OneTouch VERIOPRO + Manual

1
Meter Operator’s Guide
Blood glucose monitoring system
Yellow = 5mm margin, Red = 7mm margin
Yellow = 5mm margin, Red = 7mm margin
AW05948101B_OT_VerioPro+_OB_Insides_R1.indd 1 4/3/12 3:07 PM

2
Meter Operator’s Guide
Thank you for choosing OneTouch®.
The OneTouch® Verio™Pro+ Blood Glucose Monitoring System is one of the latest product innovations
from LifeScan®. Every OneTouch® meter is designed to make it easy to test your patient’s blood glucose
and help you manage their diabetes.
This Meter Operator’s Guide offers a complete explanation of how to use the new meter and testing
supplies, and reviews the do’s and don’ts of testing blood glucose levels. Clear instructions and visuals
will help you get comfortable using the OneTouch® Verio™Pro+ Meter, so you can expect to get reliable
results every time you test your patients. Please keep the Meter Operator’s Guide in a safe place; you may
want to refer to it in the future.
Yellow = 5mm margin, Red = 7mm margin
Yellow = 5mm margin, Red = 7mm margin
AW05948101B_OT_VerioPro+_OB_Insides_R1.indd 2 4/3/12 3:07 PM

3
Symbols
Cautions and Warnings. Refer to the Meter Operator’s Guide and inserts that came with the system
for safety-related information.
Direct current
Consult instructions for use
Battery low
Number
[Insert additional local symbols as required]
Yellow = 5mm margin, Red = 7mm margin
Yellow = 5mm margin, Red = 7mm margin
AW05948101B_OT_VerioPro+_OB_Insides_R1.indd 3 4/3/12 3:07 PM

4
Table of Contents
1Getting to know the system 11
2Setting up the meter 16
3Performing a control solution test 22
4Performing a blood glucose test 40
5Reviewing past results 58
6Performing a linearity test 62
7Care and maintenance 77
Yellow = 5mm margin, Red = 7mm margin
Yellow = 5mm margin, Red = 7mm margin
AW05948101B_OT_VerioPro+_OB_Insides_R1.indd 4 4/3/12 3:07 PM

5
8Batteries 80
9Troubleshooting 83
10
Detailed information about the system 94
11 Index 104
Yellow = 5mm margin, Red = 7mm margin
Yellow = 5mm margin, Red = 7mm margin
AW05948101B_OT_VerioPro+_OB_Insides_R1.indd 5 4/3/12 3:07 PM

6
Before you begin
Before using this product to test a patient’s blood glucose, carefully read this Meter Operator’s Guide, and
the inserts that come with the OneTouch® Verio™ Test Strips and OneTouch® Verio™ Control Solutions and
OneTouch Verio™Pro+ Linearity Solutions.
Intended use
The OneTouch® Verio™Pro+ Blood Glucose Monitoring System is intended to be used for the quantitative
measurement of glucose (sugar) in fresh capillary whole blood samples drawn from the fingertips.
Arterial and venous whole blood samples may be used as well.
The OneTouch® Verio™Pro+ Blood Glucose Monitoring System is intended for testing outside the body
(in vitro diagnostic use) by health care professionals as an aid to monitor the effectiveness of blood
glucose management.
The OneTouch® Verio™Pro+ Blood Glucose Monitoring System should not be used for the diagnosis of or
screening of diabetes. The OneTouch® Verio™Pro+ Blood Glucose Monitoring System is not intended to be
used for testing blood glucose of neonates.
Yellow = 5mm margin, Red = 7mm margin
Yellow = 5mm margin, Red = 7mm margin
AW05948101B_OT_VerioPro+_OB_Insides_R1.indd 6 4/3/12 3:07 PM

7
Test principle
Glucose in the whole blood sample mixes with chemicals in the test strip and a small electric current is
produced. The strength of this current changes with the amount of glucose in the whole blood sample.
The meter measures the current, calculates the patient’s blood glucose level, displays the blood glucose
result, and stores it in its memory.
Standard precautions
When testing multiple patients, it is important to follow your institution’s policies and local standards
and guidelines that apply to your region.
Yellow = 5mm margin, Red = 7mm margin
Yellow = 5mm margin, Red = 7mm margin
AW05948101B_OT_VerioPro+_OB_Insides_R1.indd 7 4/3/12 3:07 PM

8
The OneTouch® Verio™Pro+ Blood Glucose Monitoring System
The OneTouch® Verio™Pro+ System Kit
AOneTouch® Verio™Pro+ Meter
(batteries included)
BMeter Storage Case
AB
Yellow = 5mm margin, Red = 7mm margin
Yellow = 5mm margin, Red = 7mm margin
AW05948101B_OT_VerioPro+_OB_Insides_R1.indd 8 4/3/12 3:07 PM

