••Do not attempt to plug in your Wireless Phone Line Extender until you
have read this owners manual.
••Read, understand and follow all instructions.
••The Wireless Phone Line Extender System does not operate during a
power outage.
••The Wireless Phone Line Extender System can only be used for a single
(analog) phone line.
••Choose an easily accessible socket-outlet close to the equipment you
want to use.
••Equipment connected to the base and extension must be approved for
telephone system.
••Unplug the system from the wall outlet before cleaning. Do not use
liquid or aerosol cleaners. Use a damp cloth for cleaning.
••Do not use this system near water; for example, near a bath tub,
washbowl, kitchen sink or laundry tub, in a wet basement or near a
swimming pool.
••Never spill liquid of any kind on the system.
••This system should never be placed near or over a heat radiator.
••This system should not be placed in a built-in installation unless proper
ventilation is provided.
••Do not disassemble or open the system. Service must be done by a
qualified service center of ONE FOR ALL.
SV_1550 31-03-2006 14:44 Pagina 2

M
TThhaannkkYYoouu
WWW.ONEFORALL.COM 3
Thank you for purchasing the ONE FOR ALL “Wireless Phone Line Extender”.
ONE FOR ALL is continuously striving to develop, produce and market high
quality innovative products. We hope the “Wireless Phone Line Extender”
will give you the freedom of wireless control.
The Wireless Phone Line Extender is a wireless and cable free extension of
the phone socket or VoIP adapter for an ordinary phone, modem, fax or
satellite/cable set top box with integrated modem.
Please read the following thoroughly and observe the operating instructions
and information provided. Keep this guide for future use.
Carefully remove units from packaging. If there is any visible damage DO
NOT attempt to operate the Wireless Phone Line Extender. Contact your
dealer or shipping carrier immediately.
BBOOXXCCOONNTTEENNTTSS::
11..ONE BASE UNIT
22..ONE EXTENSION UNIT
33..ONE PHONE LINE CORD
44..WALL SOCKET ADAPTOR
55..BASE UNIT ADAPTOR
66..EXTENSION UNIT ADAPTOR
UUnnppaacckkiinngg
Indicator
light
Phone socket
Phone line
Indicator
light
Phone socket
Switch
22
33
33
44
55
77
88
99
00
r
SV_1550 31-03-2006 14:44 Pagina 3

4WWW.ONEFORALL.COM
BBaasseeuunniittiinnssttaallllaattiioonn
W
11..Plug the wall socket adaptor in the existing phone wall socket.
22..Connect the enclosed phone line cord to the Base unit and connect
the other end to the wall socket adaptor.
33..Connect your phone to the Base unit adaptor and connect Base unit
adaptor to the Base unit.
44..Connect the Base unit to a power outlet and switch power on.
The light on top of the Base unit should now glow green.
The Base unit is now installed.
Th
o
11
22
11..Wall socket adaptor
33..Base unit
adaptor
22..Enclosed phone line cord
44..Power
outlet
SV_1550 31-03-2006 14:44 Pagina 4

M
TEL LINE
PPHHOONNEE//FFAAXX
SSAATTRREECCEEIIVVEERR//CCAABBLLEEBBOOXX
PPCC
EExxtteennssiioonnuunniittiinnssttaallllaattiioonn
WWW.ONEFORALL.COM 5
The Extension unit can be connected to either a normal phone, modem, fax
or satellite/cable set top box.
11..Connect the extension unit adaptor to the Extension unit.
22..Plug the phone line cord from your phone, modem, fax or satellite/
cable set top box into the Extension unit.
it
r
11..Extension
unit adaptor
22..Extension unit
not included
SV_1550 31-03-2006 14:44 Pagina 5

6WWW.ONEFORALL.COM W
33..3A: Connection of phone. Turn the switch to “S”-position for Speech
(voice).
3B: Connection of modem, fax or satellite/cable set top box. Turn the
switch to “C”-position for Computer (modem, fax or satellite/cable set
top box).
44..Plug the Extension unit into a power outlet and switch power on. The
light on top of the Extension unit will after a short period glow green
(if switch is on C) or yellow (if switch is on S).
The Extension unit is now installed and your Wireless Phone Line Extender
are now ready for use.
Indicator light
Switch
33AA..Speech (phone)
33BB..Computer (modem, fax,
satellite/cable set top box
33..Extension unit
44..Power
outlet
S
F
N
LL
LL
S
S
F
F
N
SV_1550 31-03-2006 14:44 Pagina 6

