OPERATION MANUAL
CX-Integrator Ver. 1.1
SYSMAC
CXONE-AL@@@@C-E
Cat. No. W445-E1-02

CXONE-AL@@C-E
CX-Integrator Ver. 1.1
Operation Manual
Revised November 2005

iv

Notice:
OMRON products are manufactured for use according to proper procedures by a qualified operator
and only for the purposes described in this manual.
The following conventions are used to indicate and classify precautions in this manual. Always heed
the information provided with them. Failure to heed precautions can result in injury to people or
damage to property.
!DANGER Indicates an imminently hazardous situation which, if not avoided, will result in death or
serious injury. Additionally, there may be severe property damage.
!WARNING Indicates a potentially hazardous situation which, if not avoided, could result in death or
serious injury. Additionally, there may be severe property damage.
!Caution Indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury, or property damage.
OMRON Product References
All OMRON products are capitalized in this manual. The word “Unit” is also capitalized when it refers
to an OMRON product, regardless of whether or not it appears in the proper name of the product.
The abbreviation “Ch,” which appears in some displays and on some OMRON products, often means
“word” and is abbreviated “Wd” in documentation in this sense.
The abbreviation “PLC” means Programmable Controller. “PC” is used, however, in some
Programming Device displays to mean Programmable Controller.
Visual Aids
The following headings appear in the left column of the manual to help you locate different types of
information.
Note Indicates information of particular interest for efficient and convenient
operation of the product.
1,2,3... 1. Indicates lists of one sort or another, such as procedures, checklists, etc.
OMRON, 2005
All ri
g
hts reserved. No
p
art of this
p
ublication ma
y
be re
p
roduced, stored in a retrieval s
y
stem, or transmitted, in an
y
form,
or by any means, mechanical, electronic, photocopying, recordin
g
, or otherwise, without the
p
rior written
p
ermission o
f
OMRON.
No
p
atent liabilit
y
is assumed with res
p
ect to the use of the information contained herein. Moreover, because OMRON is
constantly striving to improve its high-quality products, the information contained in this manual is sub
j
ect to chan
g
e
without notice. Ever
y
p
recaution has been taken in the
p
re
p
aration of this manual. Nevertheless, OMRON assumes no
responsibility for errors or omissions. Neither is any liability assumed for damages resultin
g
from the use of the information
contained in this publication.
v

vi

TABLE OF CONTENTS
PRECAUTIONS
1 Intended Audience.......................................................................................................... xvi
2 Safety Precautions.......................................................................................................... xvi
3 Application Precautions .................................................................................................xviii
4 Operating Environment Precautions................................................................................xx
5 Guide to Version Upgrade .............................................................................................. xxi
Section 1 Overview
1-1 The CX-Integrator ........................................................................................................ 1-2
1-2 Specifications............................................................................................................... 1-8
1-3 Installation.................................................................................................................. 1-14
1-4 PLC Connecting Cables ............................................................................................ 1-15
1-5 Window Descriptions ................................................................................................. 1-22
1-6 Menus ........................................................................................................................ 1-34
Section 2 Basic Operations
2-1 Basic Procedures......................................................................................................... 2-2
2-2 Connecting Online to the Relay PLC......................................................................... 2-10
2-3 Uploading Network Configurations and Checking for Communications Unit Errors . 2-21
2-4 Switching the Target PLC.......................................................................................... 2-27
2-5 Creating Virtual Network Configurations Offline........................................................ 2-29
2-6 Manipulating Component Parameters ....................................................................... 2-38
2-7 Uploading, Downloading, and Comparing Network Parameters............................... 2-43
2-8 Comparing Network Configurations........................................................................... 2-44
2-9 File Operations .......................................................................................................... 2-45
2-10 Target PLC Online Operations .................................................................................. 2-49
2-11 Starting Specified Applications .................................................................................. 2-51
2-12 Printing....................................................................................................................... 2-52
Section 3 Routing Tables
3-1 Routing Table Overview .............................................................................................. 3-2
3-2 Setting the Routing Tables .......................................................................................... 3-9
3-3 Maintenance after Network Configuration ................................................................. 3-25
Section 4 Data Links for Controller Link and SYSMAC LINK
4-1 Overview...................................................................................................................... 4-2
4-2 User Interface Overview .............................................................................................. 4-4
4-3 Manually Setting Data Links ........................................................................................ 4-8
4-4 Automatically Set Data Links..................................................................................... 4-41
Section 5 Ethernet
5-1 Broadcast Node Search .............................................................................................. 5-2
5-2 Ping Test...................................................................................................................... 5-4
vii

