Omron RX Series User manual

Inverter
RX Series
LX Series
MX2 Series
LCD Digital Operator
User’s Manual
I579-E2-01
3G3AX-OP05

OMRON, 2013
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in
any form, or by any means, mechanical, electronic, photocopying, recording, or otherwise, without the prior written
permission of OMRON.
No patent liability is assumed with respect to the use of the information contained herein. Moreover, because
OMRON is constantly striving to improve its high-quality products, the information contained in this manual is
subject to change without notice. Every precaution has been taken in the preparation of this manual. Nevertheless,
OMRON assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting
from the use of the information contained in this publication.

1
Introduction
LCD Digital Operator User’s Manual (I579)
Introduction
Thank you for purchasing the LCD Digital Operator (Model: 3G3AX-OP05).
This manual explains how to set parameters required to use the LCD Digital Operator (Model:
3G3AX-OP05), operation procedures and the remedies needed if problems occur.
For the use of the LCD Digital Operator 3G3AX-OP05, please refer also to RX (I560-E2), LX
(I120E-EN) or MX2 (I570-E2) User’s Manuals.
This manual is intended for the following individuals.
Those who have electrical knowledge (certified electricians or individuals who have equivalent
knowledge) and also are qualified for one of the following:
•Introducing control equipment
•Designing control systems
•Installing and connecting control systems
•Managing control systems and facilities
This manual contains information you need to know in order to correctly use the LCD Digital Operator
3G3AX-OP05.
Before using the LCD Digital Operator (Model: 3G3AX-OP05), read this manual and gain a full
understanding of the information provided herein.
After you finished reading this manual, keep it in a convenient place so that it can be referenced at any
time.
Make sure this manual is delivered to the end user.
Intended Readers
Notice

Manual Configuration
2
LCD Digital Operator User’s Manual (I579)
Manual Configuration
This manual is compiled section by section for user’s convenience as follows.
Overview
Section 1 Overview This section provides features and specifications of the LCD Digital
Operator.
Section 2 Part Names and Functions This section describes the part names and functions of the LCD Digital
Operator.
Section 3 Installation and Wiring This section provides information on the installation and wiring of the
LCD Digital Operator.
Section 4 Operation Procedures This section provides an overview of the display modes supported by
LCD Digital Operator and how to operate the LCD Digital Operator in
each display mode.
Section 5 LCD Digital Operator Related
Parameters This section describes the Inverter parameters related to the LCD Digital Operator.
Section 6
Read/Write Functions This section describes how to read and write Inverter parameter settings
using the LCD Digital Operator.
Section 7 Error Messages and
Troubleshooting This section describes the error messages and troubleshooting of the LCD Digital Operator.
Section 8 Maintenance This section provides information on the maintenance of the LCD Digital
Operator.

3
Manual Structure
LCD Digital Operator User’s Manual (I579)
Manual Structure
The following page structure and symbol icons are used in this manual.
Note The above page is only a sample for illustrative purposes. It is not the actual content of the manual.
Page Structure and Symbol Icons
4 Operation Procedures
4 - 2
LCD Digital Operator User’s Manual
4-1 Overview of Display Modes
The LCD Digital Operator basically displays its screens in four modes as shown below.
Each mode has two levels: the higher Navigation level and the lower Edit level. The user can move
between each mode in the Navigation level only.
•
Monitor Mode A: The mode to display and set a single monitor function and a single parameter function.
•Monitor Mode B: The mode to display up to four monitor functions on a single screen.
•Function
Mode : The mode to set parameter settings. The screen also displays the parameter name
and setting range.
•Trip Mode: The mode to display the trip and warning information.
In addition to the above, the LCD Digital Operator has the following three called modes. At any of the
above levels and in any operating state, you can call these modes by pressing the key(s) shown to the
right of the down arrow above each screen, as shown below. After calling these screens, you can press
the ESC key to restore the operating state before the call.
•All Read: The mode to read allInverter parameter settings and Drive Programming data from the
Inverter.
•All Write: The mode to write all the stored Inverter parameter setting and Drive Programming program
data to the Inverter.
•Option Mode: The mode to set the LCD Digital Operator.
4-1-1 Transition of Screens
Monitor
Mode A
Monitor
Mode B
Function
Mode
Tr i p
Mode
Select the monitor item.
Select the setting item.
Select the setting
line.
Select the setting
item.
Monitor the overall
trip history.
Monitor
Mode A
Monitor
Mode B
Function
Mode
Tr i p
Mode
Monitor
Mode A
Monitor
Mode B
Function
Mode
Change the set value. Change the set value. Change theset value.
Navigation levelEdit level
Level 2 heading
Level 3 heading
Level 1 heading
Manual Name
Level 2 heading
Section Number of
Level 1 heading
Level 3 heading
Shows which section
the content of the current
page belongs to.
Shows which sub-section
the content of the current
page belongs to.
Shows which paragraph
the content of the current
page belongs to.
Note, Supplementary
Information, Reference Target
A note, supplementary
information, reference target,
etc. are provided with
difference icons.
Operation Steps
Describes
the operation steps.
4 Operation Procedures
4 - 8
LCD Digital Operator User’s Manual
1 At the Navigation level, press the or
key to select the Trip Mode screen.
2 Press the key. Now, the screen shows
information on the past trips (six trip errors)
recorded in the Inverter and the warning
information (for a single occurrence).
The trip information for a single occurrence comprises
two pages.
To switch from page 1 (P1) to page 2 (P2),
press the or key.
To display the information on the past six trip errors,
press the or key.
3 If you press the key when ERR1 is being
displayed or press the key when ERR6 is
being displayed, the screen changes to the
Warning Mode.
Precautions for Correct UsePrecautions for Correct Use
If a trip occurs, the ALARM LED lights up. Then, press the key to reset the Inverter.
4-5 Operation in the Trip Mode
4
4-1-2 Basic Operation

