1440 415
3
W
0H
H
1H
2H
3H
4
W1 D1
D
W
W1
3
1H
2H
D
0H
D1
4H
4-d 4-d
W
W1
3H 0H
1H
2H
D1
D
(5)
01H
4-d
T1
(5)
(5)
H
Fig 1 Fig 2 Fig 3
T1 T1
G7C20P41 to G7C25P51
G7C40P41 to G7C45P51
G7C27P51 to G7C20181
G7C47P51 to G7C40181
G7C20221 to G7C20751
G7C40221 to G7C41601
Fig 4
G7C4185 to G7C4300
Y203-EN2-02-Katalog.book Seite 253 Mittwoch, 24. Mai 2006 2:22 14

254 Frequency inverters
Filters
Footprint / Flat filters
Bookform filters
Model Dimensions
A B C D E F G H I J K L
200 V
3G3RV-PFI2035-SE 330 141 46 281 313 115 5.5 M5 23 126 266 M5
3G3RV-PFI2060-SE 355 206 60 302 336 175 6.5 M6 30 186 285 M6
3G3RV-PFI2100-SE 408 236 80 355 390 205 6.5 M6 40 216 335 M6
400 V
3G3RV-PFI3010-SE 330 141 46 281 313 115 5.5 M5 23 126 266 M5
3G3RV-PFI3018-SE 330 141 46 281 313 115 5.5 M5 23 126 266 M5
3G3RV-PFI3021-SE 355 206 50 302 336 175 6.5 M4 25 186 285 M5
3G3RV-PFI3035-SE 355 206 50 302 336 175 6.5 M5 25 186 285 M6
3G3RV-PFI3060-SE 408 236 65 355 390 205 6.5 M6 32.5 216 335 M6
3G3RV-PFI3410-SE 1
1. Flat filters are not possible to be mounted as footprint filters.
386 115 260 306 240 235 12.0 M12 - - - -
3G3RV-PFI3600-SE 1386 135 260 306 240 235 12.0 M12 - - - -
3G3RV-PFI3800-SE 1564 160 300 516 420 275 9.0 M12 - - - -
Model Dimensions
A B C D E F G H
200 V
3G3RV-PFI2130-SE 366 180 90 280 310 65 6.5 M10
3G3RV-PFI2160-SE 451 170 120 350 380 102 6.5 M10
3G3RV-PFI2200-SE 610 240 130 480 518 90 8.2 M10
400 V
3G3RV-PFI3070-SE 331 185 80 300 329 55 6.5 M6
3G3RV-PFI3100-SE 326 150 90 240 270 65 6.5 M10
3G3RV-PFI3130-SE 370 180 90 280 310 65 6.5 M10
3G3RV-PFI3170-SE 451 170 120 350 380 102 6.5 M10
3G3RV-PFI3200-SE 610 240 130 480 518 90 8.3 M10
Y203-EN2-02-Katalog.book Seite 254 Mittwoch, 24. Mai 2006 2:22 14

Varispeed G7 255
Braking unit
Braking resistor unit (inverter-mounted type)
Braking resistor unit (separately-installed type)
Model CDBR-2015 B, -2022 B, -4030B, -4045 B Model CDBR-2110 B
Weight 1.8 Kg Weight 8.5 Kg
Model CDBR-4220 B
Weight 12 Kg
4-M4 MTG Holes 72
3838
128
140
30 or
more 30 or
more 138.5
114.5
3-lead Wire Inlet
(20 Dia. Rubber Bush)
66.5
100 or more
150
100 or more
138
140
104
Lead Wire Inlet
(28 Dia. Rubber Bush)
2-lead Wire Inlet
(35 Dia. Rubber Bush)
111
156
200
100
59
30
or
more
50
140
180
12
36.5
317
100 or less 100 or less
73
350
370
4-M6
MTG Holes
Main Circuit
Terminal
M6
30
or
more
Lead Wire Inlet
(28 Dia. Rubber Bush)
2-lead Wire Inlet
(35 Dia. Rubber Bush)
156.5
210
104
118.5 50
210
250 200
156
111
9
36.5
100 or more 100 or more
317
355
370
70
4-M6
MTG Holes
Main Circuit
Terminal
M6
30
or
more
30
or
more
Note: Prepare mounting screws
(2-M4x8 tapped screws).
Screws 8mm or more and general
metric screws cannot be used.
182
170
150
5
1.2
13
44
Weight: 0.2 kg
Model ERF-150WJ_
Voltage Model
LKEB-_
Dimensions in mm Weight
kg
A B C D MTG Screw
220 V
class
20P7 105 275 50 260 M5 x 3 3.0
21P5 130 350 75 335 M5 x 4 4.5
22P2 130 350 75 335 M5 x 4 4.5
23P7 130 350 75 335 M5 x 4 5.0
25P5 250 350 200 335 M6 x 4 7.5
25P5 250 350 200 335 M6 x 4 8.5
400 V
class
40P7 105 275 50 260 M5 x 3 3.0
41P5 130 350 75 335 M5 x 4 4.5
42P2 130 350 75 335 M5 x 4 4.5
43P7 130 350 75 335 M5 x 4 5.0
45P5 250 350 200 332 M6 x 4 7.5
47P5 250 350 200 332 M6 x 4 8.5
MTG Screw
30 or more 30 or more
A
C
D B
150
150 or more 150 or more
Voltage Model
LKEB-_
Dimensions in mm Weight
kg
A B C D MTG Screw
220 V
class
2011 266 543 246 340 M8 x 4 10
2015 356 543 336 340 M8 x 4 15
2018 446 543 426 340 M8 x 4 19
2022 446 543 426 340 M8 x 4 19
400 V
class
4011 350 412 330 325 M6 x 4 16
4015 350 412 330 325 M6 x 4 18
4018 446 543 426 340 M8 x 4 19
4022 446 543 426 340 M8 x 4 19
4030 356 956 336 740 M8 x 4 25
4037 446 956 426 740 M8 x 4 33
4045 446 956 426 740 M8 x 4 33
MTG Screw
200 or more 200 or more
50 or more 50 or more A260
C
D B
Y203-EN2-02-Katalog.book Seite 255 Mittwoch, 24. Mai 2006 2:22 14

