One Remote RMB4 User guide

Setup Manual
Converter installed in a Beo4
OneRemote RMB4
Converter for Beo4
Type 35104452 controls
Sony TV
all TV models
35104452.s1.uk

1
www.oneremote.dk
With a OneRemote RMB4 converter type 3510.4451 installed in a Bang & Olufsen Beo4 remote
control terminal it may control a Sony TV with that terminal.
The RMB4 factory setting will fit most users, making it possible to fully control a Sony TV as with
its original Sony remote control.
This manual explains how to set up the controller for further integration.
The modified Beo4 can also control an AppleTV or a MAC PC.
A OneRemote RMB4 converter may be installed in any Beo4 model, also the latest versions with
a Joystick instead of a Go button, the so-called Navi model.
Control with a Beo4 Navi is very different thus the user manual has a separate Control table for
this.
Your OneRemote RMB4 modified Bang & Olufsen Beo4 may operate a
Sony TV and other Bang & Olufsen devices. You might even enjoy the
TV sound via your Bang & Olufsen speakers, if connected correctly.

2
www.oneremote.dk
Indhold
INITIAL INSTALLATION ................................................................................................................3
Options –Optimizing the installation ........................................................................... 3
Options -Acknowledge ................................................................................................. 3
INTEGRATION WITH A BANG & OLUFSEN RADIO. VOLUME CONTROL.....................................4
DISABLING THE ONEREMOTE CONVERSION ..............................................................................5
TEMPORARILY BANG & OLUFSEN TV CONTROL .........................................................................5
SOURCE KEY - SAT/ DTV..............................................................................................................6
SOURCE KEY - DVD......................................................................................................................7
SOURCE KEY - VAUX....................................................................................................................8
SOURCE KEY - RADIO SOURCE ....................................................................................................9
SOURCE KEY - APPLE TV CONTROL .............................................................................................9

3
www.oneremote.dk
Initial Installation
With a OneRemote RMB4 converter installed in your Bang & Olufsen Beo4 remote control
terminal you may also control a Sony TV with that terminal. You may still operate Bang & Olufsen
devices.
The RMB4 Factory setting will fit most users, making it possible to fully control an Sony TV as
with its original Sony remote control.
This manual covers special installations where further integration is needed. Maybe setups
including other Bang & Olufsen devices or even.
To alter the behaviour of the way the OneRemote modified Remote Control operates, one or
more so called Options must be entered.
Options –Optimizing the installation
An option is set simply by entering the key sequences shown in the tables. At any time, simply
enter the 7-key sequence in the modified Beo4 remote control. The function will immediately
take effect.
Some Options may require entering two separate Options. An example could be when control of
both a connected Set Top Box i.e. an Apple TV and the Sony TV is needed. Here the RMB4
converter needs to have two Options set:
1. Which Source key on Beo4 is used to activate control of the set top box i.e. d
2. Which Socket on the TV must be opened, when pressing this Source key?
Any Option can be altered at any time. An Option is available to reset all Options to factory
default settings.
Options -Acknowledge
Entering an option is straight forward, but if an acknowledge is needed, it can be achieved setting the Sony
TV in TV mode, before entering the Option.
After entering an Option, the RMB4 converter will send a status to the TV, making it change Channel.
TV receives a ‘0’: An error has occurred; the Option has not been recognized or saved properly.
TV receives a ‘1’: An Option has been saved correctly.
TV receives a ‘3’: The OneRemote RMB4 converter has been factory reset.

4
www.oneremote.dk
Integration with a Bang & Olufsen Radio. Volume Control.
If a Bang & Olufsen radio is present in the
same room as the non-Bang & Olufsen TV,
better TV sound can be achieved by passing
the sound signal through the radio to its
connected speakers.
To do this, simply connect “analog out” from
the TV to the B input on the B&O radio.
Then set the AAUX option from the table
below.
Pressing twill hereafter power on both
the non-Bang & Olufsen TV and the Bang &
Olufsen radio. All controls will hereafter be sent to the non-Bang & Olufsen TV, only Volume and Mute
controls will be sent to the Bang & Olufsen radio.
Volume controls, fully ignored.
Lmq0000
Volume controls, control the TV. Factory
Lmq0010
Volume controls, control a B&O radio. *1
Lmq0020
Volume controls, control a B&O TV. *2
Lmq0030
*1 When tis pressed the Beo4 powers on the TV. At the same time the Beo4 sends an Bcommand to a Bang &
Olufsen audio master. Until another source is selected, volume controls will be directed to the B&O audio master.
*2 When tis pressed the Beo4 powers on the TV. At the same the Beo4 sends a ccommand to a Bang & Olufsen
system. Until another source is selected, volume commands will be directed to the B&O system. Via a BeoLink Active the sound
may be moved from the TV to B&O PowerLink speakers.

