ASX344ATSC00XUEAH3-GEVB
ASX344AT
Evaluation Board
User's Manual
Evaluation Board Overview
The evaluation boards are designed to demonstrate the features of
image sensors products from ON Semiconductor. This headboard is
intended to plug directly into the Demo 3 system. Test points and
jumpers on the board provide access to the clock, I/Os, and other
miscellaneous signals.
Features
•Clock Input
♦Default – 27 MHz Crystal Oscillator
♦Optional Demo 3 Controlled MClk
•Two-wire Serial Interface
♦Selectable Base Address
•Parallel Interface
•ROHS Compliant
Block Diagram
Figure 2. Block Diagram of ASX344ATSC00XUEAH3−GEVB
www.onsemi.com
EVAL BOARD USER’S MANUAL
Figure 1. ASX344AT Evaluation Board

ASX344ATSC00XUEAH3−GEVB
www.onsemi.com
2
Top View
Figure 3. Top View of the Board −Default Jumpers
RESET SW1
SADDR P3
SPI_SOCKET_SELECT P17
SPI_FLASH_SELECT P15
SPI_SELECT P13
S_CONFIG P14
SPI_CONFIG_FLASH P16
EEPROM Sel. P32
OSC/XTAL Sel. P21, P22
SPI Program P18
Mode Sel. P26
GPI_FV P9
GPI_LV P10
GPI_LSB1 P8
JTAG I/F P19
BEAGLE_SELECT P25
BEAGLE I/F P24
TRST_N P6
CLK_OUT P20
EEPROM ADDR P23
+VDDIO P33
DOUTLSB P5
UART_EN P12
UART I/F P11
+VPP P2
ON_LED P29
ATEST P4
GPI_LSB0 P7
Sensor Mode Sel. P30, P31
IIC Control Sel. P27, P28
Bottom View
Figure 4. Bottom View of the Board −Connector
Baseboard Connector J2

ASX344ATSC00XUEAH3−GEVB
www.onsemi.com
3
Jumper Pin Locations
The jumpers on headboards start with Pin 1 on the
leftmost side of the pin. Grouped jumpers increase in pin
size with each jumper added.
Figure 5. Pin Locations for a Single Jumper. Pin 1 is Located at the Leftmost Side
and Increases as it Moves to the Right
Pins 1−4Pin 1
Figure 6. Pin Locations and Assignments of Grouped Jumpers.
Pin 1 is Located at the Top-Left Corner and Increases in a Zigzag Fashion Shown in the Picture
Pins 1 and 2Pin 1
Pins 3 and 4
Pins 5 and 6
Pins 7 and 8
Pins 9 and 10
Jumper/Header Functions & Default Positions
Table 1. JUMPERS AND HEADERS
Jumper/Header No. Jumper/Header Name Pins Description
P2 +VPP Open For Connection to External 8.5 V +VPP Power Supply for
OTPM
P3 SADDR 2−3 (Default) I2C Address Set to 0x90
1−2 I2C Address Set to 0xBA
P4 ATEST[2:1] Open (Default) For Debug/Test
P5 DOUTLSB[1:0] 1−2,
3−4 (Default)
DOUTLSB[1:0] are Used; Sensor in 10-bit Output
Configuration
Open DOUTLSB[1:0] are Not Used; Sensor in 8-bit Output
Configuration
P6 TRST_N Closed (Default) Normal Operation
Open Test Mode
P7 GPI_LSB0 2−3 (Default) Video Output in NTSC Mode
1−2Video Output in PAL Mode
P8 GPI_LSB1 2−3 (Default) Video Output is Not Vertically Flipped
1−2Video Output is Vertically Flipped
P9 GPI_FV 2−3 (Default) Video Output is Not Horizontally Flipped
1−2Video Output is Horizontally Flipped
P10 GPI_LV 2−3 (Default) Video Output does Not Have Pedestal
1−2Video Output has Pedestal
P11 UART I/F Open (Default) For Debug/Test