256 Frequency inverters
Attachments
Heatsink external mounting attachment
The Varispeed G7 inverters under the 200/400 V class 15 kW or less need this attachment for mounting the heatsink externally. This attachment
expands the outer dimensions of the width and height of the inverter. (Attachment is not required for inverters of 18.5 kW or more.)
Panel cut for external mounting of cooling fin (heatsink)
W1
WD1D2
D3 or more
WallMounting panel
H1
H
CIMR-
G7C
Attachment
order code Dimensions in mm
W H W1 H1 D1 D2 D3
20P4
72616 -EZZ08676A 155 302 126 290 122.6
37.4 40
20P7
21P5
22P2 57.4 60
23P7
25P5 72616-EZZ08676B 210 330 180 316 136.1 63.4 70
27P5
2011 72616-EZZ08676C 250 392 216 372 133.6 76.4 85
2015
40P4
72616-EZZ08676A 155 302 126 290 122.6
37.4 40
40P7
41P5
57.4 60
42P2
43P7
45P5 72616-EZZ08676B 210 330 180 316 136.1 63.4 70
47P5
4011 72616-EZZ08676C 250 392 216 372 133.6 76.4 85
4015
CIMR-
G7CFig Dimensions in mm
W H W1 (W2) (W3) H1 (H2) (H3) A B d
20P4
1
155 302 126 6 8.5 290 9.5 6 138 271 M5
20P7
21P5
22P2
23P7
25P5 210 330 180
8.5
6.5 316 9 7 197 298
M6
27P5
2011 250 392 216 8.5 372 9.5 10 233 353
2015
2018
2
250 400 195 24.5 3 385 87.5 244 369
2022 275 450 220 435 269 419
2030 375 600 250
54.5 8
575 15
12.5
359 545
M10
2037
2045 450 725 325 700 13.5 434 673
2055
2075 500 850 370 57 8 820
19 15
484 782
M12
2090 575 885 445 55 10 855 555 817
2100
40P4
1
155 302 126 6 8.5 290 9.5 6 138 271 M5
40P7
41P5
42P2
43P7
45P5 210 330 180
8.5
6.5 316 9 7 197 298
M6
47P5
4011 250 392 216 8.5 372 9.5 10 233 353
4015
4018
2
275 450 220
24.5
3435
87.5
269 419
4022
4030
325 550 260
8
535 309 519
4037
4045
4055 450 725 325 54.5 700 13.5 12.5 434 673 M10
4075
4090 500 850 370 57 820 19 15 484 782
M12
4110
4132 3 575 925 445 55 10 895 see1
1.The sizes are different between the top and the bottom. Refer to figs. 3 to 5
15 555 817
4160
4185 4 710
1305 540 76.5 8.5 1270 21.5 see1693 1227
4220
4300 5 916
1475 730 72.5 20.5 1440 21.5 see1875 1397
Y203-EN2-02-Katalog.book Seite 256 Mittwoch, 24. Mai 2006 2:22 14

Varispeed G7 257
Installation
Standard connections
+V
AC
A2 Multi-functions analog input 2
[Default: Frequency bias
4 to 20 mA (250•)]
Analog input 1 Master
frequency reference
0 to +10 V (20 k•)
A1
0V
RP
Analog input power supply
+15V,, 20 mA
Pulse train input [Default:
Frequency reference input]
0 to 32 kHz
Analog input power supply
-15 V, 20 mA
-V
E(G)
PP
-10 to 10 V/
4 to 20 mA
-10 to 10 V
32k•
MP
E(G)
AC
Pulse train output
0 to 32kHz (2.2 k•)
[Output frequency at
factory setting]
FM
+
-
AM
+
-
AC
AM
FM
Ammeter
adjusting
potentiometer
20 kΩ
Multi-function analog output 1
(-10 to +10V, 2mA)
[Output frequency af factory
setting 0 to 10 V]
Multi-function analog output 2
(-10 to +10 V, 2 mA)
[Output current at
factory o to +10 V]
R+
R-
S+
S-
IG
Terminating
resistance
Shielded cable PShielded twisted
pair cable
MEMOBUS
communication
RS-485/422
P
P
2
1
Analog input setting
adjustment
2k•
Frequency master
adjusting potentiometer
20 k•
Line
filter
L1
L2
L3
PE
T
M
3-phase
Power supply
200 to 240 V
50/60 Hz
Varispeed G7
CIMR-G7C47P5
R/L1
S/L2
T/L3
U/T1
V/T2
W/T3
DC reactor to improve inputs
power factor (optional)
Short-circuit bar
Braking resistor (option)
12B1 B2
UX
Main contactor
and fuses
Multi-step speed setting 2 S6
Jog reference S7
S8
External base
Block reference
S9
Multi-step speed setting 3
S10
Multi-step speed setting 4
S11
S12
SN
Accel/decel time 1
Emergency stop
(NO contact)
SC
SP 24V
Multi-function
digital inputs
[Factory setting]
Motor
S1
Forward run/stop
S2
Reverse run/stop
S3
External fault
S4
Full reset
S5
Multi-step speed setting 1 M2
M1 Run signal at
Factory settings
M4
M3 Open collector output 1
[Zero speed signal at
factory setting]
M6
M5 Open collector output 2
[Frequency agreement
signal at factory setting]
Fault contact output
250 VAC, 1A or less
30 VDC, 1A or less
Multi-function
contact output
250 VAC, 1A or less
30 VDC, 1A or less
MC
MB
MA
Open collector output 3
[Ready to operate at
factory setting]
Open collector output 4
[Frequency (FOUT)
detection 2 at
factory setting]
Multi-function
open collector
output
48 VDC 50mA or less
P
A2 Multi-functions analog input 3
[Default: Auxiliary Frequency
Reference 0 to 10 V (20•)]
-10 to 10 V
Y203-EN2-02-Katalog.book Seite 257 Mittwoch, 24. Mai 2006 2:22 14