Section 6 DeviceNet
6-1 DeviceNet Setting Procedures..................................................................................... 6-2
6-2 Setting Slave Parameters ............................................................................................ 6-4
6-3 Adding Slaves to the Master........................................................................................ 6-8
6-4 Setting Master Properties .......................................................................................... 6-13
6-5 Editing Master Parameters ........................................................................................ 6-15
6-6 Parameter Wizard ...................................................................................................... 6-16
6-7 Master Parameter Editing Details (Tab Descriptions) ............................................... 6-21
6-8 Manual I/O Allocations............................................................................................... 6-29
6-9 Advanced Settings (Connection, Communication Cycle Time, Slave Function Settings,
Etc.)............................................................................................................................ 6-36
6-10 Creating and Editing I/O Comments .......................................................................... 6-43
6-11 Displaying Device Properties..................................................................................... 6-45
6-12 Downloading the Network Configuration/Device Parameters to Devices.................. 6-51
6-13 Uploading and Verifying Device Parameters............................................................. 6-57
6-14 Monitoring Devices .................................................................................................... 6-62
6-15 Using General-purpose Tools to Set Devices ........................................................... 6-70
6-16 Optional Functions ..................................................................................................... 6-72
Section 7 CompoWay/F
7-1 CompoWay/F System Configuration ........................................................................... 7-2
7-2 CompoWay/F Slaves Connected to a PLC ................................................................. 7-3
7-3 CompoWay/F Slaves Connected to a Computer....................................................... 7-10
Section 8 NT Links
8-1 NT Link Connection Auto-detect Function ................................................................... 8-2
8-2 Transferring Screen Data through the PLC ................................................................. 8-6
Section 9 Network Testing
9-1 Controller Link Network Diagnostic Tool...................................................................... 9-2
9-2 Echoback Test between Nodes ................................................................................. 9-22
9-3 Ethernet Ping Test ..................................................................................................... 9-25
Appendices
A-1 CPS File Management.................................................................................................A-2
A-2 EDS File Management.................................................................................................A-4
Revision History
viii

About this Manual:
This manual describes the installation and operation of CX-Integrator and includes the sections
described below.
Please read this manual carefully and be sure you understand the information provided before
attempting to use the CX-Integrator. Be sure to read the precautions provided in the following section.
Precautions provides general precautions for using the CX-Integrator.
Section 1 outlines the functions of the CX-Integrator and describes the menus and connecting to
networks.
Section 2 describes the basic operations required to use the CX-Integrator.
Section 3 describes how to set routing tables.
Section 4 describes how to set data links for Controller Link and SYSMAC LINK Networks.
Section 5 describes the how to use the diagnostic tools for Controller Link Networks.
Section 6 describes settings and operations unique to DeviceNet Networks, including registering
slaves in the master, allocating I/O, monitoring devices, etc.
Section 7 describes settings and operations unique to CompoWay/F Networks.
Section 8 settings and operations unique to NT Links.
The Appendix describes CPS files for Ethernet, Controller Link, CompoWay/F, and NT Link
Networks and EDS files for DeviceNet Networks.
!
WARNING Failure to read and understand the information provided in this manual may result in
personal injury or death, damage to the product, or product failure. Please read each
section in its entirety and be sure you understand the information provided in the section
and related sections before attempting any of the procedures or operations given.
ix

Manuals Related to the CX-Integrator
Cat No. Models Name Description
W445
(this manual)
CXONE-AL@@C-E CX-Integrator Operation
Manual
Describes CX-Integrator operating
methods, e.g., for setting up and
monitoring networks.
W444 CXONE-AL@@C-E CX-One Setup Manual Describes installation and provides an
overview of the CX-One FA Integrated
Tool Package.
W446 WS02-CXPC1-E-V60 CX-Programmer Ver. 6.1
Operation Manual
Describes CX-Programmer operations
except those related to function blocks.
W447 WS02-CXPC1-E-V60
CS1G-CPU@@H
CS1H-CPU@@H
CJ1G- CPU@@H
CJ1H- CPU@@H
CJ1M- CPU@@
CP1H- X@@@@-@
CP1H- XA@@@@-@
CX-Programmer Ver. 6.1
Operation Manual:
Function Blocks
Describes function blocks for
CS/CJ-series CPU Units unit version 3.0
or later and CP-series CPU Units, and
CX-Programmer operations related to
function blocks.
Refer to the W447 manual above for other
CX-Programmer operations.
Manuals Related to DeviceNet
Cat No. Models Name Description
W267 --- DeviceNet Operation
Manual
Describes network communications
settings and wiring common to all
DeviceNet networks.
W380 CS1W-DRM21(-V1)
CJ1W-DRM21
DeviceNet Unit Operation
Manual
Describes CX/CJ-series DeviceNet Units.
W379 C200HW-DRM21-V1
CVM1-DRM21-V1
DeviceNet Master Unit
Operation Manual
Describes C200H and CV/CVM1-series
DeviceNet Master Units.
W381 3G8F7-DRM21 DeviceNet PCI Board
Operation Manual
Describes the DeviceNet PCI Board.
x