9
OneTouch® Verio™ Control Solutions and Test Strips
COneTouch® Verio™ Low Control Solution (Green cap)
DOneTouch® Verio™ Mid Control Solution (Blue cap)
EOneTouch® Verio™ High Control Solution (Red cap)
FOneTouch® Verio™ Test Strips
The OneTouch® Verio™ Control Solutions and Test Strips are available separately. Follow your institution’s
procedure for obtaining additional test strips and control solutions.
Use only OneTouch® Verio™ Control Solutions and Test Strips with the OneTouch® Verio™Pro+ Meter.
CDEF
Yellow = 5mm margin, Red = 7mm margin
Yellow = 5mm margin, Red = 7mm margin
AW05948101B_OT_VerioPro+_OB_Insides_R1.indd 9 4/3/12 3:07 PM

10
OneTouch® Verio™Pro+ Linearity Solutions
GOneTouch® Verio™Pro+ Linearity Solution Level 1 (Grey cap)
HOneTouch® Verio™Pro+ Linearity Solution Level 2 (Green cap)
IOneTouch® Verio™Pro+ Linearity Solution Level 3 (Blue cap)
JOneTouch® Verio™Pro+ Linearity Solution Level 4 (Red cap)
KOneTouch® Verio™Pro+ Linearity Solution Level 5 (Purple cap)
KJH IG
mWARNING
Keep the meter and testing supplies away from young children. Small items such as the test strips, and control
and linearity solution vial caps are choking hazards. Do Not allow patients to ingest or swallow any items.
The OneTouch® Verio™Pro+ Linearity Solutions are available separately. Follow your institution’s
procedure for obtaining additional linearity solutions.
Use only OneTouch® Verio™Pro+ Linearity Solutions with the OneTouch® Verio™Pro+ Meter.
Yellow = 5mm margin, Red = 7mm margin
Yellow = 5mm margin, Red = 7mm margin
AW05948101B_OT_VerioPro+_OB_Insides_R1.indd 10 4/3/12 3:07 PM

1
Getting to know the system
11
Back button
• Go back to the previous screen
(press and release)
• Go back to the Main Menu
(press and hold)
Eject button
Eject test strip from meter
Getting to know the OneTouch® Verio™Pro+ Blood Glucose Monitoring System
Meter
Low battery icon
Indicates time to change batteries
Mini USB data port
Connect to download to computer
Up and down buttons
Highlight/change information
or values
Display
mmol/L is the pre-set unit of
measure and cannot be changed
OK button
• Turns meter on/off (press and hold)
• Confirms menu selections
(press and release)
Test strip port
Insert test strip here to turn meter on
Yellow = 5mm margin, Red = 7mm margin
Yellow = 5mm margin, Red = 7mm margin
AW05948101B_OT_VerioPro+_OB_Insides_R1.indd 11 4/3/12 3:07 PM

Getting to know the system
1
12
Test strip
BackFront
Channel to
apply sample
Silver prongs
Silver prongs should face you
when you insert test strip into
test strip port
Yellow = 5mm margin, Red = 7mm margin
Yellow = 5mm margin, Red = 7mm margin
AW05948101B_OT_VerioPro+_OB_Insides_R1.indd 12 4/3/12 3:07 PM

Getting to know the system 1
13
Turning the meter on
Press and hold until the start-up screen appears. Once the start-up screen is
displayed, release .
If the meter does not turn on, check the meter batteries. See pages 80-82.
NOTE: When turning the meter on for the first time, it will automatically start at
the Set Language screen to set the language, time and date (see pages 16-18).
m CAUTION
If there are any missing pixels within the start-up screen, there may be a problem
with the meter. Contact Customer Service and/or LifeScan® sales representative.
After the start-up screen, the Insert Strip to Test screen is displayed.
To perform a blood glucose test, see pages 40-57 or a control solution test, see
pages 22-39.
Or,
Press to go to the Main Menu.
VerioPro
+
Menu
Insert Strip
to Test
Yellow = 5mm margin, Red = 7mm margin
Yellow = 5mm margin, Red = 7mm margin
AW05948101B_OT_VerioPro+_OB_Insides_R1.indd 13 4/3/12 3:07 PM