258 Frequency inverters
Main circuit
1. For 200 V class filters, consult with standard OMRON supplier.
Voltage 200 V 400 V
Model CIMR-G7C20P4 to 2015 2018, 2022 2030 to 2110 40P4 to 4015 4018 to 4045 4055 to 4300
Max. applicable motor output 0.4 to 15 kW 18.5 to 22 kW 30 to 110 kW 0.4 to 15 kW 18.5 to 45 kW 55 to 300 kW
R/L1 Main circuit input
power supply Main circuit input
power supply
R-R1, S-S1 and T-T1 have been wired
before shipment (see P59).
Main circuit input
power supply Main circuit input
power supply
R-R1, S-S1 and T-T1 have been wired
before shipment
S/L2
T/L3
R1/L11
--- ---
S1/L21
T1/L31
U/T1
Inverter output Inverter output
V/T2
W/T3
B1 Braking
resistor unit ------ Braking
resistor unit ------
B2
•DC reactor
(1- 2)
•DC power supply1
(1-)
1. 1 - DC power input does not conform to UL/c-UL listed standard.
•DC power supply
(1- 2)
1
•Braking unit
(3- )
•DC reactor
(1- 2)
•DC power supply1
(1- )
•DC power supply
(1- 2)
1
•Braking unit
(3- )
1
2
3--- ---
/l2------ Cooling fan power
supply2
2. Cooling fan power supply r/ l
1
- / l
2
: 200 to 220 VAC 50 Hz, 200 to 230 VAC 60 Hz
(A transformer is required for 230 V 50 Hz or 240 V 50/60 Hz power supply.)
---
r/l1
--- Cooling fan power
supply3
3. Cooling fan power supply r/l1- 200 / l2200: 200 to 220 VAC 50 Hz, 200 to 230 VAC 60 Hz, r/l1- 400 / l2400: 380 to 480 VAC 50/60 Hz
200 / l2200 ------
400 / l2400
Ground terminal (100 Ωor less) Ground terminal (10 Ωor less)
Main circuit configuration
200V class400V class
CIMR-G7C20P4 to 2015 CIMR-G7C2018, 2022 CIMR-G7C2030 to 2110
CIMR-G7C40P4 to 4015 CIMR-G7C4018 to 4045 CIMR-G7C4055 to 4300
Y203-EN2-02-Katalog.book Seite 258 Mittwoch, 24. Mai 2006 2:22 14

Varispeed G7 259
Control circuit
Type No. Signal name Function Signal level
Sequence input
S1 Forward run/stop signal Forward run at “closed”, stop at “open”
Photo-coupler input +24 VDC
8 mA isolation
S2 Reverse run/stop signal Reverse run at “closed”, stop at “open”
S3 Multi-function input selection 1 Factory setting: external fault at “closed”
S4 Multi-function input selection 2 Factory setting: fault reset at “closed”
S5 Multi-function input selection 3 Factory setting: multi-step speed setting 1 is valid at
“closed”
S6 Multi-function input selection 4 Factory setting: multi-step speed setting 2 is valid at
“closed”
S7 Multi-function input selection 5 Factory setting: JOG run at “closed”
S8 Multi-function input selection 6 Factory setting: external baseblock at “closed”
S9 Multi-function input selection 7 Factory setting: multi-step speed setting 3 is valid at
“closed”
S10 Multi-function input selection 8 Factory setting: multi-step speed setting 4 is valid at
“closed”
S11 Multi-function input selection 9 Factory setting: accel/decel time setting 1 is valid at
“closed”
S12 Multi-function input selection 10 Factory setting: emergency stop (NO contact) is valid at
“closed”
SC Sequence control input common –
Analog input
+V +15 V power supply output For analog reference +15 V power supply +15 V (allowable current
20 mA max.)
–V –15 V power supply output For analog reference -15 V power supply -15 V (allowable current
20 mA max.)
A1 Master speed
frequency reference -10 to +10 V/ -100 to +100%, 0 to +10 V/ 100% -10 to +10 V, 0 to +10V (input impedance 20 k)
A2 Multi-function analog input
4 to 20 mA/100%, -10 to +10 V/ -100 to +100%,
0 to +10 V/ 100%
Factory setting: added to the terminal A1 (H3-09=0)
4 to 20 mA
(input impedance 250 Ω)
A3 Master speed
frequency reference
-10 to +10 V/ -100 to +100%, 0 to +10 V/ 100%
Factory setting: preset frequency reference
0 to +10 V
(input impedance 20 kΩ)
AC Analog common 0 V –
E(G) Connection to shield wire and
option ground wire ––
Photo-coupler output
P1 Multi-function PHC output 1 Factory setting: zero speed signal
“Closed” at or below zero speed level (b2-01)
+48 VDC 50 mA or less
P2 Multi-function PHC output 2 Factory setting: frequency agreement
“Closed” within ±2Hz of setting frequency
PC Photo-coupler output common –
P3 Multi-function PHC output 3 Factory setting: ready to operate (READY).
C3
P4 Multi-function PHC output 4 Factory setting: frequency (FOUT) detection 2
C4
Relay output
MA Fault output (NO contact) Fault at “closed” between terminals MA and MC
Dry contact, contact capacity
250 VAC 1 A or less
30 VDC 1 A or less
MB Fault output (NC contact) Fault at “open” between terminals MB and MC
MC Rely contact output common –
M1 Multi-function contact output
(NO contact)
Factory setting: run signal
Running at “closed” between terminals M1 and M2
M2
Analog
monitor
output
FM Multi-function analog monitor 1 Factory setting: output frequency 0 to 10 V/100% freq.
0 to +10 VDC ±5%
2 mA or less
AM Multi-function analog monitor 2 Factory setting: current monitor 5 V /
inverter rated current
AC Analog common –
Pulse
I/O
RP Multi-function pulse input Factory setting: frequency reference input (H6-01=0) 0 to 32 kHz (3 kΩ)
MP Multi-function pulse monitor Factory setting: output frequency (H6-06=2) 0 to 32 kHz (2.2 kΩ)
RS-485/422
R+ MEMOBUS communications input For 2-wire RS-485, short R+ and S+
as well as R- and S-.
Differential input,
photocoupler isolation
R-
S+ MEMOBUS communications output Differential input,
photocoupler isolation
S-
IG Signal common – –
Y203-EN2-02-Katalog.book Seite 259 Mittwoch, 24. Mai 2006 2:22 14