5
www.oneremote.dk
Disabling the OneRemote Conversion
If the modified Beo4 remote control is to be used with Bang & Olufsen devices only, the converter can be
disabled. Simply enter the 7-key sequence shown in the table below.
Disable the OneRemote converter
Lmq0002
Enable the OneRemote converter. Factory
Lmq0012
When the OneRemote converter is disabled, the Beo4 remote control will operate as if no converter had been installed.
Temporarily Bang & Olufsen TV control
tControls a Bang & Olufsen TV
Volume down followed by 0
tControls a Sony TV factory.
Volume down followed by 1

6
www.oneremote.dk
Source Key - SAT/ DTV
Factory setting makes the Beo4 source key s/ fis used for selecting the HDMI1 socket on the
Sony TV and hereafter simultaneously control an Apple TV, connected to this input.
The s/ fkey can be programmed for other uses, simply by entering the corresponding 7-key
sequences from below table.
f opens no source
Lmq000f
fopens HDMI1
Lmq001f
fopens HDMI2
Lmq002f
fopens HDMI3
Lmq003f
fopens HDMI4
Lmq004f
fopens Video1
Lmq005f
fopens Video2
Lmq006f
fopens Video3
Lmq007f
fopens Component1
Lmq008f
fopens Component2
Lmq009f
fopens Netflix (TV)
Lmq014f
fsends Home factory
Lmq015f
Pressing fwill select the set source.
Also control will shift to control an Apple TV instead of the TV.
Not all TV models accepts all these sources.

7
www.oneremote.dk
Source Key - DVD
Factory setting makes the Beo4 source key dis used for selecting the HDMI2 socket on the Sony TV.
The dkey can be programmed for other uses, simply by entering the corresponding 7-key sequences
from the table below.
d opens no source
Lmq000d
d opens HDMI1
Lmq001d
d opens HDMI2
Lmq002d
d opens HDMI3
Lmq003d
d opens HDMI4
Lmq004d
d opens Video1
Lmq005d
d opens Video2
Lmq006d
d opens Video3
Lmq007d
dopens Component1
Lmq008d
dopens Component2
Lmq009d
dopens Netflix (TV) factory
Lmq014d
dsends Home
Lmq015d
Pressing dwill select the set source.
Not all TV models accepts all these sources.

8
www.oneremote.dk
Source Key - VAUX
Factory setting makes the Beo4 source key aselect the Video1 input on the Sony TV.
The akey can be programmed for other uses, simply by entering the corresponding 7-key sequences
from the table below.
a opens no source
Lmq000a
a opens HDMI1 factory
Lmq001a
a opens HDMI2
Lmq002a
a opens HDMI3
Lmq003a
a opens HDMI4
Lmq004a
a opens Video1
Lmq005a
a opens Video2
Lmq006a
aopens Video3
Lmq007a
aopens Component1
Lmq008a
aopens Component2
Lmq009a
aopens Netflix (TV)
Lmq014a
asends Home
Lmq015a
Pressing awill select the set source.
Not all TV models accepts all these sources.

9
www.oneremote.dk
Source Key - Radio Source
This extra option is not for use with a non-Bang & Olufsen TV, but exclusively for use with a Bang & Olufsen radio. Pressing
uon Beo4 will normally power on a Bang & Olufsen radio and select its internal radio receiver.
The Radio Source option is used to select a different source on the Bang & Olufsen radio, when uis pressed. When a
OneRemote Internet- or DAB radio receiver is connected to the Bang & Olufsen radio, it can then be selected and controlled as a
usource, though connected to the Bang & Olufsen radio’s AAUX socket.
Ou will ALWAYS select the B&O radio’s internal radio, no matter what option has been selected.
u sends uto a B&O Radio Factory
Lmq001u
u sends Bto a B&O Radio
Lmq002u
u sends yto a B&O Radio
Lmq003u
u sends Ito a B&O Radio
Lmq004u
u sends Yto a B&O Radio
Lmq005u
Source Key - Apple TV Control
Factory setting makes the Beo4 asource key select the HDMI3 input on the Sony TV. Hereafter it
changes control to an Apple TV receiver. An Apple TV connected to HDMI can then be controlled directly.
•If another source key is preferred, enter the 7-key sequence from the table below.
•If another input socket is preferred, change the appropriate Source Selection Option as shown
above.
fEnables Apple TV control.
Lmq0025
dEnables Apple TV control.
Lmq0035
aEnables Apple TV control. Factory
Lmq0055