Manual Structure
4
LCD Digital Operator User’s Manual (I579)
Special information in this manual is classified as follows:
Precautions for Safe Use
Precautions on what to do and what not to do to ensure safe usage of the product.
Precautions for Correct UsePrecautions for Correct Use
Precautions on what to do and what not to do to ensure proper operation and performance.
Additional Information
Additional information to read as required.
This information is provided to increase understanding or make operation easier.
Special Information

5
Sections in this Manual
LCD Digital Operator User’s Manual (I579)
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
Overview
Part Names and Functions
Installation and Wiring
Operation Procedures
LCD Digital Operator Related Parameters
Read/Write Functions
Error Messages and Troubleshooting
Maintenance
I
I
Index
Sections in this Manual

6
LCD Digital Operator User’s Manual (I579)
CONTENTS
CONTENTS
Introduction ...............................................................................................................1
Manual Configuration ...............................................................................................2
Manual Structure.......................................................................................................3
Sections in this Manual ............................................................................................5
CONTENTS.................................................................................................................6
Read and Understand this Manual ..........................................................................8
Safety Precautions..................................................................................................11
Precautions for Safe Use........................................................................................13
Precautions for Correct Use...................................................................................15
Regulations and Standards....................................................................................16
Items to Check after Unpacking.............................................................................17
Related Manuals......................................................................................................18
Revision History......................................................................................................19
Section 1 Overview
1-1 Features....................................................................................................................................1-2
1-2 Supported Models ...................................................................................................................1-4
1-3 Specifications .......................................................................................................................... 1-5
1-4 External Dimensions...............................................................................................................1-6
1-5 Recommended Cables............................................................................................................1-7
Section 2 Part Names and Functions
2-1 Part Names...............................................................................................................................2-2
2-2 Operation Keys........................................................................................................................2-4
2-3 LCD Display ............................................................................................................................. 2-6
Section 3 Installation and Wiring
3-1 Installation on the Inverter......................................................................................................3-2
3-1-1 Direct Installation on the Inverter ................................................................................................3-3
3-1-2 Installation on the Inverter via Cable...........................................................................................3-4
3-1-3 Checking the Operation After Installation....................................................................................3-5
3-1-4 Date and Time Setting ................................................................................................................3-6
3-1-5 Other Settings.............................................................................................................................3-6