260 Frequency inverters
Inverter heat loss
200 V class
400 V class
Connections for braking units Connections for braking resistors
Model CIMR-G7C20P4 20P7 21P5 22P2 23P7 25P5 27P5 2011 2015 2018 2022 2030 2037 2045 2055 2075 2090 2110
Inverter capacity kVA 1.2 2.3 3.0 4.6 6.9 10 13 19 25 30 37 50 61 70 85 110 140 160
Rated current A 3.2 6 8 12 18 27 34 49 66 80 96 130 160 183 224 300 358 415
Heat loss W
Fin W 21 43 58 83 122 187 263 357 473 599 679 878 1080 1291 1474 2009 1660 2389
Inside unit W 36 42 47 53 64 87 112 136 174 242 257 362 434 510 607 823 871 1194
Total heat loss W 57 85 105 136 186 274 375 493 647 839 936 1240 1514 1801 2081 2832 2531 3583
Fin coding Self cooled Fan cooled
Model CIMR-G7C 40P4 40P7 41P5 42P2 43P7 45P5 47P5 4011 4015 4018 4022 4030 4037 4045 4055 4075 4090 4110 4132 4160 4185 4220 4300
Inverter capacity kVA 1.4 2.6 3.7 4.7 6.9 11 16 21 26 32 40 50 61 74 98 130 150 180 194 230 280 340 460
Rated current A 1.8 3.4 4.8 6.2 9 15 21 27 34 42 52 65 80 97 128 165 195 240 255 302 370 450 605
Heat loss W
Fin W 10 21 33 41 76 132 198 246 311 354 516 633 737 929 1239 1554 1928 2299 2612 3614 4436 5329 6749
Inside unit W 39 44 46 49 64 79 106 116 135 174 210 246 285 340 488 596 762 928 1105 1501 1994 2205 2941
Total heat loss W 49 65 79 90 140 211 304 362 446 528 726 879 1022 1269 1727 2150 2690 3227 3717 5115 6430 7534 9690
Fin coding Self cooled Fan cooled
Internal heatsink
55 ˚C
45 ˚C
Upper cover
Upper part air
temperature
-10 to 55 ˚C
Open chassis
type inverter
Inverter inlet
temperature
-10 to 45 ˚C
Peripheral
temperature 40 ˚C
Lower cover
Heatsink
Remove the upper and lower covers for
the models of 15 kW or less in 200 V
and 400 V classes.
When using open chassis type inverters of 200 V/400 V
22 kW or more, secure spaces for eyebolts and wiring
of the main circuit.
Upper cover
50 mm or more
50 mm or more 120 mm or more
120 mm or more
30 mm or more 30 mm
or more
Heatsink
Lower cover Side spaces Top and bottom spaces
Cover MTG screw
Air
Air
Varispeed G7
Braking
resistor
· Set constant L8-01 to 1
(mounting type braking
resistor protection
enabled).
· Set sequence to shutt off
the power side at inverter
fault contact output.
3-phase
Power
Supply
MCCB
Motor
S
T
R
S
T
R
V
W
U
PB
B1 B2
MC
IM
Varispeed G7
Braking
Resistor
Unit
Braking
resistor
unit *3
Braking unit 2*2
Braking unit 1
Braking resistor overload
relay trip contact
(thermal relay trip contact)
Braking resistor overload
relay trip contact
(thermal relay trip contact)
Cooling fin overheat contact
(Thermoswitch contact) Cooling fin overheat contact (Thermoswitch contact)
3
MASTER
SLAVE
MASTER
SLAVE
Level detector
12
BP BP
12
+15 5
62
1
P
34
2
1
34
Y203-EN2-02-Katalog.book Seite 260 Mittwoch, 24. Mai 2006 2:22 14

