ASSEMBLY & OPERATING INSTRUCTIONS
®
3
CAST ALUMINUM
GARDEN TRELLIS
Brought to You by Augusta Flint

THANK YOU for choosing a HARBOR FREIGHT TOOLS product. For future reference, please complete the owner’s
record below:
Model___________ Serial No._____________ Purchase Date_____________
Save This Manual
You will need the manual for the safety warnings and precautions, assembly instructions, operating
and maintenance procedures, parts list and diagram. Keep your invoice with this manual. Write the
invoice number on the inside of the front cover. Keep the manual and invoice in a safe and dry
place for future reference.
Technical Specifications
Construction: Cast Aluminum Frame and Steel with welded hinges
Overall Dimensions: 50-1/2" W x 18" L x 86-1/2" H
Base Dimensions: 51" L x 17-1/2"
Gate Dimensions: 23-7/8" W x 41-3/4" H
Mounting Holes: 4 x .312 Diameter
Net Weight: 51.2 LBS
Safety Warnings and Precautions
WARNING: When using product, basic safety precautions should always be followed to
reduce the risk of personal injury and damage to equipment.
Read all instructions before using this product!
1. Keep work area clean. Cluttered areas invite injuries.
2. Observe work area conditions. Do not use this product in damp or wet locations. Don’t
expose to rain. Keep work area well lighted.
3. Store idle equipment. When not in use, products must be stored in a dry location to inhibit
rust. Always lock up products and keep out of reach of children.
4. Use the right product for the job. There are certain applications for which this product was
designed. It will do the job better and more safely at the rate for which it was intended. Do not
modify this product and do not use this product for a purpose for which it was not intended.
5. Check for damaged parts. Before using any product, any part that appears damaged should
be carefully checked to determine that it will operate properly and perform its intended function.
Check for any broken or damaged parts and any other conditions that may affect its operation.
Replace or repair damaged or worn parts immediately.
6. Replacement parts and accessories. When servicing, use only identical replacement parts.
Use of any other parts will void the warranty.
7. Do not operate product if under the influence of alcohol or drugs. Read warning labels on
prescriptions to determine if your judgment or reflexes are impaired while taking drugs. If there
is any doubt, do not operate the product.
#08864 Page 2
Brought to You by Augusta Flint

Additional Warnings
1. Use eye protection. Always wear ANSI approved impact safety goggles.
2. Avoid Sharp edges when assembling.
3. Always check hardware and assembled parts after assembling. Place in an area that is
flat and level. All connections should be tight and hardware tightened.
4. Use extreme caution when moving the assembled Garden Trellis. Do not lift the Trellis
without assistance. Wear gloves and be careful to avoid pinching of fingers.
5. Do not allow children to play in, stand upon or climb upon the Trellis. Do not place
anything on top of the Trellis Arch. This is a delicate assembly.
6. The Garden Trellis must be staked or bolted down to prevent toppling in strong winds.
Warning: The warnings, cautions, and instructions discussed in this instruction
manual cannot cover all possible conditions and situations that may
occur. It must be understood by the operator that common sense and
caution are factors which cannot be built into this product, but must be
supplied by the operator.
Assembly
Your Cast Aluminum Garden Trellis will require complete assembly prior to use. It is important that
you read the entire manual to become familiar with the product BEFORE you use the Garden Trellis.
Before assembling the Garden Trellis be sure that you have all parts described in the Parts List and
Assemby Diagram located on the last pages of this manual.
Step 1) Locate both of the Base parts (#9) and the two (2) Frames (#1). Each Base (#9) has
an extension at each end. Insert one extension into the leg of one Frame (#1).
Step 2) The extension at the opposite end of the Base (#9) is to be inserted into the leg of
the second Frame (#1). Repeat this procedure for the second (2nd) Base (#9) and
other side of each Frame (#1)-refer to Parts diagram.
Step 3) Secure each Base (#9) to the Frames (#1) by inserting a Screw (#5) through the
Frame (#1) and the Base (#9) and securing in place with a Washer (#7) and Plastic
Cap (#6).
Step 4) The Garden Trellis has two Arches (#3). Connect the Arches together with
three (3) Cross Bars (#4). Each Cross Bar (#4) is connected at each end to one
Arch (#3) with a Screw (#5), a Washer (#7) and a Nut (#8)-see Parts diagram.
Step 5) Attach the Arches (#3) with Cross Bars (#4) to the Frames (#1). The assembled arch
will connect both Frames (#1) and create the Trellis.
Step 6) Secure the Arches (#3) in place on the Frames (#1) with a Bolt (#10), a Washer (#7)
and tighten into place with Plastic Caps (#6).
Step 7) Hang the Shutters (#2) by inserting the two rods on the Shutter (#2) into the shafts
on the Arch (#3). Repeat for second Shutter (#2).
#08864 Page 3
Brought to You by Augusta Flint

Mounting
Your Cast Aluminum Garden Trellis has four (4) .312 diameter mounting holes for Ground stakes
(not included) or bolts (not included). Upon completing assembly of the Garden Trellis, it should be
mounted to a flat and level surface.
Unpacking
UNPACK AND CHECK CONTENTS
When unpacking your Cast Aluminum Garden Trellis, check to make sure the following parts are
included. If any parts are missing or broken, please call HARBOR FREIGHT TOOLS at
1-800-444-3353.
Parts List-Cast Aluminum Garden Trellis
Part # Description Quantity Part # Description Quantity
1 Frame 2 6 Plastic Cap 14
2 Shutter 2 7 Washer 28
3 Arch 2 8 Nut 14
4 Cross Bar 3 9 Base 2
5 Screw 14
1
3
4
5
6
6
7
7
9
Note: Some parts are listed and shown for illustration purposes only and are not available
individually as replacement parts.
Assembly/Parts Diagram
#08864 Page 4
2
PLEASE READ THE FOLLOWING CAREFULLY