7
LCD Digital Operator User’s Manual (I579)
CONTENTS
Section 4 Operation Procedures
4-1 Overview of Display Modes....................................................................................................4-2
4-1-1 Transition of Screens.................................................................................................................. 4-2
4-1-2 Overview of Each Mode.............................................................................................................. 4-3
4-1-3 Changing the Display in Each Mode........................................................................................... 4-5
4-2 Operation in the Monitor Mode A........................................................................................... 4-6
4-3 Operation in the Monitor Mode B........................................................................................... 4-7
4-4 Operation in the Function Mode ............................................................................................ 4-8
4-5 Operation in the Trip Mode..................................................................................................... 4-9
Section 5 LCD Digital Operator Related Parameters
5-1 Parameter Setting.................................................................................................................... 5-2
5-1-1 Operation in the Option Mode..................................................................................................... 5-2
5-1-2 Details of Each Option Mode Parameter.................................................................................... 5-4
5-2 Related Inverter Parameters................................................................................................... 5-6
Section 6 Read/Write Functions
6-1 Single READ Function ............................................................................................................ 6-2
6-2 Single WRITE Function........................................................................................................... 6-3
6-3 Quad READ Function.............................................................................................................. 6-4
6-4 Quad VERIFY Function ........................................................................................................... 6-6
6-5 Quad WRITE Function............................................................................................................. 6-8
6-6 Conditions for the Read/Write Operations.......................................................................... 6-10
Section 7 Error Messages and Troubleshooting
7-1 Error Messages and Remedies .............................................................................................. 7-2
7-1-1 Inverter Error Messages............................................................................................................. 7-2
7-1-2 LCD Digital Operator Error Messages........................................................................................7-2
7-2 Troubleshooting ...................................................................................................................... 7-5
Section 8 Maintenance
8-1 Battery Replacement............................................................................................................... 8-2
Index

Read and Understand this Manual
8
LCD Digital Operator User’s Manual (I579)
Read and Understand this Manual
Warranty and Limitations of Liability
WARRANTY
OMRON’s exclusive warranty is that the products are free from defects in materials and workmanship for a period of
one year (or other period if specified) from date of sale by OMRON.
OMRON MAKES NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, REGARDING
NONINFRINGEMENT, MERCHANTABILITY, OR FITNESS FOR PARTICULAR PURPOSE OF THE PRODUCTS.
ANY BUYER OR USER ACKNOWLEDGES THAT THE BUYER OR USER ALONE HAS DETERMINED THAT THE
PRODUCTS WILL SUITABLY MEET THE REQUIREMENTS OF THEIR INTENDED USE. OMRON DISCLAIMS ALL
OTHER WARRANTIES, EXPRESS OR IMPLIED.
LIMITATIONS OF LIABILITY
OMRON SHALL NOT BE RESPONSIBLE FOR SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, LOSS
OF PROFITS OR COMMERCIAL LOSS IN ANY WAY CONNECTED WITH THE PRODUCTS, WHETHER SUCH
CLAIM IS BASED ON CONTRACT, WARRANTY, NEGLIGENCE, OR STRICT LIABILITY.
In no event shall the responsibility of OMRON for any act exceed the individual price of the product on which liability
is asserted.
IN NO EVENT SHALL OMRON BE RESPONSIBLE FOR WARRANTY, REPAIR, OR OTHER CLAIMS REGARDING
THE PRODUCTS UNLESS OMRON’S ANALYSIS CONFIRMS THAT THE PRODUCTS WERE PROPERLY
HANDLED, STORED, INSTALLED, AND MAINTAINED AND NOT SUBJECT TO CONTAMINATION, ABUSE,
MISUSE, OR INAPPROPRIATE MODIFICATION OR REPAIR.

9
Read and Understand this Manual
LCD Digital Operator User’s Manual (I579)
Application Considerations
SUITABILITY FOR USE
OMRON shall not be responsible for conformity with any standards, codes, or regulations that apply to the
combination of products in the customer’s application or use of the products.
At the customer’s request, OMRON will provide applicable third party certification documents identifying ratings and
limitations of use that apply to the products. This information by itself is not sufficient for a complete determination of
the suitability of the products in combination with the end product, machine, system, or other application or use.
The following are some examples of applications for which particular attention must be given. This is not intended to
be an exhaustive list of all possible uses of the products, nor is it intended to imply that the uses listed may be
suitable for the products:
•Outdoor use, uses involving potential chemical contamination or electrical interference, or conditions or uses not
described in this manual.
•Nuclear energy control systems, combustion systems, railroad systems, aviation systems, medical equipment,
amusement machines, vehicles, safety equipment, and installations subject to separate industry or government
regulations.
•Systems, machines, and equipment that could present a risk to life or property. Please know and observe all
prohibitions of use applicable to the products.
NEVER USE THE PRODUCTS FOR AN APPLICATION INVOLVING SERIOUS RISK TO LIFE OR PROPERTY
WITHOUT ENSURING THAT THE SYSTEM AS A WHOLE HAS BEEN DESIGNED TO ADDRESS THE RISKS,
AND THAT THE OMRON PRODUCTS ARE PROPERLY RATED AND INSTALLED FOR THE INTENDED USE
WITHIN THE OVERALL EQUIPMENT OR SYSTEM.
PROGRAMMABLE PRODUCTS
OMRON shall not be responsible for the user’s programming of a programmable product, or any consequence
thereof.