Varispeed G7 261
AC reactor
DC reactor
200 V Class 400 V class
Max. applicable
motor output kW Current value AInductance mH Max. applicable motor output kW Current value AInductance mH
0.4 2.5 4.2 0.4 1.3 18.0
0.75 52.1 0.75 2.5 8.4
1.5 10 1.1 1.5 54.2
2.2 15 0.71 2.2 7.5 3.6
3.7 20 0.53 3.7 10 2.2
5.5 30 0.35 5.5 15 1.42
7.5 40 0.265 7.5 20 1.06
11 60 0.18 11 30 0.7
15 80 0.13 15 40 0.53
18.5 90 0.12 18.5 50 0.42
22 120 0.09 22 60 0.36
30 160 0.07 30 80 0.26
37 200 0.05 37 90 0.24
45 240 0.044 45 120 0.18
55 280 0.038 55 150 0.15
75 360 0.026 75 200 0.11
90 500 0.02 90/110 250 0.09
110 500 0.02 132/160 330 0.06
185 490 0.04
220
300 660 0.03
Connection example
MCCB
AC reactor
Application example
Inverter capacity (kVA)
Motor
Power supply
capacity (kVA)
AC reactor required for
power supply harmonics
AC reactor
not required
Varispeed G7
200 V class 400 V class
Max. applicable
motor output kW Current value AInductance mH Max. applicable motor output kW Current value AInductance mH
0.4 5.4 8 0.4 3.2 28
0.75 0.75
1.5
18 3
1.5 5.7 11
2.2 2.2
3.7 3.7 12 6.3
5.5 36 1 5.5 23 3.6
7.5 7.5
11 72 0.5 11 33 1.9
15 15
18.5 90 0.4 18.5 47 1.3
22 to 110 Built-in 22 to 300 Built-in
Varispeed G7
Take off the
common bar
between G1
and G2, and
wire as shown
in the diagram.
⊕⊕
DC reactor
Motor
MCCB
Power
supply
capacity
(kVA)
Inverter capacity (kVA)
Without reactor
With reactor for
power supply
coordination
Y203-EN2-02-Katalog.book Seite 261 Mittwoch, 24. Mai 2006 2:22 14

262 Frequency inverters
Fuse installation
To protect the inverter, it is recommended to use semiconductor fuses as shown in the table below
Inverter type FUSE
Voltage (V) Current (A) I2t (A2s)
20P4 240 10 12~25
20P7 240 15 23~55
21P5 240 20 34~98
22P2 240 30 82~220
23P7 240 40 220~610
25P5 240 60 290~1300
27P5 240 80 450~5000
2011 240 100 1200~7200
2015 240 130 1800~7200
2018 240 150 870~16200
2022 240 180 1500~23000
2030 240 240 2100~19000
2037 240 300 2700~55000
2045 240 350 4000~55000
2055 240 450 7100~64000
2075 240 550 11000~64000
2090 240 600 13000~83000
2110 240 700 13000~83000
40P4 480 5 16~660
40P7 480 10 19~660
41P5 480 10 46~660
42P2 480 15 78~660
43P7 480 20 110~660
44P0 480 25 220~660
45P5 480 30 240~900
47P5 480 40 320~900
4011 480 50 1000~18000
4015 480 60 1500~4100
4018 480 70 530~5800
4022 480 90 1130~5800
4030 480 110 1700~5800
4037 480 140 2000~13000
4045 480 160 3000~13000
4055 480 220 6800~55000
4075 480 300 3800~55000
4090 480 330 12000~23000
4110 480 400 18000~64000
4132 480 450 28000~25000
4160 480 540 40000~250000
4185 480 750 63000~400000
4220 480 750 63000~400000
4300 480 1000 94000~920000
Y203-EN2-02-Katalog.book Seite 262 Mittwoch, 24. Mai 2006 2:22 14