ASX344ATSC00XUEAH3−GEVB
www.onsemi.com
4
Table 1. JUMPERS AND HEADERS (continued)
Jumper/Header No. DescriptionPinsJumper/Header Name
P12 UART Disable/Enable Sel. Open (Default) UART I/F Disabled
Closed UART I/F Enabled
P13 SPI EEPROM Mem. Sel. 1−2 (Default) SPI EEPROM (1Mbit) Selected
2−3SPI EEPROM (1Mbit) Not Selected
P14 Sensor Config. Mode Sel. 2−3 (Default) Sensor Operating in CONFIG Mode
1−2Sensor Operating in FLASH Mode
P17 SPI SOCKET Mem. Sel. 2−3 (Default) SPI SOCKET Not Selected
1−2SPI SOCKET Selected
P18 SPI Program Open (Default) For Connection to External SPI Memory Programmer
P19 JTAG I/F Open (Default) For Debug/Test
P20 CLK_OUT 1−2 (Default) Connects to On-board Oscillator
2−3Connects to HB_MCLK
P21, P22 OSC/XTAL Sel. P21 2−3,
P22 Closed
(Default)
Selects Crystal as Sensor Input Clock
P21 1−2,
P22 Open
Selects Oscillator as Sensor Input Clock
P23 EEPROM Address 1−2 Closed,
3−4 Open
(Default)
EEPROM Address Set to 0xA8
1−2 Open,
3−4 Open
EEPROM Address Set to 0xAC
1−2 Open,
3−4 Closed
EEPROM Address Set to 0xA4
1−2 Closed,
3−4 Closed
EEPROM Address Set to 0xA0
P24 BEAGLE I/F Open (Default) For Debug/Test
P25 BEAGLE Disable/Enable
Sel.
Open (Default) BEAGLE I/F Disabled
Closed BEAGLE I/F Enabled
P26 Sensor Select 2−3 (Default) Auto/Host Mode
1−2IIC Master Mode
P27, P28 IIC Control Source Select P27 1−2,
P28 1−2
Demo 3 IIC Control
P27 2−3,
P28 2−3
Beagle IIC Control
P30, P31 Sensor Host/Auto Config.
Select
P30 1−2,
P31 1−2
Host Mode
P30 2−3,
P31 2−3
Auto Mode
P32 EEPROM Sel. 2−3 (Default) Device Address Set to 0xA0
P33 +VDDIO Select 2−3 (Default) Select +1V8_VDDIO
1−2Select +2V8_VDDIO
SW1 RESET N/A When Pushed, 240 ms Reset Signal will be Sent to
ASX344

ASX344ATSC00XUEAH3−GEVB
www.onsemi.com
5
Interfacing to ON Semiconductor Demo 3 Baseboard
The ON Semiconductor Demo 3 baseboard has a similar
52-pin connector which mates with J2 of the headboard.
The four mounting holes secure the baseboard and the
headboard with spacers and screws.
Shorted Jumpers for Power Measurement
Different supplies to the evaluation board are provided by
trace shorted jumper, for any voltage and power
measurements. To conduct current for current measurement
on a given power rail, cut the trace between the two pins of
their respective JP, and insert an ammeter prior to powering
up the system. The figure below shows where the trace to cut
is located.
Table 2. SHORTED JUMPERS FOR POWER
MEASUREMENT
Jumper Voltage (V)
JP1 (+2V8_VAA) 2.8
JP2 (+2V8_VAAPIX) 2.8
JP3 (+2V8_VDDPLL) 2.8
JP4 (+2V8_VDDIO) 2.8
JP5 (+2V8_VDDDAC) 2.8
JP6 (+1V8_VDD_EXT) 1.8
JP7 (+VDDIO_LS) 2.8
JP8 (+3V3) 3.3
Figure 7. Top and Bottom View of Shorted Jumper.
The Bottom View Shows the Trace Location to Cut for Current Measurement
Cut Here