Read and Understand this Manual
10
LCD Digital Operator User’s Manual (I579)
Disclaimers
CHANGE IN SPECIFICATIONS
Product specifications and accessories may be changed at any time based on improvements and other reasons. It is
our practice to change model numbers when published ratings or features are changed, or when significant
construction changes are made. However, some specifications of the products may be changed without any notice.
When in doubt, special model numbers may be assigned to fix or establish key specifications for your application on
your request. Please consult with your OMRON representative at any time to confirm actual specifications of
purchased products.
DIMENSIONS AND WEIGHTS
Dimensions and weights are nominal and are not to be used for manufacturing purposes, even when tolerances are
shown.
PERFORMANCE DATA
Performance data given in this manual is provided as a guide for the user in determining suitability and does not
constitute a warranty. It may represent the result of OMRON’s test conditions, and the users must correlate it to
actual application requirements. Actual performance is subject to the OMRON Warranty and Limitations of Liability.
ERRORS AND OMISSIONS
The information in this manual has been carefully checked and is believed to be accurate; however, no responsibility
is assumed for clerical, typographical, or proofreading errors, or omissions.

11
Safety Precautions
LCD Digital Operator User’s Manual (I579)
Safety Precautions
This manual uses the following precautionary symbols and signal words to ensure the safe use of the
LCD Digital Operator. The precautions explained in this section describe important information
regarding safety and must be followed without fail.
The precautionary symbols and signal words used in this manual and their meanings are explained
below.
Indications and Meanings of Safety Information
Meanings of Signal Words
Indicates an imminently hazardous situation which, if not avoided, is likely to result in
serious injury or may result in death. Additionally there may be severe property
damage.
Indicates a potentially hazardous situation which, if not avoided, may result in minor
or moderate injury or in property damage.
Explanation of Symbols
This symbol indicates a prohibited item (an item you must not do).
The specific instruction is indicated using an illustration or text inside or near .
The symbol shown to the left indicates “disassembly prohibited”.
This symbol indicates danger and caution.
The specific instruction is indicated using an illustration or text inside or near .
The symbol shown to the left indicates “beware of electric shock”.
This symbol indicates danger and caution.
The specific instruction is indicated using an illustration or text inside or near .
The symbol shown to the left indicates a “non-specific general danger”.
This symbol indicates caution (including warning).
The specific instruction is indicated using an illustration or text inside or near .
The symbol shown to the left indicates “risk of hot surface”.
This symbol indicates a compulsory item (an item that must be done).
The specific instruction is indicated using an illustration or text inside or near .
The symbol shown to the left indicates a “general compulsory item”.
This symbol indicates a compulsory item (an item that must be done).
The specific instruction is indicated using an illustration or text inside or near .
The symbol shown to the left indicates “grounding required”.
WARNING
CAUTION

Safety Precautions
12
LCD Digital Operator User’s Manual (I579)
Turn off the power supply and implement wiring correctly.
Not doing so may result in a serious injury due to an electric shock.
Wiring work must be carried out only by qualified personnel.
Not doing so may result in a serious injury due to an electric shock.
Do not change wiring and slide switches (SW1), put on or take off Operator and optional devices, replace
cooling fans while the input power is being supplied. Doing so may result in a serious injury due to an
electric shock.
Be sure to ground the unit. Not doing so may result in a serious injury due to an electric shock or fire.
(200V class: type-D grounding, 400V class: type-C grounding)
Do not remove the terminal cover during the power supply and 10 minutes after the power shut off.
Doing so may result in a serious injury due to an electric shock.
Do not operate the Operator or switches with wet hands.
Doing so may result in a serious injury due to an electric shock.
Inspection of the Inverter must be conducted after the power supply has been turned off. Not doing so may
result in a serious injury due to an electric shock.
The main power supply is not necessarily shut off even if the emergency shut off function is activated.
Do not touch the Inverter fins, braking resistors and the motor, which become too hot during the power
supply and for some time after the power shut off. Doing so may result in a burn.
Do not connect resistors to the terminals (+1, P/+2, N/-) directly. Doing so might result in a small-scale fire,
heat generation or damage to the unit.
Install a stop motion device to ensure safety. Not doing so might result in a minor injury. (A holding brake is
not a stop motion device designed to ensure safety.)
Be sure to use a specified type of braking resistor/regenerative braking unit. In case of a braking resistor,
install a thermal relay that monitors the temperature of the resistor. Not doing so might result in a moderate
burn due to the heat generated in the braking resistor/regenerative braking unit. Configure a sequence that
enables the Inverter power to turn off when unusual over heating is detected in the braking resistor/
regenerative braking unit.
The Inverter has high voltage parts inside which, if short-circuited, might cause damage to itself or other
property. Place covers on the openings or take other precautions to make sure that no metal objects such
as cutting bits or lead wire scraps go inside when installing and wiring.
Take safety precautions such as setting up a molded-case circuit breaker (MCCB) that matches the
Inverter capacity on the power supply side.
Not doing so might result in damage to property due to the short circuit of the load.
Do not dismantle, repair or modify the product.
Doing so may result in an injury.
WARNING
CAUTION