Read and Understand this Manual
Please read and understand this manual before using the product. Please consult your OMRON
representative if you have any questions or comments.
Warranty and Limitations of Liability
WARRANTY
OMRON's exclusive warranty is that the products are free from defects in materials and workmanship for a
period of one year (or other period if specified) from date of sale by OMRON.
OMRON MAKES NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, REGARDING
NON-INFRINGEMENT, MERCHANTABILITY, OR FITNESS FOR PARTICULAR PURPOSE OF THE
PRODUCTS. ANY BUYER OR USER ACKNOWLEDGES THAT THE BUYER OR USER ALONE HAS
DETERMINED THAT THE PRODUCTS WILL SUITABLY MEET THE REQUIREMENTS OF THEIR
INTENDED USE. OMRON DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED.
LIMITATIONS OF LIABILITY
OMRON SHALL NOT BE RESPONSIBLE FOR SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES,
LOSS OF PROFITS OR COMMERCIAL LOSS IN ANY WAY CONNECTED WITH THE PRODUCTS,
WHETHER SUCH CLAIM IS BASED ON CONTRACT, WARRANTY, NEGLIGENCE, OR STRICT
LIABILITY.
In no event shall the responsibility of OMRON for any act exceed the individual price of the product on
which liability is asserted.
IN NO EVENT SHALL OMRON BE RESPONSIBLE FOR WARRANTY, REPAIR, OR OTHER CLAIMS
REGARDING THE PRODUCTS UNLESS OMRON'S ANALYSIS CONFIRMS THAT THE PRODUCTS
WERE PROPERLY HANDLED, STORED, INSTALLED, AND MAINTAINED AND NOT SUBJECT TO
CONTAMINATION, ABUSE, MISUSE, OR INAPPROPRIATE MODIFICATION OR REPAIR.
xi

Application Considerations
SUITABILITY FOR USE
OMRON shall not be responsible for conformity with any standards, codes, or regulations that apply to the
combination of products in the customer's application or use of the products.
At the customer's request, OMRON will provide applicable third party certification documents identifying
ratings and limitations of use that apply to the products. This information by itself is not sufficient for a
complete determination of the suitability of the products in combination with the end product, machine,
system, or other application or use.
The following are some examples of applications for which particular attention must be given. This is not
intended to be an exhaustive list of all possible uses of the products, nor is it intended to imply that the
uses listed may be suitable for the products:
•Outdoor use, uses involving potential chemical contamination or electrical interference, or conditions or
uses not described in this manual.
•Nuclear energy control systems, combustion systems, railroad systems, aviation systems, medical
equipment, amusement machines, vehicles, safety equipment, and installations subject to separate
industry or government regulations.
•Systems, machines, and equipment that could present a risk to life or property.
Please know and observe all prohibitions of use applicable to the products.
NEVER USE THE PRODUCTS FOR AN APPLICATION INVOLVING SERIOUS RISK TO LIFE OR
PROPERTY WITHOUT ENSURING THAT THE SYSTEM AS A WHOLE HAS BEEN DESIGNED TO
ADDRESS THE RISKS, AND THAT THE OMRON PRODUCTS ARE PROPERLY RATED AND
INSTALLED FOR THE INTENDED USE WITHIN THE OVERALL EQUIPMENT OR SYSTEM.
PROGRAMMABLE PRODUCTS
OMRON shall not be responsible for the user's programming of a programmable product, or any
consequence thereof.
xii