OOppeerraattiinnggMMooddeess
M WWW.ONEFORALL.COM 7
r
t
Steady Green Base unit is ready None
No Extension units in use Normal operation
Flashing Green The Wireless Telephone None
Line Extender is using Normal operation
telephone line
No Light No power to Check that the Base unit
Base unit is properly connected to
a power outlet and the
power is on
LLiigghhttsshhoowwssTThhiissmmeeaannssSSuuggggeesstteeddffiixx
BBAASSEEUUNNIITT
LLiigghhttsshhoowwssTThhiissmmeeaannssSSuuggggeesstteeddffiixx
EEXXTTEENNSSIIOONNUUNNIITT
Steady Green Extension unit in None
computer/Data (“C”) is Normal operation
registered and in range
of Base unit and ready
for use
Steady Yellow Extension in Speech/ None
voice (“S”) is registered Normal operation
and in range of Base
unit and ready for use
Flashing Green Extension unit in use None
(C mode) Normal operation
Flashing Yellow Extension unit in use None
(S mode) Normal operation
No Light No power to Extension Check that the
unit Extension unit is
properly connected to
a power outlet and the
power is on
SV_1550 31-03-2006 14:44 Pagina 7

W8WWW.ONEFORALL.COM
If
Ex
yo
vis
O
- 2
- n
- p
- i
BBee
ffoo
11..
22..
33..
-
-
-
WW
-
-
-
LLiigghhttsshhoowwssTThhiissmmeeaannssSSuuggggeesstteeddffiixx
EEXXTTEENNSSIIOONNUUNNIITT
Steady Red Extension unit is not Contact our customer
registered to a Base unit service department
Flashing Red Extension unit is Check that Base unit
to Yellow or registered but not locked is powered up. If it is,
Flashing Red to to Base unit Extension unit may be
Green out of range of Base
unit. Relocate either the
Extension unit or the
Base unit to bring the
units closer together
TTrroouubblleesshhoooottiinngg
No dialling tone - Base unit power not on - Check all power and
available - Cables not correctly cable connections. If
connected in doubt please refer
- Extension unit may to the user manual.
not be registered to Check that the
base Extension unit swich is
- The Extension unit is correctly set to either
out of reach S or C
- Relocate the
Extension unit within
signal reach of the
Base unit (max 50m)
My modem/set The Extension unit Make sure that the
top box/fax is switch has not been Extension unit switch is
not working set to modem set to C
functionality
Short “hissing” The Extension unit Make sure that the
sound heard on switch has not been Extension unit switch
phone attached set properly is set to S
to Extension
unit when first
picked up
PPrroobblleemmPPoossssiibblleeccaauusseeSSoolluuttiioonn
P
t
r
l
c
B
PP
SV_1550 31-03-2006 14:44 Pagina 8

WWW.ONEFORALL.COM 9M
CCuussttoommeerrSSeerrvviiccee
If you still have questions about the operation of your Wireless Phone Line
Extender and could not find the answer(s) in the trouble shooting section,
you may want to contact the customer service department for assistance or
visit our Internet-site: wwwwww..oonneeffoorraallll..ccoomm
Our internet-site has many advantages:
- 24 hours access
- no waiting time
- page for Frequently Asked Questions
- info about the ONE FOR ALL product range
BBeeffoorreeccoonnttaaccttiinngguuss,,bbyyFFaaxx,,EE--mmaaiilloorrPPhhoonnee,,mmaakkeessuurreettoohhaavveetthhee
ffoolllloowwiinnggiinnffoorrmmaattiioonnaavvaaiillaab
bllee;;
11..The ONE FOR ALL SSVV--11555500Wireless Phone Line Extender.
22..The date of purchase (.........../.........../...........).
33..Clear description of the problem.
- [e-mail] (Just send blank message, you will get auto-reply)
- fax: [phone]
- tel: [phone] (£1 per minute)
WWaarrnniinngg::
- Do not use this equipment in places where volatile or explosive
materials may be present.
- This equipment will be inoperable if mains power fails.
- For indoor use only.
Phone connected This is normal. One -
to Extension unit ring delay is necessary
rings one ring to allow transfer of
later than phone Caller ID information
connected to from base to Extension
Base unit unit
PPrroobblleemmPPoossssiibblleeccaauusseeSSoolluuttiioonn
SV_1550 31-03-2006 14:44 Pagina 9