Varispeed G7 263
Ordering information
Varispeed G7
200 V 400 V
C22
R52
C24
PE
C16
U11
U8
R6
C26 C28
JP3
U6
U7
T1
U9
+
+
R15
R15
R25
R15
R20
R30
R7
R5
C5
R21
U14
C17
R14
R28
RR11
JP1
C1
U10
C3
R5
R1
R2
R36
R3
C21
R35
R70
R120
R75
R78
R114
C2
2
+
+
U1
+
C35 R99
U12
R95
R39
R40
R57
R56
D6
R6
U15
R54
R55
R8
TR2
11
R11
R110
R107
R113
TR1
C13
U13
C10
SI-N
CODENo.
U17
73600-C0210
JP5JP6RT4
R10
R10
R105
R102
C12
C11
R94
R97
R96
C20
R95
C39
R131
Y1
U10
C33
EDCB
A
F
GGGGG
H
Communication
option cards
Monitor option card
3G3IV-PCN329-E
Inverter to PC cable
3G3IV-PCN126/326
Digital operator
extension cable
JVOP-161-OY
Digital operator
(LED display)
JVOP-160 OY
Digital operator
(LCD display)
CX-Drive
DriveWorkEZ
Line filter Braking accessories
Feedback speed
control card
PLC option card
Varispeed
G7
Reference
option cards
Inverter Model Line Filters
Varispeed G7 Type EN55011
Class Current (A) Weight (kg)
CIMR-G7C20P4 3G3RV-PFI3010-SE B, 25 m
A, 100 m 10 1.2
CIMR-G7C20P7
CIMR-G7C21P5 3G3RV-PFI3018-SE B, 25 m
A, 100 m 18 1.3
CIMR-G7C22P2 3G3RV-PFI2035-SE B, 25 m
A, 100 m 35 1.4
CIMR-G7C23P7
CIMR-G7C25P5 3G3RV-PFI2060-SE B, 25 m
A, 100 m 60 3
CIMR-G7C27P5
CIMR-G7C2011 3G3RV-PFI2100-SE B, 25 m
A, 100 m 100 4.9
CIMR-G7C2015
CIMR-G7C2018
CIMR-G7C2022 3G3RV-PFI2130-SE A, 100 m 130 4.3
CIMR-G7C2030 3G3RV-PFI2160-SE A, 100 m 160 6.0
CIMR-G7C2037 3G3RV-PFI2200-SE A, 100 m 200 11.0
CIMR-G7C2045
CIMR-G7C2055 3G3RV-PFI3410-SE A, 100 m 400 8.6
CIMR-G7C2075
CIMR-G7C2090
CIMR-G7C2110 3G3RV-PFI3600-SE A, 100 m 600 11.0
Inverter Model Line Filters
Varispeed G7 Type EN55011
Class Current (A) Weight (kg)
CIMR-G7C40P4
3G3RV-PFI3010-SE B, 25 m
A, 100 m 10 1.2CIMR-G7C40P7
CIMR-G7C41P5
CIMR-G7C42P2
3G3RV-PFI3018-SE B, 25 m
A, 100 m 18 1.3CIMR-G7C43P7
CIMR-G7C44P0
CIMR-G7C45P5 3G3RV-PFI3021-SE B, 25 m
A, 100 m 21 1.8
CIMR-G7C47P5 3G3RV-PFI3035-SE B, 25 m
A, 100 m 35 2.2
CIMR-G7C4011 3G3RV-PFI3060-SE B, 25 m
A, 100 m 60 4.0
CIMR-G7C4015
CIMR-G7C4018 3G3RV-PFI3070-SE B, 25 m
A, 100 m 70 3.4
CIMR-G7C4022
CIMR-G7C4030 3G3RV-PFI3100-SE A, 100 m 100 4.5
CIMR-G7C4037
CIMR-G7C4045 3G3RV-PFI3130-SE A, 100 m 130 4.7
CIMR-G7C4055 3G3RV-PFI3170-SE A, 100 m 170 6.0
CIMR-G7C4075 3G3RV-PFI3200-SE A, 100 m 250 11
CIMR-G7C4090
3G3RV-PFI3410-SE A, 100 m 400 8.6
CIMR-G7C4110
CIMR-G7C4132
CIMR-G7C4160
CIMR-G7C4185 3G3RV-PFI3600-SE A, 100 m 600 11
CIMR-G7C4220 3G3RV-PFI3800-SE A, 100 m 800 31.0
CIMR-G7C4300
Y203-EN2-02-Katalog.book Seite 263 Mittwoch, 24. Mai 2006 2:22 14

264 Frequency inverters
A Line filters
200 V 400 V
BMonitor option cards
Inverter model Line filters
Varispeed G7 Type EN55011
class Current (A) Weight (kg)
CIMR-G7C20P4 3G3RV-PFI3010-SE B, 25 m
A, 100 m 10 1.2
CIMR-G7C20P7
CIMR-G7C21P5 3G3RV-PFI3018-SE B, 25 m
A, 100 m 18 1.3
CIMR-G7C22P2 3G3RV-PFI2035-SE B, 25 m
A, 100 m 35 1.4
CIMR-G7C23P7
CIMR-G7C25P5 3G3RV-PFI2060-SE B, 25 m
A, 100 m 60 3
CIMR-G7C27P5
CIMR-G7C2011
3G3RV-PFI2100-SE B, 25 m
A, 100 m 100 4.9CIMR-G7C2015
CIMR-G7C2018
CIMR-G7C2022 3G3RV-PFI2130-SE A, 100 m 130 4.3
CIMR-G7C2030 3G3RV-PFI2160-SE A, 100 m 160 6.0
CIMR-G7C2037 3G3RV-PFI2200-SE A, 100 m 200 11.0
CIMR-G7C2045
CIMR-G7C2055
3G3RV-PFI3410-SE A, 100 m 400 8.6CIMR-G7C2075
CIMR-G7C2090
CIMR-G7C2110 3G3RV-PFI3600-SE A, 100 m 600 11.0
Inverter model Line filters
Varispeed G7 Model EN 55011
class Current (A) Weight (kg)
CIMR-G7C40P4
3G3RV-PFI3010-SE B, 25 m
A, 100 m 10 1.2CIMR-G7C40P7
CIMR-G7C41P5
CIMR-G7C42P2
3G3RV-PFI3018-SE B, 25 m
A, 100 m 18 1.3CIMR-G7C43P7
CIMR-G7C44P0
CIMR-G7C45P5 3G3RV-PFI3021-SE B, 25 m
A, 100 m 21 1.8
CIMR-G7C47P5 3G3RV-PFI3035-SE B, 25 m
A, 100 m 35 2.2
CIMR-G7C4011 3G3RV-PFI3060-SE B, 25 m
A, 100 m 60 4.0
CIMR-G7C4015
CIMR-G7C4018 3G3RV-PFI3070-SE B, 25 m
A, 100 m 70 3.4
CIMR-G7C4022
CIMR-G7C4030 3G3RV-PFI3100-SE A, 100 m 100 4.5
CIMR-G7C4037
CIMR-G7C4045 3G3RV-PFI3130-SE A, 100 m 130 4.7
CIMR-G7C4055 3G3RV-PFI3170-SE A, 100 m 170 6.0
CIMR-G7C4075 3G3RV-PFI3200-SE A, 100 m 250 11
CIMR-G7C4090
3G3RV-PFI3410-SE A, 100 m 400 8.6
CIMR-G7C4110
CIMR-G7C4132
CIMR-G7C4160
CIMR-G7C4185 3G3RV-PFI3600-SE A, 100 m 600 11.0
CIMR-G7C4220 3G3RV-PFI3800-SE A, 100 m 800 31.0
CIMR-G7C4300
Type Model Description Function
Monitor option card
AO-08 / 3G3IV-PAO08
Analog monitor card
• Outputs analog signal for monitoring inverter output state (output freq., output current etc.)
after absolute value conversion.
• Output resolution: 8 bits (1/256)
• Output voltage: 0 to {10 V (non isolated) EOutput channel: 2 channels
AO-12 / 3G3IV-PAO12 • Outputs analog signal for monitoring inverter output state (output freq., output current etc.)
• Output resolution: 11 bits (1/2048) + code
• Output voltage: |10 to {10 V (non isolated) EOutput channel: 2 channels
DO-08 / 3G3IV-PDO08 Digital output card
• Outputs isolated type digital signal for monitoring inverter run state
(alarm signal, zero speed detection etc.) .
• Output channel: photo coupler 6 channels (48 V, 50 mA or less)
Relay contact output 2 channels (250 VAC, 1 A or less 30 VDC, 1 A or less)
DO-02C / 3G3IV-PDO02C 2C-relay output card • Two multi-function contact outputs (2C-relay) can be used other than those of the inverter
proper unit.
Y203-EN2-02-Katalog.book Seite 264 Mittwoch, 24. Mai 2006 2:22 14