Getting to know the system
1
14
08:0030 Apr
5.8 19:00
Last Result:
Settings
History (mmol/L)
Example
Main Menu with
History highlighted
Settings
History (mmol/L)
01 Apr
Serial #:
BCXFF2HK
12:45
Example
Main Menu with
Settings highlighted
A bar highlights the current selection on the Main Menu.
NOTE:
• When History is highlighted, the result from the most
recent blood glucose test appears at the bottom of the
Main Menu.
• When Settings is highlighted, the meter serial number
appears at the bottom of the Main Menu.
Yellow = 5mm margin, Red = 7mm margin
Yellow = 5mm margin, Red = 7mm margin
AW05948101B_OT_VerioPro+_OB_Insides_R1.indd 14 4/3/12 3:07 PM

Getting to know the system 1
15
Using the display backlight
The backlight comes on automatically whenever the meter is turned on. After a few seconds of no
activity, the backlight will dim. Pressing any button will turn the backlight back on without affecting the
current screen.
Inserting a test strip will turn the backlight back on and advance to the Apply Blood screen.
Audible cues and warnings
The meter will beep to provide prompts or confirmations and to notify of possible problems related to
the meter, test procedure, test result, or batteries.
Turning the meter o
There are two ways to turn the meter off:
• Press and hold for several seconds until the meter turns off.
Or,
• The meter will turn off by itself if it is unused for two minutes.
Yellow = 5mm margin, Red = 7mm margin
Yellow = 5mm margin, Red = 7mm margin
AW05948101B_OT_VerioPro+_OB_Insides_R1.indd 15 4/3/12 3:07 PM

2Setting up the meter
16
Setting the meter language, time and date
When turning on the meter for the first time, it will automatically start at the Set Language screen.
NOTE: You will not be able to perform a test when in the Settings mode.
1. Choose a language
In the Set Language screen, press or to highlight the language you want
and press .
Pressing after making your selection confirms each setting and takes you to
the next screen.
When setting up the meter, press to return to the previous screen to adjust a
setting.
Regional Lang.
English
Set Language
Welcome
Yellow = 5mm margin, Red = 7mm margin
Yellow = 5mm margin, Red = 7mm margin
AW05948101B_OT_VerioPro+_OB_Insides_R1.indd 16 4/3/12 3:07 PM

2
Setting up the meter
17
NOTE: The time and date formats are pre-set. These settings cannot be changed.
2. Set the time of day
In the Set Time screen, press or to set the hour and press . Repeat this
step to set the minutes.
3. Set the date
In the Set Date screen, press or to change the date and press . Repeat
these steps to set the month, then the year.
Set Time
:
12
12 45
12
Set Date
12Apr01 2011
Yellow = 5mm margin, Red = 7mm margin
Yellow = 5mm margin, Red = 7mm margin
AW05948101B_OT_VerioPro+_OB_Insides_R1.indd 17 4/3/12 3:07 PM

Setting up the meter
2
18
4. Confirm the meter settings
If the settings are correct, press with Done highlighted. The settings will be
saved.
Or,
If a setting is not correct, press or to highlight the incorrect setting and
press to return to that setting screen. After making the correction, press to
return to the Settings screen.
When finished, highlight Done and press to save the settings and return to the Main Menu.
Settings
Time:
12:45
Date:
01 Apr 2011
Language:
English
Done
Yellow = 5mm margin, Red = 7mm margin
Yellow = 5mm margin, Red = 7mm margin
AW05948101B_OT_VerioPro+_OB_Insides_R1.indd 18 4/3/12 3:07 PM

Setting up the meter 2
19
Next, select the settings to adjust Time, Date, or Language and press .
After making the adjustment to the desired setting, press to confirm the new
setting and return to the Settings screen.
Press to return to the Main Menu.
Adjusting settings after setting up the meter for the first time
Adjust the settings in the meter as needed.
Highlight Settings on the Main Menu screen and press .Settings
History (mmol/L)
01 Apr
Serial #:
BCXFF2HK
12:45
Meter Care
Settings
Time:
12:45
Date:
01 Apr 2011
Language:
English
Yellow = 5mm margin, Red = 7mm margin
Yellow = 5mm margin, Red = 7mm margin
AW05948101B_OT_VerioPro+_OB_Insides_R1.indd 19 4/3/12 3:07 PM

Setting up the meter
2
20
Next, select Meter Info and press .
Viewing information about the meter
The meter serial number, software version, unit of measure and date of last data
transfer are stored in the meter and can be viewed at any time.
Highlight Meter Care on the Settings screen and press .
Meter Care
Settings
Time:
10:05
Date:
10 Dec 2011
Language:
English
Meter Info
Meter Care
Control Reminder
Control Results
Linearity Test
Linearity Results
Yellow = 5mm margin, Red = 7mm margin
Yellow = 5mm margin, Red = 7mm margin
AW05948101B_OT_VerioPro+_OB_Insides_R1.indd 20 4/3/12 3:07 PM