13
Precautions for Safe Use
LCD Digital Operator User’s Manual (I579)
Precautions for Safe Use
Do not store or use the product in the following places.
•Locations subject to direct sunlight.
•Locations subject to ambient temperature exceeding the specifications.
•Locations subject to relative humidity exceeding the specifications.
•Locations subject to condensation due to severe temperature fluctuations.
•Locations subject to corrosive or flammable gases.
•Locations subject to exposure to combustibles.
•Locations subject to dust (especially iron dust) or salts.
•Locations subject to exposure to water, oil, or chemicals.
•Locations subject to shock or vibration.
•Take sufficient shielding measures when using the product in the following locations. Not doing so
may result in damage to the product.
Locations subject to static electricity or other forms of noise.
Locations subject to strong magnetic fields.
Locations close to power lines.
•If a parameter is set incorrectly when starting up, adjusting, maintaining, or replacing, an unexpected
operation may occur.
Perform the operation after enough confirmation.
•If the clock command is used in Drive Programming, an unexpected operation may occur due to
weak battery. Take measures such as detecting a weak battery by a check that the clock data returns
to the initial setting and stopping the Inverter or programs. When the LCD Digital Operator is
removed or disconnected, Drive Programming is in a waiting status by the clock command.
Installation and Storage
Transporting, Installation, and Wiring
Operation and Adjustment

Precautions for Safe Use
14
LCD Digital Operator User’s Manual (I579)
•When disposing of LCD digital operators and wasted batteries, follow the applicable ordinances of
your local government.
When disposing of the battery, insulate it using tape.
•Do not short + and -, charge, disassemble, heat, put into the fire, or apply strong impact on the
battery. The battery may leak, explode, produce heat or fire. Never use the battery which was applied
strong impact due to such as fall on the floor, it may leak.
•UL standards establish that the battery shall be replaced by an expert engineer.
The expert engineer must be in charge of the replacement and also replace the battery according to
the method described in this manual.
•When the display of LCD Digital Operator can not be recognized due to the service life, replace the
LCD Digital Operator.
Maintenance and Inspection
The following display must be indicated when products using lithium primary batteries (with
more than 6 ppb of perchlorate) are transport to or through the State of California, USA.
The 3G3AX-OP05 has the lithium primary battery (with more than 6 ppb of perchlorate). Label
or mark the above display on the exterior of all outer shipping packages of your products when
exporting your products which the 3G3AX-OP05 are installed to the State of California, USA.
Perchlorate Material - special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate

15
Precautions for Correct Use
LCD Digital Operator User’s Manual (I579)
Precautions for Correct Use
•Be sure to confirm the RUN signal is turned off before resetting the alarm because the machine may
abruptly start.
•Provide a separate emergency stop switch because the STOP Key on the Operator is valid only
when function settings are performed.
Retry Selection Function
Operation Stop Command

Regulations and Standards
16
LCD Digital Operator User’s Manual (I579)
Regulations and Standards
To export (or provide to nonresident aliens) any part of this product that falls under the category of
goods (or technologies) for which an export certificate or license is mandatory according to the Foreign
Exchange and Foreign Trade Control Law of Japan, an export certificate or license (or service
transaction approval) according to this law is required.
Overseas Use

17
Items to Check after Unpacking
LCD Digital Operator User’s Manual (I579)
Items to Check after Unpacking
After unpacking the product, check the following items:
•Is this the model you ordered?
•Was there any damage sustained during shipment?
The product has
the following nameplate labels on its rear face .
Checking the Nameplate
Checking the Model
3G3AX-OP 05
LCD Digital Operator

Related Manuals
18
LCD Digital Operator User’s Manual (I579)
Related Manuals
To operate this product, you must be familiar with the equipment connected to it.
Please refer to the following manual for information on the related product.
Additional Information
For Inverter operation, please refer to the manual for the Inverter.
Name Catalog No.
RX User’s Manual I560-E2
LX User’s Manual I120E-EN
MX2 User’s Manual I570-E2