Varispeed G7 265
CFeedback speed control cards
DCommunication option cards
EReference option cards
FPLC option boards
Type Model Description Function
Feedback speed control card
PG-A2 / 3G3FV-PPGA2
PG speed controller card
(used for V/f control with PG or
flux vector)
• Phase A pulse (single pulse) inputs (voltage, complementary, open collector input)
• PG frequency range: Approx. 30 kHz max.
[Power supply output for PG: +12 V, max. current 200 mA]
• Pulse monitor output: +12 V, 20 mA
PG-B2 / 3G3FV-PPGB2 • Phase A and B pulse inputs (exclusively for complementary input)
• PG frequency range: Approx. 30 kHz max.
[Power supply output for PG: +12 V, Max. current 200 mA]
• Pulse monitor output: Open collector, +24 V, Max. current 30 mA
PG-D2 / 3G3FV-PPGD2 • Phase A pulse (differential pulse) input for V/f control (RS-422 input)
• PG frequency range: Approx. 300 kHz max.
[Power supply output for PG: +5 V or +12 V, Max. current 200 mA]
• Pulse monitor output: RS-422
PG-X2 / 3G3FV-PPGX2 • Phase A, B and Z pulse (differential pulse) inputs (RS-422 input)
• PG frequency range: Approx. 300 kHz max.
[Power supply output for PG: +5 V or +12 V, Max. current 200 mA]
• Pulse monitor output: RS-422
Type Model Description Function
Communication option card
SI-N1 DeviceNet option card • Used for running or stopping the inverter, setting or referencing parameters, and monitoring output frequency, output current, or similar items through DeviceNet communication with the
host controller.
SI-P1 PROFIBUS-DP option card • Used for running or stopping the inverter, setting or referencing parameters, and monitoring output frequency, output current, or similar items through PROFIBUS-DP communication
with the host controller.
SI-S1 CANopen option card • Used for running or stopping the inverter, setting or referencing parameters, and monitoring output frequency, output current, or similar items through CANopen communication with the
host controller.
SI-J LONWORKS option card • Used for HVAC control, running or stopping the inverter, setting or referencing parameters, and monitoring output current, watt-hours, or similar items through LONWORKS communi-
cations with peripheral devices.
SI-T MECHATROLINK-II
option board
• High speed motion bus
• Used for running or stopping the inverter, setting or referencing parameters, and monitoring
output frequency, output current, or similar items through MECHATROLINK-II communica-
tion with the host controller.
• Host contoller: Trajexia, MCH and MP series 1
1. Please refer to Trajexia, MCH or MP series for host controllers detailed information.
CM090 Ethernet option card • Modbus TCP/IP ethernet interface unit
Type Model Description Function
Reference option card
AI-14U / 3G3IV-PAI14U
Analog input card
• 2 channel high resolution analog input card
• Channel 1: 0 to 10 V (20 KΩ)
• Channel 2: 4 to 20 mA (250 Ω)
• Resolution 14 bit
AI-14B / 3G3IV-PAI14B
• 3 Channel high resolution analog input card
• Signal level: -10 to +10 V (20 KΩ)
• 4 to 20 mA (250 Ω)
•Resolution: 13 bit + sign
DI-08 / 3G3IV-PDI08 Digital reference card • 8 bit digital speed reference input card
DI-16H2 / 3G3IV-PDI16H2 • 16 bit digital speed reference input card
Type Model Description Function
PLC option
3G3RV-P10ST8-E
3G3RV-P10ST8-DRT-E
PLC option
• Full PLC features, wireless installation and seamless access to the inverter parameters and
analogue/digital inputs and outputs.
• Embedded Compubus/S fieldbus
• Standard OMRON tools can be used for programming
PLC option with DeviceNet
• Same features as standard models with DeviceNet support.
Y203-EN2-02-Katalog.book Seite 265 Mittwoch, 24. Mai 2006 2:22 14

266 Frequency inverters
GAccessories
GAccessories
Type Model Description Installation
Digital operator
JVOP-160-OY
5 lines LCD digital operator
7 language support
Panel cutout installation
JVOP-161-OY
7 segment LED digital operator
Accessories
3G3IV-PCN126
3G3IV-PCN326 Digital operator extension cable 1 meter
3 meters -----
3G3IV-PCN329-E PC configuration cable -----
Type Model Description Function
Software
CX-drive 1.1 Computer software Configuration and monitoring software tool for drives (Version 1.1 or higher)
DriveWorksEZ Computer software Programming special functionality software tool for drives
CX-One Computer software Complete automation software including CX-drive.
70 70
14.5
2.5
20
44
15.8 6.4
(60)
57
Through
Hole
120
111
120
2-M3 MTG Holes
Panel
Panel cutout
Y203-EN2-02-Katalog.book Seite 266 Mittwoch, 24. Mai 2006 2:22 14