Disclaimers
CHANGE IN SPECIFICATIONS
Product specifications and accessories may be changed at any time based on improvements and other
reasons.
It is our practice to change model numbers when published ratings or features are changed, or when
significant construction changes are made. However, some specifications of the products may be changed
without any notice. When in doubt, special model numbers may be assigned to fix or establish key
specifications for your application on your request. Please consult with your OMRON representative at any
time to confirm actual specifications of purchased products.
DIMENSIONS AND WEIGHTS
Dimensions and weights are nominal and are not to be used for manufacturing purposes, even when
tolerances are shown.
PERFORMANCE DATA
Performance data given in this manual is provided as a guide for the user in determining suitability and
does not constitute a warranty. It may represent the result of OMRON's test conditions, and the users must
correlate it to actual application requirements. Actual performance is subject to the OMRON Warranty and
Limitations of Liability.
ERRORS AND OMISSIONS
The information in this manual has been carefully checked and is believed to be accurate; however, no
responsibility is assumed for clerical, typographical, or proofreading errors, or omissions.
xiii

xiv

PRECAUTIONS
This section provides precautions for using the CX-Integrator.
The information contained in this section is important for the safe and reliable application of the CX-Integrator.
You must read this section and understand the information contained before attempting to use the
CX-Integrator.
1 Intended Audience.......................................................................................... xvi
2 Safety Precautions .......................................................................................... xvi
3 Application Precautions.................................................................................. xviii
4 Operating Environment Precautions............................................................... xx
5 Guide to Version Upgrade.............................................................................. xxi

1 Intended Audience
1 Intended Audience
This manual is intended for the following personnel, who must also have
knowledge of electrical systems (an electrical engineer or the equivalent).
•Personnel in charge of installing FA systems
•Personnel in charge of designing FA systems
•Personnel in charge of managing FA systems and facilities
2 Safety Precautions
!Caution When performing any of the following operations, always check the network
address and node address of the other node (PLC) and the node address
and unit number of the mounted Unit (PLC CPU Bus Unit or Special I/O Unit)
or the node address of the Component (DeviceNet Master/Slave or
CompoWay/F Slave), and be sure that these operations can be performed
safely for the current status of the node (Unit or Component):
•Transferring parameter or program data to the other node
•Changing the operating mode of the other node
Unexpected operation may result if parameter or program data is transferred
to the wrong node (DeviceNet Master/Slave or CompoWay/F Slave), the
operating mode of the wrong node is changed, or the other node is not in a
suitable status to receive the program or parameter data or the operating
mode change.
!Caution When changing the target PLC to any PLC other than the relay PLC, check
the node address and node number of the target PLC carefully before
executing the change. Unexpected operation and injury may result if the
wrong PLC is set as the target PLC.
•Changing the operating mode
•Transferring or verifying user-set data link tables
•Transferring or verifying routing tables
•Performing I/O table operations (including transferring CPU Bus Unit or
Special I/O Unit parameters)
Note Operations performed from the CX-Integrator are performed for the target
PLC, which is not necessarily the same as the relay PLC.
!Caution When transferring parameters that have been created or edited on the
computer to actual Units (PLC CPU Bus Units or PLC Special I/O Units) or to
actual Components (DeviceNet Masters/Slaves or CompoWay/F Slaves),
always check the identifying number of the actual Units or Components (i.e.,
the unit numbers and unit addresses or node addresses) before executing
the transfer. Unexpected operation and injury may result if parameters are
transferred to the wrong Unit or Component.
!Caution When changing or removing a routing table (see note), be sure to update the
display for the Online Connection Information Window. The display for the
Online Connection Information Window could possibly be different from the
actual network status. If operations are executed without first updating the
display, particularly online operations in the Network Configuration Window, it
could cause data to be mistakenly read or written for the wrong network or
node address or unit number.
xvi

2 Safety Precautions
Note: Changing or removing a routing table refers to using the
CX-Integrator (or a CX-Integrator for another personal computer) to
start the Routing Table Component and then changing or removing
a routing table for the target PLC (either a local network table or a
relay network table).
!Caution Do not execute a broadcast node search if a node exists for something other
than an OMRON Ethernet Unit or FinsGateway within the same segment on
Ethernet, and when the Ethernet network system is in operation. When a
broadcast node search is executed, an OMRON FINS command is sent to all
nodes in the segment. Therefore, if a node exists for something other than an
OMRON Ethernet Unit or FinsGateway, the FINS command will not be
received at that node and unexpected operation may occur.
xvii