W10 WWW.ONEFORALL.COM
DDeeccllaarraattiioonnooffCCoonnffoorrmmiittyy
We, Universal Electronics Inc., 6101 Gateway Drive, Cypress, CA 90630,
U.S.A., and its subsidiaries
Universal Electronics BV, Institutenweg 21, 7521 PH Enschede,
ONE FOR ALL UK Ltd, Institutenweg 21, 7521 PH Enschede, Netherlands,
Declare under sole responsibility that the ONE FOR ALL Wireless Phone Line
Extender (SV 1550)
is in conformity with the requirements of the EC directives:
99/5/EC Directive for radio facilities and telecommunication terminals.
The presumption of conformity with essential requirements regarding
Council Directive 99/05/EC is ensured according to:
R&TTE: Directive 99/05/EC Standard: EN 301 406 V1.5.5 (2003-07)
Additionally, the Wireless Phone Line Extender is in conformity with the
below mentioned directives:
EMC: Directive 89/336/EC Standard: EN 301 489-1 V1.4.1 (2002-08)
EN 301 489-6 V1.2.1 (2002-08)
Safety: Directive 73/23/EC Standard: EN 60950-1 (2001 ed. 1)
Intended use:
The Wireless Phone Line Extender base unit is intended for being switched
into the analog telephone network via the normal telephone plug. The
Wireless Phone Line Extender extension unit is intended for being connect-
ed to the input of an analog phone or modem. Both units are supplied from
the public mains supply. Any other use is deemed as not intended use.
Unauthorized alterations or modifications, which are not described in the
user manual, are not admissible.
Enschede, 10th of March 2006
Paul J. Bennett
As Managing Director of Universal Electronics BV
Th
m
an
ho
To
se
re
Fo
go
SV_1550 31-03-2006 14:44 Pagina 10

WWW.ONEFORALL.COM 11M
e
8)
8)
-
m
The crossed –out wheeled bin symbol that can be found on your product
means that the product is covered by the European Directive 2002/96/EC
and it indicates that this product should not be disposed of via the normal
household waste stream.
To prevent possible harm to the environment or human health, please
separate this product from other waste streams to ensure that it can be
recycled in an environmentally sound manner.
For more details on available collection facilities, please contact your local
govern office or the retailer where you purchased this product.
SV_1550 31-03-2006 14:44 Pagina 11

SSVV--11555500
770033882244
RRDDNN11331100330066
GGuuaarraanntteeee
UNIVERSAL ELECTRONICS / ONE FOR ALL warrants to the original purchaser that this
product will be free from defects in materials and workmanship under normal and correct
use for a period of one (1) year from the date of original purchase. This product will be
repaired or if necessary replaced free of charge if it has been proven to be defective within
the one (1) year warranty period. The forwarding costs are on the account of the owner;
the costs of returning the product are on the account of UNIVERSAL ELECTRONICS / ONE
FOR ALL. This warranty does not cover damage or failures caused by products or services not
supplied by UNIVERSAL ELECTRONICS / ONE FOR ALL, or which result from not mounting
the product according to manual instructions. This also applies when the product has been
modified / repaired by others than UNIVERSAL ELECTRONICS / ONE FOR ALL or if a fault is
the result from accident, misuse, abuse, neglect, mishandling, misapplication, faulty
installation, improper maintenance, alteration, modifications, fire, water, lightning, natural
disasters, wrong use or carelessness. To obtain warranty service during the warranty period,
please notice that we need your original purchase receipt so that we may establish your
eligibility for service. If you have bought this product for purposes which are not related to
your trade, business or profession, please remind that you may have legal rights under your
national legislation governing the sale of consumer goods. This guarantee does not affect
those rights.
Universal Electronics BV
Europe & International
P.O. Box 3332
7500 DH, Enschede
The Netherlands
SV_1550 31-03-2006 14:44 Pagina 12