Varispeed G7 267
HBraking unit, braking resistor unit
Inverter
Braking unit
Braking resistor unit1
1. When connecting a mounting type resistor or braking resistor unit, set system constant L3-04 to 0 (stall prevention disabled during deceleration). If oper-
ating without changing the constant, motor does not stop at set deceleration time.
Inverter-mounted type
(3 %ED, 10 sec max)2
2. When connecting mounting type braking resistor, set system constant L8-01 to 1 (braking resistor protection enabled).
Separately-installed type (10 %ED, 10 sec. max.)3
3. Load factor during deceleration to stop a load with constant torque. With constant output or continuous regenerative braking, the load factor is smaller
than the specified value.
4. Resistance value per one braking unit. Select a resistance value that is larger than connectable minimum resistance value to obtain enough braking
torque.
5. For an application with large regenerative power such as hoisting, the braking torque or other items may exceed the capacity of a braking unit with a
braking resistor in a standard combination (can result in capacity overload). Contact your OMRON representatives when the braking torque or any other
item exceeds the values in the table.
Voltage Max. applicable
motor output
kW
Model
CIMR-
G7C_
Model
CDBR_ No. of used Model ERF-150WJ_ Resis- tance No. of Used Braking torque % Model LKEB_ Specifications of resistor No. of Used Braking torque %
Connectable
min resistance
value Ω
200 V
class
0.4 20P4
Built-in
201 200 Ω1 220 20P7 70 W 200 Ω1220 48
0.75 20P7 201 200 Ω1 125 20P7 70 W 200 Ω1125 48
1.5 21P5 101 100 Ω1 125 21P5 260 W 100 Ω1125 48
2.2 22P2 700 70 Ω1 120 22P2 260 W 70 Ω1120 16
3.7 23P7 620 62 Ω1 100 23P7 390 W 40 Ω1125 16
5.5 25P5
--- ---
25P5 520 W 30 Ω1115 16
7.5 27P5 27P5 780 W 20 Ω1 125 9.6
11 2011 2011 2400 W 13.6 Ω1 125 9.6
15 2015 2015 3000 W 10 Ω1 125 9.6
18.5 2018 2015 3000 W 10 Ω1 125 9.6
22 2022 2022B 1 2022 4800 W 6.8 Ω1 125 6.4
30 2030 2015B 2 2015 3000 W 10 Ω2 125 9.6
37 2037 2015B 2 2015 3000 W 10 Ω2 100 9.6
45 2045 2022B 2 2022 4800 W 6.8 Ω2 120 6.4
55 2055 2022B 2 2022 4800 W 6.8 Ω2 100 6.4
75 2075 2110B 1 2022 4800 W 6.8 Ω3 110 1.6
90 2090 2110B 1 2022 4800 W 6.8 Ω4 120 1.6
110 2110 2110B 1 2018 4800 W 8 Ω5 100 1.6
400 V
class
0.4 40P4
Built in
751 750 Ω1 230 40P7 70 W 750 Ω1230 96
0.75 40P7 751 750 Ω1 130 40P7 70 W 750 Ω1130 96
1.5 41P5 401 400 Ω1 125 41P5 260 W 400 Ω1125 64
2.2 42P2 301 300 Ω1 115 42P2 260 W 250 Ω1135 64
3.7 43P7 201 200 Ω1 110 43P7 390 W 150 Ω1135 32
4.0 44P0
5.5 45P5
--- ---
45P5 520 W 100 Ω1135 32
7.5 47P5 47P5 780 W 75 Ω1130 32
11 4011 4011 1040 W 50 Ω1135 20
15 4015 4015 1560 W 40 Ω1125 20
18.5 4018 4018 4800 W 32 Ω1 125 19.2
22 4022 4030B 1 4022 4800 W 27.2 Ω1 125 19.2
30 4030 4030B 1 4030 6000 W 20 Ω1 125 19.2
37 4037 4045B 1 4037 9600 W 16 Ω1 125 12.8
45 4045 4045B 1 4045 9600 W 13.6 Ω1 125 12.8
55 4055 4030B 2 4030 6000 W 20 Ω2 135 19.2
75 4075 4045B 2 4045 9600 W 13.6 Ω2 145 12.8
90 4090 4220B 1 4030 6000 W 20 Ω3 100 3.2
110 4110 4220B 1 4030 6000 W 20 Ω3 100 3.2
132 4132 4220B 1 4045 9600 W 13.6 Ω4 140 3.2
160 4160 4220B 1 4045 9600 W 13.6 Ω4 140 3.2
185 4185 4220B 1 4045 9600 W 13.6 Ω4 120 3.2
220 4220 4220B 1 4037 9600 W 16 Ω5 110 3.2
300 4300 4220B 2 4045 9600 W 13.6 Ω6 110 3.2
Y203-EN2-02-Katalog.book Seite 267 Mittwoch, 24. Mai 2006 2:22 14

268 Frequency inverters
In the interest of product improvement, specifications are subject to change without notice.
ALL DIMENSIONS SHOWN ARE IN MILLIMETERS.
To convert millimeters into inches, multiply by 0.03937. To convert grams into ounces, multiply by 0.03527.
Cat. No. I37E-EN-01A
Y203-EN2-02-Katalog.book Seite 268 Mittwoch, 24. Mai 2006 2:22 14