3 Application Precautions
3 Application Precautions
Observe the following precautions when using the CX-Integrator.
General Communications Precautions
•Do not turn OFF the power to the PLC or disconnect the cable connecting
the PLC when the CX-Integrator is online with the PLC. Doing so may cause
the computer running CX-Integrator to malfunction.
•Before changing the operating mode, always confirm that doing so will not
adversely affect system operation.
•Always check the operation of parameters sufficiently before using them for
actual system operation.
•Confirm that resetting CPU Bus Units and Special I/O Units will not
adversely affect system operation before resetting these Units.
DeviceNet
•Enable the scan list to before operating the system.
•When adding a new node to the network, make sure that the baud rate is
the same as other nodes.
•Use specified communications cables.
•Do not extend connection distances beyond the ranges given in the
specifications.
•Always turn OFF the power supply to the personal computer, Slaves, and
Communications Units before attempting any of the following.
•Attaching or detaching the DeviceNet Board or Card
•Assembling the Units
•Setting rotary switches
•Connecting or wiring the cables
•Connecting or disconnecting connectors
•Be sure that the communications cables and other items with locking
devices are properly locked into place.
•Observe the following precautions when wiring the communications cable.
•Separate the communications cables from the power lines or
high-tension lines.
•Do not bend the communications cables.
•Do not pull on the communications cables.
•Do not place heavy objects on top of the communications cables.
•Be sure to wire communications cable inside ducts.
•Use appropriate communications cables.
•Before touching the PCI Board, be sure to first touch a grounded metallic
object in order to discharge any static build-up. Not doing so may result in
malfunction or damage.
•When transporting a Board or Card, use the special box in which it was
shipped to protect the LSIs and ICs from being damaged. Also do not
subject the Board or Card to excessive vibration or shock.
xviii

3 Application Precautions
•Because the devices are reset in order, communications errors will
temporarily occur in the master and slaves. For this reason, do not
download the network configuration while the master-side PLC (CPU Unit)
is operating.
•When downloading the network configuration, each of the devices is reset.
If the Master Unit is reset first, it may cause errors in writing parameters to
the subsequent slaves. For that reason, this method (downloading the
network configuration) should be used only when the Master Unit has been
given the highest address.
•Downloaded device parameters will be valid only after the devices are reset
unless they are the OMRON CVM1-DRM21-V1, C200HW-DRM21-V1,
CS1W-DRM21(-V1), or CJ1W-DRM21.
•When the devices are reset, communications errors will temporarily occur.
For this reason, do not reset the devices while the master-side PLC (CPU
Unit) is operating.
Data Links in Controller Link or SYSMAC LINK Networks
•The data link mode (manual setting or automatic setting) and data link
method are determined according to the data link setting in the startup node.
In the startup node, set a data link table for manual settings and data link
automatic setting parameters for automatic settings. If the settings are
incorrect, the data links will not start.
Check the following items before starting data links.
(1) Manually Set Data Links
Check the data link tables in each node participating in the data link to
see that they are correct.
Be sure that data link tables are deleted from nodes that are not
participating in the data links.
(2) Automatically Set Data Links
Be sure that the correct DM parameters have been set in the data link
startup node.
•If incorrect data link tables or parameters are set, injury may result due to
unexpected operation of the system. Even if the correct data link tables and
parameters have been set, do not start or stop data links before verifying
that there will be no adverse influence on the system.
Routing Tables
CPU Bus Units are reset when routing tables are transferred from a
Programming Device to a PLC to allow set routing tables to be read. Make
sure that resetting CPU Bus Units will not cause equipment damage or
dangerous system behavior before transferring tables.
xix

4 Operating Environment Precautions
4 Operating Environment Precautions
!Caution Perform installation properly, according to the procedures described in this
manual.
!Caution Do not install in the following locations:
•Locations subject to direct sunlight
•Locations subject to temperatures or humidity outside the range specified in
the specifications
•Locations subject to condensation as the result of severe changes in
temperature
•Locations subject to corrosive or flammable gases
•Locations subject to dust (especially iron dust) or salts
•Locations subject to exposure to water, oil, or chemicals
•Locations subject to shock or vibration
!Caution Take appropriate and sufficient countermeasures when installing in the
following locations:
•Locations subject to static electricity or other forms of noise
•Locations subject to strong electromagnetic fields
•Locations subject to possible exposure to radioactivity
•Locations close to power supplies
xx

5 Guide to Version Upgrade
5 Guide to Version Upgrade
The following table shows the changes in the upgrade from CX-Integrator
Ver. 1.0 to Ver. 1.1.
Item Previous (Ver. 1.0) Ver. 1.1
CP1H supported as PLC model No Yes
Automatic
online
connection
Automatic
USB
connection
No Yes. When Automatic USB
Connection is selected from the
Network Menu, the PLC model
(such as the CP1H) is
automatically recognized and
connected online.
Ethernet network PING test No Yes
Echoback test between nodes
on Ethernet, Controller Link,
SYSMAC LINK, and DeviceNet
No Yes. (Response time can be
measured.)
Controller Link network
diagnosis Repeater display
No Branching information can be
displayed by Repeater Units.
Start Special Application No It is possible to select an Inverter
on DeviceNet, and to start the
CX-Drive.
Support for NSJ Series No Yes
xxi
