ON Semiconductor MT9P004EBMSTCH-GEVB User manual
©Semiconductor Components Industries, LLC, 2016
July, 2016 −Rev. 0
1Publication Order Number:
EVBUM2443/D
MT9P004EBMSTCH-GEVB
MT9P004 Evaluation Board
User's Manual
Evaluation Board Overview
The evaluation boards are designed to demonstrate the features of
ON Semiconductor’s image sensors products. This headboard is
intended to plug directly into the Demo 2X system. Test points and
jumpers on the board provide access to clock, I/Os and other
miscellaneous signals.
Features
•Clock Input
♦Default −24 MHz crystal oscillator
♦Optional Demo 2X controlled MClk
•Two Wire Serial Interface
♦Selectable base address
•Parallel Interface
•MIPI Interface
•ROHS Compliant
Block Diagram
Figure 2. Block Diagram of MT9P004EBMSTCH−GEVB
www.onsemi.com
EVAL BOARD USER’S MANUAL
Figure 1. MT9P004 Evaluation Board
MT9P004EBMSTCH−GEVB
www.onsemi.com
2
Top View
Figure 3. Top View of Evaluation Board −Default Jumpers
+2V8_VAA P6
CLK_SELECT P13
ON_LED P8
+VDD_TX P12
EEPROM P14, P15
GPI0 P16
TEST P2
RESET Switch SW1
+VDDIO P9
SHUTTER P5
FLASH P4
GPI3 P19
GPI1 P17
GPI2 P18
+VDD P11
+2V8_VAAPIX P7
+VPP P1
+VDD_PLL P10
Bottom View
Figure 4. Bottom View of the Evaluation Board −Connector
Baseboard Connector P36
Baseboard Connector P9
MIPI Connector J3
MT9P004EBMSTCH−GEVB
www.onsemi.com
3
Jumper Pin Locations
The jumpers on headboards start with Pin 1 on the leftmost
side of the pin. Grouped jumpers increase in pin size with
each jumper added.
Figure 5. Pin Locations for a Single Jumper.
Pin 1 is Located at the Leftmost Side and Increases as it Moves to the Right
Pin 1 Pins 1−4
Figure 6. Pin Locations and Assignments of Grouped Jumpers.
Pin 1 is Located at the Top-Left Corner and Increases in a Zigzag Fashion Shown in the Picture
Pins 1 and 2
Pins 3 and 4
Pins 5 and 6
Pins 7 and 8
Pins 9 and 10
Pin 1
Jumper/Header Functions & Default Positions
Table 1. JUMPERS AND HEADERS
Jumper/Header No. Jumper/Header Name Pins Description
P1 +VPP Open (Default) For connection to external 6.5~7.0 V +VPP power supply for
OTPM
P2 TEST 1−2 (Default) Configure to MIPI
2−3Configure to CCP2
P4 FLASH Open (Default) For connection to external flash
P5 SHUTTER Open (Default) For connection to external shutter
P6 +2V8_VAA 1−2 (Default) Connects to on-board +2V8_VAA power supply
2−3External power supply connection
P7 +2V8_VAAPIX 1−2 (Default) Connects to on-board +2V8_VAAPIX power supply
2−3External power supply connection
P8 ON_LED 1−2 (Default) Turn on +5V bus LED indicator
2−3Turn on +5V bus LED indicator
P9 +VDDIO 1−2 (Default) Connects to on-board +VDDIO power supply
2−3External power supply connection
P10 +VDD_PLL 1−2 (Default) Connects to on-board +VDD_PLL power supply
2−3External power supply connection
P11 +VDD 1−2 (Default) Connects to on-board +VDD power supply
2−3External power supply connection
MT9P004EBMSTCH−GEVB
www.onsemi.com
4
Table 1. JUMPERS AND HEADERS (continued)
Jumper/Header No. DescriptionPinsJumper/Header Name
P12 +VDD_TX 1−2 (Default) Connects to on-board +VDD_TX power supply
2−3External power supply connection
P13 CLK_SELECT 2−3 (Default) Connects to on-board oscillator
1−2Connects to XMCLK from Demo 2X Baseboard
P14, P15 EEPROM ADDR P14 Closed, P15
Open (Default)
EEPROM Address set to 0xA8
P14 Open,
P15 Open
EEPROM Address set to 0xAC
P14 Open,
P15 Closed
EEPROM Address set to 0xA4
P14 Closed,
P15 Closed
EEPROM Address set to 0xA0
P16 GPI0 Open (Default) For various sensor’s settings/connection to external peripherals
P17 GPI1 Open (Default) For various sensor’s settings/connection to external peripherals
P18 GPI2 Open (Default) For various sensor’s settings/connection to external peripherals
P19 GPI3 Open (Default) For various sensor’s settings/connection to external peripherals
SW1 RESET N/A When pushed, 240 ms reset signal will be sent to MT9P004
Interfacing to ON Semiconductor Demo 2X Baseboard
The ON Semiconductor Demo 2X baseboard has a similar
26-pin connector and 13-pin connector which mate with P9
and P36 of the headboard. The four mounting holes secure
the baseboard and the headboard with spacers and screws.
